djive Flowmate ARC User manual

BLADELESS FAN,
HUMIDIFIER&
AIR PURIFIER
English
Deutsch
Français
Español
Italiano
HUMIDIFIER
3IN1

CONTENTS
SAFETY INSTRUCTIONS 4
PRODUCT OVERVIEW 6
DISPLAY INTERFACE 7
REMOTE CONTROL 8
MAIN BODY FUNCTIONS 12
INSTRUCTIONS 
HUMIDIFIER UNIT 14
FILTER REPLACEMENT 15
MAINTENANCE 17
DAILY MAINTANANCE
HUMIDIFIER UNIT 19
WIFI CONNECTION 20
TECHNICAL SPECIFICATIONS 21

Dear Customer,
Your new Flowmate ARC Humidifier is about
to be used for the first time for refreshing
the air in your home.
Please take a moment to read this manual
to familiarise yourself with your new 3in1
Bladeless Tower Fan.
If you have any questions, please contact
our customer service.
Enjoy fresh clean air every day with your
new djive Flowmate.
Customer Care
Phone [phone]
[email protected]
www.djive.eu flowmate djive_home
Robovox Distributions GmbH |Hamburger Straße 11, D-45889 Gelsenkirchen
3

4
SAFETY INSTRUCTIONS \\\
WARNING
To avoid fire, electric shock or injury, you urgently need to meet the following
requirements. In addition, please follow the respective national and local electricity
regulations. Before using the Flowmate ARC Humidifier please read all instructions
and cautionary markings in this manual carefully. When using an electrical appliance,
basic precautions should always be considered, including the following:
1. The device can be used by children aged from 8 years and above and persons
with reduced physical, sensory or reasoning capabilities, or lack of experience
and knowledge, only if they have been given supervision or instruction by a
responsible person concerning use of the appliance in a safe way and understand
the hazards involved. Cleaning and user maintenance should not be performed
by children without supervision.
2. Please use a separate power outlet according to the required voltage for the fan.
Do not use a multi-purpose socket for simultaneous use with other electrical
devices.
3. Should Flowmate ARC Humidifier does not work properly due to damaged power
cord, turn off the power and ask a qualified person for repair or refer to your djive
service contact primarily.
4. Do not move Flowmate ARC Humidifier when applying the plug in or out of power
outlet.
5. Do not pull out the plug by the cable only. Pull out the plug by grip on appropriated
spot.
6. Do not operate Flowmate ARC Humidifier with damaged cord or connector.
Please contact djive customer service in order to replace or repair your device.
7. Do not stretch or violate the cord. Keep cord also away from any heat sources.
8. Do not place power cord covered by carpets or similar. Make sure to prevent cord
from tripping over.

5
English
9. Always turn off Flowmate ARC Humidifier before pulling the plug out of power
outlet. In case of long term non-usage, please plug out the device.
10. Do not place any objects covering the air inlet or outlet. Make sure the ventilation
mouths are free of dust, lint, hair or other obstacles that could impair the air flow.
11. Flowmate ARC Humidifier should be placed on horizontal, dry surface and should
also be kept away from heat sources, corrosive air and moisture. In order to grant
best function results do not place any obstacles 150 mm around the device.
12. Do not use Flowmate ARC Humidifier outdoors or on wet surfaces.
13. Do not immerse the device, power cord, or plug in water or other liquids to avoid
danger of shock or damage. The use of an extension cord is not recommended
unless it has been authorized by a qualified person.
14. The device contains an UV-C emitter. Unintended use of the appliance or damage
to the housing may result in the escape of dangerous UV-C radiation. UV-C radia-
tion may harm to the eyes and skin. WARNING – This appliance contains a UV-C
emitter. Do not stare at the light source.
15. Do not use any cleaning agents or lubricants for cleaning Flowmate ARC Humidifier
and always pull out the power plug before cleaning, transporting and servicing the
device.
16. Please only fill in water into the appropriate water tank of humidifier unit.
17. Do not turn or knock over the device.
18. Pacemakers and defibrillators may be affected by strong magnetic fields as well
as magnetic cards. If user or someone in household has a pacemaker or defibrillator,
avoid having the remote control near to the appliance.

6
Power Button
(Humidifier)
Air inlet
Humidifier Unit
(detachable)
Display
Air outlet
Base
Power connection
Power Button
(Main Body)
Ventilation ARC
(tiltable)
PRODUCT OVERVIEW \\\
FRONT VIEW

7
English
Mode
WIFI
P2.5 date
Wind speed Humidification
level
PM2.5 icon
UV
Timer
function icon
Measured humidification rate –
AUTO mode only
DISPLAY INTERFACE \\\
LED INDICATORS

8
AUTO
REMOTE CONTROL \\\
ON / OFF
Oscillation Timer function
AUTO Mode
(Air Purifier)
UV sterilization
Wind Speed +
Humidifier unit
• On / Off
• 3 levels
• Auto mode
Wind Speed -
3 Modes
• Natural
• Boost
• Sleep
REMOTE CONTROL

9
English
The device can be switched on and off by touching the „ON/OFF“ button.
This button allows to switch between 3 different wind presets:
NATURAL
Simulates a natural wind flow by adjusting the wind speed randomly.
BOOST
Highest possible wind speed running at a maximum of 7300RPM.
SLEEP
Lowest possible wind speed to reduce operational noises to a minimum
Touch the oscillation button for 1 sec to turn on oscillation function. The ARC
Humidifier can swing left and right up to 80°. Touch the button again for 1 sec
to turn off oscillation.
UV UV-Sterilization is activated by default. You can easily turn it off by touching the
UV button on the remote control. Please note: UV-Sterilization is also deactivated
automatically after 1 hour of running.
You can set the timer function from 1 hour up to 8 hours.
Please note: Whether timer is set or not you can use all functions regularly.
All timer function adjustments are turned to default once the ARC Humidifier
is turned off.
AUTO This button activates the AUTO Air Purifier mode.
Please note: For Humidifier unit AUTO mode refer to the humidifier unit functions.

000 - 035 µg Level 2
036 - 070 µg Level 4
071 - 120 µg Level 6
120 - 199 µg Level 9
10
AUTO mode: When atmospheric load (PM2.5) is detected the wind speed level is
adjusting automatically as follows:
Press the „+“ key to increase wind speed and press the „-“ key to decrease wind
speed.
This button controls several functions of the humidifier unit.
• Turning the humidifier On / Off
• Changing of humidifying level
• 1low
• 2medium
• 3high
• Activating the AUTO Humidifier mode (do not confuse with AUTO purifier mode)
• The Humidifier will automatically adjust its humidification level if it
recognizes a value higher than 55%.
REMOTE CONTROL
Please remove the insulation sheet before using the remote control.
Battery replacement method as shown in the picture. Please note the battery direction.

AUTO
11
English
Do not recharge the battery. The battery is NOT a toy, keep away from Children.
In case of battery swallowed accidently, see a doctor immediately Point remote
control directly to Flowmate ARC Humidifier in order to grant best connection results.
POTENTIAL ISSUES
It is possible that the ARC Humidifier may respond to the remote control of other
devices.
If you use the ARC Humidifier remote control it is possible that other devices may
respond to it.
This is due to the overlapping frequencies of the remote control. It is not a malfunction or
other technical issue. To avoid misuse, keep the remote control away from other electrical
devices during operation.
WARNING
When using the remote control to switch off the device be aware it is not turned off
properly.
If the device is not used for a longer period of time, make sure to disconnect the main
plug from the power outlet.

12
MAIN BODY FUNCTIONS \\\
TILTABLE VENTILATION ARC
Turn the device off. Please fix the main body in place
with one hand and adjust the ventilation arc with
the other hand. It is tiltable by 15 degrees front- and
backwards.
ON / OFF OPERATION
ON Touch the power button on main body,
the buzzer will beep once to start operation.
OFF Touch and hold the power button for 2 seconds,
the buzzer will beep two times, device will stop
operation.
Please note: Flowmate ARC Humidifier is always set
to standby unless it is plugged out from power outlet.

13
English
AIR VOLUME SHIFT
When main body is operating:
Press the power button on main body in order to switch air volume from level 1 to 9.
USE MAIN BODY WITHOUT HUMIDIFIER UNIT
The device is also operational without the humidifier unit. Rotate the humidifier unit
counterclockwise to release it and lift it carefully from the main body. Put the additional
cover on the inner workings.
WARNING
Do not operate the ARC Humidifier without the humidifier unit, or the additional cover
which protect the inner workings.

14
INSTRUCTIONS 
HUMIDIFIER UNIT \\\
In order to turn the ARC Humidifier on touch the power button. By touching the
button one time, level 1 is chosen. LED indicator will show one LED shining there-
fore. Touch twice to activate level 2 or 3 times to activate level 3. Another push
on the button will activate AUTO mode of the humidifier unit.
PLEASE NOTE
AUTO mode is indicated by the same LED as level 2. Pushing the button 5 times
will deactivate humidifier unit. (1-2-3-AUTO-OFF)
Water shortage indicator: Red LED will show water shortage. Please fill the
humidifier unit with water according to your premises from 0,2l up to 1,2l.
PLEASE NOTE
Do not fill in water above the maximum water level indicator.
This icon indicates the humidifier unit is not applied properly.

15
English
FILTER REPLACEMENT \\\
The Flowmate ARC Humidifier is equipped with a HEPA 14 air cleaning filter.
Before using the device, install the filter as explained below in order to purify the air.
After 720 hours of operation, the display will show an alarm with a beep as feedback
in addition. Press and hold the power button (either on the main body or on the remote
control) for 5 seconds to reset the filter duration counter.

16
3. Unpack the new filter and attach it
to the cover (snaps in, no screwing)
4. Finally put the cover with the
attached filter back in place until
it magnetically snaps to the main
body.
NOTE
The smooth side of the filter cover
faces forward.
1. Lift the cover with the attached
filter carefully. The cover attaches
magnetically to the main body.
2. Remove the old filter carefully from
the cover with minimal effort.
HOW TO INSTALL OR REPLACE THE HEPA 14 AIR CLEANING FILTER

17
English
MAINTENANCE \\\
POWER SUPPLY
Plug out Flowmate ARC Humidifier from power outle before maintenance.
HOUSING
Gently wipe the device with a soft, dry cloth.
If the surface of the device is dirty, dilute it with a mild detergent.

18
AIR INLET & AIR OUTLET
Use a soft brush or vacuum cleaner to remove dust from air inlet and air outlet.
Please note: If dust is not removed properly, the device functions maybe affected.
REMOTE CONTROL
Gently wipe the surface of the remote control with a soft, dry cloth. For long time
non-usage, please remove the button battery in the remote control.
POWER PLUG
Please clean the power plug with a soft, dry cloth.
SAFEKEEPING
After the device has been cleaned, it can be stored in a plastic bag. Keep away from
vibrations and electrical devices with cooling/heating function. Do not expose device
to direct sunlight, hot or humid places.
Keep away from children. Filter is absorbing any type of liquid, therefore do not use
water to clean filter directly.

19
English
DAILY MAINTANANCE 
HUMIDIFIER UNIT \\\
It is mandatory to clean the humidifier unit regularly to ensure that possible resides of
loaded water do not negatively affect the performance of the device.
Ignoring the warning can result in malfunctioning or permanent damage.
If you do not pay attention Calcium and Magnesium deposits (among other issues)
erupt together with the mist from the humidifier unit. After drying it will leave a layer
of residues on the outer surface of the device.
ATTENTION
• It is recommended to clean the water tank once a week if you are regularly using
the device.
• Do not leave water in the tank when the ARC humidifier is turned off.
• Before you stock the device make sure all parts are clean and dry.
CLEANING THE WATER TANK
• Use a small amount of easy cleaning agent for the water tank and pour 40°C
warm water over it.
• Remove the water and clean the tank with a small brush.

20
WIFI CONNECTION \\\
Make sure device is plugged in into power outlet.
Hold the power button for 5 seconds, WIFI icon on LCD display will flash when
connected. The WIFI icon on LCD display will be displayed permantly once the
connection is successful.
