Dreamer DK-S17D User manual

1. Lid
2. Glass tea infuser
3. Glass vessel 11. LCD Screen
4. Removable mesh filter
9. Hour Button
10. Minute button
12. Keep Warm button
13. Preset temp button
14. ON/OFF button
15. Power Cord
16. Open hole cable
5. Heating surface
6. Temperature sensor
8. Program Button
7. Power Base
Model: DK-S17D
USER’S MANUAL
1 2
18cm
8.9cm 8.9cm 8.9cm
26.7x18cm
III. COMPONENTS:
12
3
4
5
6
11
10
8
9
9
7
II. SPECIFICATIONS:
Power supply
Power output
Capacity
220-240 V~, 50/60 Hz
2000 W
1.7 L
Material Inox 304 - Glass - ABS Plastic
1
2
Program
Hour Preset temp
Keep warmMinute
ON / OFF
CONTENTS:
P. 1
P. 1
P. 2
P. 3
P. 5
P. 4
I.
II.
III.
IV.
V.
VI.
I. SAFETY INSTRUCTIONS:
Before using this appliance, read the following instructions
carefully and keep the instruction manual for future use:
1. Before connecting the appliance to a wall socket, make sure
that the local power supply grid matches the appliance rating
plate. Always plug your appliance into an earthed socket.
2. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
3. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
4. Children shall not play with the appliance.
5. Cleaning and maintenance shall not be made by children
unless they are older than 8 and supervised.
6. Keep the appliance and its cord out of reach of children aged
less than 8 years.
7. The surfaces of the appliance are liable to get hot during use.
8. Always disconnect the appliance from the supply if it is left
unattended and before cleaning.
9. This appliance is intended to be used in household and similar
applications such as:
– Staff kitchen areas in shops, offices and other working
environments;
– By clients in hotels, motels and other residential type
environments;
– Bed and breakfast type environments.
10. Do not use for other than heating water. Other liquids or food
will contaminate the interior and void warranty.
11. The appliance is only to be used with the stand provided.
12. WARNING: Avoid spillage on the connector.
13. WARNING: Potential injury from misuse.
14. The heating element surface is subject to residual heat after use.
15. While using the appliance, the water level has to be between
the MIN and MAX marking of the scale.
16. If the kettle is overfilled, boiling water may be ejected
17. Defective electrical appliances must be recycled and not
disposed of with household waste.
SAFETY INSTRUCTIONS
SPECIFICATIONS
COMPONENTS
BEFORE YOU START
HOW TO USE
TROUBLESHOOTING & WARNING SIGNAL

VI. TROUBLESHOOTING & WARNING SIGNAL:
a) If the kettle floor discolors: It is normal for stainless steel
heating elements to discolor. This does not affect the
performance of the Kettle. Do not use abrasive scouring pads or
cleaners since this may damage the stainless steel surface.
b) When all the keys are found to be ineffective, all the indicators
are not on. After the power is turned on again, the buzzer will
briefly sound two alarms and then return to the previous state. It
means that the kettle body and the base are not good contact,
re-place it once make good contact and just power on. If the
problem persists, when you stop using it, send it for repair
c) When the buzzer of the machine continuously emits alarm
sounds, all the light flash, indicating that the machine may have
dried up without water and the temperature in the pot is too high.
Please stop using it immediately, turn off the power and pour in
cold water to cool down. Wait for the kettle to cool down and then
power it on again. If the problem persists, stop using it and send it
for repair.
d) When all the indicator lights of the machine keep flashing, the
buzzer does not alarm, and all the keys are invalid, it means that
the temperature sensor of the kettle is abnormal. Disconnect the
power supply and power on again. If the problem persists, stop
using it and send it for after-sales maintenance
TIMER function
Make sure the current time (a) has been installed correctly.
(1) Press and keep PROG button in 2 seconds, Led button will
blink. (2) Press HOUR button and MINUTE button to set the
time to make a timer for the kettle. (3) Press PROG button to
confirm, Led button will keep the lights on. (4) Press PRESET
TEMP button to select the levels of temperature you want to
boil. (5) Press KEEP WARM button to choose keep warm
time after boiling water if it necessary.
Boiling water
KEEP WARM function
(1) Press PRESET TEMPT button to select desired
temperature, (2) press ON/OFF button to start boiling water,
Orange light of the button will flash. Temperature (e) will
change according to the current time. When the kettle
finishes boiling water, the buzzer on the base will sound 3
times “beep – beep”. If the setting temperature is lower than
the current temperature of the water in the kettle, the buzzer
will sound 3 times “beep-beep” and the device returns to
standby mode.
Press KEEP WARM button anytime during boiling water or
before that to choose keep warm time (15”, 30”, 45”, 60”). Keep
warm temperature can be change by PRESET TEMP button
during keep warm time. KEEP WARM function be activated
and maintained when ON/OFF key is light. Keep warm time
(c) will count down in every minute. When the countdown
time is over, the buzzer on the base will sound 3 times “beep
– beep” and the device returns to standby mode.
V. HOW TO USE:
Note:
■ For safety reasons, keep warm function is not available for 100°C
for temperature setting.
■ If the setting temperature before pressing PROG button is
100°C, the device will return to the lowest temperature (40°C).
■ Keep warm function still working when you lift the kettle and
put down in 1 minute.
■ KEEP WARM time will be activate when the timer completed.
Preparation Temperature Guide:
Type of drinks
■ Baby formula 40°C
■ Baby weaning
Suitable temperature
50°C
■ Cereal/Delicate Tea 60°C
■ Herbal Tea / Green Tea 80°C
■ Coffee / Cocoa / Oolong Tea 90°C
■ Black Tea / Boil 100°C
3 4 5
18cm
8.9cm 8.9cm 8.9cm
26.7x18cm
IV. BEFORE YOU START:
1. Unpack all parts.
2. Check for completeness and shipping damage immediately
after unpacking. If your shipment is damaged or incomplete,
please contact our customer service.
3. Install kettle power cable.
The power cable should be just as long as needed. Wrap excess
power cable on the cable wrap. Insert the power cable into the
cable opening. Connect the power cable to the socket.
Step 1 Step 2
- Before you insert the power
cable into the cable opening.
The buzzer of power base will
sound, the LCD screen turn
on. (a) The current time will
flash 0:00; (b) The start time
will show 19:99; (d) Warm
time 0 MIN. (c) Default
setting temperature is 100°C
and (e) show the water temperature.
- Setting the current time: press HOUR button until current HOUR
is displayed in AM or PM. Then press MINUTE button until the
current time will show on LCD screen.
- Set the temperature display to °F or °C by pressing PRESET
TEMP and KEEP WARM simultaneously.
5. Open Lid and fill Kettle with water to the MAX fill line on the
Water Level Window on the kettle. Press ON/OFF to boiling water
at 100°C, after boiling water, the kettle will turn off automatically.
Pour water and repeat 2-3 times, rinsing out the kettle each time.
The Kettle is ready to use.
(e) (a) (b)
(c)
(d)
100oC Boil / Black Tea
4. Quick Installation Guide:
Electrical Shock Hazard. Do not immerse Kettle,
Power Base or plug in water or any other liquid.
Dreamer Customer Service Centre
Australia Customer
64 Radiata Street, Hillcrest 4118, Queensland, Australia
Phone : [phone]
