Digisol DG-HR1070MSE User manual

DG-HR1070MSE Quick Installation Guide DG-HR1070MSE Quick Installation Guide DG-HR1070MSE Quick Installation Guide
Quick Installation Guide
DG-HR1070MSE
DIGISOL 4G MI-FI PORTABLE BROADBAND ROUTER
V2.0
2017-01-16
As our products undergo continuous development the specifications are subject to change without prior notice
Copyright
Copyright 2017 by Digisol Systems Ltd. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language,
in any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of this
company.
Trademarks
DIGISOLTM is a trademark of Digisol Systems Ltd. All other trademarks
are the property of the respective manufacturers.
Introduction
The DIGISOL™ DG-HR1070MSE HSPA+ Mobile Router lets you share a
fast mobile Internet connection with multiple PCs and mobile devices
wherever you go. It offers 4G/3G LTE/ HSPA+ compatibility for fast
downlink and uplink data rates, so you get the high-speed upload and
download speeds even when you’re on the go. Set up a personal mobile
network anywhere, anytime allowing you and those around you to access
the Internet, and share files.
Package Contents
The following items should be present in your package:
•DG-HR1070MSE 4G Mi-Fi Broadband Router
•Lithium 2000mAh rechargeable battery
•Power Adapter (5V, 1A)
•Micro USB Cable
•Quick Installation Guide
Make sure that the package contains above items. If any of the listed
items is damaged or missing, please contact your retailer immediately.
System Requirements
•A compatible (U) SIM card with mobile data service.
•A computer with Windows®, Macintosh®, or Linux-based
operating systems.
•Internet Explorer 8, Firefox 12.0, Chrome 20.0, or Safari
4.0.
Hardware Overview
External Buttons
LED chart
Indicator
Color
Working Status
Power
LED
Amber
Charging
Blink:
Turn on-
0.5s
Turn off-
0.5s
Blue
Battery High (100%-60%) or
Charge Completed
Green
Battery Middle (60%-10%)
Red
Blink: Battery too low nearly
shutdown (10%)
Purple
Blink: New SMS
Signal
LED
Blue
Solid: Register to LTE(not
connecedt)
Blink: Connected to LTE network
Green
Solid: Register to 3G(not
connected)
Blink: Connected to 3G network
Purple
Solid: Register to 2G(not
connected)
Blink: Connected to 2G network
Red
Blink: No Service/Device Error
WiFi LED
Blue
Solid: No Client
Blink: Client is active
Blink: WPS is active
Blink:
Turn on-
0.2s
Turn off-
0.1s
key
Illustrate
Power
key
Long press over 5 seconds to power on and long press to
power off
WPS
Press to active the WPS
Reset
The Reset button (Inside the bottom cover) if you forget
Administrator password press reset key.

DG-HR1070MSE Quick Installation Guide DG-HR1070MSE Quick Installation Guide DG-HR1070MSE Quick Installation Guide
Connect to your network
1. Ensure that your DG-HR1070MSE 4G Mobile Router is powered
OFF.
2. Remove the back cover and take out the battery. Slide your (U) SIM
card into the slot provided, ensuring that the alignment is the same as
indicated by the logo next to the slot. The gold contacts on the card
should be facing downwards.
Caution: Always unplug and turn off the router before
installing or removing the SIM card. Never insert or
remove the SIM card while the router is in use.
3. Press and hold the power button at the side of the router.
a. The Power LED will light Blue or Green after Power on
and performs its initialization processes.
b. After a few moments, the Wireless LED will glow blue.
For more details please refer to “LED Status” explained earlier.
Configure the Router
Connect via Wi-Fi:
To connect to the router using Wi-Fi, open your operating system’s
wireless networking utility and scan for available networks. By default, the
network name (SSID) of DG-HR1070MSE will be “DIGISOL”
You will then be prompted to enter the network security key for your
router. The unique security key for your router will be displayed on a
sticker in the router’s battery bay. By default the security key is
“12345678”.
Web Based Configuration
To access the configuration, open a web browser (such as Internet
Explorer) and enter the IP address of the router, which is 192.168.2.1 by
default.
Once you have reached the configuration utility through your web
browser, you will need to log in. Enter admin as the username, and then
enter the password. By default, the password is 1234.
Click Login to continue.
Note: For detailed configuration of the router, please refer to the user
manual.
This product comes with a Limited Lifetime Warranty. For further details
about warranty policy and Product Registration, please visit support
section of www.digisol.com
