ALFAtron CV2.0K1.4 User manual

HDMI Extender over Cat5e/6

HDMI Extender over Cat5e/6
Statement
Thanks for purchasing this product, please read this user manual carefully
before using this product. In the constant effort to improve our product,
we reserve the right to make functions or parameters changes without
notice or obligation.
Safety Precaution
▪Do not dismantle the housing or modify the module to avoid electrical
shock or burn.
▪Using supplies not meeting the product's' specifications may cause
damage, deterioration or malfunction.
▪Do not expose the unit to rain, moisture or install this product near
water.
▪Install the device in a place with fine ventilation.
▪Do not twist or pull by force ends of the optical cable. It can cause
malfunction.
▪Do not use liquid or aerosol cleaners to clean this unit.
▪Always unplug the power to the device before cleaning.
▪Unplug the power when not used for a long period of time.
▪Refer all servicing to qualified service personnel.
After-sales Service
We provide limited warranty for the product within seven years

HDMI Extender over Cat5e/6
Introduction
The CV2.0K1.4 is an ultra thin HDMI signal manager. It is designed to
enhance the compatibility between HDMI sources and displays to match
more display device. The transmission of 4k×2k@60Hz (max) signal from
source to display is up to 15m. Beside straight-through HDMI
transmission, the EDID bypass function ensures the best resolution of
displays. No need of any external power supply, simplifying the
installation and operation.
Features
▪Input supports HDCP 2.2.
▪Supports EDID bypass and auto input resolution detection, make sure
the best resolution of display device.
▪The transmission of 4k@60Hz 4:2:0 signal from source to display is up
to 15m.
▪No need of any external power supply, simplifying the installation and
operation.
Package Contents
▪1 x CV2.0K1.4
▪1 x Velcro Tape
▪1 x User Manual

HDMI Extender over Cat5e/6
Panel Description
① Power LED: GREEN when powered on
② IN: Connect with HDMI source
③ OUT: Connect with HDMI display
Specifications

HDMI Extender over Cat5e/6
Specifications
Input & Output
Input
(1) HDMI
Input Connector
(1) 19-pin type-A female HDMI
Output
(1) HDMI
Output Connector
(1) 19-pin type-A female HDMI
General
Transmission Distance
Input≤10m; Output≤5m
HDCP Standard
Input supports HDCP2.2
EDID Management
EDID pass-through
Bandwidth
10.2Gbps
Power Consumption
1W
Work Temperature
-10~55℃
Relative Humility
10%-90%
Dimensions (W*H*D)
45.5mm x 12mm x 75mm
Weight
50g
Note: This product can be powered by HDMI cable, if you need similar-type
model with external power supply, please contact your distributor for more
details.
1. Limited warranty in respect of Alfatron Products Only
1.1 This limited warranty covers defects in materials and
workmanship in this product.
1.2 Should warranty service be required, proof of purchase
must be presented to the Company. The serial number on

HDMI Extender over Cat5e/6
the product must be clearly visible and not have been
tampered with in any way whatsoever.
1.3 This limited warranty does not cover any damage,
deterioration or malfunction resulting from any alteration,
modification, improper or unreasonable use or maintenance,
misuse, abuse, accident, neglect, exposure to excess
moisture, fire, improper packing and shipping (such claims
must be presented to the carrier), lightning, power surges,
or other acts of nature. This limited warranty does not cover
any damage, deterioration or malfunction resulting from the
installation or removal of this product from any installation,
any unauthorized tampering with this product, any repairs
attempted by anyone unauthorized by the Company to
make such repairs, or any other cause which does not relate
directly to a defect in materials and/or workmanship of this
product. This limited warranty does not cover equipment
enclosures, cables or accessories used in conjunction with
this product.
This limited warranty does not cover the cost of normal
maintenance. Failure of the product due to insufficient or
improper maintenance is not covered.
1.4 The Company does not warrant that the product covered
hereby, including, without limitation, the technology and/or
integrated circuit(s) included in the product, will not become
obsolete or that such items are or will remain compatible
with any other product or technology with which the product
may be used.
1.5 Only the original purchaser of this product is covered
under this limited warranty. This limited warranty is not

HDMI Extender over Cat5e/6
transferable to subsequent purchasers or owners of this
product.
1.6 Unless otherwise specified, the goods are warranted in
accordance with the manufacturer’s product specific
warranties against any defect attributable to faulty
workmanship or materials, fair wear and tear being
excluded.
1.7 This limited warranty only covers the cost of faulty goods
and does not include the cost of labor and travel to return
the goods to the Company’s premises.
1.8 In the event of any improper maintenance, repair or
service being carried out by any third persons during the
warranty period without the Company’s written
authorization, the limited warranty shall be void.
1.9 A 7 (seven) year limited warranty is given on the
aforesaid product where used correctly according to the
Company’s instructions, and only with the use of the
Company’s components.
1.10 The Company will, at its sole option, provide one of the
following three remedies to whatever extent it shall deem
necessary to satisfy a proper claim under this limited
warranty:
1.10.1 Elect to repair or facilitate the repair of any defective
parts within a reasonable period of time, free of any charge
for the necessary parts and labor to complete the repair and
restore this product to its proper operating condition.; or

HDMI Extender over Cat5e/6
1.10.2 Replace this product with a direct replacement or
with a similar product deemed by the Company to perform
substantially the same function as the original product; or
1.10.3 Issue a refund of the original purchase price less
depreciation to be determined based on the age of the
product at the time remedy is sought under this limited
warranty.
1.11 The Company is not obligated to provide the Customer
with a substitute unit during the limited warranty period or at
any time thereafter.
1.12 If this product is returned to the Company this product
must be insured during shipment, with the insurance and
shipping charges prepaid by the Customer. If this product is
returned uninsured, the Customer assumes all risks of loss
or damage during shipment. The Company will not be
responsible for any costs related to the removal or
reinstallation of this product from or into any installation. The
Company will not be responsible for any costs related to any
setting up this product, any adjustment of user controls or
any programming required for a specific installation of this
product.
1.13 Please be aware that the Company’s products and
components have not been tested with competitor’s
products and therefore the Company cannot warrant
products and/or components used in conjunction with
competitor’s products.
1.14 The appropriateness of the goods for the purpose
intended is only warranted to the extent that the goods are

HDMI Extender over Cat5e/6
used in accordance with the Company’s installation,
classification and usage instructions.
1.15 Any claim by the Customer which is based on any
defect in the quality or condition of the goods or their failure
to correspond with specification shall be notified in writing to
the Company within 7 days of delivery or (where the defect
or failure was not apparent on reasonable inspection by the
Customer) within a reasonable time after discovery of the
defect or failure, but, in any event, within 6 months of
delivery.
1.16 If delivery is not refused, and the Customer does not
notify the Company accordingly, the Customer may not
reject the goods and the Company shall have no liability and
the Customer shall pay the price as if the goods had been
delivered in accordance with the Agreement.
1.17 THE MAXIMUM LIABILITY OF THE COMPANY
UNDER THIS LIMITED WARRANTY SHALL NOT EXCEED
THE ACTUAL PURCHASE PRICE PAID FOR THE
PRODUCT.
