DigitaLinx DL-HD28A-H2 User manual

11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 190501 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]
DL-HD28A-H2 Quick Install Guide
This guide is for quick installaon only.
For complete owners manual go to www.libav.com or use a QR reader to access the
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

DL-HD28A-H2 Quick Guide
3
The Digitalinx DL-HD28A-H2 is an HDMI 2.0 compable 2:8 auto scaling and auto switching HDMI
distribuon amp / splier that features two HDMI inputs and either HDMI outputs. The spliers HDMI
outputs can switch as a group to either input via auto or manual switching methods and supports down
scaling so a 4K video input can automacally be down scaled to an 1080p output when connecng
a display that only supports resoluons up to 1080p. The DL-HD28A-H2 supports 4K signals up to
4K@60Hz / 4:4:4 / 8 bit color and features an easy EDID management opon using dip switches on the
rear panel of the unit. Analog and digital audio can be de-embedded from the selected HDMI input
and the DL-HD28A-H2 supports CEC control and is HDCP 2.2 compliant. The DL-HD28A-H2 can be
controlled via front panel buons, RS232 or by TCP/IP control.
Product Overview
Package Contents
• DL-HD28A-H2 2:4 Switching DA
• Quick Install Guide
• (4) Plasc Cushions
• (2) Mounng Clips with (4) Mounng Screws
• 12V DC Power supply with US, EU, UK and AU power adapters.

DL-HD28A-H2 Quick Guide
4
Front Panel View
1 2 3 4 5 6 7 8 9
1. POWER LED INDICATOR - Illuminates solid RED when device is powered ON
2. OUTPUT LED INDICATORS - Illuminates solid GREEN when there is an HDMI output on the
corresponding channel
3. SOURCE BUTTON and LED INDICATORS
AUTO - Switching mode indicator; illuminates solid GREEN when device is in auto switching mode, OFF
when in manual switching mode. To change switching modes, hold down the SOURCE buon for 3
seconds.
IN1 / IN2 - Input indicator; illuminates solid when corresponding input channel has been selected. To
change inputs, use the SOURCE buon to toggle between inputs. Front panel input control only works in
manual switching mode.
4. DISPLAY ON - Press buon to turn connected displays ON via CEC or RS232
5. DISPLAY OFF - Press buon to turn connected displays OFF via CEC or RS232
6. VOLUME DOWN/MUTE - Press buon to turn connected display volume down via CEC or
RS232. To mute audio press and hold buon down for 3 seconds
7. VOLUME UP - Press buon to turn connected display volume UP via CEC or RS232. Use up
buon to exit audio mute mode
8. EDID - EDID value sengs selector
9. FW - Micro USB connector for rmware updates

DL-HD28A-H2 Quick Guide
5
Rear Panel View
1 2 3 4 5 6 7 8
1. INPUTS - Two HDMI input ports to connect HDMI sources
2. OUTPUTS - Eight HDMI output ports to connect HDMI displays
3. AUDIO OUT -3 pin phoenix connector for analog audio output
4. SPDIF OUT - Toslink digital audio output port for digital audio output
5. EDID - 4 pin dip switches for EDID sengs
6. RS232 - DB-9 female connector for RS232 control
7. TCP/IP - RJ45 for Telnet or web GUI control
8. DC12V - 2-pin terminal block for external power supply

DL-HD28A-H2 Quick Guide
6
Connecvity Instrucons
1. Verify all components included with the extender set are present before installaon.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
3. Connect the source devices to the HDMI inputs using HDMI cables that are less than or equal to 1.5
meters in length for 4k/60Hz signals. For source devices that are further away, it is highly recommended
to install an extender such as the Digitalinx DL-HD70, DL-HDE100 or DL-HD2100.
4. Connect the display devices to HDMI outputs using HDMI cables that are less than or equal to 7
meters in length for 4k/60Hz signals. For display devices that are further away, it is highly recommended
to install an extender such as the Digitalinx DL-HD70, DL-HDE100 or DL-HD2100.
5. Connect Ethernet and RS232 control connecons (oponal)
6. Connect and lock the power supply to the power connector by twisng the locking collar clockwise.
7. Power on aached audio/video devices.

DL-HD28A-H2 Quick Guide
7
Technical Specicaons
Input/Output Connecons
HDMI Inputs Two (2) HDMI Type A Receptacles
HDMI Outputs Eight (8) HDMI Type A Receptacles
TCP/IP One (1) 8P8C Port (Shielded RJ45 Female)
RS232 One (1) Female DB9 Port
Audio - One (1) Analog L/R audio output, 3-Pin 3.5mm Phoenix
connector
- One (1) Digital SPDIF output, Toslink connector
Supported Audio, Video, and Embedded Control
Video Resoluons Up to 4K@60Hz 4:4:4 8 bit
Video Bandwidth 18Gbps
Maximum Passive HDMI Cable Distance 1.5m for 4k60 signal for input / 7m for 4K60 signal for output
Video Compliance HDMI 2.0b, HDCP 2.2 and CEC compliant
Embedded Audio LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital®
Plus, DTS:X™, and DTS-HD® Master Audio™ pass-through.
De-embedded Audio Analog L/R Out: PCM
Digital Out: PCM, Dolby Digital, DTS, DTS-HD
Device Control Parameters
Ethernet 100BaseT
RS232 Baud Rate Up to 115200
Chassis and Environmental
Enclosure Painted Aluminum
Dimensions (H x W x D) 28.5mm x 265mm x 110mm (1.1 in x 10.4 in x 4.3 in)
Shipping Weight 830g (1.8 lbs.)
Operang Temperature -5° to +55° C (+23° to +131° F)
Operang Humidity 10% to 90%, Non-condensing
Storage Temperature -20° to +70° C ( -4° to +140° F)
Storage Humidity 10% to 90%, Non-condensing
Power, ESD, and Regulatory
Power Supply Input:100V-240VAC / 50-60 Hz
Output: 12VDC 1A
Power Consumpon 12W (Max.)
ESD Protecon 8kV air, 4kV contact
Product Regulatory FCC, CE, RoHS
Other
Standard Warranty 5 years
Included Accessories Quick Install Guide,(4) Plasc Cushions, Rack Mounng Ears with
Screws, (1) AC power adapter with US, UK, EU and AU power
plugs
