Dongcheng DCPL04-5 User manual

1
EN
DCPL04-5 ADPL04-5 KDPL04-5
EN ·········································································
DE ·········································································
FR ·········································································
ES ·········································································
IT ·········································································
2
14
28
42
55

2
EN
Original Instructions
General power tool safety warnings
WARNING Read all safety warnings, instructions,
illustrations and specicationsprovided with this power tool.
Failure to follow all instructions listed below may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1)Work Area Safety
a)Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b)Do not operate power tools in explosive atmospheres, such as
in the presence of ammable liquids, gases, or dust. Power tools
create sparks which may ignite the dust or fumes.
c)Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodied plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators,ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling
or unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
3) Personal Safety
a)Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you
are tired or under the inuence of drugs, alcohol, or medication.
A moment of inattention while operating power tools may result in
serious personal injury.
b)Use personal protective equipment. Always wear eye protection.

3
EN
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c)Prevent unintentional starting. Ensure the switch is in the o󰀨-
position before connecting to power source and /or battery pack,
picking up or carrying the tool. Carrying power tools with your nger
on the switch or energising power tools that have the switch on invites
accidents.
d)Remove any adjusting key or wrench before turning the tool on. A
wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
e)Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing, and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g)If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly
used. Use of dust collection can reduce dust-related hazards.
h)Do not let familiarity gained from frequent use of tools allow
you to become complacent and ignore tool safety principles. A
careless action can cause severe injury within a fraction of a second.
4)Power Tool Use and Care
a)Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and o󰀨.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c)Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d)Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
e)Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may a󰀨ect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier to
control.
g)Use the power tool, accessories and tool bits etc. in accordance

4
EN
with these instructions, taking into account the working
conditions and the work to be performed. Use of the power tool for
operations dierent from those intended could result in a hazardous
situation.
h) Keep handles and grasping surfaces dry, clean and free from oil
and grease.Slippery handles and grasping surfaces do not allow for
safe handling and control of the tool in unexpected situations.
5)Battery Tool Use and Care
a) Recharge only with the charger specied by the manufacturer. A
charger that is suitable for one type of battery may create a risk of re
when used with another battery.
b)Use power tools only with specically designated batteries. Use
of any other batteries may create a risk of injury and re.
c)When battery pack is not in use, keep it away from other metal
objects like paper clips, coins, keys, nails, screws, or other small
metal objects that can make a connection from one terminal to
another. Shorting the battery terminals together may cause sparks,
burns, or a re.
d)Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, ush with water.
If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
e)Do not use a battery pack or tool that is damaged or modied.
Damaged or modied batteries may exhibit unpredictable behaviour
resulting in re, explosion or risk of injury.
f)Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 130 °C may
cause explosion.NOTE The temperature „130 °C“ can be replaced by
the temperature „265 °F“.
g) Follow all charging instructions and do not charge the battery
pack or tool outside the temperature range specied in the
instructions. Charging improperly or at temperatures outside the
specied range may damage the battery and increase the risk of re.
6) Service
a)Have your power tool serviced by a qualied repair person using
only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
b)Never service damaged battery packs. Service of battery packs
should only be performed by the manufacturer or authorized service
providers..
Hold the power tool by insulated gripping surfaces, when
performing an operation where the fastener may contact hidden
wiring. Fasteners contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an electric

5
EN
shock.
Battery safety warning
a)Do not dismantle, open or shred secondary cells or batteries.
b)Keep batteries out of the reach of children Battery usage by
children should be supervised.Especially keep small batteries out
of reach of small children.
c)Do not expose cells or batteries to heat or re. Avoid storage in
direct sunlight.
d)Do not short-circuit a cell or a battery. Do not store cells or
batteries haphazardly in a box or drawer where they may short-
circuit each other or be short-circuited by other metal objects.
e)Do not subject cells or batteries to mechanical shock.
f)In the event of a cell leaking, do not allow the liquid to come in
contact with the skin or eyes. If contact has been made, wash the
a󰀨ected area with copious amounts of water and seek medical
advice.
g)Do not use any charger other than that specically provided for
use with the equipment.
h)Do not use any cell or battery which is not designed for use with
the equipment.
i)Do not mix cells of di󰀨erent manufacture, capacity, size or type
within a device.
j) Always purchase the battery recommended by the device
manufacturer for the equipment.
k)Keep cells and batteries clean and dry.
l)Wipe the cell or battery terminals with a clean dry cloth if they
become dirty.
m)Secondary cells and batteries need to be charged before use.
Always use the correct charger and refer to the manufacturer’s
instructions or equipment manual for proper charging instructions.
n)Do not leave a battery on prolonged charge when not in use.
o) After extended periods of storage, it may be necessary to charge
and discharge the cells or batteries several times to obtain
maximum performance.
p)Retain the original product literature for future reference.
q)Use the cell or battery only in the application for which it was
intended.
r)When possible, remove the battery from the equipment when not
in use.
s)Keep the cell or battery away from microwaves and high pressure.
t) Dispose of properly.

6
EN
Symbol
To reduce the risk of injury, user must
read instruction manual
WARNING
Conformity of EC
Conformity of UK
According to the European Waste Directive
2012 / 19 / EU on Electrical and electronic
equipment and the current national laws,
electric tools that are no longer available
must be collected separately and disposed
of properly.
TECHNICAL DATA
Rated voltage 4V
Charging Condition 5V /1.5A max.
Clamping Capacity 6.35 mm
Max. Screw Diameter 5 mm
Battery Type Li-Ion
No Load Speed 300/min
Torque Setting 3
Max. Torque 5 N·m
Full Charging Time 2.5-3 h
Net Weight Of The Machine(Battery Included) 0.3 kg
Due to the continuing program of research and development, the
specications herein are subject to change without prior notice.
Noise information
A-weighted sound pressure level
LpA < 70 dB(A) KpA = 3 dB(A)
wear hearing protection
Vibration information

7
EN
Vibration total vales (triax vector sum) and uncertainty K determined
according to EN 62841-2-2.
ah< 2.5 m/s² uncertainty K= 1.5 m/s²
The declared vibration total value(s) and the declared noise emission
value(s) have been measured in accordance with a standard test method
and may be used for comparing one tool with another.
The declared vibration total value and the declared noise emission
value(s) may also be used in a preliminary assessment of exposure.
A warning:
− that the vibration and noise emissions during actual use of the power
tool can di󰀨er from the declared values depending on the ways in
which the tool is used especially what kind of workpiece is processed ;
and
− of the need to identify safety measures to protect the operator that are
based on an estimation of exposure in the actual conditions of use
(taking account of all parts of the operating cycle such as the times
when the tool is switched o󰀨 and when it is running idle in addition to
the trigger time).
Intended use
This product is suitable for tightening or unscrewing screws in wood,
metal and plastics under general environmental conditions.
GENERAL DESCRIPTIONS
1 Output Shaft 2 Floodlight
3 Start Button 4 Torsion Indicator Light
5 Torque Setting Button 6 Charging Port
Accessories
CAUTION: Not all the accessories shown in the drawing, tables or
instructions are included in the scope of supply.
Bits Component
USB Cable

8
EN
INSTRUCTIONS FOR OPERATION
Battery Charging
Plug the output end of the USB charging cable into the charging port of
the power tool rst, and then insert the input end of the USB charging
cable into the USB port correctly. The battery is charged normally and
the power indicator (red light) is always on.
After the battery is fully charged, the power indicator (green) stays on.
At this point, unplug the input end of the charger from the USB port.
Then pull out the charger output end of the power tool.
Please charge the battery pack at 5-40 degrees. When the room
temperature is lower than 5 degrees or higher than 40 degrees, do
not charge the battery pack; When the room temperature is below 0
degrees, it may not be able to charge. The machine can be charged
at any time without shortening the service life of the battery, If the
charging process is suddenly interrupted, it will not damage the battery.
In the high temperature environment or after a long time of use, the
machine may be hot,
this is please do not immediately charge, wait for the machine to cool
before charging,
otherwise it will shorten the service life of the
machine or because the machine overheating
can be charge.
Do not use the power tools while charging.
It is normal for the handle of a power tool to
become hot during charging.Choose the right
phone charger and reliable USB port to charge it .
Installing or Removing the Tool
The tools referred to here include batch head, twist drill, etc,. and are
not equivalent to power tools or machines.
CAUTION:
Never press the start button before operation.
It is easy to install and remove tools, just insert the batch head into the
tool connector correctly. When using the adapter, insert the batch head
into the adapter and then into the tool connector.
Switch Action
To start the machine, just press the start button, release the start button
and the machine will stop.
CAUTION:
Make sure the machine is closed before you can top the batch head
(general tool) on the screw head. The turning batch head (refers to
the tool) is easy to slide o󰀨 the screw head. Select the corresponding
batch head from the distributed batch component according to di󰀨erent
needs.
Reverse Rotation
Forward/clockwise rotation (viewed from the tail of the machine to the
Start button
1.Start button

9
EN
head): Press the positive end of the start button to screw in and other
operations.
Reverse/counterclockwise rotation (from the tail of the machine to the
head): Press the reverse end of the start button to unscrew and other
operations.
CAUTION:
●Before operation, it is necessary to conrm the direction of
rotation, and use the positive and negative turning buttons
after the machine stops completely. Changing the direction
of rotation before the machine stops may cause damage to
the machine.
2.The start button
is turned forward
3.Start the button
reversal end
4.Floodlight
Floodlight
When the start button is pressed, the white light is lit to illuminate the
operating position in a poorly lit environment. When the battery power
is almost used up. The brightness of the white light will dim, which is a
normal phenomenon.
Torque Adjustment
This machine is equipped with the torque size of "1, 2, 3" three gears.
When using, rotate the torque knob according to di󰀨erent occasions to
select the appropriate torque gear. Press the torque adjusting button
to switch the size of the torque, and the number of the torque indicator
light indicates the gear position of the torque. It is suggested to use the
rst gear when starting to use, and gradually increase the torque if the
torque is not enough. Gear 1 is suitable for screwing small diameter
screws or screws into soft materials; 2 gear is
suitable for screwing machine tapping screw; Gear 3 is suitable for
screwing into woodworking screws or drilling holes.
Spindle Lock
When the start button is not pressed, the spindle is locked.
This enables screws to be screwed in, even when the battery is
empty and allows for the tool to be used as a screwdriver.
CAUTION:
●Do not force the switch button when the machine is used
as a hand tool. Otherwise it will damage the machine

10
EN
5.Torsion indicator
light
6.Torsion
adjusting knob
Overload Protection
The motor stops rotating when overload occurs during operation. To
restart the machine, rst release the switch button to reset the switch,
and then switch on.
Spindle Lock
When the switch trigger is not pressed, the drill spindle is locked. This
enables screws to be screwed in, even when the battery is empty and
allows for the tool to be used as a screwdriver.
CAUTION:
●Do not force the switch button when the machine is used as a hand
tool. Otherwise it will damage the machine.
Overload Protection
The motor stops rotating when overload occurs during operation. To
restart the machine, rst release the switch button to reset the switch,
and then switch on.
Over discharge Protection
There is over discharge protection circuit in this machine. When the
battery power is low, the protection circuit is activited and the machine
stops rotating.
State Description of Indicator and Floodlight
In the process of use, the state of the machine can be judged according
to the power indicator light and oodlight.
