Draper Storm Force 16048 User manual


These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.
10.8V
COMBI
DRILL
16048

1. TITLE PAGE
1.1 INTRODUCTION:
USER MANUAL FOR:10.8V Combi Drill
Stock No:16048
Part No:CHD108SF
As our user manuals are continually updated, users should make sure that they use
the very latest version.
Downloads are available from: http://drapertools.com/manuals
Draper Tools Limited
Hursley Road
Chandler’s Ford
Eastleigh
Hampshire
SO53 1YF
UK
Website: drapertools.com
Product Helpline: [phone]
General Fax: [phone]
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! – Information that draws attention to the risk of injury or death.
CAUTION! – Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal and educational use
only. Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any
other form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
1.2 REVISIONS:
Date first published April 2019.
Revised date October 2019.
Revised date September 2020.

2. CONTENTS
1 TITLE PAGE
1.1 INTRODUCTION .........................................................................................................2
1.2 REVISION HISTORY ...................................................................................................2
1.3 UNDERSTANDING THIS MANUAL ............................................................................2
1.4 COPYRIGHT NOTICE ................................................................................................. 2
2 CONTENTS
2.1 CONTENTS.....................................................................................................................3
3 WARRANTY
3.1 WARRANTY.................................................................................................................4
4. INTRODUCTION
4.1 SCOPE.........................................................................................................................5
4.2 SPECIFICATION ..........................................................................................................5
4.3 HANDLING & STORAGE.............................................................................................6
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL POWER TOOL SAFETY WARNINGS.....................................................7-8
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR COMBI DRILL.....................................8
5.3 RESIDUAL RISK ..........................................................................................................9
5.4 SAFETY INSTRUCTIONS FOR
MAINS POWERED CHARGERS & BATTERY PACKS ..........................................9-10
5.5 CONNECTION TO THE POWER SUPPLY (CHARGER) ..........................................10
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION ....................................................................................................... 11
7. UNPACKING AND CHECKING
7.1 PACKAGING .............................................................................................................. 12
7.2 DRAPER 10.8V MULTI-TOOL INTERCHANGEABLE BATTERY SYSTEM ..............12
7.3 WHAT’S IN THE BOX.................................................................................................12
8. PREPARING THE COMBI DRILL
8.1 BATTERY CHARGING............................................................................................... 13
9. BASIC COMBI DRILL OPERATIONS
9.1 DUST AND SWARF...................................................................................................14
9.2 INSTALLING AND REMOVING BITS......................................................................... 14
9.3 LED WORK LIGHT..................................................................................................... 14
9.4 FORWARD/REVERSE SELECTOR ..........................................................................14
9.5 TRIGGER ...................................................................................................................14
9.6 TORQUE SELECTION CONTROL ............................................................................ 15
9.7 HOLDING THE DRILL................................................................................................ 15
9.8 DRILLING WOOD AND PLASTIC.............................................................................. 15
9.9 DRILLING METAL ......................................................................................................15
9.10 DRILLING MASONRY................................................................................................15
9.11 SCREWDRIVING ....................................................................................................... 15
9.12 SCREWDRIVING .......................................................................................................16
9.13 DRILLING WOOD AND PLASTIC.............................................................................. 16
9.14 DRILLING METAL ......................................................................................................16
9.15 DRILLING MASONRY................................................................................................16
10. OPTIONAL ACCESSORIES
10.1 OPTIONAL ACCESSORIES....................................................................................... 17
11. MAINTENANCE & TROUBLESHOOTING
11.1 MAINTENANCE ......................................................................................................... 18
11.2 TROUBLESHOOTING GUIDE................................................................................... 18
12. DISPOSAL
12.1 DISPOSAL..................................................................................................................19
12.2 BATTERY PACK DISPOSAL INFORMATION............................................................ 19
13. EXPLANATION OF SYMBOLS
13.1 EXPLANATION OF SYMBOLS ..................................................................................20
DECLARATION OF CONFORMITY .............................................................................. ENCLOSED
- 3 -

3. WARRANTY
3.1 WARRANTY
Draper tools have been carefully tested and inspected before shipment and are guaranteed to be
free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor or
contact:
Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: [phone] or:
Product Helpline [phone].
A proof of purchase must be provided.
If upon inspection it is found that the fault occurring is due to defective materials or workmanship,
repairs will be carried out free of charge. This warranty period covering labour is 12 months from
the date of purchase except where tools are hired out when the warranty period is 90 days from
the date of purchase. The warranty is extended to 24 months for parts only. This warranty does
not apply to any consumable parts, any type of battery or normal wear and tear, nor does it cover
any damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges will
be quoted and made accordingly.
This warranty applies in lieu of any other warranty expressed or implied and variations of its
terms are not authorised.
Your Draper warranty is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the warranty period.
Please note that this warranty is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
- 4 -

4. INTRODUCTION
4.1 SCOPE
This cordless drill is designed for use with a variety of drill bits, intended for drilling holes in wood,
plastic, metal, brick etc.
This product is intended for domestic and infrequent light trade use only. Any application other
than that it was intended for, is considered misuse.
4.2 SPECIFICATION
Stock no. ................................................................................................................................ 16048
Part no. ........................................................................................................................... CHD108SF
Drilling capacity:
Wood .................................................................................................................................... 25mm
Mild steel .............................................................................................................................. 10mm
Masonry .............................................................................................................................. 10mm
Maximum torque........................................................................................................................30Nm
Torque settings ........................................................................................................................... 20+1
Revolutions per minute (no load) ........................................................................ 0-400/0-1300r/min
Impact rate ....................................................................................................... 0-6000/0-19500bpm
Chuck type ........................................................................................................................... Keyless
Sound pressure level
(LpA): ......................................................................... 83.14dB(A), K=3 db(A)
Sound power level
(LWA): ............................................................................ 94.14dB(A), K=3 db(A)
Uncertainty (K): .......................................................................................................................... 3dB(A)
Vibration level hammer drilling in metal†:............................................................
<2.70m/s² , K=1.5 m/s2
Vibration level hammer drilling in concrete†:......................................................... 5.98m/s² , K=1.5 m/s2
Weight (machine only)............................................................................................................. 1.11kg
†When sawing in wood.
Battery pack (16254):
Part No................................................................................................................................CB108LI
Type ....................................................................................................................................... Li-ion
Rated Voltage ........................................................................................................................ 10.8V
Rating .................................................................................................................................... 1.5Ah
Charger (16255):
Part No................................................................................................................................. C108LI
Rated Voltage ....................................................................................................................... 230V~
Rated Frequency ..................................................................................................................... 50Hz
Rated D.C. output voltage ..................................................................................................... 10.8V
Rated D.C. output current ........................................................................................................ 2.0A
Protective device rated current .................................................................................................... 2A
Construction ........................................................................................................................ Class II
- 5 -
Rated voltage.

- 6 -
4. INTRODUCTION
4.3 HANDLING & STORAGE
– Care must be taken when handling this product.
● Dropping this power tool could have an effect on its accuracy and could also result in personal
injury. This product is not a toy and must be respected.
– Environmental conditions can have a detrimental effect on this product if neglected.
● Exposure to damp air can gradually corrode components.
● If the product is unprotected from dust and debris, components will become clogged.
● If not cleaned and maintained correctly or regularly, the machine will not perform at its best.

- 7 -
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to become complacent
and ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the battery pack, if detachable,
from the power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR COMBI DRILL
Warnings
1. Wear ear protectors. Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a
"live" wire may make exposed metal parts of the power tool "live" and could give the operator
an electric shock.

- 8 -
5.1 GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to become complacent
and ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
5. HEALTH AND SAFETY INFORMATION
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the battery pack, if detachable,
from the power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR COMBI DRILL
Warnings
1. Wear ear protectors. Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a
"live" wire may make exposed metal parts of the power tool "live" and could give the operator
an electric shock.

- 9 -
5. HEALTH AND SAFETY INFORMATION
5.3 RESIDUAL RISK
Important note: Although the safety instructions and operating manuals for our tools contain extensive
instructions for safe working with power tools, every power tool involves a certain residual risk which
can not be completely excluded by safety mechanisms. Power tools must therefore always be
operated with caution!
5.4 SAFETY INSTRUCTIONS FOR MAINS POWERED CHARGERS &
BATTERY PACKS
Chargers
– The charger is for indoor use only.
– Prior to plugging the charger in to the supply, check that the plug and the cable are in good
repair. If either are damaged, have the defective item replaced immediately by a suitably qualified
person. If the casing of the battery charger is damaged, it is good policy to have the charger
checked over by a suitably qualified person.
– Only use a correctly rated mains outlet to provide power, do not plug into site generators, attach
to engine generators or D.C. sources. Do not use a mains socket outlet that is not switched.
– Use the correct Draper charger in conjunction with it’s corresponding battery pack (consult the
Draper website for more information or to find your local stockist).
– Do not charge any other batteries with Draper chargers. Any other application is considered
misuse.
– Do not attempt to charge battery packs that are too hot (over 30ºC) or too cold (under 5ºC), if
these conditions apply set the battery pack aside to “normalise” before proceeding with the
charging operation.
– Set up the charger and cable in a safe place where it won’t be knocked, tripped over, stepped on,
etc. and where it is well ventilated. Make sure the ventilation slots in the charger case are not
obstructed, plug the charger into the socket outlet.
– Inspect the battery pack for damage, if it is undamaged, plug it into the charger, ensuring the
correct orientation. (Most chargers and batteries have ‘keys’ etc, to make sure the battery pack is
not inserted incorrectly, if you are having to ‘force’ the battery pack into the charger, the chances
are you have it the wrong way round, check and try again.)
– Switch the charger on and check that the correct indicators illuminate, allow the battery pack to
charge (see the specific instructions for your charger). Once charging is complete, switch the
charger off, remove the battery pack and store, repeat the procedure if you have more than one
battery pack to charge.
Caution: When the battery charger has been continuously used, the battery charger will be hot.
Once the charging has been completed, give 15 minutes rest until the next charge.
– After charging is complete, unplug the charger from the socket outlet by pulling on the plug. Do
not pull on the cable. Store the charger in a dry secure place.
– If, when the charger was switched on, the correct indications did not occur, leave for two or three
minutes to allow the charger to stabilise, if the correct indications occur, allow the charging cycle
to proceed as normal. If no indication appears at all, switch off, remove the battery pack, unplug
the charger, check that the charger contacts and the battery contacts are clean and repeat the
process. If there is still no indication, switch off, remove the battery pack, unplug the charger and
check the fuse. If the fuse is blown, replace and repeat the process. If the fuse blows again, or if
the fuse was intact, attempt no further action. Refer the charger to a suitably qualified person for
repair.

- 10 -
5. HEALTH AND SAFETY INFORMATION
Battery packs
– Before charging, read the instructions.
– For indoor use. Do not expose to rain.
–
Only use Draper battery packs with this product. Consult your Draper stockist for details.
– Do not charge any other manufacturer’s battery packs using Draper chargers. Any other
application is considered misuse.
– The battery must be removed from the appliance before it is recycled.
– The charger must be disconnected from the supply mains when removing the battery.
– The battery is to be disposed of in-line with local authority procedures.
– Do not use any other than the designated Draper batteries/chargers with this product.
– Do not crush, open or burn the battery. Exposure to potentially harmful materials may occur.
– In case of fire use CO2 or dry chemical extinguisher.
– Do not expose to high temperatures >50°C. The battery may degrade at high temperatures.
– Charge battery in conditions between 5°C to 30°C with the specified charger designed for this
battery.
– Do not use battery if it has been stored at 5°C or less. Allow it to “normalise” at room temperature
before usage/charging.
Warning!
● Leaking battery packs
– The electrolyte in battery packs is corrosive. Avoid contact with the skin.
– If contact is made, flush the area with running water, pat dry and seek medical attention and
advice at the earliest opportunity.
– Inform medical personnel that the contaminant is a “high alkaline, corrosive liquid”.
– If electrolyte comes into contact with the eyes, flush with copious amounts of water only.
Seek medical attention immediately, relaying the information above.
5.5 CONNECTION TO THE POWER SUPPLY (CHARGER)
Caution: Risk of electric shock. Do not open.
This appliance is supplied with a moulded 3 pin mains plug for your safety. The value of the fuse
fitted is marked on the pin face of the plug. Should the fuse need replacing, ensure the substitute
is of the correct rating, approved to BS1362 and ASTA or BSI Kite marked.
ASTA
BSI
The fuse cover is removable with a small plain slot screwdriver. Ensure the fuse cover is replaced
before attempting to connect the plug to an electrical outlet. If the cover is missing, a replacement
must be obtained or the plug replaced with a suitable type.
If a replacement plug is to be fitted this must be carried out by a qualified electrician.
The damaged or incomplete plug, when cut from the cable should be disabled to prevent
connection to a live electrical outlet.
This appliance is Class II†and is designed for connection to a power supply matching that detailed
on the rating label and compatible with the plug fitted.
If an extension lead is required, use an approved and compatible lead rated for this appliance.
Follow all the instructions supplied with the extension lead.
†Double insulated : This product requires no earth connection as supplementary insulation is
applied to the basic insulation to protect against electric shock in the event of failure of the basic
insulation.
IMPORTANT
If using an extension lead, follow the instructions that came with your lead regarding
maximum load while cable is wound. If in doubt, ensure that the entire cable is unwound.
Using a coiled extension lead will generate heat which could melt the lead and cause a fire.

(1) Variable speed trigger switch
(2) LED worklight
(3) 10mm Keyless chuck
(4) Torque collar
(5) Hammer rotary selector
(6) Two speed gearbox
(7) belt clip
(8) Battery charge indicator
(9) Forward/Reverse selector
(10) Soft grip
(11) 10.8V 1.5Ah Li-ion battery pack
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION
- 11 -
(9)
(3)
(4) (5)
(11)
(1)
(7)
(8)
(6)
(2)
(10)

- 12 -
7.3 WHAT’S IN THE BOX
As well as the combi drill, there are
several parts not fitted or attached to it.
(12) 1hr Charger
(13) Spare 10.8V 1.5Ah Li-ion battery
pack
(12)
(13)
7. UNPACKING AND CHECKING
7.1 PACKAGING
Carefully remove the product from the packaging and examine it for any sign of damage that may have
happened during shipping. Lay the contents out and check them against the parts shown below. If any
part is damaged or missing, please contact the Draper Help Line (the telephone number appears on
the Title page) and do not attempt to use the product.
The packaging material should be retained at least during the warranty period, in case the machine
needs to be returned for repair.
Warning!
● Some of the packaging materials used may be harmful to children. Do not leave any of these
materials in the reach of children.
● If any of the packaging is to be thrown away, make sure they are disposed of correctly,
according to local regulations.
7.2 DRAPER 10.8V MULTI-TOOL INTERCHANGEABLE
BATTERY SYSTEM
This tool is supplied without a battery, and without a charger. These
optional accessories are available.
The Draper 10.8V multi-tool interchange range features an array of
machines all running from the same battery. To find out the latest range of
accessories including battery and charger please consult the Draper
website for more information or to find your local Draper stockist.

- 13 -
(12.2)
(12.1)
Charger Light Indicator
Blinking light
No light
No Light
Solid Light
Blinking Light
No Light
Blinking Light
Solid light
No light
Blinking Light
LED Indicator
Green Red
Stand by.
Damaged or faulty battery pack.
Charging.
Charging is complete.
Situation
Battery pack is too hot or cold (charging will begin
automatically when battery reaches correct charging
temperature).
8. PREPARING THE COMBI DRILL
FIG.2
8.1 BATTERY CHARGING -
FIGS. 1 - 2
Check the mains voltage. Make sure the voltage of
the power source is the same as the voltage
specified on the rating plate of the charger unit.
Plug your mains plug into the power source. The
green LED indicator (12.2) will blink indicating
stand-by mode.
Insert battery pack into battery compartment of the
charger. The red LED indicator(12.1 ) will light solid.
This indicates that the battery pack is being fast
charged automatically.
When the battery pack is fully charged, the red LED
indicator will turn off and the green LED will
illuminate solid.
Remove the battery pack from the charger and
unplug.
IMPORTANT CHARGING NOTES:
Longest life and best performance can be obtained
if the battery pack is charged when the surrounding
air temperature is between 18°C (65°F) and 24°C
(75°F). DO NOT charge battery pack in an air
temperature below 4.5°C (40°F), or above 40.5°C
(105°F). This is important and will prevent serious
damage to the battery pack.
The charger is designed to fast charge the battery
pack between 0°C (32°F) AND 45°C (113°F). If the
battery pack, when inserted, is too cold or too hot,
the charger will not charge. The green LED and the
red LED will blink alternatively and continuously to
indicate this situation. Once the air temperature is
within tolerance, the fast charging will begin.
FIG.1

- 14 -
9.1 DUST AND SWARF
A correctly fitted dust mask, suitable for the activity and in accordance to the relevant standard
must be worn.
Swarf produced by metal drilling is extremely sharp. Take precautions when clearing swarf. The
burr left on the hole is also sharp and should be removed with a suitable tool.
Always wear safety goggles.
Warning: Drill bit will be hot after use.
9.2 INSTALLING AND REMOVING BITS -
Fig. 3
The drill is fitted with a keyless chuck, this means that a
chuck key is not required to secure the drill or screwdriver bit.
i. Place the drill bit shoulder into the chuck as far as it will
go.
ii. Tighten the chuck firmly.
Note: Short screwdriver bits need only be inserted to the
depth of the hexagon shank before tightening chuck by hand.
9.3 LED WORK LIGHT - Fig. 4
To aid drilling a screwdriving in confined, inadequately lit
spaces, the LED work light (2) automatically illuminates
when the trigger is activated.
9.4 FORWARD/REVERSE SELECTOR -
Fig. 5
The forward/reverse selector switch determines the direction
of rotation of the chuck, i.e. clockwise or anticlockwise.
i. Stop the drill and push switch (9) to the left or right.
Note: When the direction switch is pushed to the left, the
chuck will rotate clockwise.
Before operation, check that the switch is set in the required
position. Do not change the direction of rotation until the
chuck comes to a complete stop.
ii. When the drill is not in use move the forward/reverse
selector switch to the neutral position (the middle setting)
to lock the trigger out.
9.5 TRIGGER - FIG.5
When the trigger (1) is depressed, the chuck will rotate
(provided the forward/reverse selector switch is set in the
forward or reverse position). This trigger switch is electronic
which enables the user to vary the speed continuously. The
speed varies according to how far the trigger is depressed.
The further it is depressed, the faster the chuck will rotate.
The lighter it is depressed, the slower it will rotate.
FIG.4
(9)
(1)
(2)
FIG.5
FIG.3
(3)
9. BASIC COMBI DRILL OPERATIONS

9. BASIC COMBI DRILL OPERATIONS
- 15 -
9.6 TORQUE SELECTION CONTROL - Fig. 6
By turning the collar (4) it is possible to adjust the amount of
torque.
Settings 1-21 provide a facility for setting the torque to the
required level. For example, this means that repetitive driving
of screws of the same size will be driven into the material to
the same torque, thus giving the same fixing strength, or in
the case of countersunk screws, these will all be driven to the
same depth in the material.
The torque control prevents the heads of small diameter
screws being twisted off when correctly set.
By turning the collar (5) it is possible to switch between rotary drilling, percussion drilling and
screwdriving functions. Set the “twist drill” setting , for rotary drilling/screwdriving, in the
“hammer drill” setting , the percussion feature will come into action. This is intended for
drilling into masonry, etc. Turn the collar to the setting to use the drill for screwdriving.
9.7 HOLDING THE DRILL - Figs. 7 - 8
The drill casing is designed to be held comfortably in two
ways,
1. By the handle.
2. Or by the in-line support grip.
9.8 DRILLING WOOD AND PLASTIC
To prevent splitting around the drill holes on the reverse side,
place a piece of scrap timber under the material to be drilled.
9.9 DRILLING METAL
Metals such as sheet steel, aluminium and brass may be
drilled. Mark the point to be drilled with a centre punch to help
the drill bit tip to locate. A drop of oil on the area will aid
cutting and help prolong the life of the bit.
9.10 DRILLING MASONRY
Start drilling at a low speed to prevent the drill bit from
wandering. Once penetration is achieved, fully depress the
trigger to achieve maximum speed and hammer power.
9.11 SCREWDRIVING
To prevent slip or damage to the screw head, match the
screwdriver bit to the screw head size. To remove screws,
move the direction switch to the reversing position and apply
pressure to the screw head and depress the trigger slowly).
Screwdriver bits are consumable items.
Before drilling check that there are no hidden hazards such as electrical cables, water or gas
pipes running below the surface use a metal/voltage detector.
Do not expose either the drill or charger to rain or water.
Do not overcharge the battery (more than six hours) as this could damage the battery cells.
FIG.7
FIG.8
(4)
(5)
FIG.6

FIG.10
FIG.9
9.13 DRILLING WOOD AND PLASTIC –
FIG. 9
To prevent splitting around the drill holes on the
reverse side, clamp a piece of scrap timber
under the material to be drilled.
9.14 DRILLING METAL – FIG.10
Metals such as mild steel, aluminium and brass
may be drilled.
– Mark the point to be drilled with a centre
punch to help the drill bit tip to locate.
– A drop of oil on the drilled area will aid
cutting and help prolong the life of the bit.
Note: Although metal drilling is technically within
the capabilities of this drill, its rotational speed
is not always fast enough to achieve perfect
results every time. For this reason, extra
caution should always be taken when drilling
metal, as snagging of the drill may occur.
9.15 DRILLING MASONRY
Start drilling at a low speed to prevent the drill bit
from wandering. Once penetration is achieved, fully
depress the trigger to achieve maximum speed and
hammer power.
9.12 SCREWDRIVING
To prevent slip or damage to the screw head, match the screwdriver bit to the screw head size.
To remove screws:
– Move the direction switch to the reversing position and apply pressure to the screw head and
depress the trigger slowly).
Screwdriver bits are consumable items.
- 16 -
9. BASIC COMBI DRILL OPERATIONS
B
C
B
C
A
A

- 17 -
5.1 GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to become complacent
and ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the battery pack, if detachable,
from the power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR COMBI DRILL
Warnings
1. Wear ear protectors. Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a
"live" wire may make exposed metal parts of the power tool "live" and could give the operator
an electric shock.
10. OPTIONAL ACCESSORIES
10.1 OPTIONAL ACCESSORIES
A full range of accessories are available from Draper Tools.
Please visit our website for details: www.drapertools.com

11.1 MAINTENANCE
Regular inspection and cleaning reduces the necessity for maintenance operations and will keep
your tool in good working condition.
The motor must be correctly ventilated during tool operation. Avoid blocking the air inlets and
vacuum the ventilation slots regularly.
11.2 TROUBLESHOOTING GUIDE
Note: Remove the battery pack before carrying out adjustment, servicing or maintenance.
11. MAINTENANCE & TROUBLESHOOTING
Drill does not operate. – Battery pack no charge.
– Forward/reverse not
selected.
– battery pack faulty or
damaged.
– Re-charge battery pack.
– Select forward/reverse.
– Replace battery pack.
Motor runs, but slowly/ losing
power.
– Battery pack no charge.
– Battery pack faulty or
damaged.
– Re-charge battery pack.
– Replace battery pack.
Chuck does not close or grip – Swarf in chuck. – Clean inside of chuck with
cleaning fluid.
Battery pack doesn’t charge
/
non-llumination / non
illumination of charger.
– Fuse blown in charger
plug.
– Charger faulty.
– Replace fuse.
– Replace charger.
Problems Possible cause Required action
- 18 -
5.1 GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools allow you to become complacent
and ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or remove the battery pack, if detachable,
from the power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR COMBI DRILL
Warnings
1. Wear ear protectors. Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a
"live" wire may make exposed metal parts of the power tool "live" and could give the operator
an electric shock.

- 19 -
Li-ion
12. DISPOSAL
12.1 DISPOSAL
– At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is
disposed of according to national regulations.
– Contact your local authority for details of collection schemes in your area.
In all circumstances:
● Do not dispose of power tools with domestic waste.
● Do not incinerate.
● Do not dispose of WEEE* as unsorted municipal waste.
* Waste Electrical & Electronic Equipment.
12.2 BATTERY PACK DISPOSAL INFORMATION
Warning!
● Do not put battery pack in fire or mutilate – cells may burst or release toxic materials.
● Do not short circuit cells, may cause burns.
● The battery pack must be removed from the appliance before it is scrapped.
● The battery pack is to be disposed of safely.
● Do not mutilate batteries, corrosive electrolyte will be released.
● Do not dispose of batteries or cells in a charged condition.
Expired batteries must be recycled/disposed of in accordance with the appropriate regulation or
legislation. They should be returned to your local warranty agent/stockist.

- 20 -
99
Single value noise marking.
(Maximum declared A-Weighted
sound power level in decibels).
13.1 EXPLANATION OF SYMBOLS
13. EXPLANATION OF SYMBOLS
Read the instruction manual.
Wear safety glasses.
Wear ear defenders.
Wear protective gloves.
Long and loose hair must be
contained or securely tied back.
Do not abandon into the
environment.
Keep out of the reach of children.
Direction of rotation.
Warning!
Warning! Risk of crushing.
For indoor use only.
Do not expose to rain.
Lithium-ion product.
WEEE –
Waste Electrical &
Electronic Equipment.
Do not dispose of Waste Electrical
& Electronic Equipment in with
domestic rubbish.
Class II construction
(Double insulated).
Polarity indication.
Rated voltage.
Do not incinerate or
throw onto fire.
Fuse.
130°
++++++++
++++++++
++++++++
++++++++
++++++++
++++++++
