DMT Controller Pixelstrip MKII User manual

Controller Pixelstrip MKII V4
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 42273
MANUAL
ENGLISH

Ordercode: 42273
Controller Pixelstrip MKII
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions.........................................................................................................................................................2
Operating Determinations..........................................................................................................................................4
Rigging............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Frontside..........................................................................................................................................................................6
Backside .........................................................................................................................................................................7
Installation...........................................................................................................................................................................7
Set Up and Operation.......................................................................................................................................................7
Control Modes...............................................................................................................................................................8
One Controller (Auto Mode)...................................................................................................................................8
Multiple Controllers (Master/Slave control)..........................................................................................................8
Multiple Controllers (DMX Control).........................................................................................................................9
Multiple Controllers (ArtNet/KlingNet Control)...................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................13
1. Auto Mode............................................................................................................................................................14
2. DMX Address ........................................................................................................................................................14
3. Software Information ..........................................................................................................................................14
4. Strip length/quantity settings.............................................................................................................................15
5. Network Settings..................................................................................................................................................15
6. Master/Slave Mode.............................................................................................................................................15
DMX Channels.............................................................................................................................................................16
8 channels.................................................................................................................................................................16
480 channels.............................................................................................................................................................17
Connecting to a Network ..............................................................................................................................................18
KlingNet settings..........................................................................................................................................................18
ArtNet settings .............................................................................................................................................................18
ArtNet Setup Example ....................................................................................................................................................19
How to make a data cable......................................................................................................................................20
Software for controlling .............................................................................................................................................20
Maintenance....................................................................................................................................................................21
Replacing the Fuse.....................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................21
No Light.........................................................................................................................................................................21
No Response to DMX..................................................................................................................................................22
Product Specifications....................................................................................................................................................23
Dimensions........................................................................................................................................................................24
1

Ordercode: 42273
Controller Pixelstrip MKII
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
•DMT Controller Pixelstrip MKII
•Pro Power power cable (1,5 m)
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
2

Ordercode: 42273
Controller Pixelstrip MKII
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always hold the fixture by the transport handles.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your DMT device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your DMT dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•The user is responsible for correct positioning and operating of the Controller. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
3

Ordercode: 42273
Controller Pixelstrip MKII
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Improper installation can cause serious injuries and/or damage of property!
4

Ordercode: 42273
Controller Pixelstrip MKII
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.
5

Ordercode: 42273
Controller Pixelstrip MKII
Description of the device
Features
The Controller Pixelstrip MKII is a LED controller. In combination with the PixelStrip P25 MKII (42272), you can
create impressive shows. The controller supports the most popular protocols, such as: DMX, ArtNet and
KlingNet.
•Power Supply: 100-240 VAC, 60/50Hz
•Power Consumption: 400W (full output)
•Control Protocol: DMX-512, ArtNet, KlingNet
•Built-in programs: 30 programs
•DMX channels: 8, 480 channels
•Maximum cable length: 20 m
•Connectors: Blue/White power connector, 3-pin XLR IN/OUT, RJ45 IN/OUT
•Cooling: Convection
•Dimmer: 0-100%
•Strobe: 0-25Hz
•Housing: Die-cast aluminum
•Color: Black
•IP rating: IP20
•Fuse: F3AL/250V
•Dimensions: 290 x 205 x 85 mm (LxWxH)
•Weight: 3,7 kg
Necessary accessories:
42272 – 4-16 x DMT PixelStrip P25 MKII
At least 4 DMT PixelStrips P25 MKII are REQUIRED for the Controller Pixelstrip MKII to work.
Frontside
Fig. 01
01) LCD display + menu buttons
02) Blue/White power connector 100-240V IN
03) Blue/White power connector 100-240V OUT
04) Power switch ON/OFF
05) Fuse F3AL/250V
06) 3-pin DMX signal connector IN
07) RJ45 ArtNet/Klingnet signal connector IN
08) 3-pin DMX signal connector OUT
6

Ordercode: 42273
Controller Pixelstrip MKII
Backside
Fig. 02
09) 1-4 RJ45 PixelStrip P25 MKII OUT
Installation
Remove all packing materials from the Controller PixelStrip MKII. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
7

Ordercode: 42273
Controller Pixelstrip MKII
Control Modes
There are 3 modes:
•Auto Mode
•Master/Slave
•DMX-512 (8CH, 480CH)/ArtNet/KlingNet
One Controller (Auto Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Controller is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 14 for more information about Auto Mode.
Multiple Controllers (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Controllers.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
04) Connect the first PixelStrip’s RJ45 "out" socket with the second PixelStrip’s RJ45 "in" socket, using a
CAT-5/CAT-6 cable. Repeat this process to link the second, third and fourth PixelStrip.
05) You can use the same functions on the master device as described on page 14 (Auto Mode).
This means that you can set your desired operation mode on the master device and all slave
devices will react the same as the master device.
Multiple Controllers (Master/Slave control)
Fig. 03
8

Ordercode: 42273
Controller Pixelstrip MKII
Multiple Controllers (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Controllers and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
05) Connect the first PixelStrip’s RJ45 "out" socket with the second PixelStrip’s RJ45 "in" socket, using a
CAT-5/CAT-6 cable. Repeat this process to link the second, third and fourth PixelStrip.
06) Supply electric power: Plug electric mains power cords into each unit's Blue/White socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Controllers DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power
9

Ordercode: 42273
Controller Pixelstrip MKII
Multiple Controllers (ArtNet/KlingNet Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a CAT-5/CAT-6 cable to connect the Controller, the PixelStrips and other KlingNet devices.
04) Link the units as shown in fig. 05. Connect the first Controller's RJ45 "out" socket with the second unit's
"in" socket, using a CAT-5/CAT-6 signal cable. Repeat this process to link the second, third, and
fourth units.
05) Connect the first PixelStrip’s RJ45 "out" socket with the second PixelStrip’s RJ45 "in" socket. Repeat this
process to link the second, third and fourth PixelStrip on each Controller.
06) Supply electric power: Plug electric mains power cords into each unit's Blue/White socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Controllers ArtNet/KlingNet Set Up
Fig. 05
Note : Link all cables before connecting electric power
10

Ordercode: 42273
Controller Pixelstrip MKII
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
DAP Audio PC Interface Cables
•CAT-5 cable 7,6 mm Matte blue PVC. Ordercode FL55150 (1,5 m), FL553 (3 m), FL556 (6 m),
FL5510 (10 m), FL5515 (15 m), FL5520 (20 m).
•CAT-6 cable (recommended for best data transfer). Ordercode FL563 (3 m), FL566 (6 m),
FL5610 (10 m), FL5615 (15 m), FL5640 (40 m).
11

Ordercode: 42273
Controller Pixelstrip MKII
The Controller Pixelstrip MKII can be operated with a light controller in control mode or without the
controller in stand-alone mode.
Control Panel
A) LCD display
B) MENU button
C) ENTER button
D) UP button
E) DOWN button
Fig. 06
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Controller will respond to the controller.
Please note, when you use the controller, the unit has 8channels.
When using multiple Controllers, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Controller should be 1(001); the DMX address of the second
Controller should be 1+8=9 (009); the DMX address of the third Controller should be 9+8=17 (017), etc.
Please, be sure that you do not have any overlapping channels in order to control each Controller
correctly. If two or more Controllers are addressed similarly, they will work similarly.
Controlling:
After having addressed all Controller fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Controller will automatically detect whether DMX 512 data is received or
not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Controller Pixelstrip MKII.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 20 seconds
When no button is pressed for 20 seconds, the display will turn off.
To light up the display, you have to press the MENU, ENTER, UP or DOWN button.
Once you have pressed the button, the display will light up.
12

Ordercode: 42273
Controller Pixelstrip MKII
Menu Overview
Main Menu Options
Auto Mode
DMX-512 Mode
Software information
Strip length/quantity settings
Network settings
Master/Slave Mode
13

Ordercode: 42273
Controller Pixelstrip MKII
1. Auto Mode
With this menu, you can set the built-in programs.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 2 options:
Program speed
Program choice
04) When the display shows , press the ENTER button to open the menu.
05) Press the UP/DOWN buttons to increase/decrease the program speed. The adjustment range is
between , from slow to fast.
06) Press the ENTER button to save changes.
07) When the display shows , press the ENTER button to open the menu.
08) Press the UP/DOWN buttons to toggle between the available programs:
. You can choose between 29
programs and Mix (all the built-in programs will be displayed in a sequence).
09) Press the ENTER button to save changes.
2. DMX Address
With this menu, you can set the desired DMX address.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose the desired DMX address. The adjustment range is between
.
04) Press the ENTER button to save changes.
3. Software Information
With this menu, you can check the currently installed software version.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) The display shows the current software version: .
14

Ordercode: 42273
Controller Pixelstrip MKII
4. Strip length/quantity settings
With this menu, you can set the strip length. This, in turn, will determine the number of PixelStrips which you
are allowed to connect per output.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 4 options:
1 meter. You can connect 4 PixelStrips to output # 1.
2 meters. You can connect 8 PixelStrips to outputs # 1 and 2 (4 per output).
3 meters. You can connect 12 PixelStrips to outputs # 1, 2 and 3 (4 per output).
4 meters. You can connect 16 PixelStrips to outputs # 1, 2, 3 and 4 (4 per output).
04) Press the ENTER button to confirm your choice.
Please note that the maximum cable length per output is 20 meters. Take this fact into
consideration while cabling your setup.
5. Network Settings
With this menu, you can adjust the device’s properties, such as the IP address, subnet mask and the
universes.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 3 options:
IP address
Subnet mask
Universe
04) Once you have chosen one of the options listed above, press the ENTER button to proceed to
edition mode.
05) Press the UP/DOWN buttons to choose the piece of the IP address/Subnet mask/Universe which
needs to be adjusted and which is indicated by the [bracket.
06) Press the ENTER button to confirm your choice.
07) Press the UP/DOWN buttons to adjust the desired seting.
08) Press the ENTER button to save changes.
6. Master/Slave Mode
With this menu, you can set the device as a slave.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose between “Yes” or “No”.
04) Press the ENTER button to confirm your choice.
15

Ordercode: 42273
Controller Pixelstrip MKII
DMX Channels
8 channels
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Strobe
0-255
Strobe frequency, from low to high frequency
Channel 3 – Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 4 – Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 5 – Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 6 – Built-in programs 1-15 CH1 and CH2 must be set to 0
0-15
Not functional
16-31
Program 1
32-47
Program 2
48-63
Program 3
64-79
Program 4
80-95
Program 5
96-111
Program 6
112-127
Program 7
128-143
Program 8
144-159
Program 9
160-175
Program 10
176-191
Program 11
192-207
Program 12
208-223
Program 13
224-239
Program 14
240-255
Program 15
Channel 7 – Built-in programs 16-30 CH1 and CH2 must be set to 0
0-15
Not functional
16-31
Program 16
32-47
Program 17
48-63
Program 18
64-79
Program 19
80-95
Program 20
96-111
Program 21
112-127
Program 22
128-143
Program 23
144-159
Program 24
160-175
Program 25
176-191
Program 26
192-207
Program 27
208-223
Program 28
224-239
Program 29
240-255
Program Mix
Channel 8 – Program speed
0-255
Speed adjustment, from slow to fast
16

Ordercode: 42273
Controller Pixelstrip MKII
480 channels
Channel 1 – Red LED 1, Pixelstrip # 1
0-255
Gradual adjustment Red, from 0-100%
Channel 2 – Green LED 1, Pixelstrip # 1
0-255
Gradual adjustment Green, from 0-100%
Channel 3 – Blue LED 1, Pixelstrip # 1
0-255
Gradual adjustment Blue, from 0-100%
Channel 4 – Red LED 2, Pixelstrip # 1
0-255
Gradual adjustment Red, from 0-100%
Channel 5 – Green LED 2, Pixelstrip # 1
0-255
Gradual adjustment Green, from 0-100%
Channel 6 – Blue LED 2, Pixelstrip # 1
0-255
Gradual adjustment Blue, from 0-100%
Channel 7 – Red LED 3, Pixelstrip # 1
0-255
Gradual adjustment Red, from 0-100%
Channel 8 – Green LED 3, Pixelstrip # 1
0-255
Gradual adjustment Green, from 0-100%
Channel 9 – Blue LED 3, Pixelstrip # 1
0-255
Gradual adjustment Blue, from 0-100%
•
•
•
•
•
•
•
•
•
Channel 478 – Red LED 40, Pixelstrip # 4
0-255
Gradual adjustment Red, from 0-100%
Channel 479 – Green LED 40, Pixelstrip # 4
0-255
Gradual adjustment Green, from 0-100%
Channel 480 – Blue LED 40, Pixelstrip # 4
0-255
Gradual adjustment Blue, from 0-100%
17

Ordercode: 42273
Controller Pixelstrip MKII
Connecting to a Network
KlingNet settings
01) Install any KlingNet-based software on your PC (Windows or Mac), for example 50180 – Arkaos LED
Master.
02) Connect the PixelStrips P25 MKII to the Controller.
03) Connect the power supply to the Controller.
04) Make sure that your PC has a fixed IP Address. The Controller requires no further network setting
adjustments.
05) Connect the Controller with a CAT-5/CAT-6 cable (see page 10) to your computer.
Once you have connected the devices, they will automatically be recognized by the software.
06) Map the devices, using the “drag-and-drop” method, by placing the fixtures in “on-screen”
interface in the right position. It only requires a few minutes and, once it is done, the system is
completely set up.
07) When creating large setups, it is recommended to use a 16-bit, high speed ethernet switch to
distribute the KlingNet data signal.
ArtNet settings
01) Install any ArtNet-based software on your PC (Windows or Mac).
02) Connect the PixelStrips P25 MKII to the Controller.
03) Connect the power supply to the Controller.
04) Connect the device’s Ethernet connector to your software/light controller’s Ethernet connector,
using a CAT-5/CAT-6 cable.
05) Set the IP address of your software/light controller to 2.x.x.x or 10.x.x.x, depending on the ArtNet
settings.
06) Set the subnet mask to 255.0.0.0. on both – the Controller and your software/light controller. Make
sure that all the fixtures in the network have a unique IP address.
07) If you want to connect more than one fixture, follow the example below.
Length
Strips
Channels
Universe
DMX
1 m
4
480
1
001-480
2 m
8
480
1, 2
001-480
3 m
12
480
1, 2, 3
001-480
4 m
16
480
1, 2, 3, 4
001-480
Note: While patching multiple universes, the output will not be visible until you start patching your final
universe. It is related to the way the Controller was designed.
18

Ordercode: 42273
Controller Pixelstrip MKII
ArtNet Setup Example
Fig. 07
