Information Guide
DocuSign Signature
Appliance
Rack Mount Instructions
Version 1.0

1
221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
DocuSign Signature Appliance Rack Mount Instructions
Copyright ©2003-2016 DocuSign, Inc. All rights reserved.
For information about DocuSign trademarks, copyrights and patents refer to the DocuSign Intellectual Property page
(https://www.docusign.com/IP) on the DocuSign website. All other trademarks and registered trademarks are the property of
their respective holders.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any
purpose, without the express written permission of DocuSign, Inc. Under the law, reproducing includes translating into
another language or format. Every effort has been made to ensure that the information in this manual is accurate. DocuSign,
Inc. is not responsible for printing or clerical errors. Information in this document is subject to change without notice.
DocuSign Signature Appliance Rack Mount Instructions
May 2016
If you have any comments or feedback on our documentation, please send them to us at: [email protected].

2
221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
DocuSign Signature Appliance Rack Mount Instructions
Table of Contents
Introduction..........................................................................................................................................3
Rack mount kit parts............................................................................................................................3
Mounting the DocuSign Signature Appliance in a rack.........................................................................3
Preparing for Installation................................................................................................................3
Step 1: Attach two rail-supports (front and rear) to the right side of the rack ..................................4
Step 2: Attach two rail-supports (front and rear) to the left side of the rack ....................................6
Step 3: Attach rails to rail-supports ................................................................................................6
Step 4: Attach rollers to the appliance............................................................................................9
Step 5: Slide the appliance into the rack........................................................................................9

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
Introduction
This guide explains how to mount the DocuSign Signature Appliance in a generic rack.
To install the appliance, you need a Phillips screwdriver and an M4 Wrench.
Rack mount kit parts
The rack mount kit is included in the shipping container, together with the DocuSign Signature
Appliance.
The rack mount kit includes:
Assembly
Item
Quantity
Rail-support
Front rail-support
2
Rear rail-support
2
M5 square nut
8
M5 washer
8
M5x16 screw
8
Telescopic rail and roller
Telescopic rail
2
M4x12 screw
8
M4 washer
8
M4 nut
8
Roller
2
M4x8 screw
6
Mounting the DocuSign Signature Appliance in a rack
Preparing for Installation
Verify there is enough space in the rack for a 3U chassis.
Determine which rack units will be used for the DocuSign Signature Appliance installation.

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
Step 1: Attach two rail-supports (front and rear) to the right side of the
rack
In this step, you will attach the rail supports to the right side of the rack:
A front rail-support to the front of the rack.
A rear rail-support to the rear of the rack.
The two rail-supports must be aligned with each other.
1. Prepare the following parts:
A front rail-support
A rear rail-support
Two sets of:
2 M5 square nuts (item 1 in figure)
2 M5 washers (item 2 in figure)
2 M5x16 screws (item 3 in figure)

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
2. On the front rail-support and rear rail-support clip two M5 square nuts to the flange at the end
of each rail-support, as shown in Figure 1.
These nuts are used to secure the rail-support to the rack post.
Figure 1
3. At the front right-hand side of the rack, attach the front rail-support to the rack post by
screwing an M5x16 screw (item 3 in Figure 2) with an M5 washer (item 2 in Figure 2) through
each square nut (item 1 in Figure 2).
Figure 2
4. Similarly, at the rear right-hand side of the rack, attach the rear rail-support to the rack post
(see Figure 2).

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
5. Tighten all four screws (the two screws securing the front rail-support, and the two screws
securing the rear rail-support).
6. Verify that the front and rear rail-supports now form a broken single rail-support, running from
the front to the rear of the rack (see Figure 3).
Figure 3
Note: The center slits in the rail-supports are used in Step 3 to attach the rails to the rail-supports.
Step 2: Attach two rail-supports (front and rear) to the left side of the rack
In this step, you will attach the rail supports to the left side of the rack:
A front rail-support to the front of the rack
A rear rail-support to the rear of the rack.
The two rail-supports should be aligned with each other.
Follow the instructions detailed in Step 1, but install the rail-supports on the left side of the rack.
Note: The rail supports for the left side of the rack are identical to the rail supports for the right side of
the rack.
Step 3: Attach rails to rail-supports
In this step you will:
Attach a rail to the inner side of the right rail-supports.
Attach a rail to the inner side of the left rail-supports.
1. Prepare the following:
Two rails

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
Two sets of the following:
4 M4x12 screws
4 M4 washers
4 M4 nuts
2. Attach a rail to the rail-supports on the right side of the rack, as follows:
a. Place a rail with its back to the rail-supports. The rear end of the rail should be flush with
the rear end of the rear rail-support.
Figure 4
b. Pull the rail’s telescopic section out to the end of its travel to reveal the slots in the rail
backing. These slots are used to secure the rail to the rail-supports.
Figure 5
c. Secure the rail to the front rail-support using two M4x12 screws. Each screw should first
pass through a slot in the rail backing and then through the center slit of the rail-support.
Secure each screw with an M4 washer and an M4 nut. Place the two screws in the
locations indicated by the red ovals in Figure 6.
Figure 6

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
d. Secure the rail to the rear rail-support using two M4x12 screws. Each screw should first
pass through a slot in the rail backing and then through the center slit of the rail-support.
Secure each screw with an M4 washer and an M4 nut. Place the two screws in the
locations indicated by the red ovals in Figure 7.
Figure 7
e. Tighten all four screws.
Figure 8
3. Attach the second rail to the rail-supports on the left side of the rack. Follow the instructions
detailed in Step 2 above, but attach the rail on the left side rail supports.

221 Main Street, Suite 1000, San Francisco, CA 94105 ΙTel. 866.219.4318 Ιwww.docusign.com Ι© DocuSign, Inc.
Step 4: Attach rollers to the appliance
In this step you will attach a roller to each side of the DocuSign Signature Appliance.
1. Prepare the following:
Two sets of the following:
1 roller
3 M4x8 screws
2. Attach a roller to the right side of the appliance using three M4x8 screws, as shown in
Figure 9.
Figure 9
3. Attach a roller to the left side of the appliance using three M4x8 screws.
Step 5: Slide the appliance into the rack
In this step you will mount the appliance in the rack.
1. Lift the appliance to a point where the appliance rollers almost meet the rack rails.
Figure 10
