Diamond audio technology Hp650 User manual

HP650

6.5” COMPONENT SYSTEM

INSTALLATION MANUAL

Dear Valued Customer,

All of us at Diamond Audio would like to thank you for your purchase of a HEX™ Pro speaker system.

HEX™ Pro component systems and subwoofers are the very best speakers available for use in the

automobile environment. By choosing these products you recognize the value in using only the best.

With our proprietary HEX™ cones and neo motors that utilize our patented TDX™ technology, we know

you will be satised with these systems for years to come.

Please keep in mind that prolonged exposure to sound pressure levels in excess of 100 dB can cause

permanent hearing loss. This high performance speaker system can exceed that level, so please

exercise restraint in its operation in order to preserve your ability to enjoy its delity in the future.

Because of their exible installation possibilities, please consider having your new speakers

professionally installed by an authorized Diamond Audio dealer. This will assure a clean and efcient

installation, and extend your one year warranty to three years.

At Diamond Audio, we strive to bring honest value and excellent quality to all of the products we build.

By your purchase of this product, you have joined the growing family of discerning listeners

who demand only the best. Welcome!

The Diamond Audio Team

SPECIAL THANKS

Thermal-Dyne eXtreme™ is a fundamentally different solution. The concept is simple, eliminate the

detrimental effects of heat in a loudspeaker system. The solution however, is quite complex. Our

engineers decided to start with a fresh sheet of paper and build a new line of products that addressed

the thermal problems and shortcomings of conventional designs while signicantly raising the existing

level of performance.

To understand TDX™ speaker technology, it must rst be compared to that of a conventional speaker

design. At the heart of every speaker is a permanent magnet motor structure that provides the

magnetic energy, or force to move the voice coil back and forth within the magnetic air gap. Conven-

tional speakers use a large ceramic magnet surrounding the voice coil that actually retains heat rather

than dissipating it. TDX™ motors use a small but very efcient high temperature Neodymium magnet

mounted inside the voice coil. The geometry, venting and material selection for the motors have all

been optimized for ideal thermal dissipation. The TDX™ thermal efciency is nearly (5) times greater

than conventional designs. In conjunction with the motor design, TDX™ Technology utilizes die-cast

aluminum frame structures to act as a heat sink for the encapsulated motor structure. To insure

maximum heat transfer from the encapsulated motor case to the aluminum frame, a special thermal

paste lls any surface voids that may be present in this mating surface.

The evolution of TDX™ Technology can be seen in the new HEX™ Pro series of products. The new HEX™

Pro component systems take this TDX™ Technology and expand on it to maximize the benet for

superior full spectrum audio performance. To faithfully reproduce an extended frequency range, the

materials and design must be optimal. This coupled with a demand for very high power handling, is

extremely challenging. These systems utilize an improved version of our legendary HEX™ cone, our

patented dual-tuned chamber tweeter along with our extruded aluminum, high power, programmable

crossover to make the very best speaker system available in mobile audio. Period.

TDX™ TECHNOLOGY

THIELE/SMALL PARAMETERS

PHYSICAL DIMENSIONS

Parameter (unit)

Sensitivity - 2.83V@1m (dB)

Qts

Fs (Hz)

Vas (L)

Re (ohm)

Xmax (mm)

Impedance (ohm)

Power (watts) NOM/MAX

HP650T

n/a

850

n/a

75/150

HP650M

12.5

3.5

200/400

Model (inches)

Total Diameter (A)

Mounting Diameter (B)

Screw Hole Diameter (C)

Mounting Depth (D)

Magnet Diameter (E)

HP650T

2.6” / 66mm

2” / 51mm

2.25” / 57.15mm

0.75” / 19mm

1.1” / 28mm

HP650M

6.5” / 166mm

5.76” / 146mm

6.2” / 157mm

2.5” / 63mm

3.5” / 89mm

CROSSOVERS

Each HEX™Pro component set comes with a pair of programmable crossovers. These crossovers

use a combination of 12 and 24 dB/oct slopes to optimize the output of the tweeter and mid-bass

driver. Each crossover features complete tweeter level, phase, and bi-amp programming

capability. An LED found on top of the crossover is used as a power limit indicator. When brightly

lit, it indicates that maximum power is being delivered to that channel.

COMPONENT SYSTEM CONNECTION

The following illustration shows how to connect one channel of the HP650 component system.

(A)

(B)

(D)

(E)

Crossover Programming

Under the sliding cover on the crossover is where the programming

controls are located. The tweeter level control has four settings: +2,

0, -2, -4 dB. This is adjusted by changing the combinations of the

two toggle switches labeled "TWT LEVEL". Use the key to the right of

the switches to configure tweeter level control. Switch the "BI-AMP"

switch only when running the crossover with a bi-amped signal. The

"PHASE" switch swaps the tweeter 180 degrees out of phase for off

axis tweeter installations.

MOUNTING

Mid-Bass Mounting

The illustration above shows the parts included and correct mounting assembly of the HEX™Pro

component mid-bass drivers. Be sure to check the available mounting depth before installation

begins. Use of the foam gasket is recommended to ensure a proper seal between the speaker and

mounting surface.

Tweeter Mounting

When mounting the tweeters, make sure

desired location can accommodate the

hole size, over all diameter and depth

required. Cut a 2" hole in the surface

chosen and feed speaker wire through.

Remove the tweeter mounting ring by

unscrewing it counter clockwise. Connect speaker

wire to tweeter terminals and mount tweeter in hole

using provided screws. When tweeter is secure, replace

trim ring by screwing it on clockwise.

FEATURES

TDX Technology™(Thermal Dyne eXtreme)™

Proprietary Kevlar™/Nomex™Hex Cone

Nitrile Butadine Rubber (NBR) Surrounds

Flat Blended Nomex™ Spider with Embedded Lead Wires

Die-cast Aluminum Frames

Ultra-high Energy Neodymium Magnet Structures

30mm Polymer Treated Alloy Domed Tweeter

Precision Model Matched Programmable Crossovers

Parts List - HP650

(2) HEX™Pro Mid-Bass Speakers

(2) Mounting Gaskets

(2) HEX™Pro Crossovers

(2) HEX™Pro Tweeters

(1) Mid-Bass Mounting Hardware Kit

(1) Tweeter Mounting Hardware Kit

HEX™Pro MID-BASS DRIVER ASSEMBLY

A FOREWORD ABOUT HEX PRO COMPONENTS TDX™TECHNOLOGY

Thermal-Dyne eXtreme™is a fundamentally different solution. The concept is simple,

eliminate the detrimental effects of heat in a loudspeaker system. The solution however, is quite

complex. Our engineers decided to start with a fresh sheet of paper and build a new line of

products that addressed the thermal problems and shortcomings of conventional designs while

significantly raising the existing level of performance.

To understand TDX™speaker technology, it must first be compared to that of a

conventional speaker design. At the heart of every speaker is a permanent magnet motor

structure that provides the magnetic energy, or force to move the voice coil back and forth within

the magnetic air gap. Conventional speakers use a large ceramic magnet surrounding the voice

coil that actually retains heat rather than dissipating it. TDX™motors use a small but very

efficient high temperature Neodymium magnet mounted inside the voice coil. The geometry,

venting and material selection for the motors have all been optimized for ideal thermal

dissipation. The TDX™thermal efficiency is nearly (5) times greater than conventional designs. In

conjunction with the motor design, TDX™Technology utilizes die-cast aluminum frame structures

to act as a heat sink for the encapsulated motor structure. To insure maximum heat transfer from

the encapsulated motor case to the aluminum frame, a special thermal paste fills any surface

voids that may be present in this mating surface.

The evolution of TDX™Technology can be seen in the new HEX™Pro series of products.

The new HEX™Pro component systems take this TDX™Technology and expand on it to maximize

the benefit for superior full spectrum audio performance. To faithfully reproduce an extended

frequency range, the materials and design must be optimal. This coupled with a demand for very

high power handling, is extremely challenging. These systems utilize an improved version of our

legendary HEX™cone, our patented dual-tuned chamber tweeter along with our extruded

aluminum, high power, programmable crossover to make the very best speaker system available in

mobile audio. Period.

Product Owners Manual

6.5” COMPONENT SPEAKERS

Dear Valued Customer,

All of us at Diamond Audio would like to thank you for your purchase of a HEX™Pro speaker system.

HEX™Pro component systems and subwoofers are the very best speakers available for use in the

automobile environment. By choosing these products you recognize the value in using only the best.

With our proprietary HEX™cones and neo motors that utilize our patented TDX™technology, we know

you will be satisfied with these systems for years to come.

Please keep in mind that prolonged exposure to sound pressure levels in excess of 100 dB can cause

permanent hearing loss. This high performance speaker system can exceed that level, so please

exercise restraint in its operation in order to preserve your ability to enjoy its fidelity in the future.

Because of their flexible installation possibilities, please consider having your new speakers

professionally installed by an authorized Diamond Audio dealer. This will assure a clean and efficient

installation, and extend your one year warranty to three years.

At Diamond Audio Technologies, we strive to bring honest value and excellent quality to all of the

products we build. By your purchase of this product, you have joined the growing family of discerning

listeners who demand only the best. Welcome!

The Diamond Audio Team

FEATURES

HEX™ PRO MID-BASS DRIVER ASSEMBLY

Encapsulating Die-Cast

Aluminum Frame Patented TDX™

Motor Assembly

Copper Clad Aluminum Wire

(CCAW) Voice Coil HEX™Cone

Butyl Rubber Surround

Flat Blended

Nomex™Spider

• TDX Technology™ (Thermal Dyne eXtreme)™

• Proprietary Kevlar™/Nomex™ Hex™ Cone

• Butyl Rubber Surround

• Flat Blended Nomex™ Spider with Embedded Lead Wires

• Die-cast Aluminum Frame

• Ultra-high Energy Neodymium Magnet Structure

• 30mm Polymer Treated Alloy Domed Tweeter

• Precision Model Matched Programmable Crossovers

Parts List - HP650

(2) HEX™ Pro Mid-Bass Speakers

(2) Mounting Gaskets

(2) HEX™ Pro Crossovers

(2) HEX™ Pro Tweeters

(1) Mid-Bass Mounting Hardware Kit

(1) Tweeter Mounting Hardware Kit

Tweeter Mounting

When mounting the tweeters, make sure

desired location can accommodate the

hole size, over all diameter and depth

required. Cut a hole in the surface

chosen and feed speaker wire through.

Remove the tweeter mounting ring by

unscrewing it counter clockwise. Connect

speaker wire to tweeter terminals and mount

tweeter in hole using provided screws. When tweeter

is secure, replace trim ring by screwing it on clockwise.
