Dodge DURANGO SRT 2019 Owner's manual

2019 DURANGO DRIVE MODE SUPPLEMENT
68437092AA SECOND EDITION
Whether it’s providing information about specific
product features, taking a tour through your
vehicle’s heritage, knowing what steps to take
following an accident or scheduling your next appointment, we
know you’ll find the app an important extension of your Dodge
brand vehicle. Simply download the app, select your make and
model and enjoy the ride. To get this app, go directly to the App
Store®or Google Play®Store and enter the search keyword
“Dodge” (U.S. residents only).
www.dodge.com/en/owners (U.S.) provides special offers
tailored to your needs, customized vehicle galleries,
personalized service records and more. To get this information,
just create an account and check back often.
Get warranty and other information online – you can review and
print or download a copy of the Owner’s Manual, Navigation/
Uconnect manuals and the limited warranties provided by FCA
US LLC for your vehicle by visiting www.dodge.com/en/owners
(U.S.) or www.owners.mopar.ca (Canada). Click on the
applicable link in the “Popular Topics” area of the
www.dodge.com/en/owners (U.S.) or www.owners.mopar.ca
(Canada) homepage and follow the instructions to select the
applicable year, make and model of your vehicle.
DOWNLOAD A FREE ELECTRONIC COPY
OF THE MOST UP-TO-DATE
OWNER’S MANUAL, MEDIA AND
WARRANTY BOOKLET BY VISITING:
WWW.MOPAR.COM/EN-US/CARE/OWNERS-MANUAL.HTML
(U.S. RESIDENTS)
WWW.OWNERS.MOPAR.CA (CANADIAN RESIDENTS)
DODGE.COM (U.S.)
DODGE.CA (CANADA)
©2018 FCA US LLC. ALL RIGHTS RESERVED.
DODGE IS A REGISTERED TRADEMARK OF FCA US LLC.
APP STORE IS A REGISTERED TRADEMARK OF APPLE INC.
GOOGLE PLAY STORE IS A REGISTERED TRADEMARK OF GOOGLE.

SRT DRIVE MODES

TABLE OF CONTENTS
SECTION PAGE
1PERFORMANCE PAGES ....................................................................5
2SRT DRIVE MODES ......................................................................15
3

4

PERFORMANCE PAGES
CONTENTS
HOME ......................................7
TIMERS .....................................8
GAUGES ....................................11
G-FORCE....................................12
ENGINE ....................................13
DYNAMOMETER (DYNO) ..........................14
5

Performance Pages is an application that provides a display for perfor-
mance indicators, as received from the instrument cluster, that will help
you gain familiarity with the capabilities of your vehicle in real-time.
To access the Performance Pages, press the “Apps” button on the touch-
screen then press the “Performance Pages” button on the touchscreen.
Press the desired button on the touchscreen to access that specific
Performance Page.
NOTE: If a USB drive is installed in the media hub, press the Camera button
on the touchscreen. A screen shot of the page will be taken and saved onto
the USB.
WARNING!
Measurement of vehicle statistics with the Performance Pages is in-
tended for off-highway or off-road use only and should not be done on
any public roadways. It is recommended that these features be used in
a controlled environment and within the limits of the law. The capabili-
ties of the vehicle as measured by the Performance Pages must never be
exploited in a reckless or dangerous manner, which can jeopardize the
user’s safety or the safety of others. Only a safe, attentive, and skillful
driver can prevent accidents.
The Performance Pages include the following:
• Home
• Timers
• Gauges
• G-Force
• Engine
• Dyno
The following describes each feature and its operation:
If a USB drive is installed in the media hub, press the Camera icon on the
top right of the touchscreen when using Performance Pages. A screen shot
of the page will be taken and saved onto the USB.
PERFORMANCE PAGES
6

The following describes each feature and its operation:
HOME
When Home is selected, a series of widgets (gauges) can be customized by
the user. Follow these steps to change a widget:
1. Press any of the gauges to change the display.
2. Press the gear icon and select the following option from the menu:
• Set Widget: Top Left
• Set Widget: Top Right
• Set Widget: Bottom Left
• Set Widget: Bottom Right
3. After selecting a Widget location: select the gauge or timer to display:
• Gauge: Oil Temp
• Gauge: Oil Pressure
• Gauge: Coolant Temp
• Gauge: Battery Voltage
• Gauge: Trans Temp — If Equipped with an Automatic Transmission
• Gauge: Boost Pressure — If Equipped
• Gauge: Air/Fuel Ratio — If Equipped
• Gauge: I/C Coolant Temp — If Equipped
• Gauge: Intake Air Temp
Performance Pages — Home
PERFORMANCE PAGES
7

• Gauge: Engine Torque
• Gauge: Engine Power
• Gauge: G-Force
• Gauge: Steering Angle
• Gauge: Current Gear
• Gauge: Current Speed
• Timer: 0-60 MPH
• Timer: 0-100 MPH
• 60 ft — If Equipped
• Timer: 1/8 Mile
• Timer: 1/4 Mile
• Timer: Brake Distance
• Timer: Reaction Time
NOTE: Pressing the “Camera” icon in the upper right corner of the
Performance Pages screen will take a screenshot of the current screen and
save it to a USB that is connected.
TIMERS
When the Timers Page is selected, you will be able to select from the
following “Tickets”:
Recent
• Pressing the “Recent” button displays a “real time” summary of perfor-
mance timers.
Performance Pages — Timers
PERFORMANCE PAGES
8

Last
• Pressing the “Last” button displays the last recorded run of performance
timers.
Best
• Pressing the “Best” button displays the best recorded run of perfor-
mance timers, except for braking data.
Save
•
Pressing the “Save” button will let you save the visible page, current/last/
best. Any saved run over ten will overwrite the last saved run for Uconnect
System storage. The operation of the Save feature is listed below:
• With a USB jump drive installed, press the “USB” button to save to the
jump drive.
• Press the “Uconnect” button to save the runs to the Owner web page.
• Press the “Cancel” button to view the last timer “Ticket”.
Performance Pages — Save
PERFORMANCE PAGES
9

The “Tickets” contain the timers listed below:
Reaction Time
• Measures the driver's reaction time for launching the vehicle against a
simulated drag strip timing light (behavior modeled after 500 Sports-
man Tree) displayed in the instrument cluster display.
NOTE: The Reaction Time, MPH, ⅛and ¼ Mile timers will be “ready” when
the vehicle is at 0 MPH (0 km/h).
0-60 MPH (0-100 km/h)
• Displays the time it takes for the vehicle to go from 0 to 60 mph (0 to
100 km/h).
0-100 MPH (0-160 km/h)
• Displays the time it takes for the vehicle to go from 0 to 100 mph (0 to
160 km/h).
60 feet (20 meter) ET
• Displays the time is takes the vehicle to go 60 feet (20 meters).
⅛Mile (200 meter) ET
• Displays the time it takes for the vehicle to go an ⅛mile (200 meters).
⅛Mile (200 meter) MPH
• Displays the vehicle speed at the time ⅛mile (200 meters) was
reached.
¼ Mile (400 meter) ET
• Displays the time it takes for the vehicle to go ¼ mile (400 meters).
¼ Mile (400 meter) MPH
• Displays the speed the vehicle was at when ¼ mile (400 meters) was
reached.
Brake Distance ft
• Displays the distance it takes the vehicle to make a full stop.
NOTE: The distance measurement will be aborted if the brake pedal is
released or the parking brake is engaged, before the vehicle comes to a
complete stop.
Brake from MPH
• Displays the speed the vehicle is traveling when the brake pedal is
pressed.
NOTE: Brake Distance and Speed timers only displays "ready" when vehicle
is traveling at greater than 30 MPH (48 km/h).
PERFORMANCE PAGES
10

GAUGES
When selected, this screen displays the following values:
Oil Temperature
• Shows the actual oil temperature.
Oil Pressure
• Shows the actual oil pressure.
Coolant Temperature
• Shows the actual coolant temperature.
Battery Voltage
• Shows actual battery voltage.
Trans Oil Temp — If Equipped with an Automatic Transmission
• Shows actual transmission oil temperature.
Boost Pressure — If Equipped
• Shows actual boost pressure.
Air Fuel Ratio — If Equipped
• Shows current air fuel ratio
I/C Coolant Temp — If Equipped
• Shows actual I/C Coolant temperature.
Intake Air Temp
• Shows actual air intake temperature.
If a gauge is selected, the Gauge Detail View page will appear on the screen.
This page shows further information on the selected gauge.
Performance Pages — Gauges
PERFORMANCE PAGES
11

Press the left and right arrows will cycle through the details for each of the
gauges. Pressing the minimize button above the graph will return to the
gauge menu.
G-FORCE
When selected, this screen displays all four G-Force values as well as
steering angle.
When G-Force is selected, the following features will be available:
Vehicle Speed:
• Measures the current speed of the vehicle in either mph or km/h, starting
at zero with no maximum value.
Gauge Detail View Page G-Force
PERFORMANCE PAGES
12

Front G-Force:
• Measures the deceleration force present on the driver during a braking
maneuver.
Right G-Force:
• Measures the force pulling toward the right during a left turn maneuver.
Left G-Forces:
• Measures the force pulling toward the left during a right turn maneuver..
Rear G-Forces:
• Measures the acceleration force present on the driver.
NOTE: Front, Right, Left, and Rear G-Froces are all peak values. These
readings can be reset by clearing peak G-Force on the instrument cluster.
Steering Wheel Angle
• Steering Wheel Angle utilizes the steering angle sensor to measure the
degree of the steering wheel relative to zero. The zero degree measure-
ment indicates a steering wheel straight ahead position. When the
steering angle value is negative, this indicates a turn to the left, and
when the steering angle value is positive, a turn to the right.
The friction circle display shows instantaneous G-Force as a highlight and
previous G-Force as dots within the circle. The system records previous
G-Force for three minutes. If there are multiple samples at a given point,
the color of the dot will darken from blue to red. Vectors more frequent will
show in red; infrequent vectors will show in blue.
ENGINE
When selected, this screen displays the following values:
Vehicle Speed
• Shows the actual vehicle speed.
Engine Power
• Shows the instantaneous power.
Engine
PERFORMANCE PAGES
13

Engine Torque
• Shows the instantaneous torque.
Gear (Automatic Transmission Only)
• Shows the current (or pending) operating gear of the vehicle.
Boost Pressure (6.2L Only)
• Shows the actual boost pressure.
DYNAMOMETER (DYNO)
The system will start drawing graphs for Power and Torque. The graph will
fill to the right side of the page (based on History time selected). Once the
right side of the page is reached, the graph will scroll with the right side
always being the most recent recorded sample.
The following options can be selected:
• Pressing the STOP button will freeze the graph. Selecting Play will clear
the graph and restart the process over
• Press the “+” or “–” buttons to change the history of the graph. The
selectable options are “30, 60, 90, 120 seconds. The graph will expand
or constrict depending on the setting selected.
• Select the “Gear” display setting to turn the graph gear markers on and
off.
NOTE: The Gear on/off feature will only display if your vehicle is equipped
with an Automatic Transmission.
Dyno Page
PERFORMANCE PAGES
14

SRT DRIVE MODES
CONTENTS
TRACK MODE.................................17
SPORT MODE.................................17
TOW MODE ..................................18
SNOW MODE .................................18
AUTO MODE .................................19
CUSTOM MODE ...............................20
Custom Mode Set-Up Info......................21
All-Wheel Drive.............................21
Transmission ..............................22
Paddle Shifters.............................23
Stability Control ............................23
Suspension ...............................24
Steering .................................25
RACE OPTIONS................................25
Launch Control.............................26
Shift Light................................30
Race Cooldown — If Equipped ..................31
VALET MODE .................................32
ECO MODE ..................................34
15

Your SRT vehicle is equipped with a Drive Modes feature which allows for
coordinating the operation of various vehicle systems depending upon the
type of driving behavior desired. The Drive Modes feature is controlled
through the touchscreen and may be accessed by performing any of the
following:
• Selecting “Drive Modes” from the “Apps” menu.
• Selecting “Drive Modes” from within the Performance Pages menu.
The SRT Drive Modes main screen displays the current drive mode and
real-time status of the vehicle’s performance configuration. The selectable
Drive Modes are Track, Sport, Auto, Snow, Tow or Custom. Information
shown will indicate the actual status of each system, along with a vehicle
graphic that displays the active drive mode status. The color red indicates
“Track,” orange “Sport,” yellow “Street” and blue for “Snow.” These
features will reset to AUTO upon an ignition cycle. If the system status
shown does not match the current drive mode set up, a message will be
displayed indicating which values are not matching the current mode.
Drive Modes — Track
SRT DRIVE MODES
16

Listed below are the available Drive Modes:
TRACK MODE
Selecting “Track” on the touchscreen will activate the configuration for
typical track driving. The Transmission, Stability Control, All-Wheel Drive,
Steering, and Suspension systems are all set to their “Track” settings
highlighted in red. The Paddle Shifters are enabled.
SPORT MODE
Selecting “Sport” on the touchscreen will activate the configuration for
typical enthusiast driving. The Transmission, Stability Control, All-Wheel
Drive, Steering, and Suspension systems are all set to their “Sport” settings
highlighted in orange. The Paddle Shifters are enabled.
Drive Modes (Track)
Drive Modes (Sport)
SRT DRIVE MODES
17

TOW MODE
Selecting “Tow” on the touchscreen will activate the configuration for
towing a trailer or hauling heavy loads in the cargo area. Once in this mode,
trailer sway control is enabled in the ESC system. The Transmission is set
to “Tow” setting highlighted in purple. Stability Control is set to “Full”
highlighted in blue. All-Wheel Drive is set to “50/50” highlighted in blue.
Steering is set to “Sport” highlighted in yellow. Suspension is set to “Sport”
highlighted in orange. Paddle Shifters are enabled
SNOW MODE
Selecting “Snow” on the touchscreen will activate snow mode for use on
loose traction surfaces. When in Snow mode (depending on certain oper-
ating conditions), the transmission will use second gear (rather than first
gear) during launches, to minimize wheel slippage. The Transmission is set
Drive Modes (Tow) Drive Mode (Snow)
SRT DRIVE MODES
18
