Digium IAXy User manual

Hello! and thank you for purchasing the Digium IAXy ATA Device! The IAXy is a single-port Ethernet-to-telephone adapter,
speaking the Asterisk-native IAX protocol, and designed for use with Asterisk, The Open Source PBX. This document covers
layout, power requirements, booting and provisioning of the IAXy. If you have any questions, please feel free to send an
e-mail to <[email protected]>.
Physical Layout
The back side of the IAXy features four components.
From left-to-right they are: RJ11 telephone interface, a small
recessed Reset button, 10baseT Ethernet interface, and Power
interface.
The IAXy measures 65mm x 65mm x 28mm (w x d x h).
Power Requirements
(If you purchased your IAXy with a Digium power supply, you may
skip this section.)
The IAXy has specic power requirements. You will need a 9-volt
switched or regulated Power Supply outputting at a minimum
of 800mA with tip positive, and a plug measuring 5.0mm outer
diameter and 2.5mm inner diameter to power the IAXy. A regulated
power supply is preferred, as a switched power supply may cause an
audible hum to be present on the line on lower quality analog handsets.
CAUTION: Do not use an unregulated or unswitched power supply with
the IAXy. Doing so will cause the unit to function unreliably and may
cause it to fail.
IAXy Conguration Guide

Provisioning the IAXy
Once the IAXy has booted, it needs to be provisioned in
order that it might register as an IAX friend with your Asterisk
server. The provisioning process species the IAX username,
password, and host. To provision the IAXy, you will need the
provisioning utility that can be downloaded by following these
instructions:
$ cd /usr/src
$ export CVSROOT=:pserver:anoncvs@cvs.
digium.com:/usr/cvsroot
$ cvs login (the password is anoncvs)
$ cvs co iaxyprov
$ cd iaxyprov
The iaxyprov package will contain the following les:
Makefile
frame.h
iaxydebug.c
iax2.h
iaxy.conf.sample
provision.c
provision.h
Build the provision utility by executing the make command.
Once this is done, modify the iaxy.conf.sample le to t
our needs:
;
; IAXY Provisioning description
;
dhcp ; (DHCP enabled)
;ip: 192.168.0.100 ; (Set a static IP for
the IAXy)
;netmask: 255.255.255.0 ; (Set a static netmask)
;gateway: 192.168.0.1 ; (Set a static gateway)
Booting the Unit
The IAXy requires that you plug in the interfaces in specic
order. The easiest suggestion is to follow a left-to-right
methodology.
Plug in the telephone cord
Insert the Ethernet cable
Power up the unit
The key point here is that the telephone cord and Ethernet
cable must be inserted before power is applied. Failing
this, the unit will not boot completely and will not properly
initialize the telephone device.
Upon booting, the unit will seek out an IP address from a
DHCP server. The easiest way to determine the IP of the
IAXy is to monitor either your syslog, messages, or your
daemon.log le in /var/log. You can watch real-time
changes to these les by using the tail command such as:
$ tail -f /var/log/syslog
or
$ tail -f /var/log/messages
or
$ tail -f /var/log/daemon.log
1
2
3

codec: ulaw ; (use G.711 ulaw codec)
;codec: adpcm ; (use ADPCM codec)
server: 192.168.0.1 ; (the IP of your Asterisk server)
;altserver: 192.168.0.2 ; (IP of your backup Asterisk server)
user: myusername ; (the username assigned to the IAXy)
pass: mypassword ; (the password assigned to the IAXy)
register ; (Registration on)
;heartbeat ; (Generate status packets on port
; 9999 sent to 255.255.255.255
;debug ; (Output extra debugging to port 9999)
Now that we have congured our iaxy.conf.sample le, we can provision the IAXy
with the following command:
./iaxyprov <ip of the IAXy> <file>
i.e.:
./iaxyprov 192.168.0.100 iaxy.conf.sample
If registration is successful, you will receive a notice on the command line.
Now power to the IAXy should be cycled. When the IAXy powers back up, it will
emit a yellow light after it has acquired an IP address and has registered with your
Asterisk server. If you do not see a solid light after 20 seconds, the IAXy has failed
to register itself with your Asterisk server—please reprovision the IAXy and try again.
If you are having trouble with installation, or need further help or support in any
way, please contact [email protected].
av
Conguring Asterisk to work with the IAXy
To congure Asterisk to accept your IAXy, you will need to set it up in the /etc/
asterisk/iax.conf le. Here is a sample entry:
[iaxy]
type=friend
accountcode=iaxy
host=dynamic
secret=yoursecretpassword

150 West Park Loop
Suite 100
Huntsville, AL 35806
(877) LINUX-ME!
context=yourcontext
disallow=all
allow=ulaw
;allow=adpcm
callerid=”My IAXy” <[phone]>
trunk=no
Once the IAXy has been added to the iax.conf le, you must execute a
reload of Asterisk for the changes to be enabled:
asterisk -rx reload
In order to call the IAXy, it must be added to your dialplan. You can call the
IAXy from the /etc/asterisk/extensions.conf le as follows:
exten => 1234,1,Dial (IAX2/asteriskhost.company.com@iaxy/s)
