DVDO DVDO-C1-1 User manual

DVDO-C1-1 USB Camera Quick Start Guide DVDO
DVDOC1_V1.0
1 Product Appearance
2 Package Contents
3 Product Features
Full HD 1080p with Wide Viewing Angle
Provides Full HD 1080p images and 1080p video @ 30fps / 25fps, with full
downward compatibility to 720p resolution and wide viewing angle of 120⁰
field of view (FOV).
USB 2.0
Full-featured USB 2.0 interface carries power, video, and audio over one
cable, supporting high-quality audio and video calls.
Built-in Microphone
Integrated microphone array picks up sound from up to six meters / 19.5
feet away, with crystal-clear audio via proprietary noise suppression.
Low-Light Sensitivity
2D / 3D noise reduction algorithms greatly reduce image noise to keep
images clean and clear with signal-to-noise ratio up to 55dB, even under
ultra-low lighting.
Easy Installation
Standard clamping rotary shaft support provides easy, stable, and reliable
installations, suitable for mounting onto monitors.
4 Safety Precautions
Careful Transportation
Avoid heavy pressure, strong vibrations, and liquid damage to camera
during transportation, installation, and operation.
Careful Installation
Place this product on a smooth surface. Please carefully avoid contact with
any liquid, gas or solid material that may cause corrosion to the camera’s
shell, made from an organic material.
Do Not Disassemble
This product contains no user-repairable parts. Any damage caused by the
user disassembling the product is not covered by warranty.
Electromagnetic fields at specific frequencies may affect image
performance.
5 Product Specifications
Camera
Sensor
1/2.7'', CMOS, Effective Pixel: 2.07M
Scanning Mode
Progressive
Lens Mount M12
Lens
Focus: f=3.1mm, FOV: 120°
Minimal Illumination
0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s ~ 1/10000s
White Balance Auto, Indoor, Outdoor, One Push,
Manual, VAR
Camera bracket
Bracket with Damper
Digital Noise
Reduction 2D, 3D Digital Noise Reduction
Backlight
Compensation
Support
USB Features
Operating System Windows XP/7/8/10
Android 4.4.2
Color / Compression
MJPEG/YUY2/H.264

DVDO-C1-1 USB Camera Quick Start Guide DVDO
DVDOC1_V1.0
Resolution
MJPEG: 1920x1080 (default), 1600x896,
160x120, 176x144, 320x240, 352x288,
640x480, 720x576, 1280x720, 1024x768,
1024x576, 960x540, 848x480, 800x600,
800x448, 640x360, 480x272, 424x240,
320x180
YUY2: 1920x1080 (default), 160x120,
176x144, 320x240, 352x288, 640x480,
1280x720, 960x540, 640x360, 480x272,
424x240, 320x180
H.264: 1920x1080 (default), 1600x896,
160x120, 176x144, 320x240, 352x288,
640x480, 720x576, 1280x720, 1024x768,
1024x576, 960x540, 848x480, 800x600,
800x448, 640x360, 480x270, 424x240,
320x180
USB Communication
Protocol
UVC 1.0
Input/Output Interface
USB Interface 1 x USB 2.0: Type A
Physical Specifications
Input Voltage
5V (USB power supply)
Current
Consumption 0.27A
Operating
Temperature
-10°C ~ 40°C / 14°F ~ 104°F
Storage
Temperature -40°C ~ 60°C / -40°F ~ 140°F
Power Consumption
1.4W
Size
118mm x 37.2mm x 30.8mm (without bracket)
Net Weight 0.093 Kg (without bracket)
MTBF
＞30000h
6 Camera Installation
The camera can be mounted to monitors with thickness less than 170mm /
6.7” as shown below.
7 Maintenance and Troubleshooting
Camera Maintenance
Please disconnect power when camera is not in use for long periods of
time. Use a soft cloth or paper to remove dust from camera housing.
Please wipe with a dry soft cloth to clean camera lens. Use a gentle
neutral cleaner if dirt has accumulated. Do not use strong or corrosive
detergents which can scratch the lens and affect image quality.
Operating Tips
Avoid pointing camera at direct sunlight, bright lights or bright objects.
Avoid unstable lighting conditions, which can cause the image to flash.
Do not use around devices that can transmit high-power radio waves,
such as radio-transmitting or television stations.
Troubleshooting
If the image jitters after the camera is properly connected,
1) Check whether the camera is installed on a stable surface.
2) Check for vibrating surfaces or machinery near the camera.
8 Toxic and Harmful Substances
Part Name
Toxic or harmful substances or elements
(Pb)
(Hg)
(Cd)
(CrVI)
(PBB)
(PBDE)
Metal
X
Ο
Ο
Ο
Ο
Ο
Plastic
Ο
Ο
Ο
Ο
Ο
Ο
Glass
X
Ο
Ο
Ο
Ο
Ο
Circuit board X ΟΟΟΟΟ
Power
X
Ο
Ο
Ο
Ο
Ο
Attached
X
Ο
Ο
Ο
Ο
Ο
This form is compiled in accordance with SJ/T 11364.
Ο: Indicates that the content of the hazardous substance in all
homogenized materials of the component is subject to the limit specified
in GB/T 26572.
X: The hazardous substance in at least one of the components’
homogenized material content is in excess of the GB/T 26572 limit
requirements, and there are no mature alternatives.
9 Warranty
If failure is due to non-human causes within one year from date of purchase
of camera, please email [e-mail] with proof of purchase / receipt
and serial number.
Any of the following circumstances is not covered by warranty:
Product has been modified or tampered with.
Use of camera in an environment that does not conform to requirements
of the product.
Uncontrollable factors such as fire, earthquake, lightning strike, etc.
Warranty card does not match product number.
