Dreamcom 10 series User manual

10 series
User Guide Docking Station
English

dreamcom 10 series
Technical Support
Dreamcom Corporation
Tittwiesenstrasse 27
7000 Chur, Switzerland
Telephone: [phone]
Contact email: [email protected]
For additional information, please visit the Dreamcom Web site: www.dreamcom.ch
Copyright © 2008 Dreamcom Corporation
All Rights Reserved.
Docking Station
User Guide

Contents
Introduction 3
Features 4
Hardware tour 5
Top view 5
Left view 6
Right view 7
Bottom view 8
Using the docking station 9
Installing the battery pack 9
Charging the battery 10
Docking the computer 12
Turning the system on 13
Turning the system off 13
Undocking the computer 14
Adjusting the computer position 16
Connecting peripherals 21
USB devices 21
External monitor 21
External keyboard 21
External pointing device 22
Printer 22
Audio devices 22
Video devices 22
ExpressCard 22
MultiMedia cards 23
IEEE 1394 devices 24
TV signal source (not supported in business version) 24
Replacing the hard disk drive module 26
Tool requirements 26
ESD (Electrostatic Discharge) precautions 26
Specifications 30
User support 31
Index 33

3
Introduction
Congratulations on your purchase of the dreamcom 10 series docking
station. The docking station transforms your dreamcom 10 notebook
computer into a full-featured desktop workstation. This compact and light
portable expansion module comes with a unique rotating holder that allows
you to position the computer in various angles. Its innovative docking
mechanism provides secure and easy installation.
The docking station also features video capabilities to provide connections
for multiple displays and peripherals simultaneously. The S/PDIF digital
audio interface connects digital audio equipment such as a digital audio
tape machine or audio processing device. It also includes a next-
generation ExpressCard 34/54 card slot and a 5-in-1 card reader for
optional MultiMedia card, Secure Digital card, Memory Stick, Memory Stick
Pro, or XD-Picture card. A built-in TV tuner on the docking station allows
viewing of standard analog television broadcast directly to your notebook
computer and an option for viewing digital television broadcast is available
when you connect the DVB-T digital TV antenna to the TV tuner. The
docking station also features additional hard drive bay that accommodates
up to two 2.5-inch SATA hard disk drives and provides easy backup of data
stored on your computer’s internal hard drive.

Features4
Features
Human-centric design and ergonomics
• Sleek, smooth, slim and stylish design
• Adjustable to different angles for comfortable tilt position and
ergonomic viewing
• Holds the dreamcom 10 notebook computer securely
• Fits easily into any laptop bag
Multimedia
• Two built-in speakers
Storage
• Two 2.5-inch hard disk drive bay (SATA interface)
• ExpressCard slot (ExpressCard 34/54 module)
• MultiMedia card slot
Connectivity
• IEEE 1394 (4-pin)
• TV input port
• Four USB 2.0 ports
• Audio in /S/PDIF In port
• Audio out/S/PDIF out port
• S-video out port
• HDMI port
• CRT/VGA port
• Ethernet LAN
• ExpressCard slot (ExpressCard 34/54 module)
• MultiMedia card slot (SD/MMC/MS/MS-Pro/XD)
• DC-in jack for AC adaptor

5
Hardware tour
Top view
#Item Description
1 Speakers Outputs sound.
2 Docking connector Connects to the computer.
3 Eject buttons
(left and right)
Simultaneous pressing of the eject buttons undock the
computer from the docking station.
4 Rotating handle Allows you to adjust the position of the docking station
and computer.
5 Docking eject pins Disconnects the computer from the docking station
docking connector when the eject button is pushed.
6 Docking restraint
brackets
Secures the computer to the docking station.
7 Docking alignment
pins
Fits to the computer docking alignment slots to align
the computer to the docking station.
5
6
7
2
1
4
33

Hardware tour6
Left view
#Item Icon Description
1 Left eject
button
Simultaneous pressing of the left eject
button with the right eject button will
undock the computer from the docking
station.
2 Charge LED
indicator
Indicates the docking station’s battery is
being charged. The indicator light goes
off when the battery is fully charged.
3 USB ports Connect to USB devices (e.g., USB
digital camera).
4 MultiMedia
card slot
Accepts a Secure Digital (SD), Memory
Stick (MS), Memory Stick-Pro (MS-Pro),
MultiMedia Card (MMC), or xD-Picture
Card (xD) memory card.
5ExpressCard
34/54 slot
Accepts an ExpressCard 34/54 module.
6 Network jack Connects to an Ethernet-based network.
7 DC-in jack Connects to an AC adapter.
123 4 5 67

7
Right view
#Item Icon Description
1 IEEE 1394 port Connects to a IEEE 1394-compatible (4-pin)
device (e.g., digital video camera).
2 TV input jack Connects to an analog TV signal cable to view
local or basic cable channels.
Connects to a digital TV signal cable through the
provided DVB-T digital TV antenna to view digital
TV channels.
Note: Not supported in business version.
3 USB ports Connects to USB devices (e.g., USB digital
camera).
4 Microphone
jack
Inputs sounds and voices into your computer.
5 Headphone-
out jack
Connects to a headphone.
6 S/PDIF line-out
jack
Connects to audio line-out devices (e.g.
speakers, headphones); supports S/PDIF
connections.
7 S/PDIF line-in
jack
Accepts audio line-in devices and supports S/
PDIF connections.
8 S-video out
port
Connects to a television or display device with
S-video input.
9 HDMI port Connects to an external video device (e.g.
DVD multimedia player, set top box).
10 VGA port Connects to an external display device (e.g.
external monitor, LCD projector).
1 2 3 7 10 114 5 6 8 9

Hardware tour8
Bottom view
11 Right eject
button
Simultaneous pressing of the right eject button
with the left eject button will undock the computer
from the docking station.
#Item Icon Description
1 Battery cover Remove cover to install the battery pack.
2 Docking
rotation latch
Slide latch towards the unlock icon to release
the docking station handle, then rotate the
handle by 0°, 80°, or 174° position.
Slide latch towards the lock icon to keep the
docking station handle locked and secured in
0°, 80°, or 174° position.
3 Application
release latch
Slide the latch down to request the operating
system to undock the computer from the
docking station.
4 Battery cover
latch
Locks and releases the battery cover.
#Item Icon Description
2
1
4
3

9
Using the docking station
This section includes instructions on the following procedures:
• Installing the battery pack
• Charging the battery
• Docking the computer
• Turning the system on
• Turning the system off
• Undocking the computer
Installing the battery pack
1. Slide the battery cover latch to the left (1), then remove the battery
cover (2).
2. Align the tabs on the battery pack with the grooves on the rear side of
the docking station, and then insert the battery pack in place.
3. Replace the battery cover.

Using the docking station10
Charging the battery
The docking station uses a Lithium-ion battery pack which does not have
the memory effect problem of Nickel Cadmium (NiCd) batteries. Li-Ion
batteries consistently provide the longest battery life, best-suited for road
warriors.
When the battery charge level becomes low, the charge indicator on the
computer flashes at regular intervals. This tells you that the battery power
is critically low (and you should save your work). You can correct this
situation by recharging the battery pack.
Warning! Do not expose battery packs to temperatures below
0ºC (32ºF) or above 60ºC (140ºF). This may adversely affect the
battery pack.
You can use the docking station to charge the battery on the computer and
the docking station.
To charge the battery in the docking station:
1. Install the battery pack. See page 9 for instructions.
2. Connect one end of the AC adapter to the DC-in port on the docking
station.
3. Connect the power cord to the AC adapter and the other end to a
properly grounded power outlet.

11
To charge the battery in the computer when the computer is
connected to the docking station:
1. Install the battery pack. See page 9 for instructions.
2. Connect one end of the AC adapter to the DC-in port on the docking
station.
3. Connect the computer to the docking station. See page 12 for
instructions.
Note: The docking station charges the battery in the computer first
before it charges the battery in the docking station. However, when
there is no battery in the docking station, you can still use the docking
station to charge the battery in the computer.

Using the docking station12
Docking the computer
Note: Before you begin, make sure your battery is fully charged and
installed on the docking station.
1. Place the docking station on a flat, stable surface.
2. Align the docking alignment slots and docking connector on the bottom
of the computer with the alignment pins, restraint brackets, and
docking connectors on the docking station, then gently push down the
computer.
3. Slide the docking rotation latch towards the lock icon to secure the
computer to the docking station.

13
4. Slide the application release latch upward.
5. Turn on the computer.
The docking indicator on the dreamcom10 notebook computer turns
on. Refer to the dreamcom 10 series Notebook User Guide for the
location of the indicator.
Turning the system on
1. Open the display by lifting up the cover then tilt it to a comfortable
viewing position.
Warning! Do not open the LCD display to more than 120° angle
when the computer is positioned at an angle of 10° to the
surface. Failure to do so may cause unit to tip over or fall and
cause serious injury.
2. Press the power button to turn on the power.
Refer to the user manual for more information on how to operate the
computer.
Turning the system off
Follow the standard shutdown procedure described in the user manual.

Using the docking station14
Undocking the computer
Important: When the docking indicator on the dreamcom 10 is on,
you cannot detach your computer with the left and righ eject buttons.
You can request the operating system to undock your computer from
the docking station by sliding the application release latch upward.
1. Make sure that all external peripheral devices connected to the
docking station are not in use.
2. Slide the application release latch down to request the operating
system to undock the computer.
3. Turn the system off.

15
4. Simultaneously press the left and right eject buttons on the docking
station.
5. Grasping both sides, lift the computer away from the docking station.

Adjusting the computer position16
Adjusting the computer position
The docking station’s rotating handle offers comfortable viewing and angle
adjustment. You can adjust the position of the docking station and
computer in three convenient position adjustment: 0°, 80°, and 174°.
Note: The computer must be connected to the docking station before
performing the below steps. Refer to “Docking the computer” on page
12 for detailed instruction.
To adjust from 174° to 0° angle:
1. Make sure the docking rotation latch is positioned to the unlock
icon .
2. Lift the computer and docking station assembly, then fold both the
computer and docking station toward the center until they meet.

17
3. Slide the application release latch upward.
To adjust the computer from 174° to 80° angle:
1. Make sure the docking rotation latch is positioned to the unlock
icon .
2. Lift the computer and docking station assembly, then fold the computer
and docking station at 80° angle, as shown in the illustration below.
There is an audible sound when the position is locked.

Adjusting the computer position18
3. Slide the docking rotation latch towards the lock icon to secure the
computer and docking station in the locked position.
4. Slide the application release latch upward.
To adjust the computer from 80° to 0°:
1. Make sure the docking rotation latch is positioned to the unlock
icon .
2. Fold in the docking station to the computer.

19
3. Slide the application release latch upward.
To adjust the computer from 0° to 174°:
1. Make sure the docking rotation latch is positioned to the unlock
icon .
2. Grasp the sides of the docking station and computer and gently pull
the docking station away from the computer until it has reached an
angular position of 174°, as shown in the illustrations below.
