DirectConnect DCHS14 User manual

H
He el lp pi in ng g y yo ou u a ac ch hi ie ev ve e y yo ou ur r i in ns st ta al ll la at ti io on n n ne ee ed ds s! !
D
Di ir re ec ct t C Co on nn ne ec ct t ®
is one of the largest manufacturers of products specifically for the custom installation
of audio, video, security, telecom and data networking industry.
O
Ou ur r e ex xt te en ns si iv ve e p pr ro od du uc ct t l li in ne e
offers items in the categories of bulk wire and cable, connectors, installation hardware,
interconnect cables, distribution panels, a/v transceivers, cameras, media servers,
baluns, mounts, tools and wall plates—virtually everything a custom installer needs!
S
Si in nc ce e 1 19 99 96 6, , D Di ir re ec ct tC Co on nn ne ec ct t®
has offered unique products that provide solutions to everyday installation headaches.
How do we come up with these ideas? By listening to you, the professional, who battles
in the field and is looking for someone on the front line he can rely on.
DirectConnect®
Houston, Texas 77027
Phone 800 –531 - 3224
Would it make your day to know that someone is waiting to hear from you?
We are. Your DirectConnect
®
representative is ready to take your call.
Or if you prefer, contact us online at …
http://www.directconnecthome.com
1
1 x x 4 4 H HD DM MI I™
™
D
Di is st tr ri ib bu ut ti io on n A Am mp pl li if fi ie er r
D
DC CH HS S1 14 4.16249
1X4HIGH SPEED HDMI™ DISTRIBUTION AMPLIFIER (SPLITTER)
USER MANUAL
This DirectConnect® High Speed
HDMI™ Distribution Amplifier
distributes the input of the HDMI™
signal into four (4) identical outputs
simultaneously while continuously
buffering and amplifying. This
amplifier‗s HDMI™ output can achieve long distance transmission of HDMI™
signal of up to 49.2 feet (15 meters). When two or more products are cascaded,
they can create a larger distribution system. The DirectConnect®High Speed
HDMI™ Distribution Amplifier (splitter) offers unlimited
solutions for multiple HDTV display devices.
Easy to install in seconds and simple to use - no set up needed
Large distribution achieved by cascading this HDMI™ Amplified Splitter
Supports HDMI™up to full 1080P resolutions and HDCP pass-through
12-bit per channel (36bit all channel) deep color
Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth
Supports uncompressed audio such as LPCM
Supports compressed audio such as DTS Digital and Dolby Digital
(Including DTS-HD and Dolby True HD)
IMPORTANT:If you do not understand correct installation instructions,
please consult your installation specialist.
Rev. 9910
The Finest Name in Audio/Video Products and Accessories
8 / 8

T
Th ha an nk k y yo ou u f fo or r c ch ho oo os si in ng g D Di ir re ec ct tC Co on nn ne ec ct t®
®
p pr ro od du uc ct ts s
D
De ea ar r C Cu us st to om me er r
Thank you for purchasing this DirectConnect®product. For optimum performance
and safety, please read these instructions carefully before connecting, operating, or
adjusting this product. Please keep this manual for future reference.
Table of Content
1.0 Features ……………………………………… 3
2.0 Specifications ……………………………… 4
3.0 Package Contents…………………………… 4
4.0 Panel Descriptions…………………………… 4
5.0 Connect and Operate……………….............. 5
5.1 Connection Diagram ……………….............. 5
6.0 Troubleshooting………………………….…… 6
6.1 Non-HDCP Compliant Devices …….……… 6
7.0 Limited Warranty……………………………... 7
Liability Statement
1. Every effort has been made to ensure that this product is free of defects.
DirectConnect®cannot be held liable for the use of this hardware or any
direct or indirect consequential damages arising from its use. It is the
responsibility of the user of the hardware to check that it is suitable for
his/her requirements and that it is installed correctly. All rights reserved. No
parts of this manual may be reproduced or transmitted by any form or means
electronic or mechanical, including photocopying, recording or by any
information storage or retrieval system without the written consent of the
publisher.
2. DirectConnect®reserves the right to revise any of its hardware and software
following its policy to modify and/or improve its products where necessary or
desirable. This statement does not affect the legal rights of the user in any
way.
3. All third-party trademarks and copyrights are recognized.
IMPORTANT:If you do not understand any installation instructions,
please consult your installation specialist
* DirectConnect® is a registered trademark.
*UL®is as registered trademark of Underwriters Laboratories. ©Copyright
7.0 LIMITED WARRANTY
Should any consumer product from DirectConnect®fail due to defects in materials
or workmanship within two years from the date of the original sale to the end-user,
DirectConnect®guarantees replacement of the defective product at no cost. Freight
charges for the replacement unit will be paid by the customer. A copy of the invoice
showing the item number and date of purchase (proof-of-purchase) must be
submitted with the defective unit to constitute a valid in-warranty claim.
Units that fail after the warranty period has expired may be returned to the factory
for repair at a nominal charge, if not damaged beyond the point of repair. All freight
charges for out-of-warranty returns for repair are the responsibility of the customer.
Units returned for repair must have a Return Authorization Number assigned by
DirectConnect®.
This is a limited warranty and is not applicable for products which, in our opinion,
have been damaged, altered, abused, misused, or improperly installed.
DirectConnect®makes no other warranties either expressed or implied, including
limitation warranties as to merchantability or fitness for a particular purpose.
Additionally, there are no allowances or credits available for service work or
installation performed in the field by the end user.
T
Th ha an nk k y yo ou u f fo or r c ch ho oo os si in ng g D Di ir re ec ct tC Co on nn ne ec ct t®
®
p pr ro od du uc ct ts s
IMPORTANT:If you do not understand any installation instructions,
please consult your installation specialist
* HDMI™ is a registered trademark.
* DirectConnect® is a registered trademark.
*DPL Rating™ is a registered trademark.
*UL®is as registered trademark of Underwriters Laboratories.
2 / 8
7 / 8

2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal
0.5-1.0 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Maximum Signal Link Range
1920X1080P
Output Video
HDMI™+HDCP1.0/1.1
Video format supported
DTV/HDTV
480i/576i/480p/576p/720p/1080i/1080P
VGA
640x480,800x600, 1,024X768, 1,920X1,200
Digital Signal I/O
HDMI™Compliance
Yes
Operating Frequency
Frequency
Up to 225MHz
Vertical Frequency Range
50/60Hz
Video Amplifier Bandwidth
2.25Gpbs/225MHz
Resolutions (HDTV)
Interlaced(50&60Hz)
480i,576i,1080i
Progressive(50&60Hz)
480p,576p,720p,1080p
Mechanical
Size(H-W-D)
10.6‖ x 7.09 ‖ x ‖1.6 (270 x 180 x 40mm)
Weight(Net)
48.8 oz. (1385grams)
Warranty
Limited Warranty
2 Year Parts and Labor
Environmental
Operating Temperature
320F - 1580F (00C + 700C)
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
140F - 1760F (-100C + 800C)
Storage Humidity
5% to 90% RH (no condensation)
Power Requirement
US standard
5 Volt DC Power Adapter (Included)
5V DC@3A
Accessories
5 Volt DC Power Adapter (Included)
5V DC@3A
User Manual
English Version
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this DirectConnect®unit, please check the packaging and
make sure the following items are contained in the shipping carton:
1 x 4 HDMI™Distribution Amplifier (splitter) - Main unit.
5VDC 3A Power Supply
User's Manual
Note:
Please retain the original packing material in case you need to return the unit. If you
find any items missing, contact DirectConnect®immediately (800.531.3224). Please
have the model number, serial number, and invoice available for reference when you call.
4.0 PANEL DESCRIPTIONS
1 -HDMI™ Input
2 - HDMI™ Output –1 - 4
3 –5VDC Power Supply
5.0 CONNECT AND OPERATE
1) Connect the HDMI™ input port of this distribution amplifier (splitter) to the HDMI™
source.
(Input cables are optional and an optional extender may be needed for runs greater than 6 feet)
*Please refer to connection diagram section.
2) Connect the HDMI™output ports (2) of this distribution amplifier (splitter) to each of
the HDTV devices and/or displays.
3) Insert the DC side of 5v power supply into the HDMI switch and then connect the
AC side of the power supply into the wall outlet.
4) Turn on the power
Attention: Insert/Remove cables gently & avoid twisting/kinking your HDMI™ cables.
5.1 CONNECTION DIAGRAM
4 / 8
5 / 8

6.0 TROUBLESHOOTING
If this DirectConnect®product does not appear to be functioning, please make
certain that the source and the destination device connected to the unit are
functioning correctly. If other problems exist please check the conditions below carefully.
Without LED light
Is the power adapter connected? If a power strip is
used, is the ON/OFF switch in ―ON‖ position?
No display
Is the display unit turning on? Are cables
connected properly? Please refer to the
connection diagram.
Without sound
1) Check the display volume
2) Turn off the HDMI™source (DVD, PS3 etc.) and
power on again. If it‘s still not ok, then
3) Turn off the switch box and turn on again
4) Repeat step 2 again if still not working
Note: Some HDMI™devices without ATC certified and
DPL ratings may have such problems.
Poor picture quality
(snow, sparkles, banding, etc)
Examine the HDMI™ cable and replace with
new cables if possible. To ensure that the
Distribution Amplifier is operating correctly, test
with the shortest HDMI™ cable possible.
Longer or inferior/ damaged cables will
compromise image quality.
DO NOT open the HDMI™ Distribution Amplifier box. There are no user repairable
parts inside. Once opened, DirectConnect®is not responsible. For other problems,
please contact DirectConnect®at 800.531.3224. http://www.directconnecthome.com
6.1 NON-HDCP-COMPLIANT DEVICES
If a DVI device does not appear to work, make certain that the device is HDCP-
compliant. A non-HDCP-compliant DVI device will not work with a signal that has
HDCP encoding present.
Notice
DirectConnect®reserves the right to make changes in the hardware, packaging
and/or any accompanying documentation without prior written notice.
.
1.0 FEATURES
This DirectConnect®High Speed HDMI™ Distribution Amplifier has many features
that enable it to perform in a superior manner. Among those features you will find:
One HDMI™ input and simultaneously four identical HDMI™ outputs
Large distribution systems achieved by cascading this HDMI™distribution amplifier
Supports HDMI™, highest video resolution 1080P, and HDCP pass-through
Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth
HDMI™ output can achieve long distance transmission of HDMI™ 1080p
signal of up to 49.2 feet (15 meters).
Supports 12bit per channel (36bit all channel) deep color.
Supports uncompressed audio such as LPCM.
Supports compressed audio such as DTS Digital and Dolby Digital
(Including DTS-HD and Dolby True HD )
