ATX LUKER AT-1S User manual
MODEL:AT-1S
Dear customer:
Lifetime Warranty for LUKER turntable. if you have questions,
please contact us directly to get the service.
Our official Facebook：ATX.Luker
Our official Instagram：lukerdirect
Size 13.8x10x4.6 in/ 350x255x118mm
Weight 7.3lb/3.3kg
Speaker 2 x 3W Stereo Speaker
Playback Speed Support for 33 / 45 / 78 RPM
Audio Output LINE OUT/Headset (3.5mm) Stereo RCA
Audio Input AUX IN / USB disk / Bluetooth 4.2
Adaptor 5V 1A，USB Interface
Transfer Cable USB to DC(1m)
I. The Playback Function of Vinyl Record Player.
1.Connect the power supply:Connect to the DC adapter to power on
2.Turn On/off:Rotate the power knob.
Turn it on from left to right;
Turn it off from right to left.
3.Playback Operation:Remove the Phonograph cover→Slide Switches of the arm
valve→Lift the lever→Put the phonorecord on the turntable→Move the arm above
the phonorecord disc→Pull down the lever.
4.If the phonorecord disc is a 45 RPM player,you need to attach the 45 RPM adapter
to the Turntable spindle and then select the playback speed(33,45,or78RPM).
5.Volume adjustment:Rotate the power knob to adjust the volume.
6.After using it,please reset the arm and the protective cover of the phonograph,
then close the safety valve of the arm When the turntable stop you can switch
it off.
7.The vinyl record player would automatically stops working in the following states.
(1) At the end of the song playing when the arm moves to thecenter of the vinyl
record.
(2)If the arm is reset artificially.
(3)If press the power button to switch modes.
Ⅱ.Bluetooth Input Function
Short press the power button 2s, search and select the bluetooth named"LUKER
AT-1S" after the player reads of "Bluetooth Mode" and the BT light flashes. If blue
-tooth is connected, the BT light will be always on.
Ⅲ.USB Input Function
1. Insert the USB disk into the interface,and the USB playback mode will be on
after the player reads of "USB mode" In this mode,the audio format (mp3,wav)
will be scanned automatically.
2. Switch the songs:Click the power knob three times to play the last song and
twice to play the next one.
Ⅳ.Vinyl Recording Function
1.Insert the U disk, short press the power button 2s to switch the vinyl playback
mode on;
2.Under this mode,long press the power button in 5s,the USB Recording Mode
will turn on when the player reads of "PHONO-REC mode” with the indicator
flashes.
3.Long Press the power button again to end up the USB Recording Mode,once
the indicator light stops flashing with beep sound The recording sound will be
saved in U disk after that.
Ⅴ.AUX IN Mode
The player will make a sound When the audio device is connected sucessfully
by AUX IN(3.5mm) interface.The speaker will speak the songs out loud.
Ⅷ.How to Change the Phonograph Stylus
1. Remove the old stylus :
(1) Grab the middle of the cartridge.
(2) Use a flat-blade screwdriver nozzle to align (point A in the following diagram),
then pull the old needle down.
(3) Grab and remove it.
Ⅵ.LINE OUT Function
Connect the external speakers with audio cables.You can turn the sound of
player itself up and down by adjust the power knob.However,it can’t adjust the
the external speakers (The wire accessories are not provided).
Ⅶ.Other Operation Tips
1.Earphone and the speaker mode can not work simultaneously.
2.Short press the power Knob to switch among different modes in turn swith a
sound noticed.(4modes include successively: Vinyl playback function, AUXIN，
USB input function,Bluetooth).
A
B
2.Install the new stylus :
(1)Grab the front end of the new stylus and the middle of the cartridge respectively.
(2)Align the tail of the new stylus at the position of the cartridge groove(point B in
the following diagram),install the tail of the new stylus into the cartridge groove
slightly and push in gently.
(3)Then press the new stylus into the front of the cartridge then lock it firmly.
CONTACT US
Company: ANTEXIN TECHNOLOGY Co.,Ltd.
ADD: Fuxingda Industrial Park Factory Building,
No. 2 Lanjing North Road, Zhukeng Community,
Longtian Street, Pingshan District, Shenzhen, China
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least
20cm from nearby persons.
