6
Press EJECT to allow the front panel to slide down. Gently
squeeze the release tab located on the bottom center
underside and pull front panel down and away from unit to
remove. To install, insert either side first, then push opposite
side to secure.
Press EJECT to allow the front panel to slide down. Install
supplied #2 x 5 mm Phillips head screws from underside of
the mounting frame into faceplate.
Press PWR or any other button (except EJECT) to turn the unit
on. Inserting a disc will turn the unit on automatically. Press
PWR to turn the unit off.
Press MODE to select between tuner, CD player and auxiliary
input. Modes of operation are indicated in the display.
Adjust volume using rotary encoder (00-46).
Press MUTE to silence the audio. “MUTE” will flash in the
display. Press MUTE again to cancel.
Press and hold PWR for 3 seconds to program currently
selected volume level. "P-VOL" and the current volume level
will momentarily appear in the display.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT,
ROCK and OFF (default) equalization curves. Any adjustment
to the Bass or Treble settings automatically cancels the
current EQ curve (if one is selected).
Press DISP to select between clock and radio frequency
(tuner mode), clock and CD track/elapsed time (CD mode), or
clock and AUX (AUX mode).
With the unit on, press and hold DISP until the clock begins to
flash, then release. Press TUNE
nn
to adjust the hours and
TUNE
ll
to adjust the minutes. Press DISP momentarily to
save the selected time.
The clock will display 12-hour AM/PM time in USA frequency
spacing mode (PM 10:00). In European frequency spacing
mode, the clock will display 24-hour time (22:00).
Front Panel Removal
Semi-permanent
Faceplate Installation
Power On/Off
Mode
Volume
Mute
Programmable
Turn-On Volume
Preset EQ Curves
Display
Set the Clock
12/24-hour Clock
XDM6830 OPERATION
General Operation
