Digital Sound Player DSP 64RC User manual
Digital sound player with remote control and 50+ tracks.
Thank you for purchasing Digital Sound Player DSP 64RC. Please read this manual before using the device and
save it for future reference. Follow the instructions to avoid damage to the device.
This device is designed for:
Chasing away birds damaging crops in vineyards and orchards;
Chasing away bee-eater birds destroying bee colonies;
Chasing away birds contaminating the facades of buildings or preventing flight safety in the vicinity of
airports;
Calling birds and animals for research purposes.
The digital device and the speaker are united in a water resistant and shockproof body, which minimizes the size
of it and increases reliability. The loudspeaker is specially designed to play digital recordings without distortion
in wide frequency range. The control is done entirely by the remote control and includes:
Direct dial tone playback
Volume control
Special mode to mixes two tunes
ON/OFF Power (switch to standby)
DSP 64RC is capable to reproduce high precision real sounds of distressed birds or raptors etc. All sounds are
easy to manage and can be programmed so as to avoid effects of habituation of birds to them. The sounds are
recorded on digitally ensuring long-term trouble-free operation of the device. Use for hunting is prohibited by
law in some countries.
For normal operation the device needs source of constant voltage with nominal 12V, which is not included in the
set. For this purpose could be used:
SLA Battery: 12V/1.3Ah, 12V/2Ah, 12V/4Ah etc.
12V car battery
220VAC/12VDC-0, 5A AC adapter / converter
Remote control manual.
With the remote control you can control:
1. Current melody: Chose corresponding melody number. After pressing the first number the remote control
indicator blinks once in green, and after pressing the second one it blinks twice in the same color. The melody
could contain a sequence of different sounds combined with pause breaks, as well as sounds with changed order
or variable playing speed. More information about the type and the content of each melody could be found on
the device’s label.
2. Sound control: Press and hold „ “for increase and „ “for decrease of the sound level. The remote control
indicator blinks rapidly in green light. When maximum or minimum level is reached the indicator blinks slower
in green.
3. Mixing melodies: To mix two melodies press the MIX button. The remote control indicator will blink once in
green and then you can chose second track as it is described in section 1.
4. Stand-by mode: Press “ ” button, the remote control indicator will blink once in green. The device goes into
reduced energy consumption mode and the indicator will blink in red briefly until the button is pressed again. It's
recommended after finishing using the device to disconnect it the battery power cable, because prolonged time in
stand-by leads to damaging the battery.
In case that the remote control doesn’t function (the indicator light doesn’t blink), you must change the battery
CR2032 Lithium 3V. With suitable screw driver unscrew the bolt of the back cover. Separate the two covers
using sharp tool. Slide the old battery to remove it then slide the new one on its place and make sure that (+) and
(-) are in their right positions.
If when pressing random button of the remote control its indicator light blinks orange that due to no connection
between the remote control and the device.
Features:
Up to 64 tracks on the internal removable flash module
Full functional wireless control up to 150m
2-way communication between remote control and device
Two sounds mixing option
Digital sampling 44100 Hz - CD quality
Class-D amplifier with 90% efficiency
Amplifier total output power 20W
Maximum (peek) output power 36W
Working temperature from -10 to +45 °C
Low battery function
Powered from external power source 8-26V DC
Optimal supply voltage 13.5V
Average supply current 85 mA
Stand-by supply current 5 mA
Total harmonic distortion + noise 0.04%
Player dimensions 89х118х69 mm
Wireless control dimensions 54х85х10 mm
Weight 0.49kg
Guarantee:
Guarantee period is 12 months commencing on the date of purchase. Within the guarantee period we will
eliminate, free of charge, any defects in the device resulted from material faults or faults caused when being
manufactured, either by repairing or replacing the complete device as we may choose.
The guarantee is valid only upon presentation of the completed guarantee card containing serial number,
dealer’s name, seal and date of purchase. The defect devise must be returned in its original package.
The guarantee is valid only on the territory of the Republic of Bulgaria.
The guarantee will not be applicable in the case of:
If there is discrepancy in the information in the guarantee card or attempts for forgery of guarantee card or
serial number,
If not observed the conditions of use, assembly, storage and transport,
In case of misuse, drop, blow, wetting, improper storage, nature disaster (lightning, flood, fire), attempts of
repairs undertaken by unauthorized persons or other external influence.
In these cases the repairs are on customer’s expense.
