Planar PY4200 User manual

PY4200
Digital Signage Monitor
PY4200
This 42" large format display
in a slim bezel design brings
to you a full HD picture
quality well suited for digital
signage in a variety of indoor
applications.
With bezels less than 14mm
wide, this LCD displays
a more natural image,
ideal for tiled and video
wall installations. Its high
brightness and contrast
ratio make it ideal for
outdoor and brightly lit
indoor installations.
In addition to sleek design
and great technology, the
PY4200 provides a wide
viewing angle and multiple
ranges of digital inputs
for greater exibility and
connectivity options.
www.planarembedded.com
KEY FEATURES
• Highly reliable and eective industrial grade LCD
• Thin 14mm bezel makes it ideal for tiled
applications
• Full High Denition 1920 x 1080 panel
• High brightness of 700 cd/m2and contrast
ratio of 3500:1 gives clear views in high ambient
light areas
• Wide viewing angle of 178
• Suitable for landscape and portrait orientation
• RS-232C interface enables remote control and
video wall operations
• Wide range of digital inputs give high exibility
and connectivity options

Digital Signage Monitor
www.planarembedded.com
SPECIFICATIONS PY4200
Screen Size 42" Diagonal
Orientation Portrait and Landscape
Aspect Ratio 16:9
Brightness (typical) 700 cd/m2
Contrast Ratio (typical) 3500:1
Backlight CCFL
(cathode cold uorescent light)
Response Time (typical) 4.5 ms
Viewing Angle (typical) 178 H, V
Native Resolution 1920 x 1080 (HDTV Format)
Display Colors 16.7M
Display Active Area 930.24 (H) x 523.26 (V)
Surface Treatment Anti-glare coating (Haze 11%,
Hard coating (3H))
Computer Input VGA, DVI
Audio Input L/R (RCA jacks), Line-in
(3.5 mm Mini-jack)
Video Input Composite video, S video,
Y Pb Pr (RCA jacks), HDMI
Control Input D–sub 9 pin, RS-232C
Computer Output VGA
Video Output Composite video
Speaker Output External Speaker Jack
(6W+6W, 8 Ohms)
Audio Output L/R (RCA jacks)
Control Output RS-232C (Mini D-Sub 9 –pin)
Line Voltage 100 -240 V
Line Current (max.) 5.5 amps
Power Consumption (max.) 210W
Operating Temperature 0 C to +40 C
Storage Temperature -20 C to +60 C
Humidity 20-80%
Product Weight 51.9 lbs. (23.6 kg)
Product Dimensions (WxHxD) 963mm x 555mm x 110mm
Approvals FCC, EN 60950, RoHS
CORPORATE HEADQUARTERS
PLANAR SYSTEMS, INC.
1195 NW Compton Dr
Beaverton, OR 97006-1992, USA
Toll-Free: +1.866.752.6270 (1.866.PLANAR.0)
Phone: [phone]
Fax: [phone]
Email: [e-mail]
© 2011, Planar Systems, Inc. Planar is a registered trademark of Planar Systems, Inc. Printed in USA. Technical information in this
document subject to change without notice.
DS.PY4200_0511
Eective May 10, 2011
