Digiplex DGP-319 Assembly instructions

16-Zone and 16-Remote Wireless Bus Module
V1.3
DGP-319
Installer’s Guide

TABLE OF CONTENTS
1.0 INTRODUCTION .............................................................................. 3
1.1 Technical Specifications .........................................................................3
1.2 System Features .....................................................................................3
2.0 INSTALLATION ............................................................................... 4
2.1 Location ..................................................................................................4
2.2 Connections and Mounting .....................................................................4
3.0 PROGRAMMING ............................................................................. 6
3.1 Programming Methods ............................................................................6
3.2 Low Battery Supervision .........................................................................7
3.3 Check-in Supervision ..............................................................................8
3.4 Tamper Supervision on Receiver Module ...............................................8
3.5 PGM Deactivation Mode .........................................................................9
3.6 PGM Base Time ......................................................................................9
3.7 PGM Timers ............................................................................................9
3.8 PGM Activation Event .............................................................................10
3.9 PGM Deactivation Event .........................................................................11
3.10 PGM Override .......................................................................................11
3.11 System Reset .......................................................................................12
3.12 Viewing Unknown Serial Numbers ........................................................12
4.0 DETECTORS AND CONTACT SWITCHES .................................... 13
4.1 Assigning Detectors & Contact Switches to Receiver .............................13
4.2 Assigning Detectors & Contact Switches to Zones .................................14
4.3 Viewing Signal Strength of Detectors & Contact Switches .....................14
5.0 REMOTE CONTROLS ..................................................................... 16
5.1 Assigning Remote Controls to the Receiver Module ..............................16
5.2 Assigning Remote Controls to User Access Codes ................................17
5.3 Programming Remote Control Buttons ...................................................18
5.4 Replacing the Remote Control’s Battery .................................................22

2 Installer’s Guide

Digiplex Liberator 3
1.0 INTRODUCTION
1.1 TECHNICALSPECIFICATIONS
Manchester Decoding
Diversity Antenna
Error Detection & Correction
Frequency Hopping: @ 902 MHz - 928 MHz or 868MHz
Range: Detectors & Contact Switches:
1000m (3280ft) or 300m (984ft) for 868 MHz
Remote Controls: 30m (100ft)
Sensitivity: -105dBm
Current Consumption: 70 mA
Dimension (without antennas) 15cm H x 16cm L x 3cm W
(6in H x 6.5in L x 1.1in W)
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Operating Humidity: 85%
PGM Outputs: 1 relay (an additional PGM Output is available)
PGM Output current: 5A
1.2 SYSTEMFEATURES
Add 16 wireless detectors or contact switches to the Digiplex System
Add 16 remote controls to the Digiplex System
Reflow Design
No tuned Circuit
Tamper Switch
Low Battery, Check-in, and Tamper supervision through Digiplex Control Panel
Trouble Display through Digiplex Control Panel
Signal Strength Indicator

4 Installer’s Guide
2.0 INSTALLATION
2.1 LOCATION
Mount the Wireless Bus Module on a wall allowing at least 5cm (2ft) around the
module to permit adequate ventilation and heat dissipation. Select a site that is not
susceptible to drastic temperature changes. Avoid installation near or in the path of
strong RF fields (i.e. neon lights, computers), on or near metal objects, circuit
breaker boxes, air conditioners, and heater ducts since they may cause interference
and reduce its sensitivity. We recommend installing it in a centralized location on the
main floor. Avoid installing it in the basement. Refer to the Digiplex Control Panel's
Reference & Installation Manual for maximum allowable distances between the
control panel and the Wireless Bus Module.
2.2 CONNECTIONSAND MOUNTING
Firmly screw the two antennas into the connectors marked ANT on the Receiver
Module (see Figure 2.1). Using a drill or screwdriver, punch out the four mounting
holes on the back of the plastic case. Align the six holes of the printed circuit board
with the six pins on the back plastic mounting case and snap into place. If placed
correctly, the antennas will lean directly over the grooves in the mounting case.
Do not cut, bend, or alter the antennas. Avoid mounting the Receiver
Module near or on metal as this may affect its sensitivity.
The Wireless Bus Module is connected to the control panel's bus in a star and/or
daisy chain configuration. The bus is a 4-wire communication bus that provides
power and two-way communication between the control panel and all the modules
connected to it. Connect the GRN and YELterminals from the Receiver Module to the
corresponding GRN and YELterminals of the control panel. Connect the REDterminal
to the AUX+ of the control panel. Connect the BLKterminal to the AUX- of the control
panel.
Remove AC power and then remove the battery from the control panel
before adding a bus module to the system or it may cause communication
trouble.

Digiplex Liberator 5
Figure 2.1: Connections for Receiver Module to Control Panel

6 Installer’s Guide
3.0 PROGRAMMING
3.1 PROGRAMMINGMETHODS
All programming can be done through Module Programming Mode in the Digiplex
Control Panel from any keypad as shown in Figure 3.1. The sections referred to in
Step 5 and the data referred to in Step 6 from Figure 3.1 are explored in the
following sections of the manual.
Figure 3.1: Module Programming Mode

Digiplex Liberator 7
3.1.1 Feature Select Programming
Sections [001], [002] and PGM Programming are programmed using the Feature Select
Method, where each number from 1 to 8 corresponds to a specific feature or option. Set
these options by turning the number corresponding to the feature ON or OFF. The option
is considered ON when the number appears within the brackets on the LCD keypad or
when the number is illuminated on an LED Keypad. Press the key again to remove or
extinguish the digit, thereby disabling (turning OFF) the option. You turn options ON and
OFF by pressing the corresponding keys on the keypad. Press the keys as many times
as you need to select the desired options and then press [ENTER]to save.
3.1.2 Module Broadcast
Copy sections [001] to [008] of one Wireless Bus Module to one or more Wireless Bus
Modules. For details see the Digiplex Reference & Installation Manual.
3.1.3 WinLoad
With the WinLoad Security System Management Software, the control panels, modules
and keypads can be programmed remotely through a modem or on-site at 19,200 baud
with a 306 Adapter. For details refer to the Digiplex Reference & Installation Manual.
3.2 LOWBATTERYSUPERVISION
SECTION[001]: OPTION[1]
When a detector or contact switch’s battery voltage drops below a recommended
level (refer to the transmitter’s Instruction Sheet), its yellow LED will flash and it will
transmit a signal to the Wireless Bus Module indicating that the voltage is low. If this
option is enabled, the Receiver Module will transmit the signal to the control panel.
The control panel will generate a trouble and can transmit a report code to the
monitoring station. For details refer to the Digiplex Reference & Installation Manual.
From Step 6 in Figure 3.1, page6, enable or disable the option:
Option [1] OFF = Low Battery Supervision disabled
Option [1] ON = Low Battery Supervision enabled (default)

8 Installer’s Guide
3.3 CHECK-INSUPERVISION
SECTION[001]: OPTIONS[2] AND[3]
The Wireless Bus Module waits for each of its assigned detectors and/or contact
switches to send a status signal within a specified time period to confirm their
presence and functionality. If a device has not sent a signal within the time period,
the Wireless Bus Module will transmit a supervision loss signal to the control panel.
The control panel can generate a trouble, an alarm and/or can transmit a report
code to the monitoring station. For details refer to the Digiplex Reference &
Installation Manual. Option [2] enables the Check-in Supervision feature and option
[3] specifies the time period required for the devices to send their signal.
From Step 6 in Figure 3.1, page6, enable or disable the options:
Option [2] OFF = Check-in Supervision disabled
Option [2] ON = Check-in Supervision enabled (default)
Option [3] OFF = Check-in every 12 hours (default)
Option [3] ON = Check-in every 12 minutes
Ensure that the assigned detectors and/or contact switches are set to the
same time period as the Receiver Module (i.e. if the Receiver Module is set
to Check-in every 12 minutes, the detectors/contact switches must be set to
Check-in every 12 minutes.
3.4 TAMPERSUPERVISIONONRECEIVERMODULE
SECTION[001]: OPTION[4]
If this option is enabled and the Receiver Module's cover is removed, the on-board
tamper switch will be triggered. When this occurs, the Wireless Bus Module will
transmit a tamper signal to the control panel. The control panel can generate a
trouble, an alarm and/or can transmit a report code to the monitoring station. For
details refer to the Digiplex Reference & Installation Manual.
From Step 6 in Figure 3.1, page6, enable or disable the option:
Option [4] OFF = Receiver Module's Tamper Supervision disabled (default)
Option [4] ON = Receiver Module's Tamper Supervision enabled

Digiplex Liberator 9
3.5 PGM DEACTIVATIONMODE
SECTION[002]: OPTION[1] AND[5]
The Wireless Bus Module has one or two on-board PGMs. Each PGM can be in
Follow Mode or in Timed Mode. If the PGM is in Follow Mode, it will deactivate
according to its PGM Deactivation Event. If the PGM is in Timed Mode, it will
deactivate according to its PGM Timer. However, if PGM Override is enabled,
Follow Mode and Timed Mode will be ignored.
From Step 6 in Figure 3.1, page6, enable or disable the options:
Option [1] OFF = PGM 1 in Follow Mode
Option [1] ON = PGM 1 in Timed Mode (default)
Option [5] OFF = PGM 2 in Follow Mode
Option [5] ON = PGM 2 in Timed Mode (default)
Ensure that both the PGM Activation Event and PGM Deactivation Event
are programmed for each PGM for Follow Mode to function properly.
3.6 PGM BASE TIME
SECTION[002]: OPTION[2] AND[6]
These options define the Base Time of the PGM Timers when the PGM is in Timed
Mode.
From Step 6 in Figure 3.1, page6, enable or disable the options:
Option [2] OFF = PGM 1 Base Time is in seconds (default)
Option [2] ON = PGM 1 Base Time is in minutes
Option [6] OFF = PGM 2 Base Time is in seconds (default)
Option [6] ON = PGM 2 Base Time is in minutes
3.7 PGM TIMERS
SECTIONS[003] AND[004]
When PGM(s) are in Timed Mode, the values programmed for PGM 1 in section
[003] and for PGM 2 in section [004] are defined as seconds or minutes by the PGM
Base Time. This value can be any decimal from 001 to 255. This defines the time

10 Installer’s Guide
period the PGM(s) will remain activated unless the PGM Override is enabled.
(Default 005)
From Step 5 in Figure 3.1, page6:
3.8 PGM ACTIVATIONEVENT
SECTIONS[005] AND[007]
The PGM Activation Events determine which events will activate the Wireless Bus
Module's one or two on-board PGMs. If other PGM(s) on other modules or the
control panel are programmed with the same PGM Activation Event as the Receiver
Module, those PGM(s) will also be activated when the event occurs. For details on
the available activation events, refer to the PGM Programming Table in the Digiplex
Programming Guide.
Both the PGM Activation Event and PGM Deactivation Event must be
programmed for the PGM(s) in Follow Mode to function properly.
From Step 5 in Figure 3.1, page6:
PGM 1: enter section [005]
PGM 2: enter section [007]
Use the PGM Programming Table in the Digiplex Programming Guide to program a
PGM Activation Event by following these steps:
1) In the selected section, enter the first digit where each digit is a hexadecimal
value from 8 to F that represents a specific event (0 = PGM Disabled,
hexadecimal values 1 to 7 cannot be used).
2) Then enter the second digit, which can be any hexadecimal value from 0 to F
depending on the first digit chosen.
3) After entering the second digit, use Feature Select Programming to enable/
disable options [1] to [8]. Select up to eight specific events as detailed in the
PGM Programming Table.
Timer PGM 1: Timer PGM 2:
1) Enter section [003] 1) Enter section [004]
2) Enter value (001 to 255) 2) Enter value (001 to 255)

Digiplex Liberator 11
These keys represent the hexadecimal values from A to F:
[STAY] = A [ARM] = C [BYP] = E
[FORCE] = B [DISARM] = D [MEM] = F
For installations using the LED Keypads, the hexadecimal values will
illuminate the following LEDs:
(A) = [STAY] LED (C) = [A1] LED (E) = [BYP] LED
(B) = [FORCE] LED (D) = [A4] LED (F) = [MEM] LED
3.9 PGM DEACTIVATIONEVENT
SECTIONS[006] AND[008]
When a PGM Activation Event occurs, the Receiver Module's on-board PGM will
deactivate when the events programmed in section [006] (PGM 1) or section [008]
(PGM 2) occurs unless PGM Timed Mode is enabled. The PGM Deactivation Event
is programmed the same way as the PGM Activation Event (see section 3.8).
3.10 PGM OVERRIDE
SECTION[002]: OPTIONS[3] AND[7], [4] AND[8]
When the PGM Override is enabled in options [3] and/or [7], the Receiver Module
will ignore the PGM Mode, PGM Activation Events, PGM Deactivation Events, and
PGM Timers of the corresponding PGM(s). Options [4] and [8] control whether each
PGM is activated or deactivated until the PGM Override is disabled.
From Step 6 in Figure 3.1, page6, enable or disable the options:
Option [3] OFF = PGM 1 Override disabled (default)
Option [3] ON = PGM 1 Override enabled
Option [4] OFF = PGM 1 deactivated (default)
Option [4] ON = PGM 1 activated
Option [7] OFF = PGM 2 Override disabled (default)
Option [7] ON = PGM 2 Override enabled
Option [8] OFF = PGM 2 deactivated (default)
Option [8] ON = PGM 2 activated

12 Installer’s Guide
3.11 SYSTEMRESET
Performing a system reset will erase all the sections in the Wireless Bus Module's
programming and set the following sections to their defaults:
Sections:
[001] = Options 1 and 2 ON; options 3 to 8 OFF
[002] = Options 1 and 5 ON; options 2, 3, 4, 6, 7, and 8 OFF
[003] = 005 (seconds)
[004] = 005 (seconds)
To perform the system reset:
1) Disconnect the bus from the Receiver Module
2) Place the reset jumper on both reset pins on the Receiver Module.
3) Reconnect the bus to the Receiver Module
4) Wait until the Locate LED turns off (takes about 4 seconds)
5) Remove the jumper
The module can also be reset using the Module Reset feature in the Digiplex Control
Panel (see Digiplex Control Panel's Reference & Installation Manual).
3.12 VIEWINGUNKNOWNSERIALNUMBERS
SECTION[025]
The serial number of a detector, contact switch, or remote control can be displayed.
From Step 5 in Figure 3.1, page6:
1) Enter section [025]
2) On LCD Screen: Press and hold the tamper switch on the detector or contact
switch or press and hold the remote's A and B buttons simultaneously until the
keypad squawks and the device's serial number appears on the LCD screen
under the words “View Data”.
On LED Screen: Press and hold the tamper switch on the detector or contact
switch or press and hold the remote's A and B buttons simultaneously until the
keypad squawks. The first number of the device's serial number will illuminate
(10 = zero). Press the key to view each subsequent number. When you
press the key on the last number of the serial number, the control panel
will exit the section.

Digiplex Liberator 13
4.0 DETECTORS AND CONTACT SWITCHES
Programming for the wireless transmitters is accomplished in three steps:
1) Assign the detectors and contact switches to the Wireless Bus Module.
2) The detectors and contact switches from the Wireless Bus Module must be
assigned to zones in the Digiplex Control Panel.
3) The zone parameters must be defined in the Digiplex Control Panel.
For more details concerning zones, refer to the Digiplex Control Panel's Reference
& Installation Manual.
Complete the Programming Guide while assigning the detectors and
contact switches. The serial numbers and the inputs that they are assigned
to will be needed when programming the zones in the control panel.
Sections [020], [021], [101] to [116],and [201] to [216] are all interrelated.
For example, when assigning a detector or contact switch to the Receiver Module:
1) The serial number and input number will be assigned in section [101]
2) The number of devices will automatically appear in section [020]
3) Its signal strength can be viewed in section [201]
4.1 ASSIGNINGDETECTORS& CONTACTSWITCHES TORECEIVER
In these sections you will assign the detectors and contact switches to the Wireless
Bus Module. Up to 16 detectors or contact switches can be assigned to each
Receiver Module.
SECTIONS[101] TO[116]
Enter the serial numbers of the detectors and contact switches in the sections [101]
to [116]. The serial numbers can be found inside the devices. Inputs 001 to 016 are
automatically assigned when the serial number is entered. For example, Section
[101] is assigned to input 001, Section [102] is assigned to input 002, etc. When one
section is programmed, the keypad will automatically switch to the next section.

14 Installer’s Guide
From Step 5 in Figure 3.1, page6:
1) Enter the desired section from [101] to [116]
2) Enter the serial number of the detector or contact switch
If you are unable to find the serial number, refer to section 3.12 of this
manual.
SECTIONS[020] AND[021]
The number of devices assigned to sections [101] to [108] can be viewed in section
[020]. The number of devices assigned to sections [109] to [116] can be viewed in
section [021].
In section [021] devices assigned to sections [109] to [116] appear as 1
through 8. For example, the device assigned to section [109] would appear
as 1 in section [021].
Devices can also be deleted through these sections. Use Feature Select
Programming (see section 3.1.1) to delete device(s) by pressing the corresponding
key(s). For example, to delete the device assigned in section [109], press the [1]
key in section [021], and then press [ENTER].
4.2 ASSIGNINGDETECTORS& CONTACTSWITCHES TOZONES
Once the detectors and the contact switches have been assigned to the Wireless
Bus Module, they must be assigned to zones in the control panel. For instructions on
how to assign the devices to the zones and then program the zones, refer to the
Digiplex Control Panel's Reference & Installation Manual.
Zones assigned to detectors or contact switches cannot be programmed
as Fire Zones.
4.3 VIEWINGSIGNALSTRENGTHOFDETECTORS& CONTACTSWITCHES
SECTIONS[201] TO[216]
Once the detectors and/or contact switches have been installed and assigned to the
Wireless Bus Module, the average signal strength of each device can be verified in
these sections by briefly holding the tamper switch or opening the zone. Each
section represents the signal strength viewer for a specific device. For example,

Digiplex Liberator 15
section [201] is the viewer for the device in section [101] and section [216] is the
viewer for the device in section [116].
From Step 5 in Figure 3.1, page6, enter a section from [201] to [216] to view the
average strength of each device.
For installations using the LCD Keypads:
The signal strength is represented by one to ten characters that will appear on the
LCD screen below the words “Module Data”. The reading (number of characters) will
appear beside the characters.Three characters or less is a very weak signal and the
device should be moved. An average reading above four characters is acceptable.
For installation using the LED Keypads:
The signal strength is represented by the illumination of the numerical LEDs from
LED 1 to LED 10. A reading from LED 1 to LED 3 is a very weak signal and the
device should be moved. An average reading above LED 4 is acceptable.

16 Installer’s Guide
5.0 REMOTE CONTROLS
To program the remote controls:
1) Remote controls must be assigned to the Wireless Bus Module
2) The remote controls from the Wireless Bus Module must be assigned to User
Access Codes in the Digiplex Control Panel.
3) The buttons on the remote controls must be programmed
Complete the Programming Guide while assigning the remote controls. The
serial numbers will be needed when assigning the remote controls to User
Access Codes. Also, knowing which User Access Code was assigned to
which remote control may affect how the remote's buttons are programmed.
Sections [030],[031],[301] to [316],[401] to [416],and [501] to [516] are all
interrelated.
For example, when assigning a remote control to the Receiver Module:
1) The serial number will be entered in section [301]
2) It will automatically appear in section [030]
3) It is assigned to a User Access Code in section [401]
4) Its buttons are programmed in section [501]
When using the remote controls, users must press the button(s) until the red
LED on the remote control illuminates. This short delay (0.25 sec.) before
sending a signal is to avoid accidental transmissions. After pressing and
holding a button continuously for five seconds, the remote control will no
longer transmit any signals until the button is released and pressed again.
5.1 ASSIGNINGREMOTECONTROLSTOTHERECEIVERMODULE
In these sections you will assign the remote controls to the Receiver Module. Up to
16 remote controls can be assigned to each Receiver Module.
SECTION[301] TO[316]
Enter the serial numbers from the remote controls in the sections [301] to [316].
When one section is programmed, the keypad will automatically switch to the next
section.

Digiplex Liberator 17
If you are unable to find the serial number, refer to section 3.12 of this
manual.
From Step 5 in Figure 3.1, page6:
1) Enter a section from [301] to [316]
2) Enter the serial number of the remote control
SECTIONS[030] AND[031]
The number of remote controls assigned to the Receiver Module can be viewed in
sections [030] and [031]. The remote controls assigned in [301] to [308] will appear
in section [030] and the remote controls assigned in [309] to [316] will appear in
section [031].
In section [031] remote controls assigned in [309] to [316] appear as 1
through 8. For example, the remote assigned in [309] would appear as 1 in
section [031].
Remote controls can also be deleted through these sections. Use Feature Select
Programming (see section 3.1.1) to delete a remote control from the system by
pressing the corresponding key. For example, to delete the remote control assigned
in section [309], press the [1] key in section [031], and then press [ENTER].
5.2 ASSIGNINGREMOTECONTROLSTOUSERACCESS CODES
SECTIONS[401] TO[416]
Each remote control must be assigned to a User Access Code. All User Access
Codes are given a User Number from 001 to 096 (001 is the System Master Code).
Each section from [401] to [416] represents the remote control assigned to sections
[301] to [316] (see section 5.1). For example, the remote assigned in section [301]
will be assigned to the User Access Code designated in section [401].
From Step 5 in Figure 3-1, page6:
1) Enter a section from [401] to [416]
2) Enter the User Number (001 to 096) to be assigned to the remote control.

18 Installer’s Guide
5.3 PROGRAMMINGREMOTECONTROLBUTTONS
SECTIONS[501] TO[516]
For each remote control, each button or a combination of the buttons pressed
simultaneously can be programmed to send a signal to the control panel to perform
certain actions as if users had gone to a keypad and entered their User Access
Codes. When a user arms or disarms using the remote, the control panel will arm or
disarm all the areas assigned to the User Access Code. For example, you arm with
a remote control whose User Access Code is assigned to areas 1 and 3, the control
panel will attempt to arm areas 1 and 3.
Each section from [501] to [516] represents the remote control assigned to the
sections [301] to [316] (see section 5.1 of this manual). For example, the buttons for
the remote control assigned in section [301] will be programmed in section [501].
Figure 5.1: Remote Controls with button identification
When you enter each section from [501] to [516], each digit represents a button or a
combination of buttons pressed simultaneously.
