Draper VC300 User manual

VACUUM CLEANER
■STOCK No.59333 ■PART No.VC300
01/2000
• INSTRUCTIONS •
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE
THE SAFE AND EFFECTIVE USE OF THIS TOOL.
GENERAL INFORMATION
This manual has been compiled by Draper Tools and is an integrated part of the power tool equipment, which should be kept with the
machine.
This manual describes the purpose for which this tool has been designed and contains all the necessary information to ensure its correct
and safe use.We recommend that this manual is read before any operation of the machine, before performing any kind of adjustment to the
machine, and prior to any maintenance tasks. By following all the general safety instructions contained in this manual, it will ensure both
machine and operator safety, together with longer life of the tool itself.
All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the machine.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the Draper Tool policy of continuous
improvement determines the right to make modifications without prior warning.

-2 -
VACUUM CLEANER
■STOCK No.59333 ■PART No.VC300
CONTENTS: Page No’s.
Specification.....................................................................................................3
Guarantee ........................................................................................................3
Power supply....................................................................................................4
General safety instructions...............................................................................5
Know your vacuum ...........................................................................................6
Operating instructions......................................................................................7
Maintenance.....................................................................................................8
Optional accessories........................................................................................9
We
Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire.
SO53 1YF. England.
Declare under our sole responsibility that the product:
Part Number:- VC300 Stock Number:- 59333
Description:- Vacuum Cleaner.
To which this declaration relates is in conformity with the following directive(s)
73/23 EEC and 89/336 with reference to EN60335-1:1988+A2:1988,
EN60335-2-2:1988+A2, A52:1990, EN50082-1:1992,
EN55014:1987+A2:1990, EN60555-2:1987 & EN60555-3:1987.
DECLARATION OF CONFORMITY
01/2000

- 3 -
The Draper Tools policy of continuous improvement determines the right to change
specification without notice.
Part No....................................................................................................................VC300
Stock No...................................................................................................................59333
Voltage......................................................................................................................240V
Motor................................................................................................................300W max
Fan speed ...................................................................................20,500RPM (+/-600RPM)
Brush speed ........................................................................................6,100 (+/-600RPM)
Sound pressure level...........................................................................................89 (db)A
Dust capacity..........................................................................................................400 ml
Noise level ..........................................................................................................90 (db)A
NOTE: This vacuum is intended for dry pick-up only (do not attempt to vacuum liquids
asbestos, burning cigarettes, ashes, etc).
SPECIFICATION
GUARANTEE
Draper machine tools have been carefully tested and inspected before shipment and are guaranteed
to be free from defective materials and workmanship for a period of 12 months from the date of
purchase except where tools are hired out when the guarantee period is reduced to ninety days from
the date of purchase.
Should the machine develop any fault please return the complete tool to your nearest authorised
warranty repair agent or contact Draper Tools Limited, Chandler’s Ford, Eastleigh, Hampshire SO53
1YF. England. Telephone [phone] .
If upon inspection it is found that the fault occurring is due to defective materials or workmanship
repairs will be carried out free of charge. This guarantee does not apply to normal wear and tear,
nor does it cover any damage caused by misuse, careless or unsafe handling, alterations, accident,
or repairs attempted by any personnel other than the authorised Draper warranty repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the 12 month period.
Please note that this guarantee is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.

POWER SUPPLY
3 6 10 13
Extension cable length Wire Size mm2
7.5m 0.75 0.75 1.0 1.25
15m 0.75 0.75 1.0 1.5
22.5m 0.75 0.75 1.0 1.5
30m 0.75 0.75 1.25 1.5
45m 0.75 1.25 1.5 2.5
Ampere rating
(on Name plate)
CONNECTING YOUR MACHINE TO THE POWER SUPPLY: (240V)
To eliminate the possibility of an electric shock your machine has been fitted with a BS
approved, non rewireable moulded plug and cable which incorporates a fuse, the value
of which is indicated on the pin face of the plug. Should the fuse need to be replaced an
approved BS1362 fuse must be used of the same rating, marked thus .
The fuse cover is detachable, never use the plug with the cover omitted. If a replacement
fuse cover is required, ensure it is of the same colour as that visible on the pin face of the
plug (i.e. red). Fuse covers are available from your Draper Tools stockist.
If the fitted plug is not suitable, it should be cut off and destroyed. *The end of the cable
should now be suitably prepared and the correct type of plug fitted. See below.
*WARNING:
A plug with bare flexible wires exposed is hazardous if engaged in a live power socket
outlet.
WARNING: THIS APPLIANCE IS DOUBLE INSULATED.
Blue – Neutral, Brown – Live.
As these colours may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal which is marked with
the letter ‘N’ or coloured black or blue.
The wire which is coloured brown must be connected to the terminal which is marked
with the letter ‘L’ or coloured red or brown.
CONNECTING YOUR MACHINE TO THE POWER SUPPLY (110V)
To eliminate the possibility of an electric shock your machine has been fitted with a BS
approved, rewireable plug and cable. If the fitted plug is not suitable, it should be
removed, the end of the cable should be suitably prepared and the correct type of plug
fitted. See below.
WARNING: THIS APPLIANCE IS DOUBLE INSULATED.
Single phase 110 volt machines must be connected using the relevant coding and
matching the colour of the flexible cable to that of the plug. The procedure is as follows:
1. Connect brown coloured core to plug terminal marked letter ‘L’ (live).
2. Connect blue colour core to plug terminal marked letter ‘N’ (neutral).
- 4 -

- 5 -
GENERAL SAFETY INSTRUCTIONS
FOR POWER TOOLS
1. KNOW YOUR POWER TOOL
Read and understand the owner's manual and labels
affixed to the tool. Learn its application and limitations as
well as the specific potential hazards peculiar to this tool.
2. KEEP WORK AREA CLEAN
Cluttered areas and benches invite accidents. Floors must
not be slippery due to oil or sawdust.
3. AVOID DANGEROUS ENVIRONMENTS
Do not use power tools in damp or wet locations, or
expose them to rain. Keep work area well lit. Provide
adequate space surrounding the work area. Do not use in
environments with a potentially explosive atmosphere.
4. KEEP CHILDREN AWAY
All visitors should be kept a safe distance from work area.
5. STORED TOOLS
When not being used, all tools should be stored in a dry,
locked cupboard or out of the reach of children.
6. WEAR PROPER CLOTHING
Do not wear loose clothing, neckties or jewellery (rings,
wristwatches) to catch in moving parts. NONSLIP footwear
is recommended. Wear protective hair covering to contain
long hair. Roll long sleeves above the elbow.
7. USE SAFETY GOGGLES (Head Protection)
Wear CE approved safety goggles at all times. Normal
spectacles only have impact resistant lenses, they are
NOT safety glasses. Also, use face or dust mask if
application is dusty and ear protectors (plugs or muffs)
during extended periods of operation.
8. NOISE LEVELS
Some types of machines may have high noise levels when
working. In such cases ear protection must be worn.
9. VIBRATION LEVELS
Hand held power tools produce different vibration levels.
You should always refer to the specifications and relevant
Health and Safety guide.
10. DUST EXTRACTION
If your tool is fitted with a dust extraction fitting, always
ensure that it is connected and being used with a dust
extractor.Vacuum cleaners can be used if suitable for the
material being extracted.
11. PROTECT YOURSELF FROM ELECTRIC SHOCK
When working with power tools, avoid contact with any
earthed items (e.g. pipes, radiators, hobs and
refrigerators, etc.). If you are using a power tool in
extreme conditions (e.g. high humidity or generating
metal dust), always use an RCD (residual current device)
at the power socket.
12. STAY ALERT
Always watch what you are doing and use common sense.
Do not operate a power tool when you are tired or under
the influence of alcohol or drugs.
13. WHEN WORKING OUT OF DOORS
Only use extension leads designed for that purpose.
14. ACCESS TO MAINS SOCKET
If a stationary machine is fitted with a moulded plug and
cable, the machine should not be positioned so that
access to the mains socket is restricted.
15. DISCONNECT POWER TO THE TOOL
When not in use, before servicing and when changing
accessories such as cutters, etc.
16. AVOID ACCIDENTAL STARTING
Make sure the switch is in the OFF position before
plugging the machine into the power supply.
17. NEVER LEAVE MACHINE RUNNING UNATTENDED
Turn power off. Do not leave machine until it comes to a
complete stop.
18. DO NOT ABUSE THE CORD
Never carry the tool by the power cable or pull it from
the socket. Keep the power cable away from heat, oil and
sharp edges.
19. NEVER STAND ON TOOL
Serious injury could occur if the tool is tipped or if the
cutting tool is accidentally contacted. Do not store
materials above or near the tool, so that it is necessary to
stand on the tool to reach them.
20. CHECK DAMAGED PARTS
Check for damage to parts, breakage of parts, mountings
and any other conditions that may affect its operation.
A guard or other part that is damaged should be properly
repaired or replaced.
21. KEEP GUARDS IN PLACE
And in working order.
22. MAINTAIN TOOLS WITH CARE
Keep tools sharp and clean for the best and safest
performance. Follow instructions for lubricating and
changing accessories. All extension cables must be
checked at regular intervals and replaced if damaged.
Always keep the hand grips on the tool clean, dry and
free of oil and grease.
23. USE RECOMMENDED ACCESSORIES
Consult the owners manual for recommended
accessories. Follow the instructions that accompany the
accessories. The use of improper accessories may cause
hazards.
24. REMOVE ADJUSTING KEYS AND WRENCHES
Form a habit of checking to see that keys and adjusting
wrenches are removed from the tool before turning it on.
25. SECURE WORK
Use clamps or a vice to hold work.This frees both hands
to operate the tool.
26. DO NOT OVERREACH
Keep proper footing and balance at all times.
27. USE RIGHT TOOL
Do not force the tool or attachment to do a job for which it
was not designed.
28. DO NOT FORCE TOOL
It will do the job better and safer at the rate for which it
was designed.
29. DIRECTION OF FEED
Feed work into a blade or cutter against the direction of
rotation of the blade or cutter only.
30. WHEN DRILLING OR SCREWING INTO WALLS
Always make sure there is no danger of hitting any hidden
power cables, water or gas pipes in the wall.
WARNING
Please read the following instructions carefully, failure to do so could lead to serious personal injury.
IMPORTANT
Draper Tools Limited recommends that this machine should not be modified or used for any application other
than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in
writing and we will advise you.
IMPORTANT NOTE
Residual Risk. Although the safety instructions and operating manuals for our tools contain extensive
instructions on safe working with power tools, every power tool involves a certain residual risk which can not be
completely excluded by safety mechanisms. Power tools must therefore always be operated with caution !

-6 -
1. On/off switch
2. Power lead
3. Hand grip
4. Release button for
dust container
5. Dust container with
filter
6. Drive belt cover
7. Brush housing
GETTING TO KNOW YOUR
✚✌
✘✌
✙✌
✕✌
✛✌
✖✌
✗✌

- 7 -
OPERATING INSTRUCTIONS
THE VC300 IS ASSEMBLED AND READY FOR
USE
TO OPERATE
Connect the vacuum to the power supply. Hold
the handle ✪✌ firmly, with your thumb slide the
switch ✫✌forward to turn the vacuum on, and
back to turn off.
REMOVAL AND CLEANING OF FILTER
To remove the filter for cleaning depress the
release button ✬✌ and remove the dust
container ✭✌ carefully. Remove the dust filter
✮✌ so you do not disturb any dust collected.
Empty the contents of the dust container. To
clean filter brush away any excess dust/dirt. If
needed the filter can be washed with warm
water. The filter must be dry before re-fitting it to
the dust container.
WARNING
DO NOT OPERATE WITHOUT A FILTER FITTED.
Fig.1
✫✌
✪✌
✭✌
Fig.2
✮✌
✬✌

-8 -
MAINTENANCE
REPLACING THE DRIVE BELT
IMPORTANT
Disconnect the vacuum from the power supply
before replacing any parts.
1. Remove screw ✯✌to release front cover
✰✌.FIG.3.
2 Remove the two screws ✱✌ holding the brush
housing ✳✌ in place and remove. FIG.4.
3.Holding the brush ✴✌ in the centre, pull
the belt off the driveshaft and remove the brush
with the bearings ✵✌ assembled. FIG.5..
4. Clean the brush if required. Slide a new belt ✶✌
onto the brush ✴✌and move it to a central
position. FIG.6
5. Replace the brush ✴✌ complete with bearings
✵✌.
6. Place the belt over the driveshaft ✷✌ FIG.6. (The
belt should be twisted in a clockwise direction
over the driveshaft ✷✌ as shown in FIG.7.)
7. Reassemble the brush housing ✳✌with screws
✱✌.
8. Replace the front cover ✰✌ and secure in place
with screw ✯✌.
✰✌
✭✌
Fig.5
✮✌
✬✌
✯✌
Fig.3
Fig.4
✶✌
✷✌
Fig.5
Fig.6
Fig.7
✱✌
✱✌
✳✌
✴✌
✵✌
✵✌
✷✌

OPTIONAL ACCESSORIES
ACCESSORY KIT FOR VC300
PART No.AVC15
STOCK No.59334
- 9 -

NOTES
-10 -

NOTES
-11 -

©Published by Draper Tools Ltd.
No part of this publication may be reproduced,
stored in a retrieval system or transmitted in
any form or by any means, electronic, mechanical
photocopying, recording or otherwise without prior
permission in writing from Draper Tools Ltd.
YOUR DRAPER STOCKIST
DRAPER TOOLS LIMITED,
Hursley Road, Chandler's Ford,
Eastleigh, Hants. SO53 1YF. England.
Tel: [phone].
Fax: [phone].
