Digi Sport Instruments DT2N User manual

STOPWATCHES
ROW DISPLAY STOPWATCHES
DT2N
7-digits stopwatch
Features:
 Ergonomic design
Chronograph with lap time display, split time
12 or 24 hours size
Date and alarm
Tactile feedback on buttons
Green limpid body
LCD display
Digit height: 1cm –
p
pe er rf fe ec ct t v vi is si ib bi il li it ty y
Wrist- strap included
Impervious to water splashes
Lithium battery CR2016 3V
Size: 6.5 cm x 7.5 cm x 2 cm
Weight: 95 g

www.digisportinternational.com
INSTRUCTION MANUAL
STOPWATCH DT2N
FEATURES:
- Chronograph with lap time display
- Alarm with chime
- Hour, minute, second, month, date and day display, 12/24 hour system and month/date or date/month display
By user option
- 3 Volt Lithium long life battery
- Drop-resistant
CLOCK MODE:
1. Depress and hold C: when the cursor starts flashing below A/S press C again. The cursor will start flashing below T/S the second’s digit is flashing.
2. Press A to reset it.
3. Depress B to reset seconds.
4. Depress B to select the minutes and depress A to set it.
5. Operate the same way to set the hour’s digit. Press B again to enter the date mode. Operate the same way as above.
6. Pressing successively B will move the cursor below the day initial (S-M-T-W-T-F-S).
7. Press C to return to clock mode.
8. Press B, the display shows the alarm time.
9. Press A, the display shows the date
ALARM MODE:
1. To set up successively the hourly chime and the alarm, press B, and at the same time, press one time A to see the chime and two times for the alarm.
Do the same to cancel it.
2. Press and hold B: the display shows the alarm time. Press C at the same time to select 12 or 24h mode.
3. Press and hold C two times. The hour digit in alarm mode starts flashing.
4. Press A to set the digits and B to select the digits.
5. When the alarm sounds you can press any of the three buttons to stop the alarm.
STOPWATCH MODE:
1. By pressing C put the cursor below the CHr sign.
2. Press A to start measurement.
3. Each time you will press B will allow you to view the lap time while the stopwatch keeps measuring.
4. To stop the stopwatch press A.
5. Press B to reset the stopwatch.
CARE OF YOUR STOPWATCH:
WATER RESISTANCE
- The stopwatch is designed to withstand accidental contact with water such as splashes or raindrops, but it is not designed for use in water. Do not
operate the buttons when the stopwatch is wet.
TEMPERATURE
- Do not leave your stopwatch under direct sunlight or in very high temperatures for a long time, the display may become black. Do not leave your
stopwatch in very low temperature as this may cause a slight time loss or gain and the change of digits becomes slow. In both cases the above conditions
will be corrected when the stopwatch returns to normal temperature.
SHOCKS
- Be careful not to drop your stopwatch or hit it against hard surfaces as it may cause a mechanical damage.
STATIC ELECTRICITY
- The integrated circuit in your stopwatch can be affected by static electricity. If the static electricity is very strong, a permanent damage can occur. Be
careful of the screen of the TV set and the wearing of clothing made of synthetic material in dry weather; in such cases very strong electricity can be
generated.
MAGNETISM
- Not affected
CHEMICALS
- Do not expose your stopwatch to solvents such as gasoline and alcohol, spray of cosmetics,
Cleaners, paints etc may cause damage to the stopwatch.
BATTERY
- When the display becomes dim or faded out, battery replacement is necessary.
1. Turn the battery cover off from close to open position by using the rope holder.
2. Push the Battery Lock in the direction shown to release the old battery.
3. Install a fresh lithium battery CR2016 into the battery holder, please make sure the BatteryLock is in the position shown.
4. Re - install the battery cover; turn the dot from open to close position.
Use a battery of quality.
THE WARRANTY DOES NOT COVER THE BATTERY.
