Thank you for selecting the "docomo STYLE series L-02B".
Read this manual before use to correctly operate your L-02B.
Operation Description of L-02B
Operations of L-02B are described in this manual as well as "Guide" (installed in this FOMA terminal, Japanese
only) and "Instruction Manual (Detailed version, Japanese only)" (in PDF format).
b "Instruction Manual" (This Manual): Describes screen displays and operating procedures of basic functions.
b "Guide" (installed in this FOMA terminal, Japanese only): Describes the overview or operating procedures of
frequently used functions.
From L-02B, press Y(for over 1 second).
b "Instruction Manual (Detailed version, Japanese only)" (in PDF format): Describes detailed information and
operating procedures of all functions.
From a PC, download it from the following DOCOMO website.
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html
* The URL and contents of the manuals are subject to change without prior notice.
Accessories
L-02B FOMA terminal
(With Warranty and Back Cover L16)
Battery Pack L06 Instruction Manual (Japanese version) CD-ROM for L-02B
取扱説明書
Options compatible with this FOMA terminal → P75
• Note that "L-02B" is referred to as "FOMA terminal" in this manual.
• It is prohibited to copy all or part of this manual without permission.
• The screens or illustrations used in this manual are examples. The actual screens and illustrations may differ.
• This manual describes operations mainly using the default settings ("L02B_red" in Kisekae Tool). If settings are
changed, screen displays or operations may differ from those described in this manual.

Introduction
P2
FOMA Terminal What You Can Do with L-02B Part Names and Functions Precautions
Handling Precautions
Basic Operation
P18
Before Using Screen Explanation Character Entry Sound/Screen Setting
Lock/Security
Connect
P36 Call Telephone Mail Phonebook
Search
P48 i-mode/Full Browser i-Channel
Enjoy
P52 Camera 1Seg Music i-αppli i-motion
More Convenient
P60 Osaifu-Keitai Convenient Tools Data Management
Others
P66 Support Appendix Index
Contents
1

2
Introduction
• Because the FOMA terminal uses radio waves, it may
not function in locations where radio waves cannot
reach, such as in tunnels, underground, or in buildings;
outside the building where radio waves are weak or out
of FOMA service area. Even when you are in an upper
floor of a tall building and nothing blocks your view
outside, your FOMA terminal may not be able to receive
or transmit signals. Also, even when radio waves are
strong with three antenna bars displayed, and you are
not moving, communication may still be interrupted.
• Be considerate of other people around you in public or
where it is especially crowded or quiet.
• Because your FOMA terminal uses radio waves to
communicate, there is a possibility that calls may be
intercepted by third parties. The W-CDMA and GSM/
GPRS systems automatically encode signals for all
calls so even if third parties should intercept calls with
the receiver, they will hear only noise.
• The FOMA terminal sends and receives voice
communication as encoded digital data. When you are
operating the FOMA terminal while moving, sometimes
you may encounter weaker radio waves and the
transmitted digital data may not be correctly decoded
resulting in sound distortions.
• It is recommended that you save important data on a
microSD card. If you use a PC, use DOCOMO keitai
datalink to send and save data such as Phonebook
entries, mail messages, Schedule events, etc. to the
PC.
• When you use SSL for a secure connection, you
agree that you are responsible for any actions you
take. DOCOMO and the certifiers listed below do
not guarantee the safety of SSL for any activities of
customers while using SSL, and are not liable for any
damages incurred through using SSL.
Certifiers: VeriSign Japan K.K.,
Cybertrust Japan Co., Ltd.,
GlobalSign K.K.,
RSA Security Japan Ltd.,
SECOM Trust Systems Co., Ltd.
• The FOMA terminal supports FOMA Plus-Area and
FOMA HIGH-SPEED Area.
• The FOMA terminal can be used only via the FOMA
network provided by DOCOMO and DOCOMO's
roaming area.
• It is recommended that you make a backup of user-
defined data (Phonebook entries, Schedule events,
text memos, Record messages, voice memos, or
moving picture memos) saved in the FOMA terminal
by keeping the separate record or note of those data,
etc. and storing them at a separate location. DOCOMO
is not responsible for lost data due to failure, repair, or
replacement of the model of your FOMA terminal.
FOMA Terminal

3
Introduction
Guide (Japanese only) → P21
Guide pre-installed in the FOMA terminal allows you
to look for operating instructions of a desired
function. When you cannot refer to this manual, you
can search functions with Guide quickly.
Stand-by display XY(for over 1 second)
i-Channel (Japanese only) → P51
You can receive graphic information such as news or
weather forecasts.
Also, you can obtain rich content created with Flash
by selecting your favorite channels from the Channel
list.
* This service is a fee-based service that requires
subscription.
International roaming → P41
Your FOMA terminal, phone number, and mail
address that are used in Japan are available
overseas (supporting 3G and GSM areas).
Full browser → P49
You can browse web pages incompatible with i-mode
on the FOMA terminal in the same way as on a PC.
Camera functions → P52
You can capture still images (with auto focus) and
moving pictures using the Outer camera with approx.
3.1 Mega effective pixels (approx. 3.1 Mega recorded
pixels) and Inner camera with approx. 300 Kilo
effective pixels (approx. 300 Kilo recorded pixels).
1Seg → P54
You can enjoy 1Seg (digital terrestrial broadcasting
for mobile devices). Subtitles and data broadcasting
are available.
Osaifu-Keitai→P60
You can download i- α ppli that supports Osaifu-Keitai to
deposit electronic money to the IC card on the FOMA
terminal, check your balance or view usage history
using communication. DOCOMO credit service "DCMX"
application is preinstalled. "iC transfer service" is also
available, which allows transfer of data on the IC card
when you replace your FOMA terminal.
What You Can Do with L-02B

4
Introduction
Part Names and Functions
b
d
f
g
h
i
j
a
c
k
e
n
s
t
u
v
w
x
y
A
z
B
C
D
q
o
l
m
p
r
* 1Seg antenna is inside the FOMA terminal, and whole part of the FOMA terminal works as antenna.
●Front ●Front with FOMA terminal closed ●Rear
●Left side ●Right side

5
Introduction
a Infrared port
b Earpiece/Speaker
c Display
d MMenu key
Display the main menu.
e gMail key
Display the mail menu.
f AStart key
Make/receive a call.
g Dial keys
Enter a phone number or character.
h * Public mode (Drive mode)
key
i YMusic/Guide key
Display the music screen.
j NMultitask key
Display the task list.
k Charging terminals
l Inner camera
m Illumination sensor
n Multi Selector
o
Ii-mode/i-αppli key
Display the i-mode menu.
p GCamera key
Display the still image shooting
screen.
q QClear/i-Channel key
Return to the previous state or
to the Stand-by display.
r PPower/Exit key
End a call or exit a function.
s #Manner mode key
t TTV key
Display the 1Seg watching screen.
u Mouthpiece
v Illumination
w External connector terminal
x Outer camera
y Back cover
• Do not remove the sticker on the
back side of the Back cover. If
removing it, the IC card contents
may not be read or written.
z FOMA antenna
• The FOMA antenna is
inside the FOMA terminal.
To communicate in better
condition, avoid covering the
antenna part with your hands.
A mark
B Strap hole
C FEVolume key
Adjust the volume.
D microSD card slot
Using earphones
Connect optional earphones compatible with
the external connector terminal.
If you use the incompatible earphones,
connect the optional conversion plug
adapter to the earphones.
a
b
Earphone terminal
(Flat type)
Flat plug for the flat-plug
Earphone/Microphone
with Switch
Plug
Ex.: Connecting the Flat-plug Earphone/
Microphone with Switch (optional)

6
Introduction
Precautions (ALWAYS FOLLOW THESE PRECAUTIONS)
bBefore using your FOMA terminal, read these "Precautions"
carefully so that you can use it correctly. After reading these
precautions, keep this manual for later reference.
bBe sure to observe these precautions because they are
intended to protect you or others around you from causing
injury and to avoid damage to the property.
bThe symbols below indicate the levels of danger or damage
that may occur if the particular precaution is not observed and
the FOMA terminal is used improperly.
DANGER
This symbol indicates
that incorrect handling
may directly or
immediately cause death
or serious injury.
WARNING
This symbol indicates
that incorrect handling
poses a risk of causing
death or serious injury.
CAUTION
This symbol indicates
that incorrect handling
poses a risk of causing
injury or damage to the
product or property.
bThe following symbols indicate specific directions:
Don’t
Denotes things not to do (Prohibitions).
No
disassembly
Denotes not to disassemble.
No
wet hands
Denotes not to touch with wet hands.
No
liquids
Denotes not to use where it could get
wet or not to wet it.
Do
Denotes mandatory instructions
(matters that must be complied with).
Unplug
Denotes to unplug from the outlet.
b "Precautions" are explained in the following 6 sections:
General Precautions for FOMA Terminal, Battery Pack,
Adapter, and UIM ................................................................ P7
Precautions for FOMA Terminal........................................... P8
Precautions for Battery Pack............................................. P11
Precautions for Adapter .................................................... P12
Precautions for UIM........................................................... P14
Precautions on Using near Electronic Medical Equipment ... P14

7
Introduction
General Precautions for
FOMA Terminal, Battery
Pack, Adapter, and UIM
DANGER
Don’t
Do not use, store, or leave the
FOMA terminal and its
accessories in locations
subject to high temperatures,
such as near fire, in direct
sunlight, or inside a car under
the hot sun.
The devices could be deformed
or malfunction, or the battery pack
may leak, overheat, explode, or
ignite, resulting in the deterioration
of performance and shortening of
the life of devices. Also, part of the
case could get heated, causing
bare skin burns.
No
disassembly
Do not disassemble or
remodel the FOMA terminal
and its accessories. Do not
solder them.
Fire, injury, electric shock, or
malfunction may result. The
battery pack may leak, overheat,
explode, or catch fire.
No
liquids
Do not get the FOMA terminal
and its accessories wet.
If liquids such as water or pet
urine get onto them, overheating,
electric shock, fire, malfunction,
or injury, etc. may result. Pay
attention to the place of use and
the way of handling.
Do
Use only the battery packs
and adapters specified by NTT
DOCOMO.
Using the accessories other than
specified one may cause the
FOMA terminal, battery pack and
other devices to leak, overheat,
explode, ignite, or malfunction.
WARNING
Don’t
Do not put the battery pack,
FOMA terminal, adapter, or
UIM in heating appliances
such as microwaves or high
pressure containers.
The battery pack may leak,
overheat, explode, or ignite. Also,
the FOMA terminal or adapter may
overheat, smoke or ignite, or the
circuit boards may be damaged.
Don’t
Do not throw the FOMA
terminal and its accessories,
or subject them to severe
shocks.
The battery pack may leak,
overheat, explode, or ignite. Also,
the devices may malfunction or
catch fire.
Don’t
Keep conductive foreign
objects (metal, pencil lead,
etc.) away from the charging
terminals or external
connectors. Do not insert
such objects inside the FOMA
terminal.
Fire or malfunction may result from
a short-circuit.
Do
Make sure to turn the power
of a mobile phone off before
you go near flammable gas
such as a gas station. Do not
charge the FOMA terminal.
Catching fire may result.
Be sure to turn the power off
before you use Osaifu-Keitai in a
place such as a gas station. (If
the IC card lock is set, unlock the
IC card lock before turning the
power off.)

8
Introduction
Do
If you notice any strange
smells, overheating,
discoloration, or deformation
while using, charging, or
storing the FOMA terminal,
immediately take the
following actions:
1. Remove the power plug from the
outlet or cigarette lighter socket.
2. Turn the FOMA terminal power off.
3. Remove the battery pack from the
FOMA terminal.
If you continue to use the
FOMA terminal and its
accessories, overheating,
explosion, ignition, or leakage
of the battery pack may result.
CAUTION
Don’t
Do not place the FOMA
terminal and its accessories
in unstable places such as
wobbly tables or sloping
shelves.
The FOMA terminal or its
accessories may fall, resulting in
injury or malfunction.
Don’t
Do not store the FOMA
terminal and its accessories
in humid or dusty places, or
in high temperatures.
Malfunction may result.
Do
If children use the FOMA
terminal, a guardian should
explain the safety instructions
and correct operations. The
guardian should also make
sure that the instructions are
followed during use.
Injury may result.
Do
Keep out of the reach of
babies and infants.
Accidental swallowing or injury
may result.
Do
Pay extra attention when you
use the FOMA terminal for an
extended period of time while
it is connected to the adapter.
If you use i-αppli, make a long
videophone call, or watch
1Seg for a long time while
charging, the FOMA terminal,
battery pack, or adapter may
become hot.
Some users who continuously
or repeatedly touch a hot
FOMA terminal may develop
rashes, itching, or eczema
depending on their physical
health or existing medical
conditions, or a low-
temperature bare skin burn
may result.
Precautions for FOMA
Terminal
WARNING
Don’t
Do not directly point the
Infrared port at someone's
eyes during transmission.
Their eyes may be adversely
affected. Also, pointing it to other
infrared devices to transmit data
may interfere with the operation
of those devices.
Don’t
Do not put the FOMA terminal
in a place where it could be
impacted by an expanding
airbag, e.g. on the dashboard
of a car.
If the airbag expands, the FOMA
terminal may hit you or others,
resulting in an accident or injury
and the FOMA terminal may
malfunction or be damaged.

9
Introduction
Don’t
If you wear any imbedded
electronic medical devices, do
not place the FOMA terminal
in a chest pocket or inner
pocket.
If you use the FOMA terminal near
electronic medical devices, failure
of the electronic medical devices
may result.
Don’t
Do not get liquids such as
water or foreign objects such
as metal pieces or flammable
materials into the UIM or
microSD card slot of the
FOMA terminal.
Fire, electric shock, or malfunction
may result.
Don’t
Do not flash a light directed to
a driver of the vehicle.
It disturbs driving and may cause
an accident.
Do
Turn the FOMA terminal
power off in places where
use is prohibited such as in
airplanes or hospitals.
Electronic devices or electronic
medical devices may be
adversely affected. If the FOMA
terminal is set to be turned
on automatically, cancel the
setting before turning it off. For
use in medical facilities, follow
instructions of each medical
facility. You may be punished if
you take activity prohibited by law
such as use of the FOMA terminal
in airplanes.
Do
When using Hands-free,
make sure to keep the FOMA
terminal away from your ear.
When you use the headphone/
microphone connected to the
FOMA terminal to play a game
or music, adjust the volume.
The excessive sound volume may
result in hearing loss. Also, if you
cannot hear ambient sounds, an
accident may result.
Do
For those who suffer from
heart ailments, the vibrator or
ring tone volume should be
adjusted carefully.
Those functions may affect the
heart.
Do
In case of thunder while using
the FOMA terminal outdoors,
immediately turn the power off
and move to a safe place.
Lightning or electric shock may
result.
Do
Turn the FOMA terminal off in
places near high-precision
electronic devices or devices
using weak electronic signals.
The FOMA terminal may possibly
cause the electronic devices to
malfunction.
* Electronic devices that may be
affected:
Hearing aids, implanted
cardiac pacemakers and
implanted defibrillators, other
medical electronic devices, fire
alarms, automatic doors, and
other automatically controlled
devices.
If you are using an implanted
cardiac pacemaker and
implanted defibrillator,
or any other electronic
medical devices, consult the
manufacturer or retailer of the
device for advice regarding
possible effects from radio
waves.

10
Introduction
Do
If the display glass or camera
lens is broken, avoid touching
the broken glass or exposed
parts inside the FOMA
terminal.
The surface of the display is
covered with a protective film and
the camera lens is covered with
a plastic panel so that shattered
glass pieces do not scatter easily,
however, if you touch the broken
glass or exposed parts, injury
may result.
CAUTION
Don’t
Do not swing the FOMA
terminal by strap, etc.
It may hit you or others, resulting
in an accident such as injury,
malfunction, or damage.
Don’t
If you use "M-Toy", make
sure the safety of your
surroundings, hold the FOMA
terminal firmly, and do not
shake it more than necessary.
"M-Toy" is a game to play by tilting
or shaking the FOMA terminal.
Shaking the FOMA terminal too
much may hit others or object,
resulting in a serious accident or
malfunction.
Don’t
If you attach a strap made of
metal or similar material, be
careful not to hit others or
object by the strap when you
play "M-Toy".
Injury, malfunction, or damage
may result.
Don’t
If the display is broken and
the LCD liquid leaks, do not
put the liquid into your mouth,
swallow the liquid, or apply
the liquid to your skin.
If the LCD liquid gets
into your eyes or mouth,
immediately flush with clean
water and consult a doctor.
Also, if the liquid gets on your
skin or clothes, immediately
wipe it off with alcohol and
wash with soap and water.
Blindness or injury to your skin
may result.
Don’t
Keep your ear away from the
speaker when the ring tone is
sounding or melody is being
played on the FOMA terminal.
Hearing loss may result.
Don’t
The surface of the display
is covered with a protective
film that prevents shattered
plastic pieces from scattering
in case the display breaks by
being dropped or an external
impact. Do not forcibly
remove or damage the film.
If the film has been removed,
injury may result when the display
breaks.
Do
If you use the FOMA terminal
in a car, in-car electronic
devices may be affected,
depending on the type of a
car.
In this case, do not use the FOMA
terminal for safety's sake.

11
Introduction
Do
Itching, rash or eczema may
be caused depending on
your physical conditions
or predisposition. If an
abnormality occurs, stop
using the FOMA terminal
immediately and consult a
doctor.
Metals are used for the following parts:
Part Material Surface
treatment
Multi Selector
(Center part C)ABS resin Cr plating
Both sides of
hinge PC resin Sn plating
Strap hole Stainless
steel −
Charging terminal
Stainless
steel+BeCU
(Beryllium
copper)
Gold
plating
Do
Be careful not to get your
fingers or strap caught when
you close the FOMA terminal.
Injury or failure may result.
Do
Watch 1Seg in a well-lit place,
keeping a certain distance
from the screen.
Eyesight may be failing.
Precautions for
Battery Pack
bCheck the battery type by the label
attached to the battery pack.
Description Type
Li-ion00 Lithium-ion battery
DANGER
Don’t
Do not get any metal objects
such as wire come into
contact with the battery
terminal. Do not carry or store
the FOMA terminal together
with any metal objects such
as a necklace.
The leakage, overheating,
explosion, or ignition of the
battery pack may result.
Don’t
Do not put excessive force
when inserting the battery
pack into the FOMA terminal,
even if you have difficulty in
inserting it.
Also, check the direction
of the battery pack before
inserting.
The leakage, overheating,
explosion, or ignition of the
battery pack may result.
Don’t
Do not throw the battery pack
into fire.
The leakage, overheating,
explosion, or ignition of the
battery pack may result.
Don’t
Do not pierce the battery
pack with a nail, hit it with a
hammer, or step on it.
The leakage, overheating,
explosion, or ignition of the
battery pack may result.
Do
If the battery fluid gets into
your eyes, do not rub them.
Immediately flush with clean
water and consult a doctor.
Blindness may result.

12
Introduction
WARNING
Don’t
If an abnormality occurs to
the battery pack when it is
damaged or deformed by
the FOMA terminal being
dropped, stop using the
FOMA terminal immediately.
The leakage, overheating,
explosion, or ignition of the
battery pack, or malfunction of the
devices or fire may result.
Do
If charging is not completed
when the specified charging
time elapsed, stop charging.
The leakage, overheating,
explosion, or ignition of the
battery pack may result.
Do
If the battery leaks or emits
strange smell, immediately
stop using the FOMA terminal
and keep it away from fire.
The leaked battery fluid may
ignite, resulting in fire or burst.
Do
Make sure that your pets do
not bite the battery pack.
The leakage, overheating,
explosion, or ignition of the
battery pack, or malfunction of the
devices or fire may result.
CAUTION
Don’t
Do not dispose of exhausted
batteries with ordinary
household waste.
Ignition or environmental damage
may result. Cover the battery
terminals with a non-conductive
tape and take them to the
docomo Shop, etc. or dispose
of them in accordance with local
waste disposal regulations.
Don’t
Do not charge a wet battery
pack.
The battery pack may overheat,
explode or ignite.
Do
If battery fluid gets on your
skin or clothes, immediately
stop using and flush with
clean water.
Injury to your skin may result.
Precautions for
Adapter
WARNING
Don’t
Do not use a damaged
adapter cord or power cord.
Electric shock, overheating, or fire
may result.
Don’t
Do not use the AC adapter
and desktop holder in a place
with high humidity such as a
bath room.
Electric shock may result.
Don’t
The DC adapter is for
use only in a negative (-)
grounded vehicle. Do not use
it in a positive (+) grounded
vehicle.
Fire may result.
Don’t
If it starts to thunder, do not
touch the FOMA terminal or
adapter.
Lightning or electric shock may
result.

13
Introduction
Don’t
Do not short-circuit the
charging terminals when
the adapter is plugged into
an outlet or cigarette lighter
socket. Also, never touch
the charging terminals with
fingers or other bare skin.
Fire, malfunction, electric shock,
or injury may result.
Don’t
Place the charger or desktop
holder in a stable location
while charging. Also, do not
cover or wrap the charger or
desktop holder with cloth or
bedding.
The FOMA terminal may drop off,
or charger and desktop holder
may overheat, resulting in fire or
malfunction.
Don’t
Do not place heavy objects
on the adapter cord or power
cord.
Electric shock or fire may result.
No
wet hands
Do not touch the adapter cord
or outlet with wet hands.
Electric shock may result.
Do
Use the adapter at the
specified power source and
voltage.
Failing to do so may result in fire
or malfunction. When you use
the FOMA terminal overseas,
use an AC adapter appropriate
for the location.
AC adapter: 100V AC
DC adapter: 12/24V DC (for
negative grounded vehicles
only)
AC adapter available overseas:
100 to 240V AC (Connect only
with household AC outlet)
Do
If the fuse of the DC adapter
blows, replace it with the
specified fuse.
The use of an incorrect fuse may
cause fire or malfunction. See
each instruction manual for the
specified fuse.
Do
Keep the power plug dust-
free.
Fire may result.
Do
When plugging the AC
adapter into an outlet, plug it
in firmly, being careful not to
let it contact with any metal
objects such as metal strap.
Electric shock, a short-circuit, or
fire may result.
Do
When removing the adapter
from the outlet or cigarette
lighter socket, do not forcibly
pull the adapter cord or power
cord, instead hold the power
plug and pull it out.
If you pull the plug by the cord,
the cord may be damaged,
resulting in electric shock or fire.
Unplug
If you do not use the adapter
for a long period of time,
unplug the power plug from
the outlet.
Electric shock, fire, or malfunction
may result.
Unplug
If liquids such as water get
into the adapter, unplug the
power cord from the outlet
or cigarette lighter socket
immediately.
Electric shock, smoke, or fire
may result.
Unplug
Before cleaning, pull the plug
out of the outlet or cigarette
lighter socket.
Electric shock may result.

14
Introduction
Precautions for UIM
CAUTION
Do
Be careful not to touch the
edge of UIM (IC portion) when
removing it.
Your hands or fingers may be
injured.
Precautions on Using near
Electronic Medical Equipment
bThe following description meets
"Guideline on the Use of Radio-
communication Equipment such as
Cellular Telephones - Safeguards for
Electronic Medical Equipment" by
the Electromagnetic Compatibility
Conference Japan.
WARNING
Do
Comply with the following
instructions inside medical
facilities:
●Do not bring the FOMA
terminal in operating rooms,
intensive care units (ICU), or
coronary care units (CCU).
●Turn the FOMA terminal off
in hospital wards.
●Turn the FOMA terminal
off in hospital lobbies
and corridors if electronic
medical devices could be
nearby.
●If the medical facility has
specific zones where use
or possession of mobile
phones is prohibited, follow
those regulations.
●If the FOMA terminal is set
to be turned on
automatically, cancel the
setting before turning it off.
Do
Turn the FOMA terminal off in
crowded places such as on a
train where implanted cardiac
pacemaker or defibrillator
wearers could be nearby.
Operation of an implanted
cardiac pacemaker or implanted
defibrillator may be affected by
radio waves.
Do
If you use an implanted
cardiac pacemaker or
implanted defibrillator, use
or carry the FOMA terminal
22cm or more away from the
implanted cardiac pacemaker
or implanted defibrillator.
Operations of an implanted
cardiac pacemaker or implanted
defibrillator may be affected by
radio waves.
Do
Patients using electronic
medical equipment other
than implanted cardiac
pacemakers or implanted
defibrillators (outside medical
facilities for treatment at
home, etc.) should check the
influence of radio waves upon
the equipment by consulting
the manufacturer.
Operations of electronic
medical equipment may be
affected by radio waves.

15
Introduction
General notes
b Do not wet the equipment.
The FOMA terminal, battery pack,
adapter, and UIM are not waterproof.
Do not use them in places with high
humidity such as a bathroom or
where rain may get them wet. If you
are carrying them against your body,
moisture from sweat may corrode the
internal parts, causing malfunction.
Note that malfunction deemed to be
caused due to exposure to liquids
is not covered by the warranty, and
repair may be impossible. This may
be repaired at your expense even if
repairs are possible.
b Use a dry soft cloth (lens cleaning
cloth) to clean the equipment.
• In some models, the display of
the FOMA terminal has a special
coating in order to make the color
display clear. If you rub the display
strongly with a dry cloth, it may be
scratched. Take care of handling
the FOMA terminal and use a dry
soft cloth (lens cleaning cloth) to
clean the equipment. If the display
is left with water drop or stain
adhered, smear may be generated
or the coating may peel off.
• Do not use alcohol, thinner,
benzene, detergent or other
solvents for cleaning, otherwise
the printed images or text may
disappear or discoloration may
result.
b Occasionally clean the terminals
with a dry cotton swab.
If the terminals become dirty, the
contact may become loose and the
FOMA terminal power may be turned
off, or the terminal may not be fully
charged.
Be careful not to damage the
terminals when you clean them.
b Do not place the equipment near
air conditioner outlets.
Condensation may form due to
rapid changes in temperature, and
this may corrode internal parts and
cause malfunction.
b Do not place excessive force on the
FOMA terminal or the battery pack.
If the FOMA terminal is put under
heavy objects in a bag, or if it is
sat upon while in your pocket, the
display, internal circuit board, or
battery pack may be damaged
or malfunction. While external
devices are inserted to the external
connector terminals, the connector
may be damaged or malfunction.
b Carefully read each manual
attached to the FOMA terminal,
adapter, and desktop holder.
b Do not rub or scratch the display
with a metal object.
Doing so may cause damage or
malfunction.
Notes on the FOMA terminal
b Avoid using in extremely high or
low temperatures.
Use the FOMA terminal within a
temperature range of 5 ℃ to 35 ℃
and a humidity range of 45% to 85%.
b The FOMA terminal may affect
general phones, televisions, or
radios, etc. in use nearby. Use the
FOMA terminal as far away from
such equipment as possible.
b Keep a separate record of any
information stored on the FOMA
terminal and store the copies in a
safe location.
DOCOMO assumes no responsibility
for the loss of any of your data.
b Do not drop the FOMA terminal or
subject it to shocks.
Damage or malfunction may result.
Handling Precautions

16
Introduction
bDo not insert an external device
to the external connector terminal
(earphone/microphone terminal)
crookedly or do not pull it when it is
inserted.
Damage or malfunction may result.
bDo not close the FOMA terminal with
a strap caught inside.
Damage or malfunction may result.
bIt is normal for the FOMA terminal to
become warm during use or being
charged.You can continue to use it.
bDo not leave the camera in a place
exposed to direct sunlight.
Pixels may be discolored or burns may
result.
bUsually close the covers of the
external connector terminals and
microSD card slot.
Dust or moisture may seep in and
cause malfunction.
bDo not use the FOMA terminal with
the back cover removed.
The battery pack may fall out or
malfunction or damage may result.
bDo not attach extremely thick
stickers on the display or keypad.
Malfunction may result.
bWhile using a microSD card, do not
remove it or turn the FOMA terminal
power off.
Data loss or malfunction may result.
bDo not place magnetic media near
the FOMA terminal.
Data on magnetic media such as cash
cards, credit cards, telephone cards or
floppy disks may be lost.
bDo not place a magnetized item near
the FOMA terminal.
A strong magnetic field may cause
malfunction of the FOMA terminal.
Notes on the battery pack
bThe battery pack is a consumable.
Depending on the usage, a battery
pack may run out of its charge
extremely quickly even if it is fully
charged. Purchase a new battery pack
specified in this manual.
bCharge the battery pack in a place
with an ambient temperature of 5 ℃
to 35 ℃ .
bWhen you use the FOMA terminal
for the first time or when you have
not used for a long time, be sure to
charge the battery pack before use.
bThe actual usage time of the
battery pack depends on the usage
environment or the deterioration
level of the battery pack.
bThe battery pack may swell as the
battery life is near its end depending
on the battery pack condition, but it
is not a malfunction.
bWhen you store the battery pack
for a long time, avoid the following
conditions.
• Fully charged (immediately after
charge is completed)
• No battery (the state where the
power cannot be turned on due to
battery drain)
The performance or life of the battery
pack may be reduced.
It is recommended that you store the
battery pack when the battery level
icon shows two bars.
Notes on the adapter
bCharge the battery pack in a place
with an ambient temperature of 5 ℃
to 35 ℃ .
bCharge the battery pack where:
• There is very little humidity, vibration,
and dust.
• There are no land-line phones,
television sets or radios nearby.
bIt is normal for the adapters to
become warm while using or
charging the FOMA terminal.You can
continue to use it.

17
Introduction
bUse the DC adapter only when the
car engine is running.
The car battery may be exhausted.
bWhen using an outlet with a latch
mechanism, follow the instruction
manual of the outlet.
b Do not place strong impacts. Also, do
not deform the charging terminals.
Malfunction may result.
Notes on the UIM
bDo not use excessive force to insert/
remove the UIM.
bIt is normal for the UIM to become
warm while using the FOMA
terminal.You can continue to use it.
bNote that you are responsible for
malfunction caused by inserting the
UIM into a different IC card reader/
writer.
bAlways keep the IC portion of the
UIM clean.
bClean the UIM with a soft, dry cloth
(lens cleaning cloth).
bKeep a separate record of any
information stored on the UIM and
store the copies in a safe location.
DOCOMO assumes no responsibility
for the loss of any of your data.
bTo protect the environment, please
bring unnecessary UIM to a service
counter such as the docomo Shop.
bAvoid using in extremely high or low
temperatures.
bDo not scratch, carelessly touch, or
short-circuit the IC portion.
Data loss or malfunction may result.
bDo not drop the UIM or subject it to
shocks.
Malfunction may result.
bDo not bend the UIM or put heavy
objects on it.
Malfunction may result.
bDo not insert the UIM with labels
or stickers attached into the FOMA
terminal.
Malfunction may result.
Cautions
bNever use a modified FOMA terminal.
Using a modified device violates the
Radio Law.
The FOMA terminal acquires the
certification of conformity with technical
standards of specified radio equipment
based on the Radio Law. As a proof,
"Technical conformity mark " is
printed on the nameplate of the FOMA
terminal.
If you remove screws to modify the
internal components of the FOMA
terminal, the certification of conformity
with technical standards becomes
invalid.
Do not use the FOMA terminal with the
invalid certification of conformity with
technical standards. Doing so violates
the Radio Law.
bBe careful when using the FOMA
terminal while driving.
Using a mobile phone in hand while
driving is subject to punishment by law.
If you receive a call unavoidably, use
Hands-free to tell the caller to call back
and park the car at a safe place and
then make a call.

18
Basic Operation
Before Using
Attaching UIM (FOMA Card)/Battery Pack
The UIM is an IC card that contains subscription
information such as your phone number.
• When inserting, close the FOMA terminal and hold it
with both hands.
1While pressing
the back cover in
the direction of
a, slide it in the
direction of b
and hold it up in
the direction of
cand remove it
2With the gold IC
side down, push
the UIM surface
to insert it slowly
to the end
Notch
3With the " A"
side up, align the
metal contacts of
the battery pack
and the FOMA
terminal, attach
the battery pack
Tabs
in the direction of a, and then push it
down in the direction of b
4Align the back
cover to the
ditch of the
FOMA terminal
with approx.
3mm gap kept
between the
Back cover
(Approx. 3mm)
back cover and FOMA terminal.
While pressing the back cover in the
direction of a, slide it in the direction
of band insert it until it clicks
