Digilin LDR-CV-15A-1CH User manual

©2020 Digilin Technologies
Document Rev: 3.0 - 24 November 2020
Product specifications are subject to change without notice.
LDR-CV-15A-1CH
High Current PWM Repeater
User Manual

LDR-CV-15A-1CH - High Current PWM Repeater
User Manual
3.0 - 24 November 2020
digilin.com.au Page 2 of 3
[phone]
Table Of Contents
Notes.....................................................................................................................................................................................................................................................................................................2
Introduction..................................................................................................................................................................................................................................................................................2
Specifications .............................................................................................................................................................................................................................................................................2
Physical.......................................................................................................................................................................................................................................................................................2
Inputs............................................................................................................................................................................................................................................................................................3
Outputs......................................................................................................................................................................................................................................................................................3
Installation ...................................................................................................................................................................................................................................................................................... 3
1. Open Enclosure ...........................................................................................................................................................................................................................................................3
2. PWM Input....................................................................................................................................................................................................................................................................... 3
3. LED Fitting ........................................................................................................................................................................................................................................................................3
4. Power.....................................................................................................................................................................................................................................................................................3
5. Close Enclosure..........................................................................................................................................................................................................................................................3
Appendix A. Wiring Diagram .................................................................................................................................................................................................................................... 3
Notes
•Install in a dry sheltered position
•Interior use only
•Ensure adequate ventilation
•Installation should only be performed by a qualified professional
•Install in accordance with all appropriate wiring standards
•Never connect a LED fitting to a driver that is powered. Doing so may result in damage to the LED.
•Always make sure the output voltage range and output current of the LED driver match the
requirements of the LED fitting. Failure to do so may result in damage both the driver and fitting.
Introduction
The LDR range provides a cost-effective means to expand a LED dimming system without the need for
extra protocol receivers, by simply repeating the input PWM signal. The constant voltage version switches
up to 15A, making it suitable for higher current fittings and strips.
Specifications
Physical
U n i t s
Dimensions
115 x 36 x 30
mm
Weight
100
g

LDR-CV-15A-1CH - High Current PWM Repeater
User Manual
3.0 - 24 November 2020
digilin.com.au Page 3 of 3
[phone]
Inputs
U n i t s
Voltage
12 - 24
VDC
Communications
Low side Switched PWM
PWM Input Current Draw (max)
20
mA
Outputs
U n i t s
Outputs
1 Channel Low side PWM
Current Per Channel
15
A
Fuse
20
A
Installation
1. Open Enclosure
To access the wiring terminals, remove the top plate by first removing the 4 screws securing it.
2. PWM Input
Connect a low side switched PWM source (such as a single channel from the LDMX-PWM-4) to the PWM In
pins. The PWM in pins are optically isolated from the rest of the circuit.
3. LED Fitting
Wire the LED fitting(s) to the output port of the LDR.
4. Power
Connect the input voltage to the Power +/- Pins. This is also the power to the LED fitting(s) as such it
should be selected to match the power requirements of the fitting.
5. Close Enclosure
Replace the top panel (making sure of correct orientation) and secure it with the 4 screws.
Appendix A. Wiring Diagram
