DOTWORKZ COOLDOME Series User manual

INSTALLATION GUIDE
Mounting & Sealing of Housing & Electrical Details
COOLDOME™ENCLOSURE SERIES
D2 COOLDOME™
D3 COOLDOME™
S-TYPE COOLDOME™

0
PRODUCT INSTALLATION
PRECAUTIONS –WARNINGS –ADDITIONAL INFORMATION
(RETAIN THIS DOCUMENT)
IMPORTANT SAFEGUARDS
1 Read Instructions - All the safety and operating instructions should be read
before the unit is operated.
2 Retain Instructions -The safety and operating instructions should be retainedfor
future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions
should be adhered to.
4. Follow Instructions -All operating & user instructions should be followed.
5. Electrical Connections - Only a qualified electrician should make electrical
connections.
6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards
7. Cable Runs - All cable runs must be within permissible distance
8. Mounting -This unit must be properly and securely mounted to a supporting
structure capable of sustaining the weight of the unit. Accordingly:
a. Installation should be made by a qualified installer.
b. Installation should be in compliance with local codes
c. Care should be exercised to select suitable hardware to install the unit,
taking into account both the composition of the mounting surface and
the weight of the unit. Be sure to periodically examine the unit and the
supporting structure to make sure that the integrity of the
installation
is intact. Failure to comply with the foregoing could result in the unit
separating from the support structure and falling, with resultant damages
or injury to anyone or anything struck by the failing unit,
SERVICE
If the unit ever needs repair service, customer should contact Dotworkz Systems +1
(619) 224-LIVE (5483) for return authorization & shipping instructions
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT EXPOSE
COMPONENTS TO WATER OR MOISTURE
The lightning flash with an arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of non-insulated "dangerous
voltage" within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance
UNPACKING
Unpack carefully. Electronic components can be damaged if improperly handled
or dropped. If an item appears to have been damaged in shipment, replace it
properly in its carton and notify the shipper. Be sure to save
1.The shipping carton and packaging material. They are the safest material in
which to make future shipments of the equipment.
2. These Installation and Operating Instructions.
For technical questions or product returns –call Dotworkz Customer Service (866-575-4689) 7:30 AM to 4:30 PM (PST). The proper
technician will contact you as soon as possible.
The External Nut on All electrical wire feed Glands must be tightened to create a weather tight seal prior to putting D2 in service. Failure
to create this seal may result in water incursion into enclosure. This may lead to electrical shock, product failure and damage to electrical
systems installed within enclosure, including but not limited to damage to camera, heater and blower circuitry, cooling circuitry and other
systems installed in unit.
All screws on hinged lower must be tightened to create seal on enclosure. Failure to create this seal may result in water incursion into
enclosure. This may lead to electrical shock, failure and damage to electrical systems installed within enclosure, including but not limited
to damage to camera, heater and blower circuitry, cooling circuitry and other systems installed in unit.
Do not over tighten any Screws, Stand Offs, or other fasteners on this unit. Failure to heed this warning will cause damage or failure of
the D2 enclosure.
Be sure to take extra care to Protect Lens of unit prior to and during installation, and during service. Suspension packaging box is a handy
platform to protect lens and enclosure, while installing camera and accessory electronics before installation. Failure to protect lens will
adversely affect product perform

1
Conduit Guidelines:
1) If wires, cabling, or conduit are coming at enclosure wire entry level, or above, always create a drip loop.
2) Please use only approved watertight electrical conduit and connectors, IP66 or better, with proper seals and fittings installed & fully seal.
3) Then, after all wire and cables are installed into enclosure, Seal wire entry ports inside of enclosure with any number of commercially
available sealing putty’s, Silicone Sealant, or similar products that are approved by applicable local and relevant electrical codes.
SHOCK HAZARD! Failure to fully seal enclosure wire and cabling entry ports may lead to shock hazard,
unsatisfactory product performance, a possibility of damage to electronics in the Dotworkz enclosure product,
including camera damage, and damage to integrated electronics due to air driven moisture traveling thru the
conduit, condensing and collecting in the enclosure creating a short circuit hazard.
Dotworkz does not endorse, nor has it evaluated any of these products. Test products first, and follow all manufacturers’ instructions.
Follow all applicable electrical and building codes and installation guidelines. End user assumes liability for applicability of these products and
their effectiveness and incurred liability in using these products.
Electrical Conduit Guidelines
For optimal performance, your Dotworkz Enclosure is designed to be Air & Water Tight to eliminate any
moisture, dust, and insect damage, safety, performance, reliability, and maintenance related issues.
Use of Electrical Conduit, without sealing the entry ports/ inside wire feeds within Camera Enclosure, will
subject the inside of your enclosure to possibility of condensation driven moisture, dust, and insect contamination
hazards.
Dotworkz has provided each enclosure with two Cable Gland Strain Relief seal ports that fully seal
enclosure to an IP68 rating, Waterproof and Airtight Seal. To properly seal, only one round cable is used in each
cable gland port. (Holes on enclosure are 7/8” diameter, ready for standard ½” I.D. NPT connector, or PG13 fittings.)
However, we realize our customers are retrofitting these connectors with electrical conduit fittings. We
acknowledge this industry customization and installation practice, and would like to guide customers to properly
install these products.
Humid Air Condensing to Water
FORCES AT WORK IN ANY UNSEALED, CONDUIT WIRE FEED ENCLOSURE SYSTEM
WARM/MOIST IN UNSEALED CONDUIT MOVES THRU CONDUIT
FEEDS EXPAND & CONTRACT WHEN CONDUIT HEATS & COOLS
WITH OUTSIDE TEMPERATURES
EXPANDING HEATED AIR IS PUSHED INTO ENCLOSURE THEN COOLS &
CONDENSES, HUMID AIR CONDENSES ON SURFACES INSIDE
ENCLOSURE
Electrical Putty & Putty Tapes Silicone Sealants Foam Sealants (use very sparingly)
Dotworkz supplies two ½” diameter foam conduit plugs, that when installed, will assist in
sealing off airflow in conduit feed thru, at cable entry inside of enclosure. Putty or Sealant can be
used in conjunction with these plugs, to assure a full seal inside enclosure cable feed entry.

2
Foam Conduit Feed Plugs for ½” I.D. (PG-13) Conduit
Prevents Humid Air exchange from venting thru electrical conduit into Dotworkz sealed enclosures,
Thus eliminating condensation issues within Dotworkz sealed enclosures.
QUICK INSTALLATION GUIDE
VENT STOPPER PLUGS for Conduit
1) Pull wires to final installed length.
2) Open Vent Stop Plug and install over wire.
3) Pinch Plug to compress over wire, and insert into
conduit feed mouth.
4) Push plug into conduit mouth with finger
tips till it flush with outside of fitting
5) Repeat steps 1-4 for any other conduit
feeds as needed.
6) To assure an airtight seal, caulk around wires
and cables, coating entire plug surface with sealant.

3
Dotworkz D-Series Seals & drip edges are engineered for horizontal installation Only: Dome bubble faces down.
Vertical and dome-up installations are not advised, and will be prone to moisture incursion within housing, and
will void warranty.
Dotworkz D-Series Mounting Guidelines
COOLDOME™Wiring
Dotworkz CD Series Operate using DC low voltage only, and
creates ample currents when cooler is engaged.
18 gg wire is Not recommended for cooler wiring.
Follow relevant Cable Gauge Guidelines provide in this
document applicable to your product model.
CD’s are Dedicated 12 VDC or 24 VDC models Only.
Use Step Down Power supply Included in CD Package to power
from high voltage line supply.
Dotworkz Humidity Removal Canister
Dotworkz Provides a Humidity Removal Canister must be installed into COOLDOME prior to entering
enclosure into service.
Active Cooler within COOLDOME lowers temperature to at or near dew point within
COOLDOME, so trapped air must be dried out to eliminate condensation issues. The sealed air is
efficiently dried out by this desiccant canister, which provides a color coded saturation state window.
It must be removed from its foil envelope, and can be installed on shelf next to cooler, or
above camera on camera mounting plate. See installation section for service info on this product.
COOLDOME™Accessories & Mount Options
(some brackets only compatible with D-Series, consult Dotworkz Sales Representative for Details)
Your COOLDOME is wall mount ready, but can be Installed with a number of Dotworkz Optional Mounts (sold separately)
NO
18 gg
BR-ECB1
BR-PSA1
BR-CNR1
NM-CDPS NEMA for
CD Power Supply
KT-CDR2 Outdoor CD Power Pole Mount Kit
BR-MPM1 BR-MPM1-AC
BR-APM1
BR-MPM1
With common
Pipe anchor for
pendant mounting

4
Proper Cable Management to Enclosure
Avoid common Installation Mistakes
Always Create a Drip Loop for all Cables or Conduit Entering
Dotworkz D2 Housing from level or Above D2
Conduit, Power, Data, & Antennae
To avoid gravity driven moisture entry into Enclosure
To properly seal, Dotworkz Cable Gland Strain Relief Ports will only accept One single round cable per port
NO
Romex
Flat Cable
* SJOOW
* Cat5/ Cat6
* Coaxial
+=
Dotworkz Standard Cable Gland Port
Seals are designed for ONE single round
cable only per port
Use Round Cable Only with
provide Cable Gland Port Seal
Only Use Qualified Installation or Service Technician for Installing & Servicing Dotworkz Enclosures.
Power Must be disconnected and kept off while installing or Servicing Enclosure.
Follow All Local and Applicable Electrical Codes and Standards for Installation of Electrical components.
All Cable Ports, wire feeds, or Conduit must be fully sealed to eliminate moisture within Enclosure.
All Dotworkz Enclosures are required to be fully sealed before placing into service, to protect integrated products, to
eliminate any moisture driven shock hazard, to perform optimally as designed.
DRIP LOOPS
Cable can be multi-conductor in single round cable bundle such as Cat5/ 6e (burial rated), or Conductor cable SJ00W (water rated)
Cable Gland Strain Relief Port Seals
Conduit
+
If Conduit is used in Lieu of Cable Gland Port Seals provided,
Then Use Only Liquid Tight Conduit & fittings properly sealed.
Internal Wire feeds must be fully sealed prior to placing Enclosure into Service.
See Conduit Guidelines section of this manual.

5
- #1 & #2 Phillips head screw driver
-#1 Flat Blade screw driver or smaller
- 3/8 Socket wrench, nut driver, or adjustable wrench
- 5/16 Socket wrench, nut driver, or adjustable wrench
- 7/16 Socket wrench, nut driver, or adjustable wrench
- 7/32 Socket wrench, nut driver, or adjustable wrench
- 11/32 Socket wrench, nut driver, or adjustable wrench
- Wire stripping tool
- Caulk Gun & Silicone Sealant
Tools Recommended for Enclosure & Camera Mounting
Pole Strapping Tools
Drill & Bits
For Wall Mounting
- Drill and Bits for user supplied fasteners for wall mounting enclosure
For Pole Mounting
- Strapping / Banding Tools for user supplied Stainless Steel Pole Straps
For other needed Mounting Styles:
**See Dotworkz for Available Optional Mounting Brackets for a wide selection of Enclosure
Mounting Styles @ www.dotworkz.com, or ask your favorite distributor or Sales Associate, or call
Dotworkz Support [phone]
Dotworkz D2 COOLDOME accepts four (4) 3/8" Bolts or Lag Screws to Wall Mount
See Mounting Template at back of this manual for hole pattern.
(Customer provides enclosure mounting hardware)
Hand Tools

6
Low Voltage Line Drop Wire Gauge Tables
See 12 VDC & 24 VDC Low Voltage Wire Gage Selector –Appendix Chart

7

8
Low Voltage Wire Gage Selector Charts- Per Conductor Pair, Per Cooler
(D3 COOLDOME uses Dual Coolers –Requires Two Pair)

9
COOLDOME Input Power Configuration: D3-CD-12VDC
110 –220 VAC Power Source
Single Phase Only 500 watt Step Down P/S
High Voltage to 12 VDC
Provided P/S: SP500
Must be Housed Indoors, or in
a NEMA Electrical Enclosure
Site Power Available
High Voltage A/C Input, Single Phase, USA Wiring Color Code
Color Symbol Terminal Description
Black L 1 Line Conductor, AKA Live, Hot
White N 2 Neutral Conductor
Green FG 3 FG, Field Ground, Chassis Ground
Front of Power Supply with terminal strip
The D3 CD has two Coolers that run
independently.
To reduce low voltage current load, it is best to
run two pairs- individually –
So each 12VDC paired wiring runs load of one
cooler
Low Voltage 12 VDC Output Terminals
Color Symbol Terminals Description
Red +, V+ 9,10,11 Positive VDC
Black -. V- 12,13,14 Negative VDC
12 VDC Cable to
COOLDOME
Turn Off Power or leave power disconnected during Installation of All Wiring.
Follow all local and relevant electrical codes & standards.
Test all Wiring and confirm correct voltages before wiring up & powering up COOLDOME.
LOW VOLTAGE RUN
LOW VOLTAGE RUN: Wire Gauge Chart for D3-CD-12VDC: each cooler wired on independent 12VDC wire pairs
Wiring from Step Down P/S to D3 CD
Round, Water rated cable bundle,
such as SJOOW - 4 conductor
makes for an easy install and seal
into provided cable ports

10
COOLDOME Input Power Configuration: D3-CD-12VDC
Warning!!!: COOLDOME Enclosure runs on 12 VDC only! If high voltage is applied directly to COOLDOME enclosure,
you will damage housing, void warranty, and create electrocution hazard that can be harmful or fatal. Do not start
wiring until you have fully read and understand these installation instructions.
External Power Supply: Model SP-500
The step down power supply provided with each D3 COOLDOME must be mounted outside of the D3 enclosure. This
power supply is must be mounted indoors or in an environmentally protective enclosure. The power supply can be powered by 95-
264 VAC, single phase source voltage. It is self-ranging, so no switch adjustment is needed if you power it from a 110 VAC source,
or 220 VAC source voltage (single phase). Optional outdoor rated, sealed power supplies are available sold separately.
The output of the SP-500 is rated up to 40 amps peak output @ 12VDC. Output 12 VDC can be tuned up or down 10% to
optimize regulated output, via a small nylon adjustment to left of 12V output terminals on face of power supply . It is
recommended to tune the voltage at power supply between 12.0 VDC –13.5 VDC in unloaded condition. A higher voltage setting
may create premature fan failure, and settings above 15VDC may cause costly failure to main cooling components. Use voltage
meter to confirm all voltages before connecting COOLDOME to power supply. Firmly tighten all screw terminal connections and
check there are no stray wire strands that can create short between wires and terminals.
Wiring Guidelines:
Dotworkz recommends wiring the low voltage 12VDC outputs so that there are two pairs of wires from the SP-500
P/S outputs, to power each cooler independently, to reduce the need for very heavy wire gages on low voltage wiring run, thus
eliminating voltage drop issues. Dotworkz recommends to keep all low voltage wiring runs, as short as possible, by installing step
down power supply near to COOLDOME.
Dotworkz recommends using 12gg copper wire, or thicker, even on shortest wire runs of 20 ft or less, wired between
coolers and step down power supply (per cooler). SJOOW 12-4 type cable provides a stranded 4 conductor round bundle ideal for
under 20 ft low voltage cabling, when using our stock cable gland ports, creating a good waterproof seal around cabling to
enclosure.
Follow wire gage recommendation on table provided found on prior page, for proper wire gage minimums based on
distance between step down power, and COOLDOME. Voltage drop is based on fully loaded “cooler engaged” conditions (and
camera powered, allowing up to 3 amps) at typical ambient temperatures of 100F.
Inside D3 CD at rear of upper on enclosure will be two pairs of color coded screw terminal blocks to conveniently
and securely attach low voltage wiring. Always check voltage to assure 12VDC is properly wired into enclosure, and observe
proper polarity.
Each of the Coolers on the D3 are set up for independent operation, and therefore will switch on and off at slightly
different set points, when properly powered and wired. This adds fail safe redundancy to system, as well as electrical efficiency;
as second cooler only engages only at higher thermal loads.
Fully Seal Enclosure
D3 COOLDOME is engineered to operate in fully sealed conditions only. Failure to fully seal wire ports and all seals will
allow unsatisfactory cooling, and condensation to form within enclosure.
Always completely seal wire ports when completing wiring installation, especially when using conduit; even within inside
wire feeds. See Conduit guideline section in this manual for proper conduit installation.
Always create a Drip Loop on wiring that comes from overhead the enclosure, to reduce the risk of water entering
enclosure at wire seal ports.
Only use one round cable per provided wire port seal / cable gland. Attempting to run multiple separate wires thru one
cable gland will create air and water leaks, and will not seal properly. Use of flat cable or zip cord will not allow cable gland ports
to seal properly, creating leaks and product damage.
Humidity Control Pack
A Humidity control pack is provided to eliminate humidity in trapped air within COOLDOME. Each COOLDOME product
includes a canister that contains 40 grams of silica gel. This will prevent moisture buildup inside of the CD housing.
Make sure to remove canister from its sealed foil packaging, and secure into enclosure prior to enclosure use. Double stick
tape, Velcro tape, large zip ties, or fine wire are common ways to secure the canister. Secure canister above camera- on top of
camera bracket, or where space provides. Be sure not to obscure holes on canister so as to allow it to operate effectively.
There is a small window on the canister (see white circle on image). Ensure that the crystals are blue. Occasionally,
especially in humid environments, the canister may need to be serviced. If so, the crystals in the window turn pink when silica gel
is saturated with moisture. The tin canister can be reactivated by being placed in an oven at 300F for three hours, or until crystals
turn blue again. The gel can be reactivated virtually and infinite number of times.

11
COOLDOME™Input Power Configuration: ST-CD-12VDC
110 –220 VAC Power Source
Single Phase Only 250 watt Step Down P/S
High Voltage to 12 VDC
Provided P/S Must be
Housed Indoors, or in a
Nema Electrical Enclosure
Site Power Available
High Voltage A/C Input, Single Phase, USA Wiring Color Code
Color Symbol Description
Black L Line Conductor, AKA Live, Hot
White N Neutral Conductor
Green G Ground Conductor, Safety Ground
Front of Power Supply with
terminal strip
Rear of Power Supply with
Input Voltage Selector
Select Input Voltage before
Hooking up Power Supply
110 VAC or 220 VAC
Low Voltage 12 VDC Output Terminals
Color Symbol Description
Red +, V+ Positive VDC
Black -. V- Negative VDC
12 VDC Cable to
COOLDOME
Turn Off Power or leave power disconnected during Installation of All Wiring.
Follow all local and relevant electrical codes & standards.
Test all Wiring and confirm correct voltages before wiring up & powering up ST COOLDOME.
LOW VOLTAGE RUN
LOW VOLTAGE RUN: Wire Gauge Chart for ST & D2 CD –400 BTU Cooler

12
External Power Supply
The output of the S-250-12 external power supply, can be adjusted up and down 10%. It is recommended to keep
the voltage at the S-Type adjusted to at least 11.5 vdc, but no more than 13.5 vdc. By running the enclosure higher than 13.5
vdc may cause premature fan failure. It is best to check and tune the voltage at the COOLDOME™ with a voltage meter at
the time of installation, and use the adjustment screw, located on the S-250-12, to the right side of the terminal screws, to
raise or lower the output voltage.
For all outdoor wiring, always use an outdoor rated wiring, or wiring in weather rated conduit, out from power supply,
into the COOLDOME™ . Follow all local and applicable wiring and safety standards.
Please keep D/C wire runs short, to reduce low voltage line drop. Also, the suggested wiring gauge table is
provided on previous page to further prevent low voltage line drop, and to guide you in selecting the proper wire gauge for the
dc run from the power supply to the ST-CD.
It is always advisable to use a drip loop on all wiring going directly into the ST enclosure, to reduce the risk of water
entering and damaging internal components. All fittings and seals must be firmly tightened and sealed, before placing the ST-
CD in service.
Inside the ST-CD we have provided a convenient Screw cage clamp style terminal blocks to wire the 12 vdc positive
(V+), and the 12 vdc Negative (V-) terminal. Please strip the insulation off the last 3/8” of the wires and fasten wiring securely
to terminal, using a small blade screwdriver to tighten the caging mechanism on the terminal blocks.
Please be especially attentive to wire using the Proper Polarity, so as not to damage the internal components, or
damage your camera within.
Power Supply Specifications
Input Voltage: 90-132VAC/ 176-264VAC Selected by Switch
Frequency Range: 47- 63 HZ
Input Current @ Full Load(Typ.): 4A @115VAC, 2A @230VAC
Recommended Min. Circuit Breaker for 110VAC In: 10 A (type C)
Int. Electrical. Working Temp*: -20 ~ +70C
Ext. Power Supply Output: 18A @ 12VDC up to 50C
Derate 0.5A/ deg. C over 50C
COOLDOME™Specifications
Current Draw by COOLDOME @ 12VDC:
Active Cooler OFF: 0.4A/ Active Cooler Peak On: 10.5A
Active Cooler On Typ.: 9.0A/ (Cam. Draw Not Incl.)
MTBF: 238.9Khrs min. MIL-HDBK-217F(25C)
COOLDOME™Input Power Configuration: ST-CD-12VDC
LOW VOLTAGE RUN: Voltage Drop Table (shown on prior page)
Where we conservatively try to keep the voltage drop under 1.2 vdc over the low voltage direct current run. These multipliers
are approximate, and voltage drop (Vd) is maximum at full 12 amp load at 12 vdc. This voltage drop is under fully loaded condition, when
the cooling unit is engaged, and camera and all accessories are on. Voltage drop will be much less, if the current is not at full load.
Reusable Desiccant Canister
The reusable desiccant canister contains forty grams of silica gel. This will prevent moisture
buildup inside the COOLDOME™ . Make sure to remove the canister from its foil envelope packaging
before the COOLDOME™ is put to use.
There is a small window on the canister (white circle). Ensure that the crystals are blue.
Occasionally, especially in humid environments, the canister may need to be serviced. If so, the crystals in
the window turns pink, indicating the silica gel is saturated with moisture and can be reactivated by being
placed in an oven at 300 °F for three hours or until the crystals turn blue again. The gel can be reactivated
virtually an infinite number of times.
Warning!!!: COOLDOME Enclosure runs on 12 VDC only! If high voltage is applied directly to COOLDOME™
enclosure, you will damage housing, void warranty, and create electrocution hazard that can be harmful or fatal.
Do not start wiring until you have fully read and understand these installation instructions.

13
D2 & D3 Mounting Detail

14
S-Type Strong-Arm Mount
Wall Mounting Pattern
Not to Scale
