DFI-ITOX SR330-L User manual

SR330-L
SR330-L20C
System Board
User’s Manual
935-SR3301-500G
A07010026

Copyright
This publication contains information that is protected by copyright.
No part of it may be reproduced in any form or by any means or
used to make any transformation/adaptation without the prior writ-
ten permission from the copyright holders.
This publication is provided for informational purposes only. The
manufacturer makes no representations or warranties with respect to
the contents or use of this manual and specifically disclaims any ex-
press or implied warranties of merchantability or fitness for any par-
ticular purpose.The user will assume the entire risk of the use or the
results of the use of this document. Further, the manufacturer re-
serves the right to revise this publication and make changes to its
contents at any time, without obligation to notify any person or en-
tity of such revisions or changes.
© 2010. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for iden-
tification purpose only and are the properties of the respective own-
ers.

FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential
installation.This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following meas-
ures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio TV technician for
help.
Notice:
1. The changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
2. Shielded interface cables must be used in order to comply with
the emission limits.

Table of Contents
About this Manual................................................................................
Warranty.................................................................................................
Static Electricity Precaution................................................................
Safety Measures.....................................................................................
About the Package...............................................................................
Before Using the System Board.........................................................
Chapter 1 - Introduction....................................................................
Specifications...................................................................................................................................
Features..............................................................................................................................................
Chapter 2 - Hardware Installation....................................................
System Board Layout ..........................................................................................................
System Memory..........................................................................................................................
CPU.......................................................................................................................................................
Jumper Settings............................................................................................................................
Rear Panel I/O Ports.............................................................................................................
I/O Connectors..........................................................................................................................
SPI Flash ROM Socket.........................................................................................................
Chapter 3 - BIOS Setup......................................................................
Overview...........................................................................................................................................
Updating the BIOS..................................................................................................................
Chapter 4 - Supported Softwares.....................................................
Drivers for Windows 7 / Windows Vista System.....................................
Drivers for Windows XP System..............................................................................
Appendix A - NLITE and AHCI Installation Guide..........................
Appendix B - Watchdog Timer.............................................................
Appendix C - Troubleshooting..........................................................
Appendix D - Frequently Asked Questions...................................
Appendix E - Hot Keys for Graphics Displays..............................
5
5
6
6
7
7
8
8
10
14
14
15
18
22
28
39
54
55
55
89
91
91
114
129
141
143
147
149

About this Manual
An electronic file of this manual is included in the CD. To view the
user’s manual in the CD, insert the CD into a CD-ROM drive. The
autorun screen (Main Board Utility CD) will appear. Click “User’s
Manual” on the main menu.
Warranty
1. Warranty does not cover damages or failures that arised from
misuse of the product, inability to use the product, unauthorized
replacement or alteration of components and product specifica-
tions.
2. The warranty is void if the product has been subjected to physi-
cal abuse, improper installation, modification, accidents or unau-
thorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may
not, under any circumstances, attempt to perform service, adjust-
ments or repairs on the product, whether in or out of warranty.
It must be returned to the purchase point, factory or authorized
service agency for all such work.
4. We will not be liable for any indirect, special, incidental or
consequencial damages to the product that has been modified
or altered.

1
6
Introduction
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board,
components or devices even before installing them in your system
unit. Static electrical discharge can damage computer components
without causing any signs of physical damage. You must take extra
care in handling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its
anti-static bag until you are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of
the components, contacts or connections.
5. Avoid touching the pins or contacts on all modules and connec-
tors. Hold modules or connectors by their ends.
Important:
Electrostatic discharge (ESD) can damage your processor,
disk drive and other components. Perform the upgrade in-
struction procedures described at an ESD workstation
only. If such a station is not available, you can provide
some ESD protection by wearing an antistatic wrist strap
and attaching it to a metal part of the system chassis. If a
wrist strap is unavailable, establish and maintain contact
with the system chassis throughout any procedures requir-
ing ESD protection.
Safety Measures
To avoid damage to the system:
• Use the correct AC input voltage range.....
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis
cover for installation or servicing. After installation or servicing,
cover the system chassis before plugging the power cord.
Battery:
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend by
the manufacturer.
• Dispose of used batteries according to local ordinance.

1
7
Introduction
About the Package
The system board package contains the following items. If any of
these items are missing or damaged, please contact your dealer or
sales representative for assistance.
;The system board
;A user’s manual
;One IDE cable
;One FDD cable
;One USB cable
;One Serial ATA data cable
;One Serial ATA power cable
;One “Main Board Utility” CD
;Two floppy diskettes
;One I/O shield
;One QR (Quick Reference)
The system board and accessories in the package may not come
similar to the information listed above.This may differ in accordance
to the sales region or models in which it was sold. For more infor-
mation about the standard package in your region, please contact
your dealer or sales representative.
Before Using the System Board
Before using the system board, prepare basic system components.
If you are installing the system board in a new system, you will need
at least the following internal components.
•A CPU
•Memory module
•Storage devices such as hard disk drive, CD-ROM, etc.
You will also need external system peripherals you intend to use
which will normally include at least a keyboard, a mouse and a video
display monitor.

1
8
Introduction
Processor
Chipset
System Memory
Expansion Slots
Graphics
Audio
LAN
Serial ATA
IDE
Chapter 1 - Introduction
Specifications
• SR330-L20C
- Intel®Celeron®M 550 2.0GHz 1MB cache mobile processor
(bundled with board)
• SR330-L
- Intel®Celeron®M 500 series processor
• 533MHz system data bus
• Processor socket: mPGA478P
• Intel®chipset
- Intel®GLE960 Express chipset
- Intel®ICH8M
• Two 240-pin DDR2 DIMM sockets
• Supports 533MHz DDR2 SDRAM
• Supports maximum of 2GB system memory
• 1 PCI Express x4 slot
• 2 PCI slots
• Internal graphics feature
- Mobile Intel®Graphics Media Accelerator X3100
- Dynamic Video Memory Technology 4.0
- Microsoft DirectX 9x
- OpenGL 1.5
• Integrated graphics interface
- Analog CRT
- 400MHz core render clock
- Analog monitor supports up to QXGA (2048x1536@60Hz)
- DVI (supports DVI-D signal only)
- DVI 1.0 support for external digital monitor
• Realtek ALC262 2-channel High Definition Audio
• Two 24-bit stereo DACs and three 20-bit stereo ADCs
• S/PDIF input/output interface
• One Realtek RTL8111C PCI Express Gigabit controller
• Supports 10Mbps, 100Mbps and 1Gbps data transmission
• IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps) compliant
• Three Serial ATA ports, compliant with SATA 1.0a
specification
• Data transfer rate up to 3Gb/s
• Supports Advanced Host Controller Interface (AHCI)
• Supports up to two IDE devices
• Supports Ultra ATA 100/66/33

1
9
Introduction
Rear Panel I/O
Ports
I/O Connectors
BIOS
Energy Efficient
Design
Damage Free
Intelligence
Temperature
Humidity
PCB
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 2 DB-9 serial ports
• 1 DB-15 VGA port
• 1 DVI-I port (DVI-D signal only)
• 1 RJ45 LAN port
• 4 USB 2.0/1.1 ports
• Mic-in, line-in and line out jacks
• 3 connectors for 6 additional external USB 2.0/1.1 ports
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF connector
• 3 Serial ATA connectors
• 1 40-pin IDE connector
• 1 FDD connector
• 1 parallel connector
• 1 IrDA connector
• 1 24-pin ATX power connector
• 1 front panel connector
• 1 chassis intrusion connector
• 3 fan connectors
• Award BIOS
• 8Mbit SPI flash memory
• Supports ACPI specification 2.0/1.0
• Wake-On-Events include:
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- PCI Express PME
- Wake up by PCI card
- Wake-On-Ring
- RTC timer to power-on the system
• Enhanced Intel®SpeedStep Technology
• AC power failure recovery
• Monitors CPU/system temperature and overheat alarm
• Monitors CPU(V)/3.3V/5V/12V/VBAT(V)/5VSB(V) voltages and
failure alarm
• Monitors CPU/system/2nd fan speed and failure alarm
• Read back capability that displays temperature, voltage and fan
speed
• Watchdog timer function
•0
oC to 60oC
• 10% to 90%
• 6-layers, microATX form factor
• 24.4cm (9.6") x 24.4cm (9.6")

1
10
Introduction
Features
The Watchdog Timer function allows your
application to regularly “clear” the system at
the set time interval. If the system hangs or fails to function, it will
reset at the set time interval so that your system will continue to
operate.
DDR2 is a higher performance DDR technology
whose data transfer rate delivers bandwidth of 4.3
GB per second and beyond. That is twice the speed of the conven-
tional DDR without increasing its power consumption. DDR2
SDRAM modules work at 1.8V supply compared to 2.6V memory
voltage for DDR modules. DDR2 also incorporates new innovations
such as the On-Die Termination (ODT) as well as larger 4-bit pre-
fetch against DDR which fetches 2 bits per clock cycle.
The Intel northbridge chip comes integrated with the
Intel Graphics Media Accelerator X3100 delivering
exceptional 3D graphics performance. It supports analog CRT and
DVI interfaces.
DVI (Digital Visual Interface) is a form of video inter-
face technology made to maximize the quality of flat
panel LCD monitors and modern video graphics cards. Data is
transmitted using the TMDS (Transition Minimized Differential
Signaling) protocol, providing a digital signal from the PC’s graphics
subsystem to the display.
S/PDIF is a standard audio file transfer format that
transfers digital audio signals to a device without
having to be converted first to an analog format. This prevents the
quality of the audio signal from degrading whenever it is converted
to analog. S/PDIF is usually found on digital audio equipment such as
a DAT machine or audio processing device.The S/PDIF connector on
the system board sends surround sound and 3D audio signal out-
puts to amplifiers and speakers and to digital recording devices like
CD recorders.
watchdog timer
DDR2
graphics
DVI
S/PDIF

1
11
Introduction
Serial ATA is a storage interface that is compliant
with SATA 1.0a specification. With speed of up to
3Gbps, it improves hard drive performance faster than the standard
parallel ATA whose data transfer rate is 100MB/s.
The Realtek RTL8111C PCI Express Gigabit
controller supports up to 1Gbps data transmis-
sion.
The system board supports USB 2.0 and USB 1.1
ports. USB 1.1 supports 12Mb/second bandwidth
while USB 2.0 supports 480Mb/second bandwidth providing a
marked improvement in device transfer speeds between your com-
puter and a wide range of simultaneously accessible external Plug
and Play peripherals.
This feature allows the system that is in the
Suspend mode or Soft Power Off mode to
wake-up/power-on to respond to calls coming from an external mo-
dem or respond to calls from a PCI modem card that uses the PCI
PME (Power Management Event) signal to remotely wake up the
PC.
Important:
The 5V_standby power source of your power supply must sup-
port ≥ 720mA.
This feature allows the network to remotely
wake up a Soft Power Down (Soft-Off) PC.
It is supported via the onboard LAN port or via a PCI LAN card
that uses the PCI PME (Power Management Event) signal. However,
if your system is in the Suspend mode, you can power-on the system
only through an IRQ or DMA interrupt.
Important:
The 5V_standby power source of your power supply must sup-
port ≥ 720mA.
USB
wake-on-lan
wake-on-ring
SERIAL ATA
gigabit lan

1
12
Introduction
This function allows you to use the PS/2 key-
board or PS/2 mouse to power-on the sys-
tem.
Important:
The 5V_standby power source of your power supply must sup-
port ≥ 720mA.
This function allows you to use a USB key-
board or USB mouse to wake up a system
from the S3 (STR - Suspend
To RAM) state.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for
2 USB ports, the 5V_standby power source of your power sup-
ply must support ≥ 1.5A. For 3 or more USB ports, the
5V_standby power source of your power supply must support
≥ 2A.
The RTC installed on the system board allows your
system to automatically power-on on the set date
and time.
The system board is designed to meet the ACPI
(Advanced Configuration and Power Interface) specifi-
cation. ACPI has energy saving features that enables PCs to imple-
ment Power Management and Plug-and-Play with operating systems
that support OS Direct Power Management. ACPI when enabled in
the Power Management Setup will allow you to use the Suspend to
RAM function.
With the Suspend to RAM function enabled, you can power-off the
system at once by pressing the power button or selecting “Standby”
when you shut down without having to go through the sometimes
tiresome process of closing files, applications and operating system.
This is because the system is capable of storing all programs and
data files during the entire operating session into RAM (Random
Access Memory) when it powers-off. The operating session will
resume exactly where you left off the next time you power-on the
system.
rtc timer
ACPI STR
wake-on-PS/2
wake-on-USB

1
13
Introduction
Power failure
recovery
Important:
The 5V_standby power source of your power supply must sup-
port ≥ 720mA.
When power returns after an AC power fail-
ure, you may choose to either power-on the
system manually or let the system power-on
automatically.

14
2Hardware Installation
System Board Layout
Chapter 2 - Hardware Installation
Note:
The DVI-I port supports DVI-D signal only.
COM 2
COM 1
PS/2 Mouse
PS/2 KB
LAN
USB 1
USB 0
Mic-in
Line-in
Line-out
1
Front audio
USB 4-5
1
S/PDIF
SATA 0
SATA 1
SATA 2
1
1
1
1
Front panel
USB 6-7 USB 8-9
11
1
1
1
1
CPU
fan
1
1
2nd fan
1
ATX power
1
Chassis
5
6
1
21
System fan
1
1
PCIE 2
Battery
SPI Flash
BIOS
CD-in
1
Realtek
ALC262
1
1
DDR2-1
DDR2-2
Display device
setting (J 5)P
1
2
3
4
Winbond
I/O
FDD
1
LPT
1
IrDA
Clear CMOS
(J 11)P
Power-on
select (J 13)P
PS/2 power
select ( )JP3
COM 2 RS232/AUX
select ( )JP4
Chrontel
CH7307
Realtek
RTL8111
Intel
GLE960
Intel
ICH8M
USB 0-3 power
select (J )P2
open
21
11
1
30
20
10
Display device
setting (J )P9
IDE
Display device
setting (J 5)P1
PCI 1
PCI 2
USB 4-9 power
select (J 12)P
VGA
DVI-I
DVI-I port
(DVI-D signal only)
1
24 12
113
Power LED
USB 2-3

15
2
Hardware Installation
1
System Memory
Warning:
When the Power LED lit red, it indicates that there is power on the
system board. Power-off the PC then unplug the power cord prior to
installing any devices. Failure to do so will cause severe damage to
the motherboard and components.
Warning:
Electrostatic discharge (ESD) can damage your system board, proces-
sor, disk drives, add-in boards, and other components. Perform the
upgrade instruction procedures described at an ESD workstation only.
If such a station is not available, you can provide some ESD protec-
tion by wearing an antistatic wrist strap and attaching it to a metal
part of the system chassis. If a wrist strap is unavailable, establish
and maintain contact with the system chassis throughout any proce-
dures requiring ESD protection.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
DDR2-2
DDR2-1 Power LED
The system board supports two 240-pin DDR2 DIMM sockets.

16
2Hardware Installation
Installing the DIM Module
1. Make sure the PC and all other peripheral devices connected to
it has been powered down.
2. Disconnect all power cords and cables.
3. Locate the DDR2 socket on the board.
4. Push the “ejector tabs” which are at the ends of the socket to
the side.
Ejector
tab
5. Note how the module is keyed to the socket.
DDR2 socket
Ejector
tab
Key
Notch

17
2
Hardware Installation
7. Seat the module vertically, pressing it down firmly until it is com-
pletely seated in the socket.
6. Grasping the module by its edges, position the module above
the socket with the “notch” in the module aligned with the “key”
on the socket. The keying mechanism ensures the module can be
plugged into the socket in only one way.
8. The ejector tabs at the ends of the socket will automatically
snap into the locked position to hold the module in place.

18
2Hardware Installation
1
CPU
Overview
The system board is equipped with a surface mount mPGA478P
CPU socket.
Note:
The system board used in the following illustrations may not re-
semble the actual one. These illustrations are for reference only.
Installing the CPU
1. Make sure the PC and all other peripheral devices connected to
it has been powered down.
2. Disconnect all power cords and cables.
3. Locate the mPGA478P socket on the system board.
4. Use a screwdriver to turn the screw to its unlock position.
Lock
Unlock
X

19
2
Hardware Installation
5. Position the CPU above the socket. The gold triangular mark on
the CPU must align with pin 1 of the CPU socket.
Important:
Handle the CPU by its edges and avoid touching the pins.
6. Insert the CPU into the socket until it is seated in place. The
CPU will fit in only one orientation and can easily be inserted
without exerting any force. Use a screwdriver to turn the screw
to its lock position.
Important:
Do not force the CPU into the socket. Forcing the CPU into
the socket may bend the pins and damage the CPU.
Gold
triangular
mark
Pin 1 of the socket

20
2Hardware Installation
Installing the Fan and Heat Sink
The CPU must be kept cool by using a CPU fan with heat sink.
Without sufficient air circulation across the CPU and heat sink, the
CPU will overheat damaging both the CPU and system board.
Note:
•Use only certified fan and heat sink.
•Your fan and heat sink package usually contains the fan
and heat sink assembly, and an installation guide. If the in-
stallation procedure in the installation guide differs from the
one in this section, please follow the installation guide in the
package.
1. On the solder side of the board, match the screw holes of the
retention module base to the mounting holes around the CPU
socket.
Retention
module base
