Draper Orbiter Manual

Copyright © 2012 Draper Inc. Form Orbiter_Inst12 Printed in U.S.A.
Installation/Operating Instructions
Orbiter by Draper
If you encounter any difficulties installing or servicing your Orbiter, call your dealer or Draper, Inc. in
Spiceland, Indiana, 765-987-7999, or fax [phone]. Outside the United States, fax [phone].
®
Planning
①Based on screen location and projector specifications, determine proper
position for projector installation.
②Confirm that there is adequate space for installation and operation.
③Arrange to provide service access to the unit.
④Space required above unit is the same with or without Environmental Air
Space Housing.
⑤When installed with Environmental Air Space Housing unit is suitable for
use in an environmental air space in accordance with in accordance with
Section 300.22(C) of the National Electrical Code, and Section 2-128, 12-
010(3) and 12-100 of the Canadian Electrical Code, Part 1, CSA C22.1.
⑥ Total capacity of lift is 26 lbs (11.8 kg), including projector and closure panel.
As Soon As Orbiter Arrives
➀Open carton and inspect for damage.
➁Locate the following parts:
A. The unit itself
B. Controls
C. Any optional equipment
➂Test unit before installing.
Hanging Unit
The Orbiter is provided with four (4) mounting points for suspending the unit
from above. The unit should be guy wired or blocked to prevent swinging. All
installations should observe the following guidelines:
➀Installer must ensure that all fasteners and supports are of adequate
strength to securely support Orbiter and projector. It is recommended
that hardware structure be able to hold at least four times the combined
weight of the lift and projector.
➁Fastening methods must be suitable for mounting surface, and securely
anchored so that vibration or abusive pulling on unit will not weaken
installation.
➂Bottom of unit must be unobstructed after installation. Sufficient clearance
must be allowed below projector.
➃Do not use unit to support adjacent ceiling, light fixtures, etc.
➄Do not complete the ceiling below unit until electrical connections have
been completed and unit has been operated successfully.
Electrical Connections
Unit operates on 12V DC.
The Orbiter is shipped closed
Please note: Make sure electrical supply has been disconnected before
attempting to connect Orbiter to electricity.
Orbiter must be installed in accordance with the requirements of the Local
Building Codes, the Canadian Electrical Code (CEC), CAN/CSA C22.1 and
the National Electric Code(NEC), NFPA 70. All operating switches should be
“off” before power is connected.
110V or 220V AC for projector must be supplied by others. Orbiter should be
operated and checked prior to installing projector.
Caution
①Read instructions completely before proceeding.
②Follow instructions carefully. Installation contrary to instructions
invalidates warranty.
③Do not obstruct operation of Orbiter with fingers or any object.
Serious injury or damage could result.
④Entire bottom of unit must be unobstructed to permit proper operation.
⑤Unit operates on 12V DC.
⑥Unit must be installed by qualified personnel.
Note: Unit has been thoroughly inspected and tested at factory and found
to be operating properly prior to shipment.
Operation
Unit is automatically supplied with a double pole double throw switch. When
unit is first operated, be cautious! If unit fails to operate when the switch is
flipped “down”, return switch to “off” and recheck electrical connections before
proceeding. Cycle unit down and up several times to confirm satisfactory
operation.
Optional DC Motor Control (Not CE Approved)—Optionally available to
allow remote control, RS232 or Ethernet connection.
Optional Infrared or Radio Frequency Remote Control (Not CE
Approved)—If ordered, a three-button transmitter is provided, with “up”,
“down”, and “stop” buttons. Unit starts opens or closes when appropriate
button is pressed, and may be stopped by pressing “off” button. When
using RF or IR control, a three-button up-stop-down wall switch is also
recommended and optionally available. DC Motor Control required.*
Optional RS232/Ethernet (Not CE Approved)—Serial communication and
network communication optionally available with wall switches, RF or IR
remote. When using RS232 or Ethernet control, a three-button up-stop-down
wall switch is also recommended and optionally available. DC Motor Control
required.*
* Please Note: If unit is being operated using RF, IR, RS232 or Ethernet,
but you still wish to have a wall switch, the standard double pole, double
throw switch provided with the lift will not work.You must use the
optional three-button up-stop-down switch.
Closed
Rotating
Open
Orbiter Operation
Angled Ceiling Adapter
For installing the Orbiter in an angled ceiling, use the optional Angled
Ceiling Adapter. Instructions for installing the adapter can be found in the
Angled Ceiling Adapter kit. Once the adapter is installed, return to the Orbiter
instructions and complete installation of the Orbiter. This allows the Orbiter to
be installed to a maximum of 90°.
These Installation/Operating Instructions are available in the official language
of the country where you purchase the product. Please contact your
distributor to request a copy.
Vous pourriez demander les instructions d’installation et d’opération traduises
dans la langue officielle du pays ou vous achetez le produit. Veuillez
demander à votre distributeur.
Die Gebrauchsanweisung für Installation und Konstruktion sind in der
offiziellen Sprache des Landes, indem Sie das Produkt gekauft haben,
vorhanden. Fragen Sie die jeweilige Verkaufs-Abteilung.
Projector is Horizontal
when in use

Orbiter by Draper, Inc. page 2 of 4
www.draperinc.com (765) 987-799
9
285/8"/72.7 cm
(329/16"/82.7 cm)
1315/16"/35.4 cm
(1515/16"/40.5 cm)
37/8"/9.8 cm
(57/8"/14.9 cm)
3/4"/2 cm
(3/4"/2 cm)
213/16"/7.1 cm
(23/4"/7 cm)
19/16"/4 cm
(19/16"/4 cm)
1813/16"/47.8 cm
(227/8"/58.1 cm)
193/8"/49.2 cm
(235/16"/59.2 cm)
411/16"/11.9 cm
(411/16"/11.9 cm)
215/16"/54.1 cm
(251/4"/64.1 cm)
3/4"/2 cm
(3/4"/2 cm)
13/16"/3 cm
(13/16"/3 cm) 213/8"/54.3 cm
(253/8"/64.5 cm)
23"/58.4 cm
(2615/16"/68.4 cm)
2011/16"/52.5 cm
(245/8"/62.5 cm)
37/8"/9.8 cm
(37/8"/9.8 cm)
Knockout provided
at each end for
cable and power
connections.
51/2"/14 cm
221/4"/56.5 cm
(263/16"/66.5 cm)
1815/16"48.1 cm
(227/8"/58.1 cm)
205/8"/52.4 cm
(249/16"/62.4 cm)
259/16"/65 cm
(291/2"/75 cm)
23"/58.4 cm
(2615/16"/68.4 cm)
3"/7.6 cm
(3"/7.6 cm)
7/8"/2.2 cm
(7/8"/2.2 cm)
2011/16"/52.5 cm
(245/8"/62.5 cm)
213/8"/54.3 cm
(253/8"/64.5 cm)
41/4"/10.8 cm
(41/4"/10.8 cm)
37/8"/9.8 cm
(37/8"/9.8 cm)
1813/16"/47.8 cm
(223/4"/57.8 cm)
193/8"/49.2 cm
(235/16"/59.2 cm)
Orbiter—Dimensions
Orbiter with Environmental Air Space Housing—Dimensions
Please note: non-bracketed
dimensions are for Model A;
bracketed dimensions are
for Model B.
Item Quantity Description
1 1 Orbiter
2 1 Orbiter Environmental Air Space Housing
(individual pieces listed below)
3 2 End Environmental Air Space Housing Panel
4 1 Front Environmental Air Space Housing Panel
5 1 Top Environmental Air Space Housing Panel
6 1 Lower Large Environmental Air Space Housing Panel
7 1 Lower Small Environmental Air Space Housing Panel
8 1 Rear Side Environmental Air Space Housing Panel
9 26 #8-32 x.375 (9.5 mm) Zinc Hex Head Screw/Washer
10 8 #10-32 x.375 (9.5 mm) Zinc Hex Head Screw/Washer
11 26 #8-32 Zinc Keps Nu
t
3
4
5
6
7
8
9
11
1
Orbiter with Environmental Air Space Housing—Exploded View

Orbiter by Draper, Inc. page 3 of 4
www.draperinc.com (765) 987-799
9
Projector Installation
The Orbiter uses a universal projector mount system. The parts kit
contains:
-2 x long arms
-4 x short arms
-4 x M3, 4 x M4, 4 x M5 and 4 x M6 mounting bolts (30mm in length)
-4 spacers (1/2" [12.7], 5/8" [15.875], 3/4" [19.05], 7/8" [22.225 mm])
➀Determine which size mounting bolts suit your projector, and set others
aside. They are no longer required. If your projector has only three
mounting holes, set aside one of the skyhook arms.
➁Assemble the universal mount (see diagram at right) using arms
appropriate to projector. Spread out the arms so each end is over one of
the mounting holes.
➂Connect universal mount to Projector. Fit the 1/2" (12.7 mm) spacer under
the lowest arm, the 5/8" (15.875 mm) under the next arm and so on. If the
projector base is uneven, you may use combinations of spacers and arms
to ensure the triangular plate is horizontal.
➃Do not tighten any bolts yet.
➄Move the position of the triangular plate over the centre of the projector,
with the edge with the two holes towards the front (lens).
➅Tighten the mounting bolts. The projector and universal mount are ready to
be installed to the Orbiter.
➆Open the Orbiter and bolt the triangular projector plate to the underside of
the Orbiter using the supplied ¼" (6.35 mm)-20 bolts and springs. These
bolts will also give you Roll and Tilt adjustment to align your image on the
screen, while the center 5/16" (8 mm) bolt provides Yaw adjustment. The
springs will ensure that the projector is held still during motion. Do not
install the projector plate without springs.
Please Note: Projector can be installed either parallel or perpendicular
to the pivot axis of the Orbiter, as long as projector is small enough.
Extra Adjustment
To adjust the amount of rotation, rotate the multiflip arms to strike the limit
switches for either more or less rotation.
For additional adjustment, you can also bend the arms of the
microswitches.
springs
Detail: ¼" (6.35 mm)-20 bolts and Spring
¼" (6.35 mm)-20
Bolt and
Washer
Spring
Multiflip Arms
Roll Tilt Yaw
In order to use the
universal mount, the
mounting holes in
your projector must be
located within the area
indicated by the circle.
Minimum: 3" (7.6 cm)
Maximum: 13" (33 cm)
Caution: Beware of pinch point.

Orbiter by Draper, Inc. page 4 of 4
Wiring Diagrams
www.draperinc.com (765) 987-799
9
Optional Wireless (RF, IR), RS232 and IP Control
Standard Switch Control
Please note: CE certification
applicable on 220V units only.
DC CONVERTER
OUTPUT: 12 VDC
1.25-1.5 Amp
24 VDC MOTOR
WALL SWITCH
(DPDT)
RD
BK
BN
BL
BN
BL
DASHED LINES INDICATE
WIRES PROVIDED BY INSTALLER
LS1
D1 D2
LS2
STOP
WALL SWITCH
3 BUTTON
DOWN - BLACK
COM - WHITE
UP - RED
DASHED LINES INDICATE
WIRES PROVIDED
BY INSTALLER
AUX PORT- For connecting multiple
controls together (up to six total-
connect from AUX to Eye). EYE PORT- For IR EYE; RF Receiver or LED
Switch. If more than one of these three is
used with control, a splitter is required.
DC Motor Control
DC CONVERTER
OUTPUT: 12 VDC
1.25-1.5 Amp
24 VDC MOTOR
BL BL
BN BN
LS2
D2 D1
LS1
WH
(-)
(+)
Black wire with white type
