DFI MDPi Series User manual

True-Flat Healthcare Display
with color calibration
User’s Manual
MDPi Series
ver.A_MP_3-1521_13-13

2User's Manual | MDPi Series
Copyright
This publication contains information that is protected by copyright. No part of it may be repro-
duced in any form or by any means or used to make any transformation/adaptation without the
prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions or
changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2020. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
Notice:
1. The changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.
About this Manual
This manual can be downloaded from the website. The manual is subject to change and up-
date without notice, and may be based on editions that do not resemble your actual products.
Please visit our website or contact our sales representatives for the latest editions.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product,
inability to use the product, unauthorized replacement or alteration of components and product
specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper installa-
tion, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in or out of
warranty. It must be returned to the purchase point, factory or authorized service agency for all
such work.
4. We will not be liable for any indirect, special, incidental

User's Manual | MDPi Series 3User's Manual | MDPi Series
Table of Contents
Copyright........................................................................................................................................ 2
Trademarks....................................................................................................................................2
Notice:............................................................................................................................................ 2
About this Manual.........................................................................................................................2
Warranty.........................................................................................................................................2
Chapter 1 - Introduction................................................................................................................4
1.1 Monitor description..........................................................................................................4
1.2 Box of contents................................................................................................................ 4
1.3 Product overview .............................................................................................................4
1.4 Key Features..................................................................................................................... 7
1.5 Outline Dimension............................................................................................................8
Chapter 2 - Important information............................................................................................... 9
2.1 Safety Information ........................................................................................................... 9
2.2 Environmental Information............................................................................................10
2.3 Regulatory Information..................................................................................................11
2.4 Equipment Symbols.......................................................................................................11
Chapter 3 - Cleaning the display................................................................................................13
3.1 Cleaning instructions.....................................................................................................13
3.2 EMC notice .....................................................................................................................13
Chapter 4 - Monitor Installation.................................................................................................15
4.1 Cleaning instructions.....................................................................................................15
4.2 Stand removal & VESA mount installation ..................................................................16
Chapter 5 - Daily operation.........................................................................................................18
5.1 Main power switch.........................................................................................................18
5.2 Power/Status indication................................................................................................18
Chapter 6 - OSD menu operation...............................................................................................19
6.1 On-Screen Display..........................................................................................................19
6.2 Menu Descriptions.........................................................................................................19
6.3 OSD Structure.................................................................................................................19
6.4 Main Menu......................................................................................................................20
6.4.1 Exit.........................................................................................................................20
6.4.2 Auto Setup (Only Support Analog) .....................................................................20
6.4.3 Brightness.............................................................................................................21
6.4.4 Contrast ................................................................................................................21
6.4.5 Display (Only Support Analog)............................................................................21
6.4.6 Color Mode ...........................................................................................................22
6.4.7 Clock/Phase (Only support Analog)...................................................................23
6.4.8 Audio .....................................................................................................................23
6.4.9 Management ........................................................................................................24
6.4.9.1 Scaling ...............................................................................................................25
6.4.9.2 OSD Display.......................................................................................................25
6.4.9.3 Scaling ...............................................................................................................26
6.4.9.4 Source................................................................................................................26
6.4.9.5 Power Key Lock ................................................................................................27
6.4.9.6 Recall .................................................................................................................27
6.4.10 Operating Hours.................................................................................................27
6.5 Supported Video Modes.........................................................................................28

4
Chapter 1
INTRODUCTION
User's Manual | MDPi Series
X1.1 Monitor description
Age: Adult (Age above 21)
Gender: Can be use by all genders
Linguistic/ Cultural Background: At least English
Education/ Professional Competence: General level of education
Intended User Group: Hospital staff
Knowledge Base: User should possess basic medical knowledge
The equipment is applied for healthcare that is intended for general use in hospital environ-
ment for data collection and display for reference. It shall not be used with life support system
or for medical diagnosis.
Type of equipment: Portable (on a table) Intended location: Medical environment
Intended User Profile
Intended User Profile
X1.2 Box of contents
• 21.5”/23.8”/27” LCD Touch Screen Monitor
• AC Power Cord
• VGA Cable
• DVI or HDMI Cable
• USB Cable (for touch version)
• Power Adapter (Delta 24V)
(Optional)
• Audio Cable
• RS232 Cable
• DP Cable
The main body and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
X1.3 Product overview
Front View
The image below shows the front view of the display.
1. P-CAP touch (for touch version) / AG/AR/CLEAR cover glass
2. Bezel
3. LED
Chapter 1 - Introduction

User's Manual | MDPi Series 5
Chapter 1
INTRODUCTION
Chapter 1
INTRODUCTION
Side View
The image below shows the control keys located in the right bottom corner of the display.
1. Menu / Enter key / Scrolling key
Rear View
1. Rear cover
2. IO cover
3. Monitor stand
4. Hinge cover
User's Manual | MDPi Series

User's Manual | MDPi Series 6
Chapter 1
INTRODUCTION
Available Connections
1. USB
2. RS232
3. Audio
4. Display Port
5. DVI
6. HDMI (RGD model)
7. VGA
8. POWER
9.
User's Manual | MDPi Series

7
Chapter 1
INTRODUCTION
User's Manual | MDPi Series
Model MDPi215 MDPi238 MDPi270
Display Display 21.5" TFT LCD 23.8" TFT LCD 27" TFT LCD
Max. Resolution 1920 x 1080 1920 x 1080 1920 x 1080 (4K option)
Luminance 350 nits 250 nits 300 nits
Contrast 1000:1 1000:1 3000:1
View Angle 178(H) / 178(V) 178(H) / 178(V) 160(H) / 140(V)
Color Depth 8 bits 6 bits + FRC 8 bits
Display Colors 16.7M 16.7M 16.7M
Response Time (ms) 22 (On/Off) 14 (GtG)) 12 (On/Off)
Backlight MTBF 50,000 hrs (Min.) 30,000 hrs (Min.) 30,000 hrs (Min.)
Touch Screen Type Projected Capacitive Projected Capacitive Projected Capacitive
Touch Point 10 10 10
Glass Coating AG AG AG
Interface Combo(USB/RS232) Combo(USB/RS232) Combo(USB/RS232)
Systems Color Temperature Neutral/Warm/Cool/User Neutral/Warm/Cool/User Neutral/Warm/Cool/User
Gamma Selection Neutral/2.2/DICOM Neutral/2.2/DICOM Neutral/2.2/DICOM
Gamma LUT (bits) 10 10 10
OSD Languages English/French/German/Italian/Spanish/Japanese English/French/German/Italian/Spanish/Japanese English/French/German/Italian/Spanish/Japanese
Speaker 2 x 2W Speaker 2 x 2W Speaker 2 x 2W Speaker
I/O Interface VGA 1 x VGA 1 x VGA 1 x VGA
DP 1 x DP1.2 1 x DP1.2 1 x DP1.2
HDMI or DVI 1 x HDMI 1.4 or DVI-D 2 x HDMI 1.4 or DVI-D 3 x HDMI 1.4 or DVI-D
Audio 1 x Line-in 1 x Line-in 1 x Line-in
Power input 1 x DC IN 1 x DC IN 1 x DC IN
Power requirements AC Input External power adapter,100 ~ 250V External power adapter,100 ~ 250V External power adapter,100 ~ 250V
Power Consumption 40W (Max) 40W (Max) 40W (Max)
Mechanical Chassis Material Plastic ABS Plastic ABS Plastic ABS
Color White White White
Dimension (W)(H)(D) "537 (W) x 387 (H) x 175 (D) mm (with Stand)
537 (W) x 339 (H) x 69 (D) mm (w/o Stand)"
"581 (W) x 400 (H) x 175 (D) mm (with Stand)
581 (W) x 360 (H) x 69 (D) mm (w/o Stand)"
"651 (W) x 441 (H) x 175 (D) mm (with Stand)
651 (W) x 402 (H) x 69 (D) mm (w/o Stand)"
Weight "8.2 (with Stand)
6.5 (w/o Stand)"
"9.5 (with Stand)
7.7 (w/o Stand)"
"10.3 (with Stand)
8.4 (w/o Stand)"
Mounting 100 x 100 mm VESA mount 100 x 100 mm VESA mount 100 x 100 mm VESA mount
Operating Temperature 0°C ~ 40°C 0°C ~ 40°C 0°C ~ 40°C
Storage Temperature -20°C ~ 60°C -20°C ~ 60°C -20°C ~ 60°C
Operating Humidity 30% to 75% non-condensing 30% to 75% non-condensing 30% to 75% non-condensing
Others OSD "RotaryKnob buttons on the side edge
Power On/Off, Menu"
"RotaryKnob buttons on the side edge
Power On/Off, Menu"
"RotaryKnob buttons on the side edge
Power On/Off, Menu"
Certifications EMC / Safety cTUVus(60601 Ed3.1),CE(EN 60601-1, EN60601-1-2,)FCC-
class B
cTUVus(60601 Ed3.1),CE(EN 60601-1, EN60601-1-2,)FCC-
class B
cTUVus(60601 Ed3.1),CE(EN 60601-1, EN60601-1-2,)FCC-
class B
Protection IP level IP65 Front Panel IP65 Front Panel IP65 Front Panel
Accessory Packing List "Audio Cable
DP Cable
HDMI Cable
VGA Cable
USB 2.0 Cable
Power Adapter"
"Audio Cable
DP Cable
HDMI Cable
VGA Cable
USB 2.0 Cable
Power Adapter"
"Audio Cable
DP Cable
HDMI Cable
VGA Cable
USB 2.0 Cable
Power Adapter"
X1.4 Key Features

8
Chapter 1
INTRODUCTION
User's Manual | MDPi Series
X1.5 Outline Dimension

User's Manual | MDPi Series 9
Chapter 2
Important Information
Chapter 2 - Important information
X2.1 Safety Information
User's Manual | MDPi Series
General recommendations
Read the safety and operating instructions before operating the device. Save the safety and
operating instructions for future reference.
Adhere to all warnings on the device and in the operating instructions manual. Follow all in-
structions for operation and use.
Electrical Shock or Fire Hazard
To prevent an electrical shock or fire hazard, do not remove the cover.
No serviceable parts are inside. Refer servicing to qualified personnel. Do not expose this ap-
paratus to rain or moisture.
Modifications to the unit:
Do not modify this equipment without authorization of the manufacturer.
Degree of safety (flammable anesthetic mixture):
Equipment is not suitable for use in the presence of a flammable anesthetic mixture of air,
oxygen, or nitrous oxide.
Non-patient care equipment
• Equipment primarily for use in a health care facility. It is intended for use when contact with
a patient is unlikely (no applied part).
• The equipment may not be used with life support equipment.
• The user should not touch the equipment, nor its signal input ports (SIP)/signal output ports
(SOP) and the patient at the same time.
Mission critical applications
We strongly recommend for there to be a replacement monitor immediately available in mis-
sion critical applications.
Power connection – Equipment with internal power supply
• This equipment must be grounded.
• Power requirements: The equipment must be powered by the DC mains voltage.
• The equipment is intended for continuous operation.
Power cords:
• Do not overload wall outlets and extension cords as this may result in fire or electric shock.
• Main leads protection (U.S.: Power cord): Power cords should be routed so that they are not
walked upon or pinched by items placed upon or against them. Pay particular attention to
cords at plugs and receptacles.
• The power supply cord should be replaced by the designated operator only at all time.
• Use a power cord that matches the voltage of the power outlet, which should be approved
and in compliance with the safety standard of your particular country.
• Avoid placing the monitor near places that is hard to reach or difficult to disconnect the
power supply cord.
• “WARNING: To avoid risk of electric shock, this equipment must only be connected to a sup-
ply mains with protective ground”
• “AVERTISSEMENT” : Pour éviter le risque de choc électrique, cet équipement doit être
uniquement raccordé à un réseau d'alimentation avec protection par mise à la terre.
Grounding reliability
Grounding reliability can only be achieved when the equipment is connected to an equivalent
receptacle.
Liquids and moisture
Never expose the monitor to liquids or moisture.
Never use the monitor near water - e.g. near a bathtub, washbasin, swimming pool, kitchen
sink, laundry tub or in a wet basement.
Ventilation
Do not cover or block any ventilation openings in the cover of the set. When installing the de-
vice in a cupboard or another closed location, heed the necessary space between the set and
the sides of the cupboard.
Installation
Place the device on a flat, solid, and stable surface that can support the weight of at least 3
devices. If you use an unstable cart or stand, the device may fall, causing serious injury to a
child or adult, and serious damage to the device.
Accessory equipment connected to the analog and digital interfaces must be in compliance
with the respective nationally harmonized IEC standards (i.e. IEC 60601-1 for medical equip-
ment.) Furthermore all configurations shall comply with the system standard in IEC 60601-1.
Anyone who connects additional equipment to the signal input part or signal output part is
configuring a medical system, and is therefore, responsible that the system complies with
the requirements of the system standard IEC 60601-1. The unit is for exclusive interconnec-
tion with IEC 60601-1 certified equipment in the patient environment and IEC 60XXX certified
equipment outside of the patient environment.

User's Manual | MDPi Series 10
Chapter 2
Important Information
User's Manual | MDPi Series
This apparatus conforms to:
EN 60601-1:2006+A11:2011+A1:2013+A12:2014
IEC 60601-1: 2005 + CORR. 1 (2006) + CORR. 2 (2007) + AM1(2012) ANSI/AAMI ES60601-
1:2005+A2(R2012)+A1
CAN/CSA-C22.2 No. 60601-1:14
EN 60601-1-2 (2015)
IEC 60601-1-2 (2014)
FCC CFR 47 Part 15 Subpart B (Level B) RoHS (2011/65/EU & 2015/863/EU)
X2.2 Environmental Information
Disposal Information
Waste Electrical and Electronic Equipment
This symbol on the product indicates that under the European Directive 2012/19/EU,
governing waste from electrical and electronic equipment, this product must not be disposed
of with other municipal waste. Please dispose of your waste equipment by handing it over to
a designated collection point for the recycling of waste electrical and electronic equipment. To
prevent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to pro-
mote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or
your municipal waste disposal service.

User's Manual | MDPi Series 11User's Manual | MDPi Series
Chapter 2
Important Information
X2.3 Regulatory Information
Indications for use
The monitor (21.5”/23.8”/27” Touch Screen LCD Monitor) is applied for healthcare that is in-
tended for general use in hospital environment for data collection and display for reference.
FCC class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any inter-
ference received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installation. This device generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by turning the
device off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device and receiver.
• Connect the device to an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Canadian notice
This ISM device complies with Canadian ICES-003.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
X2.4 Equipment Symbols
Electrical and electronic equipment symbols
Indicates the device meets the requirements of the applicable EC directives.
Indicates compliance with Part 15 of the FCC rules (Class A or Class B)
Indicates the device is approved according to the TUV regulations for Canada
and US
Indicates the USB connectors on the device
Indicates the Display Port connectors on the device
Indicates the legal manufacturer
Indicates the manufacturing date
Indicates the temperature limitations for the device to safely operate within
specs.
Indicates the device serial number
Indicates the device part number or catalog number
Warning: dangerous voltage
AVERTISSEMENT : Tension dangereuse
Caution ATTENTION
Consult the operating instructions

User's Manual | MDPi Series 12
Indicates this device must not be thrown in the trash but must be recycled,
according to the European WEEE (Waste Electrical and Electronic
Equipment) directive
Indicates Direct Current (DC)
Indicates Alternating Current (AC)
Stand-by
Power ON. Power connection to the mains
Power OFF
Protective earth (ground)
Equipotentiality. Connect device to a potential equalization conductor.
Chapter 2
Important Information
User's Manual | MDPi Series

User's Manual | MDPi Series 13
Chapter 3
Cleaning the display
Chapter 3 - Cleaning the display
X3.1 Cleaning instructions
User's Manual | MDPi Series
To clean the display
Cleaning the display using a sponge, cleaning cloth, or soft tissue with lightly moistened rec-
ognized cleaning product for medical equipment. Read and follow all labeled instructions on
the cleaning product. In case of doubt about a certain cleaning product, use plain water.
CAUTION:
• Take care not to damage or scratch the front glass or LCD. Be careful with rings or other
jewelry and do not apply excessive pressure on the front glass or LCD.
• Do not apply or spray liquid directly to the display as excess liquid may cause damage to
internal electronics. Instead, apply the liquid to a cleaning sponge, cloth, or tissue.
ATTENTION :
• Veillez à ne pas endommager ou rayer la vitre avant ou l'écran LCD. Soyez prudent lorsque
vous portez des bagues ou autres bijoux et n'appliquez pas une pression excessive sur le
verre avant ou l'écran LCD.
• N'appliquez ou ne vaporisez pas de liquide directement sur l'écran car l'excès de liquide
peut endommager l'électronique interne. Appliquez plutôt le liquide sur une éponge, un chiffon
ou un mouchoir en papier.
X3.2 EMC notice
Electromagnetic emissions
The monitor is intended for use in the electromagnetic environment specified below. The cus-
tomer or the user of the monitor should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment – Guidance
RF emissions
CISPR 11 Group 1
The monitor uses RF energy only for its internal
function. Therefore, its RF
emissions are very low and are not likely to
cause any interference with nearby
electronic equipment.
RF emissions
CISPR 11 Class B
The monitor is suitable for use in all establish-
ments, including domestic establishments
and those directly connected to the public low-
voltage power supply network that supplies
buildings used for domestic purposes.
Harmonic emis-
sions
IEC 61000-3-2
N/A
(power consumption
less than 75W)
Voltage fluctua-
tions/ flicker emis-
sions
IEC 61000-3-3 Complies
This monitor complies with appropriate medical EMC standards on emissions to, and interfer-
ence from surrounding equipment. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any inter-
ference received, including interference that may cause undesired operation.
Interference can be determined by turning the equipment off and on.
If this equipment does cause harmful interference to, or suffer from harmful interference of,
surrounding equipment, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna or equipment.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced technician for help.

User's Manual | MDPi Series 14
Electromagnetic immunity
The monitor is intended for use in the electromagnetic environment specified below. The cus-
tomer or the user of the monitor should assure that it is used in such an environment.
Immunity test IEC 60601
Test levels Compliance level Electromagnetic envi- ronment – guidance
Electrostatic
discharge
(ESD)
IEC 61000-4-2
± 8kV contact
± 15kV air ± 8kV contact ± 15kV air
Floors should be wood,
concrete or ceramic
tile. If oors are cov-
ered with synthetic
material, the relative
humidity should be at
least 30%
Electrical fast
transient/burst
IEC 61000-4-4
± 2kV for power supply
lines
± 1kV for input/ output
lines
± 2kV for power supply lines
± 1kV for input/ output lines
Mains power qual-
ity should be that of a
typical commercial or
hospital
environment
Surge
IEC61000-4-5 ± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
Mains power qual-
ity should be that of a
typical commercial or
hospital
environment
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input
lines
IEC 61000-4-
11
0% residual voltage for
0.5 cycle.
0% residual voltage for
1 cycle.
70% residual voltage
for 0.5s.
0% residual voltage for
5s.
0% residual voltage
for 0.5 cycle.
0% residual voltage
for 1 cycle.
70% residual voltage for 0.5s.
0% residual voltage for 5s.
Mains power qual-
ity should by that of a
typical commercial or
hospital
environment. If the user
of the monitor requires
continued operation
during power mains
interruptions, it is
recommended that the
monitor be powered
from an uninterruptible
power supply or a bat-
tery.
Power fre-
quency (50/60
Hz) mag-
netic field IEC
61000-4-8
30 A/m Not applicable
Power frequency mag-
netic elds should be
at levels characteristic
of a typical location in
a typical commercial or
hospital environment.
Chapter 3
Cleaning the display
User's Manual | MDPi Series
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 V at 0,15 - 80MHz
6 V at ISM bands
10 V/m at 80-2,
700MHz.
And 9-28V/m at 385-
6,000MHz, Pulse
Mode: 27 V/m at
385MHz
28 V/m at 450MHz
9V/m at
710/745/780MHz
28 V/m at
810/870/930MHz
28 V/m at
1720/1845/1970MHz
28 V/m at
2450MHz 9V/m at
5240/5500/5785MHz
3 V at 0,15 - 80MHz
6 V at ISM bands
10V/m at 80-2,700MHz.
And 9-28V/m at 385-
6,000MHz, Pulse Mode: 27 V/
m at 385MHz
28 V/m at 450MHz
9V/m at 710/745/780MHz
28 V/m at 810/870/930MHz
28 V/m at
1720/1845/1970MHz
28 V/m at 2450MHz 9V/m at
5240/5500/5785MHz
Portable and mobile
RF communications
equipment should be
used no closer to any
part of the monitor,
including cables, than
the recommend
separation distance
calculated from the
equation applicable
to the frequency
of the transmitter.
Recommended
separation distance
d = 1.2√P
d = 1.2√P 80 MHz to
800
MHz
d = 2.3√P 800 MHz to
2.5
Ghz
Where P is the
maximum output
power rating of the
transmitter in watts (W)
according to
the transmitter
manufacturer and d
is the recommended
separation
distance in meters (m).
Field strengths from
fixed RF transmitters,
as
determined by an
electromagnetic site
survey,5 should be less
than the compliance
level in each frequency
range.6
Interference may
occur in the vicinity of
equipment marked with
symbol:
Note:
At 80 MHz and 800 MHz, the higher frequency range applies.
These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects, and people.

15
Chapter 4
Monitor Installation
User's Manual | MDPi Series
Chapter 4 - Monitor Installation
X4.1 Cleaning instructions
To install your monitor
To get access to the connectors, put the display on a flat surface.
1. Connect one or more video source(s) to the corresponding video inputs of the monitor. Use
the appropriate video cable(s) to do this.
2. Connect the USB or RS232 connector for touch screen function.
3. Connect the Audio cable for audio function.
4. Connect the power cord input to a power adapter with a grounded Power Outlet.
5. Connect the power adapter input to the monitor.
6. Install cable cover back on the monitor.
Warning:
Sufficient expertise is required to install this equipment. All devices and com-
plete setup must be tested before operation.
AVERTISSEMENT:
Une expertise suffisante est requise pour l'installation de cet équipement. Tous
les appareils et la configuration complète doivent être testés avant d'être mis en
service.
Image 4-1-1 Connectors (RGP)
Image 4-1-2 Connectors (RGD)

16
Chapter 4
Monitor Installation
User's Manual | MDPi Series
X4.2 Stand removal & VESA mount installation
This monitor provided with a validated stand. The monitor has been designed to be used in
landscape position with a maximum tilt of -5° to 30° backward. If a different stand is needed
in the final application, the monitor VESA interface (VESA 100 mm standard) could be used.
To remove the stand and install the VESA mount
1. Place the monitor face down on a flat, solid and stable surface.
2. Remove the hinge cover
3. Unscrew the 4x M4 (length: 10mm) screws fixing the stand and rear cover
4. Remove the stand and install the VESA mount.
Caution: Use a protective cloth or cushion to prevent the monitor and LCD from any
damage or scratches.
Attention: Utilisez un chiffon ou un coussin de protection pour éviter d'endommager
ou rayer le moniteur et l'écran LCD.
Tip: Store the fixation screws at a known place for possible future use.
Image 4-2-1 Remove the hinge cover
Image 4-2-2 Remove the 4x M4 screws
Image 4-2-3 Remove the stand from the monitor

17
Chapter 4
Monitor Installation
User's Manual | MDPi Series
5. Attach the monitor in landscape position to a 100 mm VESA mounting bracket. Mounting in
portrait position is not feasible.
Image 4-2-4 VESA mount is located at the back of the monitor.

18
Chapter 5
Daily operation
User's Manual | MDPi Series
Chapter 5 - Daily operation
X5.1 Main power switch
The monitor is switched on or off with the main switch, sees image 1-2 Control key.
X5.2 Power/Status indication
During start-up the monitor performs signal detection before going into normal operation
mode. Depending on the detection result, the status LED on the side of the monitor will show
different LED color.
Below is an overview of the possible status LED modes:
LED Color Status LED modes Operation Description
OFF (No LED) OFF mode Monitor is not powered.
Blue, static Normal mode Monitor is ON, video sync OK.
Red, static Stand-by mode (Power saving) Automatically enters power saving and standing by for
input signal

19
Chapter 6
OSD menu operation
User's Manual | MDPi Series
Chapter 6 - OSD menu operation
X6.1 On-Screen Display
The LCD monitor features an On-Screen Display (OSD) menu with easily identifiable icons
designed to make adjustment of your monitor display settings a more user-friendly process.
When highlighted, the icon illustrates the control function and brief instruction to assist the
user in identifying which control needs adjustment.
The OSD menu is activated by pressing the Control Dial inward and you can select and adjust
the function of your choice by rotating and clicking the Control Dial. The main menu displays
a list of sub menu icons and the current video input mode. Rotate the dial to move the high-
lights to the control you would like to adjust, then press the Control Dial inward to select that
control or to activate that function. Depending on the control you selected, a submenu of the
control with a status bar will appear. The status bar indicates in which direction, form the fac-
tory preset; your adjustments arebeing made. Rotate the Control Dial to adjust the control.
When you have finished making the adjustments, the setting is saved automatically by ac-
tivating the control function. If you do not touch the Control Dial for 30 seconds, the OSD is
automatically exited saving your current settings.
X6.2 Menu Descriptions
The LCD monitor is capable of accepting VGA, DVI(HDMI), Display Port signal inputs and
therefore has two different sets of OSD control functions. Because the digital signaling al-
ways achieves optimum display quality without mush adjustment, it requires much less OSD
functions than the analog input mode. The following options are not available in digital input
mode: Auto Setup, Display, Clock/Phase, denoted by as trick (*) in the following descriptions. If
switched to digital input model, you will
encounter a “Not Available” message.
The Charts displays the function tree and brief explanations of the functions. Color, OSD, and
other adjustments have submenus under each tree.
X6.3 OSD Structure

20
Chapter 6
OSD menu operation
User's Manual | MDPi Series
X6.4 Main Menu
6.4.1 Exit
6.4.2 Auto Setup (Only Support Analog)
• Exit: To exit the auto setup of the OSD menu.
• Yes: Automatically adjust the analog settings of the image.
• No: Enter Clock/Phase OSD menu when NO is selected.
To exit the OSD menu.
