Digikeijs DR5033 User manual

DR5033 DIGIBOOST
P 1
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
DR5033
DIGIBOOST
instrucon manual
(2021-07-06)
© Copyright 2005 – 2019 digikeijs, the Netherlands. All
rights reserved. No informaon, images or any part of
this document may be copied without the prior wrien
permission of Digikeijs.

DR5033 DIGIBOOST
P 2
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
1Index
1.0 General informaon 2
1.1 Index 2
1.2 Warranty and warranty condions 3
1.3 Legal informaon 3
2.0 Product overview 4
2.1 General product informaon 4
2.2 Technical Specicaons 4
2.3 Hardware Overview 5
3.0 Adjusng the DR5033 Conguraon 6
3.1 LocoNet® Variables (LNCV) Table 7
3.2 Descripon Conguraon LNCV 3 7
4.0 Connecon examples 8
4.1 Important instrucons for using the DR5033. 8
4.2 Tested central units and connecon types 9
4.3 DR5000, DR5033 Boosters and Feedback
DR4088 modules 11
4.4 DR5000, DR5033 Boosters and Feedback Modules
DR5088RC 12
4.5 DR5000, DR5033 Booster and feedback modules
DR4088xx 13
4.6 Roco® z21®, z21Start®, DR5033 Connecon via
the R-Bus® 14
4.7 Roco® Z21®, DR5033 Connecon via R-Bus® 15
4.8 Lenz Central®, DR5033 via CDE connecon 16
4.9 Uhlenbrock Intellibox®, DR5033 Connecon via
LocoNet® B 17
4.10 Various control panels and snier input of the
DR5033 18
1.0 General Informaon

DR5033 DIGIBOOST
P 3
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
1.2 Warranty and warranty condions
All our products have a 24-month manufacturer's warranty. Please read this manual carefully.
Damage to the product caused by non-compliance with these instrucons will void the warranty.
ATTENTION: The warranty is void if the housing of the product is opened.
1.3 Legal informaon
Prinng errors and mistakes, technical or other changes as well as changes in the availability of individual products are expressly reserved.
Data and illustraons are non-binding. All changes to hardware, rmware and soware are reserved.
We reserve the right to change the design of the product, the soware and / or the rmware without prior noce.
Copyright
All Digikeijs manuals and other wrien instrucons supplied and/or downloadable are copyrighted.
Reproducon is not permied without the wrien permission of Digikeijs.

DR5033 DIGIBOOST
P 4
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
2.0 product overview
2.1 General product informaon
The DR5033 is a pure DCC booster capable of Railcom®. All other protocols (e.g. Märklin® Mfx®) are not supported!
The DR5033 is an H-bridge booster with various connecon opons (CDE booster connecon, LocoNet® B, Roco® booster bus, track snier) to connect the
DR5033 to an exisng central. The conguraon of the DR5033 can be customized via LNCV programming. The DR5033 can be congured to switch the polarity
of the track output automacally or by magnec command. The DR5033 can be switched on and o separately via a magnec command and the current status
can be queried by the control panel.
Important! The DR5033 must not be used in systems that operate according to the common ground principle. This can lead to the destrucon of the booster
and/or the central unit.
2.2 Technical specicaons
The terminals are designed for a cross-secon of 0.75mm².
outputs loading capacity inputs power supply
DR5033 Track Out 3A LocoNet® B
Track Snier
Roco® Booster Bus
15-19V DC
3A

DR5033 DIGIBOOST
P 5
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
2.3 Hardware Overview
1CDE Booster connecon
(Please check whether the CDE connecon of your control panel com-
plies with the requirements specied by Lenz®).
2LocoNet® B Connector 1
3LocoNet® B Connector 2
4Tack Snier Input
By connecng the Track Snier input to the track output of the central unit, the track
signal is recognized even if none of the other input opons are available.
(CDE Booster connecon, LocoNet® B, Roco® B Bus) can be used on the DR5033.
5Roco® Booster Bus Connector 1
6Roco® Booster Bus Connector 2
7power supply
DC 15-19V 3,5A
8Track Output
9Booster Status LED
Track signal present (normal operaon)
No track signal present.
(Loconet® B, B-Bus, CDE, Track Snier Input)
Booster load under 90%.
(LED becomes brighter under load)
Booster load greater than 90%.
Short circuit detected
Stop command detected (e.g. by the control unit)
Track Out reversed polarity.
Note: If the blue LED lights up when driving over the booster separaon
points, the track output of the DR5033 is connected with reversed polarity.
12
7
45
89
36

DR5033 DIGIBOOST
P 6
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
3.0 Adjusng the DR5033 Conguraon
The DR5033 is a DCC booster whose sengs (LocoNet® module address, magnec arcle address, etc.) can be easily adjusted via LNCV programming. With the
LNCV 3, the behaviour (short-circuit behaviour, start behaviour, automac polarity reversal, etc.) of the booster can be adapted.
1. Connect the DR5033 to the LocoNet B port on the DR5000.
(Important! if LocoNet® module addresses are idencal or if the LocoNet® module address is un-
known, only one DR5033 may be plugged into the LocoNet®.)
2. Connect the DR5033 to the power supply.
3. Call the "LNCV Programming" programming menu of the DR5000 under Loconet B.
4. Select the DR5033 from the list or enter its product number numerically.
5. Read out or enter the module address via the buon. (Delivery State =1)
6. If necessary, assign a free module address. (Delivery State =1)
7. If a new address has been assigned, the newly assigned address must of course also be entered in
the "Module address" selecon eld, otherwise further programming of the DR5033 is not possible.
8. Enter the CV number to be changed or read in the input eld.
9. Enter the desired value or select the bits to be set.
10. Use the "Read value" or "Write LNCV value" buons to read out the LNCV or write it to the booster.
11. This bar indicates the progress of the read or write process.
Message display of the read/write operaon.
TIMEOUT No module detected (possibly wrong module address entered?!)
OKAY Read/write operaon performed correctly. 4
5
7
8
10 11
9
56
1
2
3

DR5033 DIGIBOOST
P 7
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
3.1 LocoNet® Variables (LNCV) Table
LNCV Descripon range Default LNCV Descripon range Default
0Loconet module address 1-9999 112
Waing me aer automac polarity reversal of the track
out before a short circuit is reported to the control unit.
(Seng in 3 millisecond steps.)
32-250 48
1Firmware version (1000 = 1,000)
(Value can only be read) - - 13 Waing me before polarity reversal or short-circuit signal. (Seng in 3 millisecond steps.) 16-250 32
3Conguraon LNCV siehe unten 92 14 Oponal switching address for polarity reversal of the out-
put 0-2048 0
6Temperature of the H-bridge in degrees °C
(Value can only be read) 0-150 - 15 Polarity reversal ON for feedback A 0-2048 0
7Current load in %
(Value can only be read) 0-100 - 16 Polarity reversal ON for feedback B 0-2048 0
8Turnout address for booster Individual switch-o 0-2048 017 Polarity reversal OFF for feedback D 0-2048 0
11
Waing me unl restart aer short circuit.
The default value corresponds to approx. one 3/4 second
(750 ms). (Seng is done in three millisecond steps.)
64-30000 244 18 Polarity reversal OFF for feedback E 0-2048 0
Bit Wert Descripon Default Bit Wert Descripon Default
0
0Not used
04
0Booster does not send a special LocoNet® message in case of
short-circuit shutdown.
16
1Not used 16
Booster sends a LocoNet® message in case of a short circuit so
that the central unit can display which booster has been
switched o.
1
0Track Out acve as soon as an input signal is detected.
05
0Track Out acve without output polarity reversal (blue LED o)
0
2
Track Out acve as soon as the GO/Stop buon of the control
unit is pressed or the connected switching address (LNCV 8) is
switched to green.
32 Track Out acve Output reversed polarity (blue LED on)
2
0Booster does not send 'GPON/GPOFF' L.NET report on short
circuit. Automac short-circuit repair is enabled. 46
0Automac polarity reversal o
64
4Booster sends 'GPON/GPOFF' L.NET report to headquarters. The
central determines when the track out is switched on again. 64 Automac polarity reversal on
30Not used 870Not used 0
8Not used 128 Not used
3.2 Descripon Conguraon LNCV
With the LNCV 3 the behaviour (short-circuit behaviour, start behaviour, automac reverse polarity, etc.) of the booster can be adapted.

DR5033 DIGIBOOST
P 8
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.0 Connecon examples
The connecon examples shown here represent only a small part of the possibilies for connecng the DR5033 to dierent control panels. Please note that
there are of course further possibilies and special cases which cannot be shown here!
4.1 Important notes on using the DR5033.
• The conguraon is done via LocoNet®.
• The DR5033 can be used with control panels that use an H-bridge to generate track signals.
• The same voltage must be set on the power supply units of the boosters and control panels.
• When using the CDE booster connecon on the DR5033, it must be ensured that the CDE connecon of the central unit meets the specicaons of Fa. Lenz®.
• Operaon of the DR5033 in conjuncon with control panels (e.g. Uhlenbrock®, Piko® Smart ControllerLigth®, etc.) which operate according to the "common
ground principle" is not possible on the same circuit. This can lead to damage to components. Even a busbar separaon on both sides is not sucient! Please
note connecon example 4.9.
• The tracks must always be separated on both sides between the booster and central areas.
• The maximum number of boosters on the Roco® B-Bus® is limited to four.
• The transion voltage between the booster ranges must always be less than 0.8 Volt. This can easily be checked with a mulmeter (seng the measuring
range to AC alternang voltage). Both rail separaons must always be checked. If the value of 0.8 Volt is exceeded, the input voltage of the booster or the
voltage seng of the central unit must be adjusted.
Central Booster
DR50333
The displayed measured value must not
exceed 0.8 Volt!
Always check both track separaons!

DR5033 DIGIBOOST
P 9
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.2 Tested central units and connecon types
Central Connecon Possibil-
ies Central
special features
DR5000
B-Bus® No Railcom®, max. 4 boosters possible.
LocoNet® „B“Our recommendaon! Full booster connecon.
Railcom® is generated by the DR5000 and passed on to the booster. The status of
the DR5033, for example, can be queried via LocoNet®. In addion, the booster can
be individually switched o and on again via a magnec arcle address.
Roco®/Fleischmann®
Z 21®
B-Bus® Our recommendaon!
(if the number of 4
Booster is sucient)
No Railcom®, max. 4 boosters possible.
Snier Input Our recommendaon! Railcom® is recognized and passed on by the booster.
LocoNet® Since the Z 21® has no LocoNet® "B" connecon, the DR5033 can only be cong-
ured. Operaon via LocoNet® „B“ on the Z 21 is therefore not possible.
Roco®/Fleischmann®
z21®/z21®Start
B-Bus® Our recommendaon!
(if the number of 4
Booster is sucient)
No Railcom®, max. 4 boosters possible.
Snier Eingang Our recommendaon! Railcom® is recognized and passed on by the booster.

DR5033 DIGIBOOST
P 10
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
Central Connecon Possibil-
ies Central
special features
Lenz®
CDE Our recommendaon!
Snier Input
Uhlenbrock®
Intellibox, Intellibox 2,
Intellibox Basis, etc.
LocoNet® „B“Our recommendaon! Full booster connecon.
Railcom® is generated by the central unit and passed on to the booster. The status
of the DR5033, for example, can be queried via LocoNet®. In addion, the booster
can be individually switched o and on again via a magnec arcle address.
Important! As Uhlenbrock® works according to the Common Ground principle, the
track output DR5033 must never be used with the track output of the central unit
on the same circuit. Even a track separaon on both sides is not sucient!
Piko®
Smartcontrol light®
Uhlenbrock® Daisy®
LocoNet® „B“Our recommendaon! Full booster connecon.
Important! AS Piko®/Uhlenbrock® works according to the Common Ground princi-
ple, the track output DR5033 must never be used with the track output of the cen-
tral unit on the same circuit. Even a track separaon on both sides is not sucient!
Please note that it is not possible for us to test all central/booster combinaons available on the market.

DR5033 DIGIBOOST
P 11
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.3 DR5000, DR5033 Boosters and feedback modules DR4088
More LocoNet®
components

DR5033 DIGIBOOST
P 12
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.4 DR5000, DR5033 Booster and Feedback Modules DR5088RC
Module 2
Detector address
17 to32
Global Detector
1001 Global Detector
1017
Modul 1
Detektor Adresse
1 bis 16
Detector 10
Detector 1 Detector 2 Detector 3 Detector 18
Detector 17 Detector 19 Detector 26
More LocoNet®
components

DR5033 DIGIBOOST
P 13
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.5 DR5000, DR5033 Booster and Feedback Modules DR4088xx
DR4088LN CS
More LocoNet®
components
More S88
feedback unit

DR5033 DIGIBOOST
P 14
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.6 Roco® z21®(white), z21Start® , DR5033 Connecon via the B-Bus®
More Boosters
max. 4 pieces on
B-Bus® possible
Central Booster
DR50333
The displayed measured value must not
exceed 0.8 Volt!
Always check both track separaons!
R-Bus®
Track
Out
P N
z21®Start
z21®(white)
B-Bus®

DR5033 DIGIBOOST
P 15
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.7 Roco® Z21®, DR5033 Connecon via the B-Bus
More Boosters
max. 4 pieces on
B-Bus® possible
Central Booster
DR50333
The displayed measured value must not
exceed 0.8 Volt!
Always check both track separaons!
B-Bus® Track
Out
P N
Z21®

DR5033 DIGIBOOST
P 16
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.8 Lenz Zentrale®, DR5033 via the CDE connector
Note the designaon of
the terminals!!!
(EDC)
Note the designaon of
the terminals!!!
(EDC)
Note the designaon of
the terminals!!!
(EDC)
C D E
J K
Lenz® LZ100®
Lenz® LZ200®
Central Booster
DR50333
The displayed measured value must not
exceed 0.8 Volt!
Always check both track separaons!

DR5033 DIGIBOOST
P 17
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.9 Uhlenbrock Intellibox®, DR5033 connecon via LocoNet® B
The track output of the Intellibox® may not be connec-
ted with the the same circuit that is formed by the
boosters. Even a rail separaon on both sides is not
sucient!
If this is not observed, damage to components may oc-
cur!
More LocoNet®
components
Track
Out
3 4
Uhlenbrock®
Intellibox®/IR
Intellibox® Basic
Intellibox® 2 Loconet®
B T

DR5033 DIGIBOOST
P 18
www.digikeijs.com ® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
4.10 Any H-bridge control panel, DR5033 connecon via Track Snier
Digital Central
mi H-bridge
at the track out
Track Out
J K
Central Booster
DR50333
The displayed measured value must not
exceed 0.8 Volt!
Always check both track separaons!
