Drinkpod CHEFtop DP-CHEFTOP-1-B Operator's manual

Induction Cooktop Hob
User Instruction Manual
Model: DP-CHEFTOP-1-B
Dimensions: 11.4” x 14.56” x 1.61”
WWW.DRINKPOD.COM
POWERED BY

01 02
Important Safety Instructions
When using an electrical appliance, basic safety precautions should always be
observed, including the following
1.This appliance is intended to be used for residential and indoor only.
2.To avoid fire or shock hazard, check the voltage indicated on the rating label.
Plug in the unit into a correct electrical supply socket that match the conditions
on the rating label.
3.Do not use extension cord with this appliance, recommended to use individual
electric supply socket.
4.Do not place the electric cord under a cover. Do not overlay the cord with little
covers or sharp element. Place the cord in an area where there is not any risk to
stumble over it.
5.Do not use the appliance that is having cord, plug or cooking plate damaged,
or it is fallen or have been damaged by any way.
6.Place the unit on a plat, firm, dry and safety place and make sure there is at least
10cm free space and free of metallic surfaces around it to prevent overheating
before use. Do not operate the appliance on a plastic or other soft tablecloth.
7.Do not cover any part of the cooking plate with aluminum foil and plastic vessels
to prevent the risk of electric shock, short circuiting or fire.
8.Metallic objects such as knives, forks, spoons and lids should not be placed on
the cooking plate since they can get hot.
9.Take care when operating the appliance, as rings, watches and similar metallic
objects worn by the user could get hot when in close proximity to the cooktop ;
10.Never put empty cookware on the switched-on induction cooker, as this could
cause thecookware distorted or heating coil damaged.
11.Beware of the hot steam comes out from the cookware to avoid being burned.
Do not overfill the cookware to avoid water splash out and damage the appliance.
12.For better performance and maintenance, do not operate the unit for more than
2 hours continually.
13.Always switch off the appliance before leveling and unattended.
14.Users with pacemakers should consult with the manufacturer.
15.To avoid shortening the life span or damaging the product, never use any
accessories or parts from other manufacturers not recommended by original
manufacturers or service agent. Use original parts or accessories only, otherwise,
warranty becomes invalid.
12cm

04
1.Plug in the AC power cord. The buzzer sound will indicate the induction cooker is now
in standby mode.
2.Touch on/off button to power up the induction cooker.
3.Power :
Put the suitable pot or pan onto the inducion cooktop center it over the effective
induction perimeter ring. Touch the power button and the unit will begin to operate at
factory power preset.Touch the “-” and “+” button to select the desired power setting.
The setting will be displayed on the LED screen.
4.Temp.
The temeprature can be selected from 60--240℃ （ 140--460℉). Put the suitable pot
or pan onto the inducion cooktop center it over the effective induction perimeter ring.
Touch the Temp button and the unit will begin to operate at factory temperature preset.
Touch the “-” and “+” button to select the desired temperature setting.The setting will
be displayed on the LED screen.
4.Timer:
The Timer range from 1 to 240minutes.
Touch the Timer button and the induction cooker will begin to operate at factory
time preset of “0” minutes.Touch the “-” and “+” to select the desired time. Touch
“+” (“-”) to prolong ( shorten) the time by 1 minute every
time.Hold “+” (“-”) to prolong ( shorten) the time by 10 minute every time.The
setting will be displayed on the LED screen for 5s,then change to display the power
or temperature.
5.Child lock:
hold the Lock button for 3 seconds .The LED will display “LOC” to indicate the
unit is child locked. Hold the lock button for 3 seconds. The child lock will disengage.
6.Auto-off:
The unit will automatically shut off itself after a period of 2 hours.
Note: The induction cooker fan will continue for 2 minutes after the unit has been
switch off to cool the internal components. It is important to that the unit is left
plugged in and allowed to complete the cooling systems in order to extend the
long service life of the
components.
On/Of
f
03
Operating Instruction
1
2
3
1.Ceramic face plate
2.Effective induction perimeter ring
3.Timer button
4.Temp. button
5.Decrease button
6.LED display screen
7.Increase button
8.Power
9.On/Off button
4 5 89
6 7

Error Guide
05 06
Warranty
The Company offers two years warranty start from the date of manufacturing,
for the product for repairing or replacing parts free of cost against any
manufacturing fault
• Plastic body and ceramic plate which are breakable are not covered in warranty.
• Electronic parts damaged due to voltage surge do not come under warranty.
• This appliance is only meant for domestic use.
Commercial use does not cover warranty.
Damage due to normal wear & tear, improper maintenance, improper use & altered
or repaired by anyone other than an authorized person , shall void the warranty.
• Any surface scratch or cosmetic changes due to wear & tear shall render the
warranty void.
• Parts repaired or replaced under this warranty are warranted only for the reminder
of the original period, and no fresh warranty period shall be provided for the said
replaced/repaired part
Packing list
parts QTY
manual 1
1
Induction cooker
ERROR CODE REASON SOLUTION
When the unit has the below problems, it will stop working and along with
buzzer sound to warn the user
EO
E1
E2
E3
E4
E5
E6
E7
Pot is not suitable Place a suitable pot
A/C voltage is too low Connect the device to correct
voltage power outlet
A/C voltage is too high Connect the device to correct
voltage power outlet
Short circuit or open
circuit
The sensor broken
IGBT sensor overheated
IGBT sensor open circuit
IGBT sensor short circuit Allow the device to cool down.
Turn it off and then turn on again
The device requires repair
