Dual XDMA6415 Operating instructions

x
A64
INSTALLATION/OWNER'S MANUAL
AM/FM/CD/MP3/WMAlU5B/3.5mm/iPod®/Bluetooth® Receiver with Detachable Face
disc
DIGITAL AUDIO
1
_. Plays
_.
Windows
TM Medla™
fOl Made for
@J iPod
o Bluetooth®
AUX
Front Panel Input

.. XDMA6415 INSTALLATION
-"------~-~----_._-~---------_ .... _"""" ...... -_.="""'..-_"'--------_._,-""",,",,""'''''''''''''''''''''.-',"''''''
Preparation
Please read entire manual before installation.
Before You Start
•Disconnect negative battery terminal. Consult aqualified technician for instructions.
•Avoid installing the unit where it would
be subject to high temperatures. such as from
direct sunlight.
or where it would be subject to dust. dirt or excessive vibration.
Getting Started
•Remove trim ring from unit.
•Remove 2transit screws located
on top of the unit.
•Insert the supplied keys into the
slots as shown. and slide the unit
out of the mounting sleeve.
•Install mounting sleeve into
opening. bending tabs
to secure.
•Connect wiring harness and
antenna. Consult aqualified
technician if you are unsure.
•Certain vehicles may require
an
installation kit and/or wiring
harness adapter (sold separately),
•Test for correct operation and slide
into mounting sleeve
to secure.
•Snap trim ring into place.
HEXIOIJ'
MOUNnNG STRAP
HEX NUT
PLAIN WASHER.
MOUNT1NG SLEEVE
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
2

XDMA64151NSTALLATION •
Wiring Diagram
RCA Connections
Right Channel (Red)
Left Channel (White)
FUSE
When replacing the fuse.
make sure new fuse is the
correctlype and amperage.
Using an incorrect fuse
could damage the radio.
The XDMA6415 uses one
10 amp ATM fuse located
beside the
wiring connector.
Bluetooth Microphone
(must be connected for Bluetooth functionality)
Antenna
Connector
ut
o
SUBWOOFER
Green (+)
Steering Wheel Interface Input
FRONT
Whlte(+)
(PAC
SWI-PS required)
r
BLACK
Bluetooth Microphone Inp
Connect the included
Bluetooth microphone.
BLUE I Remote Tum-On
Connect to amplifier or power
antenna. Insulate wire
if not used.
BLACK I Ground
Connect to vehicle
chassis ground.
RED I Accessory
Connect to existing ignition
circuit or switched
12 volt source.
+-
YELLOW I Memory
Connect to ballery
circuit or constant
12 volt source.
Right Front @
Right Rear
~
0
Gray/Black H0Violel/Black (-)
Gray(+)
J.
Violet(+) 0
~
Left Rear
OJ
0
Left Front
White/Black H0Green/Black H0
3

XD A6 15 OPERA TIO
Con ro ocations -• ecelver
CD
Release ®Auxiliary Input
CD
Talk @TunefTrack Up
CD
Audio/Menu @Tune/Track Down
({) Preset l/Repeat ®Display
CD
Preset 4/Play/Pause @Volume
CD
Preset 2/Random ®AS/PS/Enter
(j) Preset 5/Folder Down @Band/Back
CD
Preset 3/lntro @Mode/Search
CD
Preset 6/Folder Up
@Power
@Eject ®Mute/End Call
®
USB Port
The XDMA6415 allows playback of your favorite
MP3 and WMA files recorded on CD-R and
CD-RW discs. Its powerful on-board
DSP processor decodes the compressed audio while
maintaining near-CD sound quality.
An internal SRAM buffer provides ESP (Electronic
Skip Protection) to virtually eliminate skipping and allows alphanumeric
or direct track
search -even while asong is currently playing!
4

XDMA64150PERATIO
Control Locations - Remote
CD
Power @Preset 5/Folder Down
CD
Audio/Menu @Key 9/EQ
CD
Volume Up
@Mute/End Call
oMode/Search @Key O/Display
CD TunelTrack Up
@Talk
CD Volume Down @Key a/Scan
(j) AS/PS/Enter/# Key @Key 7
CD
Preset 3/1 ntro @Preset 4/Play/Pause
CD
Preset 2/Random ®Preset l/Repeat
@Preset 6/Folder
Up
@Band/Back/* Key
@TunelTrack Down
5

.. XDMA6415 OPERATION
General Operation
Faceplate Removal
Semi-Permanent
Faceplate Installation
Power On/Off
Mode
Auxiliary Input
Press
RELEASE and pull away from the left side to remove.
To re-install. insert right side of faceplate first then push
left side to secure.
Remove
trim ring and install supplied #1 x 7132" Phillips
head screw through left side of mounting frame into faceplate.
Press
POWER or any other button (except eject) to turn the
unit
on. Inserting adisc will turn the unit on automatically.
Press
POWER to turn the unit off.
Press
MODE to select between AM/FM. CD player. auxiliary
input. iPod. Bluetooth and
USB. Modes of operation are
indicated in the display.
CD mode will not appear unless a CD
is inserted.
Insert a3.5mm connector in the front panel
AUX port.
Connect the other end of the 3.5mm connector to the
headphone output of
an audio device. MP3 player. etc. Press
MODE to select AUX mode.
Steering Wheel
Input Interface The steering wheel interface input located
on the back of
the head unit allows connection to the Pacific Accessory
Corporation
(PAC) SWI-PS interface module (sold separately).
Visit www.pac-audio.com for details.
To configure steering wheel controls. follow the instructions
provided with the
PAC SWI-PS interface module. After
installing the interface module. insert the module's 3.5mm
jack into the port
on the back of the head unit.
Volume Adjust volume using the volume knob (00-46).
Programmable Press and hold
POWER for 3seconds to program currently
Tum-On Volume selected volume level.
uP-VOL" and the current volume level
will momentarily appear in the display.
Mute Press
~ to silence the audio. "MUTE" will flash in the
display. Press
~ again to cancel.
Preset
EQ Curves On the remote control. press EQ to select between POP.
JAZZ. CLASSIC. BEAT. ROCK and OFF (default) equalization
curves. Any adjustment to the Bass
or Treble settings
automatically cancels the current
EO curve (if one is
selected).
Display Press
DISP to select between clock and different types of
information. such
as radio frequency. CD track/elapsed time.
or MP3/WMA song information.
6

XDMA6415 OPERATION ..
General Operation
Reset IPress to RESET the unit upon initial installation or if abnormal
Ioperation occurs. Reset button is located behind the faceplate.
Set the Clock IWith the unit on. press and hold DISP until the clock begins to
Iflash. then release. Press
TUNE ~~ to adjust the hours and
.TUNE
~~ to adjust the minutes. Press DISP momentarily to
Isave the selected time.
I
12124-hour Clock The clock will display 12-hour AM/PM time in USA frequency
spacing mode
(PM 10:00). In European frequency spacing
mode. the clock
will display 24-hour time (22:00).
Setup Menu Press and hold AUDIO/MENU for more than 3seconds to
access the setup menu. Press AUDIO/MENU momentarily
to
select between the menu functions and rotate the volume knob
left/right
to adjust or activate the desired function.
Setup Menu
loudness Curve lOUD OFF Disables the loudness function.
lOUD ON Enables the loudness function. Activating this feature will
enhance the bass and treble frequencies when listening to
music at low volumes.
Tuner Frequency
Spacing
FREQ USA Programs the unit to USA tuner spacing.
(200kHz for FM and 10kHz for AM)
FREQ EUR Programs the unit to European tuner spacing.
(50kHz for FM and 9kHz for AM)
Clock Display ClK OFF Programs the unit to not display the clock when the power is off.
ClK ON Programs the unit to display the clock when the power is off.
Auxiliary Input AUX ON Enables the front panel3.5mm auxiliary input.
AUX OFF Disables the auxiliary input.
Beep Confirmation BEEP OFF Disables the confirmation beep.
BEEP ON Enables.the confirmation beep.
locaVDistance
Tuning lOC
OFF Activates distance tuning.
lOC ON Activates local tuning for strong station reception only.
Subwoofer SB-W ON Enables the subwoofer RCA output
SB-W OFF Disables the subwoofer RCA output
MSG OFF Disables power on message.
MSG ON Enables power on message to be displayed.
Power on Message
I------+------:.------..,;~-------------I
Demonstration
Mode
DEMO OFF Disables the demonstration message.
DEMO ON Enables the "BlUETOOTH - IPOD - USB" message.
Note: Refer to page 24 for Bluetooth setup menu options.
7

• XDMA6415 OPERATION
General Operation
Audio Press AUDIO/MENU momentarily to select between Volume
(default). Bass. Treble. Balance. &Fader.
e VOLUME ~ BASS ~ TREBLE ~ BALANCE ~ FADER ~ SUBWOOFER J
Bass Press AUDIO/MENU until BAS appears then rotate volume
left/right
to adjust (-6 minimum /+6 maximum).
Treble Press AUDIO/MENU until
TRE appears then rotate volume
left/right to adjust (-6
minimum /+6 maximum).
Balance Press AUDIO/MENU until BAL appears then rotate volume
left/right to adjust (BAL L12-BAL
OO-BAL R 12).
BAL 00 represents equal balance
Fader Press AUDIO/MENU until
FAD appears then rotate volume
left/right to adjust (FAD F12-FAD OO-FAD R 12).
FAD 00 represents equal fader
Subwoofer Press AUDIO/MENU until SUB appears. then press SELECT
to confirm. Rotate volume left/right to adjust (0-12).
Adjusting levels to 0
turns the subwoofer off.
Source Audio Memory Individual Bass and Treble settings are retained in
memory
for tuner. CD. AUX. USB and iPod modes. This allows you to
save the Bass and Treble settings separately for each mode.
Note:
Any adjustment to the Bass
or Treble settings automatically
cancels the current
EO curve (if one is selected).
8

XDMA6415 OPERATION ••
AM/FM Tuner Operation
Seek Tuning Press TUNE ........ or TUNE ~~ momentarily to seek the
next strong station.
ManualTuning Press
TUNE ........ or TUNE ~~for more than two seconds.
then release. "MANUAL"
will momentarily appear in the
display. Press
TUNE ........ or TUNE ~~ momentarily to
move radio frequency up or down one step at atime. Press
and hold to advance quickly. If tuning is not adjusted for five
seconds. the unit
will return to seek tuning mode (default).
"AUTO" will momentarily appear in the display.
Scan Tuning On the remote control. press SCAN to preview strong
stations on the current band. pausing for five seconds at
each. Press
SCAN again to cancel.
Band Press BAND
to select between FM1. FM2. FM3. AM1 and
AM2 bands.
Storing and Recalling
Up to 18 FM stations and 12 AM stations can be stored. To
Station Presets store astation. select the desired band and station. Press
and hold the desired preset button (1-6) for more than
two seconds. When stored. the preset number
will appear in
the display. The station can be recalled anytime by pressing
the corresponding preset button.
Note: Function keys
7. 8. 9and 0 on the remote control apply
to Bluetooth operation only.
Automatically Store Press AS/PS for more than two seconds to automatically
Stations store the six strongest stations.in the current band.
Automatic local tuning is activated during the initial band
scan.
Preset
Scan Press AS/PS for less than two seconds to scan presets 1-6
on the current band. pausing for five seconds at each. Press
AS/PS again to cancel.
______ . .-J _
9

.. XDMA6415 OPERATION
CD Player Operation
Insert co With the label facing up. insert astandard size CD into the
CD slot. The CD will automatically begin playback.
Eject
CO Press • to eject the CD. The unit will change to previous
mode of operation (AM/Ht1. AUK iPod. Bluetooth
or USB).
If the disc is not removed within 10 seconds. the unit will
reload the disc. The unit does not have to be turned on to
eject
CD.
Track Select Press TRACK ~~ to skip to the beginning of the next
track. Press
TRACK .......... to return to the beginning of the
current track. Pressing
TRACK.......... again skips to the
beginning of the previous track.
Fast Forward and Reverse Press and hold
TRACK ~~ or TRACK.......... to fast forward
or reverse atrack.
Pause Press "III to temporarily stop CD playback.
Press
"III again to resume playback.
Scan Press INT to play the first
10 seconds of each track.
Press INT again to cancel.
Repeat Press
RPT to continuously repeat selected track.
Press
RPT again to cancel.
Random Press
ROM to play all tracks in random order. Press ROM
again to cancel. Random mode is retained in memory
when selecting between AM/FM. CD. AUX. USB. iPod and
Bluetooth modes and when the unit is turned on/off.
CO-R/CO-RW Compatibility Some
CD-Rs and CD-RWs may be incompatible with this
unit. depending
on media type and recording method. In
addition. the following CDs may be incompatible with this
unit:
CDs exposed to extreme temperatures or direct sunlight
for extended periods of time. CDs recorded in which a
recording session failed
or are-recording was attempted
and.
or encrypted or copy-protected CDs which do not
conform to the audio CD-DA red book recording standard.
10

XDMA64150PERATION [11"
CD Player Operation - MP3/WMA Files
Playing an MP3/WMA Disc
I
Displaying Information I
When an MP3/WMA encoded disc is first inserted.
"READING"
will appear in the display. Depending on the
number of files and folders. this may take several seconds.
Press DISP to select between track number/elapsed time
(default). clock. track name. directory name. title. artist and
album.
"NO 103 TAG" will be displayed if the MP3 file contains no
103 tag information.
"UNKNOWN"
will be displayed if the WMA file contains no
WMA tag information ..
"Roor will be displayed if the directory name of aroot
folder is not labeled.
Title Icon ( TITLE IThis icon will illuminate when the song title is displayed.
Artist Icon IART/Srl This icon
will illuminate when the artist name is displayed.
Album Icon
(ALBUMI This icon will illuminate when the album name is displayed.
Folder Icon Iii This icon
will illuminate when the folder name is displayed.
CharacterSupport Maximum character display information
•Track name - 32 character maximum
•Directory name -
23 character maximum
•*50ng title -
30 character maximum
•*Artist name -
30 character maximum
•*Album name -
30 character maximum
*50ng title. Artist Name. and Album name.
will only be
displayed if included with the MP3/WMA file.
When referring
to MP3/WMA playback. the following terms
are synonymous:
•File name and track name
•Folder name and directory name
11

Press SRCH for more than 3seconds. to select between the
following modes:
•Direct File Select
•File
or Folder Navigate
.. XDMA6415 OPERATION
CD. Player Operation - MP3/WMA Files
Direct Select and I
Navigate Modes I
I
12
Direct File Select
Step 1I
I
Step 21
Step 31
File/Folder Navigate I
Step 1I
I
Step 2i
!
Step 3I
I
Step 4
*Folder Access
(Up one level)
Press
SRCH for more than 3seconds. then release.
"MP3 T*" or "WMA T*" will flash in the display.
Turn the volume knob to change to the desired track
number.
Press I
.... )to confirm the selected file number or wait for
the input cycle to time out (approximately 5seconds).
Press SRCH for more than 3seconds. then release.
Press
SRCH again to navigate files/folders on the disc.
The current folder name will scroll one time followed by
available files and folders.
Turn the volume knob to preview files/folders in the current
folder. If afolder is selected. the
iii icon will illuminate.
Press I..... )to select the desired file
or folder. If afolder is
selected. ,\," will be displayed. Turn the volume knob to the
right to begin searching files in the folder.
Press 1
..... 1to select the desired file within the folder.
When navigating folders (and .\
," is displayed). press BACK
to access the previous level (up one level).
*Only available
on MP3/WMA discs recorded with more than
one folder.
-_._------------

XDMA6415 OPERATION m'
CD Player Operation - MP3/WMA Files
Navigating Note After navigating by direct select or file/folder navigate
modes. the track number and elapsed time will be displayed
by default. Press OISP momentarily to select clock. track
name. directory name. title. artist and album.
*Folder Access Press
ti to select the previous folder.
Press /Zj to select the next folder.
*Folder access is only available on MP3/WMA discs recorded
with more than one folder.
File Repeat Press
RPT momentarily to continuously repeat selected file.
fPress RPT again to cancel.
Folder Repeat Press
RPT for more than 2seconds to consecutively repeat
all files
in the current folder only. The" icon will appear in
the display when
in folder repeat mode.
Press RPT again to cancel.
Disc Random Press
RDM momentarily to play all files on entire disc in
random order. Press ROM again to cancel.
Folder Random Press
ROM for more than 2seconds to play all files in
current folder only in random order. The" icon will appear
in the display when in folder random mode.
Press
ROM again to cancel.
Disc Intro Press INT momentarily
to play the first 10 seconds of each
file on the entire MP3/WMA disc. Press INT again to cancel.
Folder Intro Press INT for more than 2seconds
to play the first 10
seconds of each file in the current folder only. The" icon
will appear in the display when in folder intro mode.
Press INT again
to cancel.
Note:
.Folder repeat. folder random and folder intro functions are
only available
on MP3IWMA discs recorded with more than
one folder.
13

• XDMA6415 OPERATION
~ -
CD Player Operation - MP3/WMA Files
Media Compatibility The following types of discs/files are compatibLe:
•CD-ROM
(ISO), CD-R. CD-RW
•CD-DA
•MP3 data
•WMA data
The following types of discs/fiLes are not compatibLe:
•WMA
fiLes that are protected by DRM (DigitaL Rights
Management).
•WMA
LossLess format
•Discs recorded
with Track At Once or packet writing
• MP3 PRO format
• MP3 pLayLists
•WAV format
14
Playback Order
Compatible Recording
Formats
MP3/WMA pLayback sequence is based on recorded order
of files and begins in the root folder of the disc. Any empty
foLders
or foLders that do not include MP3/WMA files are
skipped. This unit may not
pLay files in the order they were
recorded in depending
on the recording software used.
Refer to
your recording software's user's manuaL for more
information.
•1509660
LeveL 1
•1509660 leveL 2
•Yellow Book
MODE 1
•Yellow Book MODE 2 FORM 1
•Multi session
•
Maximum foLders and files - 256
• Maximum foLder LeveLs - 8
•MPEG-1I2/2.5 Audio Layer-3
1509660 standards:
•
Maximum nested foLder depth is 8(including the root
foLder).
•Valid characters
for foLder/fiLe names are letters A-Z
(all caps), numbers 0-9, and "_" (underscore). Some
characters
may not be dispLayed correctly. depending on
the character type.
•This device can
pLay back discs in JoLiet. Romeo. and other
standards that conform to 1509660. MP3/WMA written in the
formats other than the above
may not pLay and/or their fiLe
names or foLder names may not be dispLayed properly.

XDMA6415 OPERATION .-
--------
CD Player Operation - MP3/WMA Files
Additional MP3/WMA
Information .
I
Sampling Frequency Rates
MP3
WMAI
I
Transfer Bit rates I
MP3 I
WMA I
I
I
I
I
MP3 Tag Display I
I
I
I
Recommended Settings ;
I
An internal buffer provides ESP (Electronic Skip Protection) to
virtually eliminate skipping.
When playing adisc recorded with regular audio files
(CO-OA or .WAV) and MP3/WMA files. the unit will play the
MP3/WMA files only.
Only MP3 files with filename extension (.mp3) can be played.
Only WMA files with filename extension (.wma)
can be played.
Do not attempt to play discs which contain non-MP3/WMA
files with the MP3/WMA extension.
8kHz -48kHz
32kHz -48kHz
32kbps -320kbps constant
Variable bit rates
48kbps -192kbps constant
Variable bit rates
Note:
Some files may not play
or be displayed correctly.
depending on sampling rates and bit rates.
103 tags Version 1.x
This model will not display 103 Version 2.0 or greater tags.
For best results. use the following settings when burning an
MP3 disc:
128kbps or higher constant bit rate
44.1 kHz or higher sampling frequency
For best results. use the following settings when burning a
WMA disc:
64kbps or higher constant bit rate
32kHz
or higher sampling frequency
15

• XDMA6415 OPERATION
USB Operation - MP3/WMA Files (Optional)
Connecting a USB Device
(sold separately)
Playing Music
Displaying Information
Play MP3/WMA files from most mass storage devices
by
connecting them to the XDMA6415's USB port. To connect
a
USB device. line up the connectors and insert the USB
device into the port. The USB icon will appear in the display.
Press
MODE to enter USB mode. When a USB device is
first connected. "READING"
will appear momentarily in
the display. Depending
on the number of files and folders.
this may take several seconds. Music
will begin playing
automatically unless aBluetooth phone call is detected.
If
no valid MP3/WMA files are detected. "NO FILE" will be
displayed and the last mode will be resumed.
Press DISP
to select between elapsed time (default), track
number. clock. track name. directory name. title. artist and
album.
"NO TITLE" will be displayed if no song title information is
available.
"NO ARTIST" will be displayed if no artist information is
available.
"NO ALBUM" will be displayed if no album information is
available.
Title Icon I
TITLE JThis icon will illuminate when the song title is displayed.
Artist Icon IART/Srl This icon
will illuminate when the artist name is displayed.
Album Icon
IALBUMJ This icon will illuminate when the album name is displayed.
Folder Icon
II This icon will illuminate when the folder name is displayed.
Character Support Maximum character display information
•Track name -
32 character maximum
•Directory name -
32 character maximum
•*Song title -
30 character maximum
•*Artist name -
30 character maximum
•*Album name -
30 character maximum
*50ng title. artist name and album name
will only be
displayed if included with the MP3/WMA file.
16

XDMA6415 OPERATION .-
USB Operation - MP3/WMA Files (Optional)
Direct File Select I
I
I
Press SEARCH for more than three seconds. then release.
"T*" will appear in the display. Use the volume knob to select
the desired track number and press ,
... J to confirm.
Note: When afile is accessed. the elapsed time
will be
displayed. Press D1SP momentarily to select track number.
clock. track name. directory name. title. artist
or album.
*Folder Access Press
~ to select the previous folder.
Press
IQ to select the next folder.
*Folder access is only available
on USB devices with more
than one folder.
Press
RPT momentarily to continuously repeat selected file.
Press
RPT again to cancel.
Press
RPT for more than two seconds to consecutively
repeat
all files in the current folder only. The,. icon will
appear in the display. Press RPT again to cancel.
File Random IPress
ROM for more than two seconds to play all files on
entire USB device in random order. Press ROM again to
cancel.
File Repeat I
I
Folder Repeat .
FolderRandom
I, Press ROM momentarily to play all files in current folder
only in random order.
The,. icon will appear in the display.
Press
ROM again to cancel.
File Intro Press INT momentarily to play the first
10 seconds of each
file
on the entire USB device. Press INT again to cancel.
Folder Intro Press INT for more than two seconds
to play the first 10
seconds of each file in the current folder only. The,. icon
will appear in the display. Press INT again to cancel.
Note: Folder repeat. folder random and folder intro functions
are only available
on USB devices with more than one folder.
. _L
17

• XDMA6415 OPERATION
USB Operation - MP3/WMA Files (Optional)
Track Select Press TRACK ~~ to skip to the beginning of the next
.track. Press
TRACK .......... to return to the beginning of the
current track. Pressing TRACK .......... again skips to the
beginning of the previous track.
Fast Forward and Reverse Press and hold
TRACK ~~ or TRACK.......... to fast
forward
or reverse atrack.
Pause Press ~/II to temporarily stop USB playback.
Press
~/II again to resume playback.
Media Compatibility The following types of files are compatible:
• MP3 data
• WMA data
The following types of files are not compatible:
•
WMA files that are protected by DRM (Digital Rights
Management).
•
WMA lossless format
•
MP3 PRO format
•
MP3 playlists
•
WAY format
Playback Order I
Playback Capacity I
______ • __ • __ .....l.
18
MP3/WMA playback sequence is based on order the files
are copied to the USB device and begins in the root folder.
Any empty folders or folders that do not include MP3/
WMA files are skipped. Depending on your software, the
playback order may vary.
•Maximum number of files:
48896
•Maximum number of folders: 127 plus the root directory
•Maximum number of files in each folder and root: 382
•Maximum number of folder levels (sub folders): 8
(7 levels plus the root)
Note: If the number of files/folders exceeds the maximum
outlined above. the additional files/folders will be ignored.

XDMA6415 OPERATION •
USB Operation - MP3/WMA Files (Optional)
Additional MP3/WMA Only MP3 files with filename extension (.mp3) can be played.
Information Only
WMA files with filename extension (.wma) can be played.
00 not attempt to play non-MP3/WMA files with the MP3/
WMA extension.
Sampling Frequency
Rates
MP3 8kHz -48kHz
WMA 32kHz -48kHz
Transfer Bit rates
MP3 32kbps -320kbps constant
Variable bit rates
WMA 48kbps -192kbps constant
Variable bit rates
Note:
Some files may not play
or be displayed correctly.
depending
on sampling rates and bit rates.
MP3 Tag Display 103 tags Version l.x
This model will not display 103 Version 2.0 or greater tags.
Note: If
an invalid 103 tag version is detected. "NO SUPPORT"
will scroll on the display.
19

• XDMA6415 OPERATION
iPod® Operation (Optional)
Connect iPod Use the included 2-wire iPod cable to connect an iPod to the
(Not Included)
XDMA6415. Press MODE until "IPOD" appears in the display.
The iPod will automatically begin playback. Ifasong is
playing
on the iPod before it is connected, it will continue to
play.
INote: Both the USB and auxiliary input connections must be
made when connecting the 2-wire iPod cable.
Displaying Information Press DISP
to select between elapsed time (default), track
number, clock. title. artist and album.
"UNKNOWN ARTIST" will be displayed if the file contains no
artist tag information.
"UNKNOWN ALBUM"
will be displayed if the file contains no
album tag information.
Search Functions Press and hold
SRCH for 3seconds to enter the search
mode. Turn the volume knob to select between playlist.
artist. album and song. Press
SRCH to select the desired
search type. Press
BACK to access the previous level (up
one level).
Playlist Search Turn the volume knob to select between playlists. Press
SRCH to select desired playlist. Turn the volume knob to
select between songs from the chosen playlist. Press [+-oJ )
Ito begin playback.
Artist Name Search ITurn the volume knob to select between artists. Press
IARTISTI SRCH to select desired artist. Turn the volume knob to
Iselect between albums from the chosen artist. Press
SRCH
to select desired album from the chosen artist. Turn the
volume knob
to select between songs from the chosen
album. Press
[+-oJ ) to begin playback.
Album Name Search Turn the volume knob
to select between albums. Press
IALBUMI SRCH to select desired album. Turn the volume knob to
select between songs from the chosen album. Press (+-oJ)
to begin playback.
Song Name Search Turn the volume knob to select between songs. Press
[+-oJ)
I TITLE Ito begin playback.
Song Select Press
~~ to skip to the beginning of the next song.
Press........ to return to the beginning of the current song.
Pressing........ again skips to the beginning of the previous
song.
20
