SERVICE MANUAL
SPEAKER SYSTEM SX-W35
Contents:
Instructions and specifications
Guide to repair
Parts list (SX-W35-L)
Parts list (SX-W35-R)
Parts list (SX-W35-C)
Parts list (SX-W35W SUBWOOFER)
INSTRUCTIONS
THIS SYSTEM CONSISTS OF THE FOLLOWING:
2 MAIN SPEAKERS
2REAR SPEAKERS
1 CENTER CHANNEL SPEAKER
1 8" SUBWOOFER
1 RM-SR664U MULTI-BRAND REMOTE CONTROL
1 SPEAKER CABLE PACKAGE
4 SUBWOOFER FEET
8 SCREWS
(to attach Satellite Speakers to optional SS-UL3 Speaker Stands)
4 PADS FOR CENTER CHANNEL SPEAKER
1 INSTRUCTION MANUAL
For your convenience, speaker wire has been included with your purchase.
HOW TO CONNECT SPEAKER WIRES
Begin by removing the end of the vinyl covering from the wire. Then, follow the steps below and on the following pages.
SPEAKER AND SUBWOOFER CONNECTIONS
CONNECTIONS: (See figure 1)
Connect your main (front) speakers to your SUBWOOFER'S OUTPUT terminals using the 12' Red/Black wires.
Connect your subwoofer's INPUT terminals to your receiver's main speaker outputs using the 8' Blue/Black wires.
Connect your center speaker to your receiver's center speaker output using the 8' Grey/Black wire.
Connect your surround (rear) speakers to your receiver's surround speaker outputs usingthe 30'
White/Black wires.
1. Connect the FRONT SPEAKER OUTPUTS on yourreceivertotheINPUTS onthe SX-W35W
SUB usingtheblue/blackwire provided;leftto left, rightto right.Be suretoconnectthe blackwire
tothe blackterminaland the bluewireto theredterminal. See the"SupplementalSpeaker
Instructions"sheetfor recommendedspeakerplacement.
2. Connect the OUTPUT on your SX-W35W SUB speaker to the terminals of your main speakers
(one unit model SX-W35L and one unit model SX-W35R) using the red/black wire; left to left, right
to right. Connect the black wire to the black terminal and the red wire to the red terminal.
3. Connect the CENTER SPEAKER OUTPUTS on your receiver to the terminals of your center
speaker (model SX-W35C) using the grey/black wire; left to left,rightto right. Connect the black
wire to the black terminal and the grey wire to the red terminal.
4. Connect the SURROUND SPEAKER OUTPUTS on your receiver to the terminals of your rear
speakers (model SX-W35L)and (model SX-W35R) using the 30' white/black wires provided; left
to left, right to right. Connect the black wire to the black terminal and the white wire to the red
terminal.
(figure 1)
£-A---
.--,IOlOlOlOl
-,-,IOlOlOlOl
SPECIAL SPEAKER INSTRUCTIONS
RUBBER FEET and NON-SLIP PADS:
Please attach the rubber feet (included) to the bottom of your subwoofer cabinet's comers approximately 1" in from the edges.Place the small
non-slip pads on the center channel speaker, to the surface that the speaker will be resting on, to minimize movement.
CABINET FINISH:
Yourspeakercabinets require no maintenanceundernormaluse. The cabinetsurfacemay,however, be cleanedby usingadampcloth. If
youchooseto useanykindofcleaningagent(suchas a non-abrasiveglasscleaner)pleasebe sureto testa smallarea onthe bottomofthe
cabinetfirst.
RECOMMENDED SUBWOOFER PLACEMENT:
Against the wall between your left and rightfront speakers (strong bass output and optimum blending with front speakers); or Within afew
inches of the room comer closest to your left or rightfront speaker (maximum bass output); or near any other room corner or wall. Other loca-
tions will provide less predictable degrees of bass impact and/or blending with your front speakers.
RECOMMENDED CENTER AND MAIN SPEAKER PLACEMENT:
We recommend you place your center speaker horizontally on top of (or just below) your TV. For the best effect, we recommend you place
your main speakers approximately 3-4 feet to the left and right of your TV.
RECOMMENDED SURROUND SPEAKER PLACEMENT:
Behind you, equally spaced to your left and right either: facing towards the front of the room (more widely dispersed sound); or facing in
- towards the listening area (more directional sound); Other locations will provide varying degrees of directional and dispersed (ideal) sound
characteristics.
SPEAKERPROTECTION:
Yourspeakersare designedto handlea wide rangeoflisteninglevels.Forextra protectionagainstoverloads,we have includeda circuitthat
willhelpprotectthespeaker.Thisfeature willautomaticallyreducethe outputofthespeakerwhen itsensesexcessivevolumelevelor bass
boost. Ifyou noticethevolumelevelsuddenlydrop,(and itwillbe obviouswhenthisoccurs),please loweryourreceiver'svolumeand/orbass
control. Yourspeakerwillquicklyreturnto normaloperation.Useyour bestjudgmentheresincebothexcessivebassand overallvolumelevel
canoverloadyour speakers. With reasonablecare, however,theywill offeryearsof listeningpleasure.
NOTE:
BE SURE YOUR RECEIVER'S CENTER CHANNEL MODE IS SET TO "NORMAL". YOUR SYSTEM
WILL PRODUCE LESS AUDIBLE BASS WITH THE CENTER CHANNEL MODE SET TO "WIDE".
WALL MOUNTING OF SPEAKERS:
Make sure the wall is sturdyenough to support the speaker(s) before driving the screws
into the wall. For safety, use 4 pounds for reference. If the wall is not sturdy enough,
reinforce it. Use roundhead wood screws (not included) that are long and large enough
to stick out 1/8". (See figure 2) Place the speaker against the wall so that the round-
head screw enters the key hole bracket at the back of the speaker.
SPECIFICATIONS
SX-W35W Subwoofer
Speaker Type
Frequency Response
Max. Power Rating
Crossover Frequency
Nominal Impedance
Sensitivity
Cabinet Construction
Physical Dimensions
Weight
8" Dual Voice Coil Polypropylene Cone
36-200Hz
150 Watts
200Hz
8Q
92riB
High Density Particle Board
10"W x 10"H x 10-3/4"D
9 pounds
SX-W35 Satellites
Tweeter
Midrange
Frequency Response
Max. Power Rating
Nominal Impedance
Sensitivity
Cabinet Construction
Physical Dimensions
Weight
g
10mm Liquid Cooled Polyimide
3" Shielded Driver with Rubber Surround
200Hz-20kHz
150 Watts
8_
90dB
High Impact Molded Black Plastic
6-1/4"W x 3-1/2"H x 4"D
1 3/4 pounds
GUIDE TO REPAIR.
(Note: Models SX-W35L, SX-W35R, and SX-W35C have no individual parts to replace. The entire unit is replaced when repairs are necessary)
MODEL SX-W35W SUBWOOFER:
A. "Removing grille assembly"
1. Uft with even pressure the press-fit frame away from the grommet holes in the speaker cabinet.
A1."Replacing the grille assembly"
1. Insert new grille assembly into the grommet holes on the cabinet and press down using even pressure.
B. =Removing the woofer"
1. Unscrew the (4) screws holding down the woofer.
2. Remove the (4) wire clips from the woofer terminal, noting positive (blue & green) and negative (black & brown) wires.
B1 =Replacing the woofer
1. Attach the blue crossover wire to the (+) terminal, Side #1
2. Attach the black crossover wire to the (-) terminal, Side #1
3. Attach the green crossover wire to the (+) terminal, Side #2
4. Attach the browncrossover wire to the (-) terminal, Side #2
5. Screw down the woofer using (4) screws, pin hw scr #8x7.
C. =Removing the crossover"
1. Remove the woofer following steps outlined in "B" above.
2. Unscrew the (6) screws holding down the crossover.
3. Remove the crossover from the cabinet.
Cl. "Replacing the crossover"
1. Insert the crossover into the hole in the rear of the cabinet and screw down into position using (6) screws, pin hw scr 6x6
2. Attach the blue crossover wire to the (+) terminal of the woofer, side #1
3. Attach the black crossover wire to the (-) terminal of the woofer, side #1
4. Attach the green crossover wire to the (+) terminal of the woofer, side #2
5. Attach the brown crossover wire to the (+) terminal of the woofer, side #2
6. Screw the woofer back into position using (4) screws, pin hw scr #8x7
D1 ."Replacing the grey logo cavity =backing" strip"
1. Remove the old backing by prying up.
2. Press fit the new grey backing strip into the logo cavity on the grille frame, making sure the logo stud hole is towards the
bottom.
3. Pry up the top half and put a small amount of hot melt glue in the center of the strip, upper half, and press down into
place, making sure the glue does not overflow the sides.
E. =Replacing the logo"
1. Press the logo stud through the hole in the grey backing.
2. Use a nut driver and a 5mm socket to =push" pushnut (pin hw pnu t-sub) over the logo stud and lock the logo in place in
the grille frame.
PARTS LIST, MODELS SX-W35L, SX-W35R, SX-W35C
ITEM PART NUMBER PART NAME QTY DESCRIPTION
1
2
3
4
5
sp-asy-jsat-I Complete speaker 1 Left speaker
sp-asy-jsat-r Complete speaker 1 Right speaker
sp-asy-sat-c Complete speaker 1 Center speaker
pk-bag-sat Polybag 1
hw-bmp-jsatc Rubber =pad" 4 Foot/center ch
PARTS LIST, MODEL SX-W35W SUBWOOFER
ITEM PART NUMBER PART NAME QTY DESCRIPTION
1hw-bmp-jsubh Rubber Bumper
2 hw-grom-orb Grommet
3 hw-pnut-sub Pushnut
4 hw-scr-#6x6 Screw
5 hw-scr-#8x7 Screw
.6 pk-bag-jsubh Polybag
7 sp-woo-jsubh Woofer
8 wo-jsubh-cab Cabinet
9 grf-jsubh Grille frame
10 Ibk-jsubh Grey back strip
11 Iog-subh Logo
,12 tuf-a- 1/2 Insulation
13 xov-jsubh Crossover
4
4
1
6
4
1
1
1
1
1
1
1
1
"Feet" for sub
Grille frame support
Logo support stud
Size 6 x 5/8"
Size 8 x 3/4"
8" DVC woofer
Wood cabinet
Adhesive strip
Logo with stud
Crossover with wires
pACKAGING MATERIALS, PARTS LIST, MODELS SX-W35L, SX-W35R, SX-W35C
ITEM PART NUMBER PART NAME QTY DESCRIPTION
1
2
3
4
5
6
7
8
pk-fom-ljslt =Footprint" top
pk-fom-ljslb =Footprint" bottom
pk-ctn-ljsi Packing carton
pk-ctn'ljs0 Packing carton
pr-man-ljsl Literature manual
wir-ljsl Wireset pack
pk-bag-9x12 Literature polybag
hw-scr-#10x5 Wall mount screws
1
1
1
1
1
1
1
8
Polystyrene pack
Polystyrene pack
Inner speaker pack
Outer overpack
/
EXPLODED VIEW PARTS LIST, MODELS SX-W35W SUBWOOFER:
ITEM PART NUMBER PART NAME QTY DESCRIPTION
1sp-woo-jsubh Woofer
2 hw-scr-#8x7 Screw
3 grf-jsubh Grille frame
4 Iog-jsubh Logo
5 xov-jsubh Crossover
6 Ibk-jsubh Grey backing
7 tuf-a-1/2 Insulation
8 wo-cab-jsubh Wood cabinet
9 hw-grom-.25 Grommet
10 hw-scr-6x6 Screw
11 hw-pnt-jsubh Pushnut
12 pk-bag-jsubh Polybag
13 hw-bmp-jsubh Rubber bumper
1
4
1
1
1
1
1
1
4
6
1
1
4
8" Woofer
Screw for woofer
Logocavitystop
Screw for x-over
Logo fastener
(not shown)
(not shown)
