DirectConnect DCHS12 User manual

1 X 2 HDMI™
Distribution Amplifier
Model# DCHS12 SKU# .16248
Plug and play: No extensive configuring required
1 HDMI input to 2 HDMI outputs—same video both displays from single
source
HDCP 1.1 compliant
3D HDMI video format support
3D video support for formats up to a 297MHz TMDS clock
Supports display resolutions up to 4K x 2K@30Hz, 1080P 3D@60Hz
Supports deep color 30bit, 36bit, 48bit per pixel
Supports DTS-HD / Dolby-True-HD / LPCM / 7.1 / DTS / Dolby-AC3 / DSD
audio formats
USER MANUAL
IMPORTANT: If you do not understand correct installation instructions, please consult
your installation specialist.

2
Thank you for choosing DirectConnect® Products
For optimum performance and safety, please read these instructions
carefully before connecting, operating, or adjusting this product. Please
keep this manual for future reference.
Table of Contents
1.0 Specifications…………………………………... 3
2.0 Package Contents..…………………………... 4
3.0 Panel Description….…………………………. 4
4.0 Connection and Operation.………..……. 4
5.0 Troubleshooting…….………………………... 5
6.0 Non-HDCP-Compliant Devices.…………. 5
7.0 Limited Warranty…………………………..... 6
Liability Statement
Every effort has been made to ensure that this product is free of defects.
DirectConnect®cannot be held liable for the use of this hardware or any direct
or indirect consequential damages arising from its use. It is the responsibility
of the user of the hardware to check that it is suitable for his/her require-
ments and that it is installed correctly. All rights reserved. No parts of this
manual may be reproduced or transmitted by any form or means electronic
or mechanical, including photocopying, recording or by any information
storage or retrieval system without the written consent of the publisher.
DirectConnect®reserves the right to revise any of its hardware and software
following its policy to modify and/or improve its products where necessary or
desirable. This statement does not affect the legal rights of the user in any
way.
All third-party trademarks and copyrights are recognized.
DirectConnect® is a registered trademark
HDMI™ is a registered trademark
UL® is a registered trademark of Underwriters Laboratories

3
Frequency Bandwidth 2.97Gbps
Input 1—HDMI Female
Output 2—HDMI Female
Power Supply DC 5V 1A
Dimensions 2.76” x 2.36” x .79” (70 x 60 x 20mm)
Weight .28 lbs (125g)
Warranty
Limited Warranty 2 Year Parts and Labor
Environmental
Operating Temperature 320F - 1040F (-00C - 400C)
Storage Temperature -40F - 1400F (-200C - 600C)
Relative Humidity 20% to 90% RH (no condensation)
Power Requirement
5 Volt DC Power Adapter 5V DC@1A Power Consumption: 5 Watts
maximum
Accessories
(1) 5 Volt DC Power Adapter
UL,CE, & FCC 100-240v, 50-60Hz to 5.0vdc
User Manual English Version
1.0 SPECIFICATIONS
NOTE: Specifications are subject to change without notice

4
2.0 PACKAGE CONTENTS
Before attempting to use this DirectConnect®unit, please check the packaging
and make sure the following items are contained in the shipping carton:
1x2 HDMI™ Distribution Amplifier (splitter) - Main unit
DC 5V power supply
User’s Manual
3.0 PANEL DESCRIPTION
FRONT PANEL REAR PANEL
1—Power LED: This LED will illuminate when power is supplied to the unit
2—Power supply input (supplied)
3—HDMI™ Input from source (DVD, STB)
4—Input LED: This LED will illuminate when the HDMI™ is connected
5—Output #2 to display monitor
6—Output #2 LED will illuminate when both unit and display are connected
7—Output #1 LED will illuminate when both unit and display are connected
8—Output #1 to display monitor
4.0 CONNECTION AND OPERATION
Connect the HDMI™ cable from the splitter (3) to the HDMI™ output of
the source unit
Connect the HDMI™ cable from the splitter (5,8) to the input of the display
device
Plug In the power (2) to the splitter and plug into the wall outlet

5
CONDITION POSSIBLE SOLUTIONS
Power light not on Make sure power is connected to the unit. Only use the
power supply supplied with the unit 5V
No display image/LED light ON
Is the display unit turned on? Is the display unit set to
the correct video input? Are the cables connected
properly? Please refer to the connection diagram.
Image without sound
Note: That units connected with a
DVI adapter will not have sound –
DVI is a video-only connection
standard
1- Check the display unit’s volume
2- Turn off the HDMI™ source (DVD, PS3 etc.) and power
on again. If there is still no sound, then:
3- Unplug the power adapter on the Extender transmit-
ter and receiver unit for 10 seconds and then plug
in again.
4- Repeat step 2 again if still not working.
Note: Some devices not HDMI™ certified may have
compatibility problems.
Poor picture quality
(snow, sparkles, banding, etc)
Examine the HDMI™ and replace with new cables if
possible.
5.0 TROUBLESHOOTING
6.0 NON-HDCP-COMPLIANT DEVICES
If a DM device does not appear to work, make certain that the device is HDCP-
Compliant. A non-HDCP-compliant DM device will not work with a signal that
has HDCP encoding present.

6
7.0 LIMITED WARRANTY
Should any consumer product from DirectConnect®fail due to defects in mate-
rials or workmanship within two years from the date of the original sale to the
end-user, DirectConnect®guarantees replacement of the defective product at
no cost. Freight charges for the replacement unit will be paid by the customer.
A copy of the invoice showing the item number and date of purchase (proof-of-
purchase) must be submitted with the defective unit to constitute a valid in-
warranty claim.
Units that fail after the warranty period has expired may be returned to the
factory for repair at a nominal charge, if not damaged beyond the point of
repair. All freight charges for out-of-warranty returns for repair are the respon-
sibility of the customer. Units returned for repair must have a Return Authori-
zation Number assigned by DirectConnect®.
This is a limited warranty and is not applicable for products which, in our opin-
ion, have been damaged, altered, abused, misused, or improperly installed.
DirectConnect®makes no other warranties either expressed or implied, includ-
ing limitation warranties as to merchantability or fitness for a particular pur-
pose. Additionally, there are no allowances or credits available for service work
or installation performed in the field by the end user.
DirectConnect®
Houston, TX 77027
800.531.3224
Scan the code to visit our
website.
www.DirectConnectHome.com
