Durango
OWNER’S MANUAL SUPPLEMENT
2016
2016 Durango Police
First Edition
Printed in U.S.A.
16WD01-226-AA
©2015 FCA US LLC. All Rights Reserved.
Dodge is a registered trademark of FCA US LLC.
STICK WITH THE SPECIALISTS®
Police

VEHICLES SOLD IN CANADA
With respect to any Vehicles Sold in Canada, the name FCA
US LLC shall be deemed to be deleted and the name FCA
Canada Inc. used in substitution therefore.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-
drinking driver, call a cab, a friend, or use public trans-
portation.
WARNING!
Driving after drinking can lead to an accident.
Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you
have been drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or op-
tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
FCA US LLC reserves the right to make changes in design
and specifications, and/or make additions to or improve-
ments to its products without imposing any obligation
upon itself to install them on products previously manu-
factured.
Copyright © 2015 FCA US LLC

TABLE OF CONTENTS
SECTION PAGE
1INTRODUCTION . ..............................................................3
2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ..................................5
3UNDERSTANDING THE FEATURES OF YOUR VEHICLE ..................................23
4UNDERSTANDING YOUR INSTRUMENT PANEL .......................................25
5MAINTAININGYOURVEHICLE ...................................................29
6INDEX ......................................................................31
1
2
3
4
5
6

INTRODUCTION
CONTENTS
䡵INTRODUCTION ........................4
1

INTRODUCTION
This booklet is a supplement to the Owner’s Manual
prepared with the assistance of service and engineering
specialists, and is intended to aid the operators of police
or fleet vehicles (used in severe duty, high-mileage op-
erations) in understanding the operation and required
maintenance procedures for such vehicles. It covers
maintenance procedures for vehicles equipped with
heavy-duty packages. However, other vehicles operated
under the conditions listed below are also considered
“severe service” vehicles, and should be serviced and
maintained as prescribed in this booklet. You are urged to
read this publication and the Owner’s Manual carefully.
Refer to the Police Upfitter’s Guide provided with your
vehicle, prior to the addition of any aftermarket equip-
ment.
Following the instructions and recommendations pro-
vided herein, will help assure safe and reliable operation
of your vehicle. After you have read the booklet, it should
be stored in the vehicle for convenient reference and
remain with the vehicle when sold.
When it comes to service, remember that your authorized
dealer knows your vehicle best, has factory-trained tech-
nicians and genuine MOPAR® parts, and cares about
your satisfaction.
4 INTRODUCTION

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
䡵DOOR LOCKS ..........................6
▫Manual Door Locks......................6
▫Power Door Locks ......................8
䡵PASSIVE ENTRY SYSTEM ..................9
䡵OCCUPANT RESTRAINTS .................11
▫Air Bag Deployment Zones ...............12
2

DOOR LOCKS
Manual Door Locks
The power door locks can be manually locked from
inside the vehicle by using the door lock knob. To lock
each door, push the door lock knob on each door trim
panel downward. To unlock the front doors, pull the
inside door handle to the first detent. For Police vehicle,
both rear passenger doors are inoperable from the rear
seat position, inside of the vehicle. If the lock knob is
down when the door is closed, the door will lock.
Therefore, make sure the key is not inside the vehicle
before closing the door.
Manual Door Lock Knob
6 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
•For personal security and safety in the event of an
collision, lock the vehicle doors as you drive as
well as when you park and leave the vehicle.
•Never leave children alone in a vehicle, or with
access to an unlocked vehicle. Allowing children to
be in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Children should be
warned not to touch the parking brake, brake pedal
or the gear selector.
(Continued)
WARNING! (Continued)
•Do not leave the key fob in or near the vehicle, or
in a location accessible to children, and do not
leave the ignition of a vehicle equipped with
Keyless Enter-N-Go in the ACC or ON/RUN mode.
A child could operate power windows, other con-
trols, or move the vehicle.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 7

Power Door Locks
The power door lock switch is located on each front door
panel. Press the switch to lock or unlock the doors.
If the lock knob is down when the door is closed, the door
will lock. Therefore, make sure the key fob is not inside
the vehicle before closing the door.
If you press the door lock switch while the key fob is in
the ignition switch and the driver’s door is open, the
doors will not lock.
For Police vehicle, both rear passenger doors are inoper-
able from the rear seat position, inside of the vehicle.
Automatic Unlock On Exit Feature — If Equipped
If Auto Unlock is enabled, this feature will unlock all the
doors when any door is opened if the vehicle is stopped
and in PARK. Refer to “Uconnect Settings” in “Under-
standing Your Instrument Panel” for further information.
Power Door Lock Switch
8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

PASSIVE ENTRY SYSTEM
The Passive Entry system is an enhancement to the
vehicle’s Remote Keyless Entry (RKE) system. This fea-
ture allows you to lock and unlock the vehicle’s door(s)
without having to press the RKE transmitter lock or
unlock buttons.
NOTE:
•Passive Entry may be programmed ON/OFF; refer to
“Electronic Vehicle Information Center (EVIC)/ Per-
sonal Settings (Customer-Programmable Features)” in
“Understanding Your Instrument Panel” for further
information.
•If wearing gloves on your hands, or if it has been
raining on the Passive Entry door handle, the unlock
sensitivity can be affected, resulting in a slower re-
sponse time.
•If the vehicle is unlocked by Passive Entry and no door
goes ajar within 60 seconds, the vehicle will re-lock
and if equipped will arm the theft alarm (if equipped).
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9

To Unlock From The Driver’s Side:
With a valid Passive Entry RKE transmitter within 5 ft
(1.5 m) of the driver’s door handle, grab the driver’s front
door handle to unlock the driver’s door automatically.
The interior door panel lock knob will raise when the
door is unlocked.
NOTE: If “Unlock All Doors 1st Press” is programmed all
doors will unlock when you grab hold of the driver’s
front door handle. To select between “Unlock Driver
Door 1st Press” and “Unlock All Doors 1st Press”, refer to
“Electronic Vehicle Information Center (EVIC)/Personal
Settings (Customer-Programmable Features)” in “Under-
standing Your Instrument Panel” for further information.
To Unlock From The Passenger Side:
With a valid Passive Entry RKE transmitter within 5 ft
(1.5 m) of the passenger door handle, grab the front
passenger door handle to unlock only the front doors
automatically. The interior door panel lock knob will
raise when the door is unlocked.
The vehicle doors can also be locked by using the RKE
transmitter lock button or the lock button located on the
vehicle’s interior door panel.
Grabbing The Driver’s Door Handle
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

OCCUPANT RESTRAINTS
Driver/passenger air bags affect the way police equip-
ment can be safely mounted in police vehicles.
Any surface that could come into contact with an air bag,
once it has been deployed, must not damage the air bag
or alter its deployment path.
The addition of the supplemental equipment (such as
radios, weapons, mounting brackets, cage, etc.), must be
installed such that it will not interfere or come in contact
with a deploying air bag. Air bag deployment zones are
described below. Sharp edges, corners or protrusions on
supplemental equipment, could damage the nylon air
bag material and reduce the effectiveness of the air bag
during a deployment.
WARNING!
•Vehicles equipped with left and right Supplemen-
tal Side Curtain Air Bags (SABIC) must use police
cages, which have been approved by the equip-
ment manufacturer, for use in the vehicle.
•The area where the Supplemental Side Curtain Air
Bags (SABIC) is located should remain free from
any obstructions.
•
If your vehicle is equipped with left and right
Supplemental Side Curtain Air Bags (SABIC), care
must be taken when installing any type of roof
equipment. Drilling and installation of fasteners or
other equipment that may interfere with the Supple-
mental Side Curtain Air Bags (SABIC) and air bag
wiring harness is not permitted. Furthermore, make
sure no equipment or fasteners are located in the air
bag deployment zone.
(Continued)
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11

WARNING! (Continued)
•Do not place objects or mount equipment in front
of the air bag module cover, or in front of the seat
areas that may come in contact with a deploying
air bag.
•Dash, tunnel or console mounted equipment
should not be placed outside of the specified zone.
•Failure to follow these instructions could result in
personal injury.
Air Bag Deployment Zones
There are four zones to be aware of:
1.
Driver Air Bag Deployment Zone (Figure 1), and Driver
Air Bag/Steering Wheel Specifications (Figure 2)
2. Passenger Air Bag Deployment Zone (Figure 3) and
(Figure 4)
3. Supplemental Side Air Bag Inflatable Curtain (SABIC)
Deployment Zone (Figure 5)
4. Supplemental Seat-Mounted Side Air Bag (SAB) De-
ployment Zone (Figure 6)
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Figure 1 - Driver Air Bag Deployment Zone, depicts the
following.
1.
Vertical Plane Passing Through Center of Steering Wheel
2. 18.5 inches (47 cm)
3. Vertical Plane Passing Through Maximum Rearward
Point that the Driver Air Bag Cushion Reaches
4. Steering Wheel
5. Driver Air Bag Retainer/Housing
6. Driver Air Bag Cushion
Figure 1
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13

DRIVER AIR BAG/STEERING COLUMN
SPECIFICATIONS
DRIVER AIR BAG CUSHION POSITION
DAB Diameter When
Deployed (Full)
26.5 inches (67 cm)
DAB Depth When
Deployed (Full)
15 inches (38 cm)
Maximum Rearward
Displacement During
Deployment (Fill)
18.5 inches (47 cm)
DRIVER AIR BAG CUSHION POSITION
STEERING COLUMN TILT POSITION RANGE
+/– 2.7 Degrees from Steering Column Tilt
Pivot Point
21.0 Degrees from Vertical is the Nominal Position
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Figure 2 - Driver Air Bag Lateral Deployment Zone,
depicts the following.
1. Driver Seating Reference
2. Driver Air Bag Cushion Lateral Deployment Zone,
28 inches (71 cm)
Figure 2
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15

Figure 3 - Passenger Air Bag Deployment Zone, depicts
the following.
1. Passenger Air Bag Cushion
2. Vertical Plane from Point of Instrument Panel
3. Passenger Air Bag Module
4. Instrument Panel
5.
Vertical Plane Passing Through the Maximum Rearward
Point that the Passenger Air Bag Cushion Reaches
6. 15.6 inches (398 mm)
Figure 3
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Figure 4 - Passenger Air Bag Lateral Deployment Zone,
depicts the following.
1. 23 inches (77 mm)
2. Passenger Air Bag Cushion Deployment Zone
3. 20 inches (515 mm)
4. Reference Point
Figure 4
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17

Figure 5
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
