AOC 619Fh User manual

619Fh
619Fh
Cabinet Color Piano Black Finish
Panel TFT Active Matrix LCD
26" Widescreen, Diagonal
25.5" Viewable Image Size
Pixel Pitch 0.2865mm x 0.2865mm
Display Area 550mm x 344mm
Brightness 400 cd/m2 (typ)
Contrast Ratio 10,000:1 (dynamic)
Response Time 3ms (typ)
Viewing Angle
Horizontal: 160 Degrees (CR>10)
Viewing Angle
Horizontal: 160 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Scanning Frequency Horizontal: 24K~83KHz
Vertical: 56~76 Hz
Pixel Frequency 170MHz
Maximum Resolution
Recommended Resolution 1920x1200x60Hz
1920x1200@60Hz
Supported Resolutions
640x480@56/60/67/72/75Hz, 720x400@70Hz,
Supported Resolutions
640x480@56/60/67/72/75Hz, 720x400@70Hz,
800x600@56/60/72/75, 832x624@75Hz, 1024x768@60/70/75Hz,
1280x960@60Hz, 1280x1024@60/75Hz, 1440x900@60Hz,
1680x1050@60Hz, 1920x1200@60Hz
Color 16.7M
Signal Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Digital Input DVI-D & HDMI with HDCP*
Connectors Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D, 18-pin HDMI
Power: (3-Pin Plug CEE22)
Power Source Universal 100~240VAC, 50/60Hz
Power Consumption 120Watts ( Max. )
Plug & Play DDC/2B, DDC/CI
EPA ENERGY STAR® Yes
User Control
Auto, Eco/up, Down, Menu, Power, Source
OSD Languages
8 Languages including English, French and Spanish
Regulations
cULus, FCC, CE, Certified for Windows Vista Logo, ROHS
Built-in Speakers
3W x 2
Other Features
720p/1080i/1080p HD Compatible (Digital Input Only), Built-in 4-port
USB hub, Earphone Jack, User Friendly Graphical OSD Menu, VESA
100mm Wall Mount Compliant**, Kensington Security Slot, includes
AOC proprietory i-Menu software OSD
Other Features
AOC proprietory i-Menu software OSD
Dimensions (WxHxD mm) Monitor: 605x473x240, Carton: 690x566x188
Dimensions (WxHxD inches) Monitor: 23.8x18.6x9.4, Carton: 27.2x22.3x7.4
Weight 17.1 lbs (7.75 kgs) Net
23.8 lbs (10.8 kgs) Gross
Loading Qty w/pallet 20' = 352 pcs.; 40' Std = 748 pcs.
UPC Code
685417021680
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracket not
included. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
A06/08
