Dual XHD6425 Operating instructions

INSTALLATION/OWNER'S MANUAL
AM/FM/CD/MP3/WMA/USB/3.5mm Bluetooth® Ready Receiver
with Built-In HD Radio™ and Detachable Face
XHD6425
R
®

2
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Remove trim ring from unit,
• Remove 2 transit screws located
on top of the unit.
• Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
• Install mounting sleeve into
opening, bending tabs to secure.
• Connect wiring harness and
antenna. Consult a qualified
technician if you are unsure.
• Certain vehicles may require an
installation kit and/or wiring
harness adapter (sold separately).
• Test for correct operation and slide
into mounting sleeve to secure.
• Snap trim ring into place.
XHD6425 INSTALLATION
Preparation

3
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse
could damage the radio.
The XHD6425 uses one
10 amp ATM fuse located
beside the wiring connector.
XHD6425 INSTALLATION
Wiring Diagram
BLACK 8-pin Female Mini-DIN
BTM60 Connection (sold separately)
Antenna Connector
BLACK
Front Preamp Output

4
The XHD6425 allows playback of your favorite MP3 and WMA files recorded on CD-R and
CD-RW discs. Its powerful on-board DSP processor decodes the compressed audio while
maintaining near-CD sound quality. An internal SRAM buffer provides ESP (Electronic
Skip Protection) to virtually eliminate skipping and allows alphanumeric or direct track
search - even while a song is currently playing!
Function keys 7, 8, 9 and 0 apply to Bluetooth, USB and MP3/WMA operation only.
XHD6425 OPERATION
Control Locations - Receiver
Release
Eject
Mode/Search
Volume/Audio/Setup
Tune/Track Up
IR Remote Sensor
Talk/Redial
EQ/Key 9
Display/Key 0
USB Port (Covered)
Auxiliary Input
Tuner Scan/Key 8
Key 7
1
2
3
4
5
6
7
8
9
10
11
Preset 6/Folder Up
Preset 5/Folder Down
Preset 4
Preset 3/Intro
Preset 2/Random
Preset 1/Repeat
Auto Store/Preset Scan/Enter/Key #
Band/Play/Pause/Key *
HD Seek
Mute/End Call
Tune/Track Down
Power
12
14
15
16
17
18
19
20
21
22
23
24
25
13
2123 20 19 18 17 16 15 14
12357 8 9
13
4
22 12 112425
610

5
XHD6425 OPERATION
Control Locations - Remote
Key 9/EQ
Key 8/Scan
Mute
Talk/Redial
Key 7
Preset 5/Folder Down
Preset 4
Preset 1/Repeat
Mode/Search
Tune/Track Down
Band/Play/Pause/Key *
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Power
Volume Up
AS/PS/Enter/Key #
Audio/Setup
Tune/Track Up
Display/Key 0
Volume Down
Preset 3/Intro
Preset 2/Random
Preset 6/Folder Up 20
21
12
4
3
6
5
8
19
9
10
11
12
16
14
17
18
7
20
21
13
15

6
Faceplate Removal
Semi-Permanent
Faceplate Installation
Power On/Off
Mode
Auxiliary Input
Volume
Programmable
Turn-On Volume
Mute
Preset EQ Curves
Reset
Display
General Operation
XHD6425 OPERATION
Press RELEASE and pull away from the left side to remove.
To re-install, insert right side of faceplate first then push
left side to secure.
Remove trim ring and install supplied #1 x 7/32” Phillips
head screw through left side of mounting frame into faceplate.
Press POWER or any other button (except eject) to turn the
unit on. Inserting a disc will turn the unit on automatically.
Press POWER to turn the unit off.
Press MODE to select between AM/FM, CD player, USB,
auxiliary input and Bluetooth (optional). Modes of operation
are indicated in the display.
NOTE: CD and Bluetooth modes will not appear unless a CD
is inserted or BTM60 (Bluetooth module - sold separately) is
attached.
Insert 3.5 mm plug to connect your portable audio device.
Adjust volume using rotary encoder (00-46).
Press and hold POWER for 3 seconds to program currently
selected volume level. "P-VOL" and the current volume level
will momentarily appear in the display.
Press MUTE to silence the audio. “MUTE” will flash in the
display. Press MUTE again to cancel.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT,
ROCK and OFF (default) equalization curves. Any adjustment
to the Bass or Treble settings automatically cancels the
current EQ curve (if one is selected).
Press to RESET the unit upon initial installation or if
abnormal operation occurs. The reset button is located
behind the faceplate.
Press DISP to select between clock and different types
of information, such as radio frequency, HD Radio song
information, CD track/elapsed time, or MP3/WMA/USB song
information.

7
With the unit on, press and hold DISP until the clock begins to
flash, then release. Press TUNE
nn
to adjust the hours and
TUNE
ll
to adjust the minutes. Press DISP momentarily to
save the selected time.
Press and hold the rotary encoder for more than 3 seconds to
access the setup menu. Press the rotary encoder momentarily
to select between the menu functions and rotate the rotary
encoder left/right to adjust or activate the desired function.
Set the Clock
Setup Menu
XHD6425 OPERATION
General Operation
Setup Menu
Menu
Function
Options Action
Loudness
Curve
LOUD OFF Disables the loudness function.
LOUD ON Enables the loudness function. Activating this feature will
enhance the bass and treble frequencies when listening to
music at low volumes.
Clock
Display
CLK OFF Programs the unit to not display the clock when the power
is off.
CLK ON Programs the unit to display the clock when the power is
off.
Auxiliary
Input
AUX ON Enables the front panel 3.5mm auxiliary input.
AUX OFF Disables the auxiliary input.
Beep
Confirmation
BEEP OFF Disables the confirmation beep.
BEEP ON Enables the confirmation beep.
Local/Distance
Tuning
LOC OFF Activates distance tuning.
LOC ON Activates local tuning for strong station reception only.
Power on
Message
MSG OFF Disables power on message.
MSG ON Enables power on message to be displayed.
Demonstration
Mode
DEMO OFF Disables the demonstration mode.
DEMO ON Enables the "BUILT IN HD RADIO AND BT READY" message.
Display
Scrolling
SCRL ON Programs the unit to scroll display information continuously.
SCRL OFF Disables the display scroll feature.

8
XHD6425 OPERATION
Press rotary encoder momentarily to select between
Volume (default), Bass, Treble, Balance, & Fader.
Press rotary encoder until BAS appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press rotary encoder until TRE appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press rotary encoder until BAL appears then rotate encoder
left/right to adjust (BAL L 12-BAL 00-BAL R 12).
BAL 00 represents equal balance
Press rotary encoder until FAD appears then rotate encoder
left/right to adjust (FAD F 12-FAD 00-FAD R 12).
FAD 00 represents equal fader
Individual Bass and Treble settings are retained in memory
for AM, FM, CD, AUX, USB and Bluetooth modes. This allows
you to save the Bass and Treble settings separately for each
mode.
Note:
Any adjustment to the Bass or Treble settings automatically
cancels the current EQ curve (if one is selected).
Audio
Bass
Treble
Balance
Fader
Source Audio Memory
General Operation
BASSVOLUME TREBLE BALANCE FADER

9
XHD6425 OPERATION
Analog and Digital Tuning
Seek Tuning
Manual Tuning
Scan Tuning
Storing and Recalling
Station Presets
The following tuning functions will access both analog and
digital stations. Refer to the HD SEEK mode section on page
10 for instructions on tuning to only digital stations.
Press TUNE
nn
or TUNE
ll
momentarily to seek the
next strong station.
When an HD Radio station is selected, an HD Radio logo will
begin to flash on the display. In about five seconds, HD or
HD1 will illuminate after the radio frequency.
• If "HD" appears, the radio station is broadcasting a higher
quality sound. No additional stations are available.
• If "HD1" appears, additional multicast channels (HD2
and/or HD3) are available. Press TUNE
nn
or
TUNE
ll
to tune to other available multicast channels.
Press TUNE
nn
or TUNE
ll
for more than two seconds,
then release. "MANUAL" will momentarily appear in the
display. Press TUNE
nn
or TUNE
ll
momentarily to
move radio frequency up or down one step at a time. Press
and hold to advance quickly. If tuning is not adjusted for five
seconds, the unit will return to seek tuning mode (default).
"AUTO" will momentarily appear in the display.
Press SCN to preview strong stations on the current band,
pausing for five seconds at each. Press SCN again to cancel.
Up to 18 FM stations and 12 AM stations can be stored,
including HD Radio stations. To store a station, first select
the desired band and station. Press and hold the desired
preset button (1-6) for more than two seconds. When stored,
the preset number appears in the display. The station can be
recalled by pressing the corresponding preset button.
Note: Function keys 7, 8, 9 and 0 apply to MP3/WMA, USB
and Bluetooth operation only.
HD Radio™ AM/FM Tuner Operation

10
XHD6425 OPERATION
Automatically Store
Stations
Preset Scan
Band
Display
HD Seek Mode
Press AS/PS for more than two seconds to automatically
store the six strongest stations in the current band.
Automatic local tuning is activated during initial band scan.
Press AS/PS momentarily to scan presets 1-6 on the
current band, pausing for five seconds at each. Press AS/PS
again to cancel.
Press BAND to select FM1, FM2, FM3, AM1 or AM2.
When the unit is tuned to an analog station, press DISP to
toggle the display between the following options:
When the unit is tuned to an HD Radio station, press DISP to
toggle the display between the following options:
When information is unavailable, "NO DATA" appears in the
display.
Press HD SEEK to activate digital-only tuning mode. The HD
SEEK icon will appear on the display, indicating that the unit
will skip over analog stations and tune to HD Radio stations
only. Follow the instructions on page 9 to access seek,
manual and scan tuning.
• Storing and Recalling Station Presets
HD Radio multicast stations (HD2 and HD3) can also
be stored as presets. When a preset multicast station
is recalled, "LINKING" appears in the display until the
download process is complete (approximately 5 seconds).
Note: If the HD radio signal on the preset is unavailable,
the unit reverts to the previous analog or digital station.
• Automatically Store Stations
While in HD SEEK mode, press AS/PS to automatically
store HD Radio stations to presets 1-6. Multicast
channels (HD2 and/or) HD3 are not stored but can be
accessed by pressing TUNE
ll
from the HD1 station.
HD Radio™ AM/FM Tuner Operation
CLOCK
FREQUENCY
STATION
NAME ARTIST SONG
TITLE CLOCK
FREQUENCY
PROGRAM
TYPE
