Epson PowerLite 715c User manual

Component video input
• Great for movie viewing; the best video quality of any
superportable available
Easy installation, setup and operation
• Zoom lens adds versatility
• 15º digital keystone correction adjusts the angle, aspect ratio
and shape of projected images
• EPSON SizeWise™resizing technology supports virtually any
computer (Mac or PC) up to UXGA (1600 x 1200)
Renowned Epson service and support
• Comprehensive 2-year warranty
• 90-day bulb warranty for added dependability
• EPSON PrivateLineSM dedicated toll-free support line available
from 6 a.m. to 6 p.m. PST Monday – Friday. This program is free
for the duration of the warranty
• EPSON Road Service Program provides a replacement projector,
typically within 24 hours. This program is free for the duration
of the warranty
• Interntional warranty in over 45 countries, offered exclusively
by Epson
*PCMCIA adapter required, not included
Twelve hundred lumens in a 6 lb package–when you
size it all up, it’s the perfect solution for highly effective mobile
presentations. The brightest 6 lb projector in its class, the
EPSON PowerLite 715c consistently delivers sharp, vivid images, even
in the most challenging lighting conditions. Take it across the hall or
around the world. Its award-winning 3-LCD design and exceptional
video processing make it the ideal partner for business professionals. Its
innovative EPSON EasyMPTM technology facilitates PC-free presentations
so you can leave your laptop and cables behind without sacrificing
advanced features. This technology also delivers lightning-fast image
renderings plus 15 transitional effects. And, with its “power-on-and-
go” operation, even novice users can be up and running in no time.
Having brought over 50 years of engineering excellence to the business
world, Epson continues to contribute technologically-advanced, user-
friendly solutions like the EPSON PowerLite 715c–
the perfect combination of portability and performance.
Ultra bright 1200 lumens
• Projects brilliant images, even in the most challenging lighting
conditions
Superior detail and razor-sharp contrast
• 3 LCD technology offers three 0.9" high aperture LCDs for
evenly distributed color
• XGA (1024 x 768) resolution delivers sharp, vivid detail
• 400:1 contrast ratio for blacker blacks and whiter whites
Compact and lightweight
• Only 6 lb, allowing travel flexibility for presentations of any size,
in any environment
PC-free presenting with EPSON EasyMP
• Auto-run capability – just power on the projector and
begin presenting
• Unique editing capability:
- Rearrange the order of projected images, individually or
as a group
- Select and hide individual images
- Customize your presentation to your audience
• Easy to use – drag and drop your entire presentation using
Epson conversion software
• Smooth picture transitions – jpeg or bitmap images advance as
fast as 40 milliseconds, either automatically or with a mouse click
• 15 PowerPoint®-type transitions – includes wipes, dissolves, etc.
for smooth, professional presentations
• Make notes and annotations directly on the image and capture
them for future reference
• Memory card slot – multicard capability including PCMCIA Flash
Memory, Compact Flash*, SmartMedia* and Memory Stick*
cards
CYAN
MAGENTA
YELLOW
BLACK
PMS 519C
PMS 5483C
EPSON®
EPSON PowerLite®715c
The stand alone projector that stands above the rest
full-featured
IR remote control
zoom lens
stylish metallic
silver finish
Front View
Back View
composite video
audio in/out
s-video
EasyMP PC
card slot
audio left/right
PL 715c Cat Sheet c10884 2/7/01 1:57 PM Page 1 (2,1)

Video I/O
Display performance NTSC: 550 line
PAL: 550 line
(Depend on observation
of multi-burst pattern)
Input signal NTSC/NTSC4.43/NTSC5.0/
PAL/M-PAL/N-PAL/PAL60/SECAM
Input terminal Composite video: RCA x 1
S-video: Mini D-sub 15pin x 1
Component video: Mini D-sub 15pin x1
(common with component video)
Audio terminal RCA x 2
Output terminal Stereo mini jack
(common analog RGB audio output)
(plug in, then speaker off)
Control I/O
Mouse/Serial I/O
I/O terminal Din 9pin x 1/USB type B x 1
Mouse compatibility PS/2, ADB, Serial, USB
Security Kensington-style lock provision
Supplied Accessories
Power cord, RCA video/audio cable, remote control,
2 batteries, computer cable HD15/HD15, PS/2 mouse cable, USB mouse
cable, soft case, memory card set (8MB Compact Flash Card), application
software CD-ROM (EMP Slidemaker for EasyMP), Start Here kit
Warranty
Standard two year limited warranty, international warranty, 90-day lamp
warranty, EPSON Road Service Program and EPSON PrivateLine dedicated
toll-free support (U.S. and Canada only)
Product/Accessory Part Numbers
EPSON PowerLite 715c projector EMP-715
Samosonite wheeled soft case ELPKS35
Shoulder case ELPKS31
Shoulder case ELPKS32
ATA molded hard shell carrying case ELPKS30
Component video interface cable ELPKC19
50” portable screen ELPSC06
60” insta-theatre screen ELPSC07
80” insta-theatre screen ELPSC08
Replacement lamp ELPLP14
Mac adapter set ELPAP01
Kensington security lock ELPSL01
Ceiling mount ELPMB32
Suspension adapter for ceiling mount, 1-1/2" pipe ELPMBAST
Suspension adapter for ceiling mount, 1" pipe ELPMBAPS
Mediaphile PAS presentation audio system ELPPAS1
Mediaphile wireless microphone and satellite speakers ELPCVVS1
Support-The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
SM
EPSON PowerLite 715c Specifications
Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount/stack
LCD
Size 0.9" Dream Panel
Driving Method EPSON Poly-Silicon TFT Active Matrix
Pixel Number 786,432 dots (1024 x 768) x 3
Native Resolution XGA
Aspect Ratio 4:3 (supports 16:9, 5:4)
Pixel Arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 2.0 to 2.2
f-number 35mm to 42mm
Zoom ratio 1:1.2
Lamp
Type 150W UHE
Life (typical) 1000H
Screen Width Ratio: (Distance/Width) 1.83 to 2.23:1
Screen Size (Projected Distance) 26" to 300"
Keystone Correction ±15 degrees
Brightness (typical) 1200 ANSI lumens
Contrast Ratio 400:1
Brightness Uniformity (typical) 85%
Color Reproduction 24 bit; 16.7 mil
Sound Output 1W monaural
Operating Temperature 5º C to 35ºC (41ºC to 95ºF)
Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC
Power Consumption 220W/4W @ standby mode
Dimensions (including lens and feet) 10.5"D x 8.4"W x 2.8"H
Weight 6.0 lb
Fan Noise 42db
Effective Scanning Frequency Range
Pixel clock 13.5MHz to 162MHz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 85Hz
Remote Control Features
Keystone, picture in picture, special effects, source selection, power, resize,
right/left mouse click, EasyMP, volume, presets
RGB Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1600 x 1200
1280 x 1024
800 x 600
640 x 480
Input terminal
Video Mini D-sub 15pin x 1
Audio Stereo mini jack
Output terminal
Audio Stereo mini jack
(common video
audio output)
(plug in, then speaker off)
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
Specifications and terms are subject to change without notice. EPSON is a registered trademark and EasyMP is a trademark of Seiko Epson Corporation. PowerLite is a registered trademark,
SizeWise is a trademark and EPSON Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or
registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2000 Epson America, Inc. CPD-10884 50K 2/01 GAC
