Dimplex DEVA-13 User manual

13 Litre Evaporative Cooler – DEVA-13
Please read this manual carefully before use and keep it for future reference

IMPORTANT SAFEGUARDS
1. Read all instructions.
2. Disconnect the power plug before dismantling, assembling or before cleaning.
3. Avoid touching mobile parts of the unit.
4. Make sure the unit is on a dry and even surface.
5. Never insert fingers, pencils or any other objects though the guards whenever
the power plug is connected, especially while running.
6. Do not use the appliance for any other purpose than its intended use.
7. The fan must not be used if the guards are not fastened according to
instructions.
8. When the power cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.
9. Do not use your appliance with an extension cord unless it has been checked
and tested by a qualified electrician or electrical supplier.
10. Return to Hagemeyer or authorised service agent.
11. The appliance is not intended for use by young children or infirm persons
unless they have been adequately supervised by a responsible person to
ensure that they can use the appliance safely.
12. Young children or infirm persons should be supervised to ensure that they do
not play with the appliance.
Read all instructions before operating.
IMPORTANT PRODUCT INFORMATION
Congratulations on your purchase of this versatile product, whichcombines a room
cooler, humidifier and air cleaner. To get the best cooling effect from your product
please read these instructions carefully.
2

For the best performance of your Evaporative Cooler it should be filled with water,
and ice if available, and positioned in a location that will create a 'flow through' air
effect. The greatest cooling effect will be felt if the unit is operated in a partly
opened doorway or window with the cooled air directed into the room. It is also
important to have a door or window partly opened away from the air cooler, in order
to create the 'flow through' effect. If this arrangement cannot be met the
Evaporative Cooling System will be less efficient.
PARTS DESCRIPTION
1. Control Panel
2. Handle
3. Lid (opening for ice and water)
4. Water level indicator
5. Castors
6. Front louvres
7. Rear screen (removable)
8. Drain plug
9. Rear panel
10. Remote control
3

HOW TO USE
ON / SPEED ADJUSTMENT: To turn the unit on press the SPEED
button. The unit will automatically start in low speed position. Each time
the button is pressed the speed increases from low to medium and then
high. The control panel will show the increase in speed in the indicator
shown to the right.
TIMER: Press the timer button to set the time on the fan. The running time can be
set from 1 hour to 8 hours. Each time the button is pressed the time increases. On
the fifth time the timer function will be switched off.
1HR Î2HR Î4HR Î8HR ÎTIMER OFF
COOL: This unit is designed for spot (evaporative) cooling. To start the
evaporative function of this unit press the COOL button and the
snowflake icon will be illuminated.
SWING (LOUVRE): This button gives you the choice of having either a
fixed or continuously sweeping airflow. For a continuous sweeping
airflow switch the oscillation control to the on position. If you require the
airflow to be delivered in a fixed direction, switch the swing control off.
ION: This button starts the ionizer function. An ionizer introduces
negative ions into the air that work to purify the air in the room. When this
function is on the tree icon will be illuminated. Press the ion button again
to turn this function off.
REMOTE CONTROL: This unit comes with a full function remote control. The
remote requires batteries. The effective range is approximately 6m.
4

PREPARATION AND OPERATION
1. To obtain the optimum performance from your Dimplex DEVA-13 Evaporative
Fan, we recommend the following procedure be followed, as different areas
within Australia have differing water types.
2. With the first use add a teaspoon of dishwashing liquid or Fabric softener to the
water. This will ensure the DEVA-13 curtain absorbs the water for maximum
cooling effect. You may find it necessary from time to time to add the liquid if
the curtain is not adequately wet.
3. Remove the unit from its packaging.
4. If you wish for the evaporative function towork, lift the top cover of the machine
and fill where indicated. Do not put water into the compartment marked ICE
ONLY. Only fill with cold clean water into the WATER ONLY compartment. Do
not overfill with water (check the water level at front).
5. For extra cooling, remove the separate ice container provided in the top of the
unit, fill with water and freeze. Return the frozen ice container to the top
compartment of the machine marked ICE ONLY. Only fill halfway with water if
using ice in conjunction.
6. Always use clean water (not tap water) and do not allow the same water to stay
in the machine for extended periods of time. It is recommended tht any water
left in the machine for 3ormore daysshould be drained away via the drain plug
provided.
7. Make sure the drain plug is tight before filling. When draining out water please
ensure the drain plug is refitted correctly and tightly.
5

CARE AND MAINTENANCE
CLEANING: Your unit is designed to remove dirt and other atmospheric impurities
by drawing air through the air filter. On no account should this be blocked in any
way, as this will impair the efficiency of the machine. Pushing the unit up against a
wall or operating in a very close proximity to long window drapes will impair the
airflow and efficiency.
REAR AIR FILTER: This is easily accessible by removing the rear screen and
removing the filter. Disconnect the machine from the power supply, gently wash the
filter in mild soapy water and replace. Be sure to refit the rear screen securely.
WATER TANK: If the unit is in regular use it is not necessary to clean the water
tank regularly. However, in hard water areas, deposits will build up and it is
recommended that cleaning with mild soapy water once every six months should
be sufficient.
1. Disconnect the appliance from mains supply.
2. Remove complete rear panel by carefully removing the service screws. Do not
use to pull the rear frame out as the mains lead is still connected internally via
quick fit connector.
3. When the connector can be seen and reached, disconnect and remove panel
completely.
4. Remove any deposits or dirt from within the tank with a mild soapy detergent
and cloth.
5. Flush with clean water and drain via the drain plug.
6. Reverse procedure and make sure the rear panel is correctly located before
replacing and tightening service screws.
INTERNAL HUMIDITY SCREEN: The internal humidity screen (water curtain), like
the water tank may also require cleaning. Follow the below steps:
1. Disconnect the appliance from mains supply.
2. Remove complete rear panel by carefully removing the service screws. Do not
6

use to pull the rear frame out as the mains lead is still connected internally via
quick fit connector.
3. When the connector can be seen and reached, disconnect and remove panel
completely.
4. Carefully remove the humidity screen from its rollers and soak in warm mild
soapy water until clean.
5. Replace onto the rollers and revers the removal procedure.
6. It is recommended that this should be done every 6-12 months.
OUTSIDE CABINET: Use warm mild soapy water and cloth. Do not use abrasive
products. Be careful to ensure the control panel does not come into contact with
water or any other liquids.
7
