Casio 3069 User manual

Module No. 3069

Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out
of your purchase, be sure to read this manual carefully.
•Be sure to keep all user documentation handy for future reference.
Applications
The built-in sensors of this watch measure direction, barometric pressure,
temperature and altitude. Measured values are then shown on the display.
Such features make this watch useful when hiking, mountain climbing, or
when engaging in other such outdoor activities.
E

E-1
Warning!
•The measurement functions built into this watch are not intended for
taking measurements that require professional or industrial precision.
Values produced by this watch should be considered as reasonable
representations only.
•When engaging in mountain climbing or other activities in which losing
your way can create a dangerous or life-threatening situation, always be
sure to use a second compass to confirm direction readings.
•Note that CASIO COMPUTER CO., LTD. assumes no responsibility for
any damage or loss suffered by you or any third party arising through
the use of this product or its malfunction.

E-2
Keep the watch exposed to bright light
The electricity generated by the solar cell of the
watch is stored by a built-in battery. Leaving or
using the watch where it is not exposed to light
causes the battery to run down. Make sure the
watch is exposed to light as much as possible.
•When you are not wearing the watch on your
wrist, position the face so it is pointed at a
source of bright light.
•You should try to keep the watch outside of
your sleeve as much as possible. Charging is
reduced significantly if the face is covered only
partially.
l
l
l
l
l
l
l
l
l
l
l
Bright light
Solar cell

E-3
•The watch continues to operate, even when it is not exposed to light.
Leaving the watch in the dark can cause the battery to run down, which will
cause some watch functions to be disabled. If the battery goes dead, you
will have to re-configure watch settings after recharging. To ensure normal
watch operation, be sure to keep it exposed to light as much as possible.
Bright light
Electrical
energy
All
functions
enabled
LEVEL 1
LEVEL 2
LEVEL 3
LEVEL 4
Charge
Solar cell
(Converts light to
electrical power.)
Rechargeable battery
LEVEL 1
LEVEL 2
LEVEL 3
LEVEL 4
Some
functions
disabled
Dis-
charge
Battery charges in the light. Battery discharges in the dark.

E-4
•The actual level at which some functions are disabled depends on the
watch model.
•Frequent display illumination can run down the battery quickly and require
charging. The following guidelines give an idea of the charging time
required to recover from a single illumination operation.
Approximately five minutes exposure to bright sunlight coming in through
a window
Approximately 50 minutes exposure to indoor fluorescent lighting
•Be sure to read “Power Supply” (page E-108) for important information
you need to know when exposing the watch to bright light.
If the display of the watch is blank...
If the display of the watch is blank, it means that the watch’s Power Saving
function has turned off the display to conserve power.
•See “Power Saving” (page E-126) for more information.

E-5
About This Manual
•Depending on the model of your watch, display
text appears either as dark figures on a light
background, or light figures on a dark
background. All sample displays in this manual
are shown using dark figures on a light
background.
•Button operations are indicated using the
letters shown in the illustration.
•Each section of this manual provides you with
the information you need to perform operations
in each mode. Further details and technical
information can be found in the “Reference”
section.
•To ensure that this watch provides you with the
years of service for which it is designed, be
sure to carefully read and follow the
instructions under “Operating Precautions”and
“User Maintenance”.
(Light)

E-6
Contents
General Guide ................................................................................. E-10
Radio-controlled Atomic Timekeeping ........................................... E-12
Digital Compass ............................................................................... E-32
Barometer/ Thermometer .................................................................E-54
Altimeter .......................................................................................... E-61
Altitude Data Recall ........................................................................ E-83
World Time ........................................................................................ E-89
Stopwatch ........................................................................................ E-91
Countdown Timer ............................................................................. E-93
Alarms .............................................................................................. E-95
Illumination ...................................................................................... E-98
Questions & Answers ....................................................................E-102
Power Supply ................................................................................. E-108
Timekeeping ...................................................................................E-116
Reference ........................................................................................E-122
Specifications .................................................................................E-140

E-7
Procedure Lookup
The following is a handy reference list of all the operational procedures
contained in this manual.
To specify your Home City ............................................................. E-13
To perform manual receive .............................................................E-25
To turn auto receive on and off ....................................................... E-27
To check the latest signal reception results ................................. E-28
To enter and exit the Digital Compass Mode ................................. E-33
To take a direction reading ............................................................. E-34
To perform magnetic declination correction .................................E-41
To perform bidirectional calibration .............................................. E-43
To perform northerly calibration ..................................................... E-44
To store a compass reading in Bearing Memory .......................... E-46
To set a map and find your current location .................................E-49
To find the bearing to an objective ................................................ E-50

E-8
To determine the direction angle to an objective on a map
and head in that direction ......................................................... E-51
To take barometric pressure and temperature readings ............. E-54
To display your current altitude ...................................................... E-65
To select the altitude measurement type ....................................... E-67
To select an Altimeter Mode display format ................................. E-68
To start a new save session ........................................................... E-70
To set a reference altitude ............................................................... E-77
To reset the altitude differential value to zero .............................. E-80
To use altitude differential measurement ..................................... E-81
To view periodic records and current session record contents .. E-86
To view historical record contents ................................................ E-87
To clear the historical record ......................................................... E-88
To view the time in another city ...................................................... E-89
To toggle a city code time between Standard Time and
Daylight Saving Time ................................................................. E-90
