DULUCK A104 Assembly instructions
DULUCK A104 - KNOW YOUR DEVICE
(KYD )
DULUCK A104
Let’s ... act smart
PANEL SOFT-TOUCH-KEY’S DESCRIPTION
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
1.MIC hole
2.Lamp brightness control
3.Lamp on & off /lamp switch
4.Startup & Shutdown key/mode switch
5.Play/pause key
6.Volume level control
7.MIC hole
8.Microphone on-off key
9.Awakening / Networking key WPS button
10.Power adapter jack
11.digital clock display
Content in Box:-
• One Duluck Alexa enabled speaker,
• One USB power Adopter & USB charging cable
• User manual,
• Warranty card,
• Duluck Alexa enabled mini guide,
• Duluck smart controller information card.
PANEL SOFT-TOUCH-KEY’S FUNCTIONS
NOTE:- ALL THE KEY’S OF THE DULUCK-A104 DEVICE ARE SOFT-TOUCH KEYS.
1. MIC hole
Receive the spoken voice and then the host recognizes voice command
2. Lamp brightness control
Slide up to increase the lamp brightness and slide down to decrease the lamp brightness
3.Lamp on & off /lamp switch
Short press to turn on the lamp, Long press 3 seconds to enter multi-color lamp mode with circular gradient, and short press to switch multi-
color lamp color
4. Startup & Shutdown key/mode switch
Short press to switch BT mode/WIFI mode, long press 3 seconds to shut down/start up the device.
5. Play/pause key
Short press, for pause/play the music
Long press can turn digital clock On/Off
6. Volume level control
Slide up to increase the volume level. When the volume is at its maximum, the device will beep remind.
Slide down to decrease to volume level. When the volume is at its lowest, the last little lamp will flash.
7. MIC hole
Receive the spoken voice and then the host recognizes voice command
8. Microphone on-off key
Short press to turn on/off the MIC and recognize the received voice.
9.Wake up/connect key (WPS)
Long press is to connect/configure the device to Wi-Fi internet and follow the instructions given by device as well as APP
Short press to wake-up the device & device is ready for taking voice command (Its just like saying wake-up command “Alexa”
(Some times, if the place is very-very noise and its hard for device to recognize the wake-up command, then user can activate the device by
soft touching this key and give voice instructions to device.)
10.Power adapter jack
Plug in the adapter to power the host
11.Digital clock display
Clock will show the time as per location entered in the device-setting module in your Amazon account. For correct information of local time
and other businesses, user must enter the device location and other input parameters in his Amazon-account in Amazon-APP.
Basic requirements:-
• Smart phone,
• Wifi Network,
• Duluck-Alexa-Device,
• Power adopter
• Power source for power adopter 230V 60Hz.
Important:-
Connect your phone to the same wifi network to which you want your Duluck- Alexa-Device to connect.
Download Amazon Alexa-APP from Apple/Google App store
Make/Signup your account and login ID. Memorize your user Id and Password of Amazon-Alexa-account.
Note:- Do not share your password with any one.
Download Duluck-APP from Apple/Google APP store
Or
By copying the APP-Download link in Duluck website www.duluckos.com and open in cellphone browser
DULUCK A104 INSTALLATION & DEVICE SETTINGS
To gain maximum use / utilization of Duluck-Alexa-speaker, kindly read the following booklets supplied with Duluck-Alexa-device. Or Check
www.duluckos.com and read “Alexa in our life”
Duluck-Alexa user mini guide.
Duluck-Alexa voice commands.
Duluck smart controllers.
Procedure:-
• Connect your phone to Wi-Fi network.
• Download Duluck-APP from Apple/Google APP store ( ) Or https://play.google.com/store/apps/details?id=com.wifiaudio.DULUCK
• By copying the APP-Download link in Duluck website www.duluckoverseas.com and open in cellphone browser
Or
Connect the Power adopter supplied with device. When you hear the power-on prompt sound, enter the network configuration state directly
or long touch the WPS ("Awakening/ Networking") key for 5 seconds, and the panel UI Led ring will keep rotating and running. Your Duluck
device will say “Entering setup mode.”
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
Long press Awakening / Networking key
button to enter the network configuration
state mode.
First, check whether the phone has
WIFI on and connect to the router to
be connected.
Click the mobile desktop to enter the
APP
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
P.T.O.
Click
Press Duluck-APP icon on your
phone screen.
The APP will start searching the Duluck-Alexa-Devices near by and
you will see a radar searching the same.
To add New device press “ + “ on the right corner of the screen.
Press “Settings”
Press “Add Device”
OR
Note:-
If some Duluck-Alexa enabled -Devices are already connected on the same wifi network on which your phone is connected, then you will see
the following screen with number of devices written in the middle and after that, the app will display list of devices already connected to the
same wifi network.
The app will take you to the Wifi setting screen of your phone showing available Wifi networks.
• Press “DULUCK model no. A104_XXXXX” in available wifi list.
• Your speaker will say “You are now connected to your speaker”.
• Above screen’s will appear with list of available wifi networks near your location
• Select the Wifi network you wish to connect and enter password. Press “continue”
• After this, APP will take about 45 to 120 seconds and following screen will appear. When your speaker is connected to wifi, it says
“Connected to Wifi”
Note:- After completing the process of Wi connection, some times following screen will appear. Follow the instructions
mentioned on the screen. Make sure your phone & speaker both should be connected to same network.
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
Click
• This screen will appear with list of available wifi networks near your location.
• Select the Wifi network you wish to connect and enter password. Press “continue”
• After successful connection of your speaker with Wifi you will see following screen.
• Press Name of the Duluck-Alexa-Device. Press top right corner arrow “>”.
Enter your custom name
and click confirm
Click
Wifi
Setting
Click Next
Click
Click
Custom
• Press “Switch account” and the app will take you to Amazon Alexa Account sign-in screen
• If you press skip, the device will automatically connect the Amazon account it was connected before.
After enter Amazon account and
password, please click sign in
Please select your lanuage
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
Enter Amazon account
and password
If you don’t
have an
Amazon
account,
please
create a new
Amazon
account
Click
Click
Click
Click
Note:- If your Duluck Alexa enabled Device is fitted with Duluck-Smart-Controllers then app will take you to the binding of device option
screen. Kindly follow the instructions on your smart phone screen and bind the device.
Settings wheel
Click
Click
Click
If you don’t know
how to
set the lamp, please
click
“How
to enable skill”
Prompt
binding
success
After successful binding you will see the following screen with newly added Duluck-Alexa enabled -Device.
• Press “Speaker info” and in “Hotspot Status” options, Turn slider button “On”
• Press “Wi-Fi password” option and enter the password you want for your “Hotspot-Wifi”. Now after this user can see the Wifi name in
his smart phone wifi list with the name written in SSID column
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
Press-setting
icon “Wheel”
on the right
corner of your
device name.
Press Amazon-
Alexa settings.
Select your
language by
pressing
“Amazon
Alexa
language” and
set request
sound “On”.
Now you can use extended-Wifi-network with the SSID name written in SSID column with new password as you entered. Means your
Duluck Alexa Device (DAD) also act as wifi extender/Hotspot.
Congratulations:-
After this you are ready to “Act … Smart” with Duluck-Alexa-Device to assist and entertain you.
Now you can listen to songs as per your ,mood desire and wish with your voice command (The particular song/set of songs,
which you wish to listen according to your mood.)
(Not the forced one’s which are playing on FM or Pre-saved songs on any device like USB Or Radio).
In case user want to switch amazon account of a particular device to another account name, then tap on your device name in device list
in Duluck-APP and go to drawer menu of that particular device.
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
Then tap “Amazon Alexa” Icon in the list. This will take you to the Amazon login screen for that particular device. (User can link different
Duluck-Alexa enabled-Devices to different Amazon accounts.
User can swap between Bluetooth-Wifi mode remotely by pressing the Bluetooth and wifi options in drawer menu.
P.T.O.
Press to go to
drawer menu
In case user
don't see its
device in list
then press re-
freshPress
Multi Mode:- In case user have more then one Duluck- Alexa enabled-Devices, then user can make two or all the devices connected to
each other by making a particular device as MASTER and rest as slaves.
(Please note that in multi mode, user will have to give voice command to MASTER speaker only and in reply he can have answers on all
the connected speakers. Slave speakers will not take voice commands)
To know the procedure to use multi room mode, Tap on “How to switch between solo and multi mode?”. After this follow the instructions.
In Amazon prime music APP, user can play the songs on his Duluck- Alexa enabled-Devices by taping the streaming icon in Amazon
prime music APP.
Basic settings in Amazon Alexa APP
Important:- Download Amazon Alexa APP from Apple/Google App store
Make/Signup your account and memorize your user Id and Password of Amazon Alexa account.
Update your location for more accurate answers related to your country/place/location
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
To avoid saying “Alexa” again & again, before every command, Enable follow-up in Amazon-App-Device-settings-option for your Alexa
device.
Now you are ready to “Act ….. smart” with Duluck-Alexa enabled -Device to assist and entertain you.
Now you can listen to songs as per your mood, desire and wish with your voice command.
(The particular song/set of songs, which you wish to listen according to your mood. Not the forced one’s which are playing on FM or Pre-
saved songs on any device like USB Or Radio)
And to take full use of Duluck-Alexa-speaker kindly read
Duluck-Alexa user mini guide. (DAD)
Duluck-Alexa voice commands. (DAVC)
Duluck smart controller. (DSC)
Bluetooth operation
Bluetooth pairing method:
1. Switch the host to BT mode by soft touching the button 4, then turn on the mobile phone BT, and search & connect bluetooth
name“A104”.
2. User can switch remotely (without physically moving and pressing Wifi-BT mode button) between Bluetooth-Wifi mode by pressing the
Bluetooth and wifi options in drawer menu of Duluck APP.
3. When the host didn’t connect the BT device, the UI lamp of the host panel will flash; When successfully connected to bluetooth, the
UI lamp in the host panel stops flashing and appear bright blue color.
4. In the bluetooth playing state, open your mobile music player, the device will play bluetooth music immediately.
5. The default password for the initial pairing is "0000" or "1234". After the pairing is successful, the host panel UI lamp will display the
bright blue color.
6. When switching to other playing states and then back to bluetooth state, the host will automatically connect to bluetooth and issue a
sound prompt, and the UI LED ring on the panel will display the bright blue color. When exiting the bluetooth device, the host will
issue a prompt sound.
Technical Parameters:
• Audio frequency response: 60HZ-15KHZ
• Audio distortion factor ≤0.3%
• The signal-noise ratio of audio≥50dB
• Audio output power: 10W
• Sound type: Home Intelligent WIFI sound host
• Effective distance: less than 12ft
• Operation type: touch the key slightly, voice control command, mobile phone APP control
• Power adopter specifications: Input AC 100-240V - Output DC 12V-2A 60HZ
• Host power supply: range of 10V-2A 15V-3A
• Sound accessories: host horn x1, instruction manual x1, power adapter x1, Warranty card x1, User mini guidex1
www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]
