Dynasty DBQ Series Assembly instructions

Outdoor
Gas Grill
This Base Manual covers, but is
not limited to the following:
DBQ*
JBQ*
MBQ*
Service
This manual is to be used by qualified appliance
technicians only. Maytag does not assume any
responsibility for property damage or personal
injury for improper service procedures done by
an unqualified person.
16025981
January 2005
R

2 16025981 © 2005 Maytag Services
Important Notices for Servicers and Consumers
Maytag will not be responsible for personal injury or property damage from improper service procedures. Pride and
workmanship go into every product to provide our customers with quality products. It is possible, however, that during
its lifetime a product may require service. Products should be serviced only by a qualified service technician who is
familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts, testing
instruments and the appropriate service information. IT IS THE TECHNICIANS RESPONSIBLITY TO REVIEW ALL
APPROPRIATE SERVICE INFORMATION BEFORE BEGINNING REPAIRS.
!WARNING
To avoid risk of severe personal injury or death, disconnect power before working/servicing on appliance to avoid
electrical shock.
To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this
product. For further assistance, please contact:
Customer Service Support Center
CAIR Center
Web Site Telephone Number
WWW.JENNAIR.COM ............................................. 1-800-536-6247
WWW.MAYTAG.COM ............................................. 1-800-688-9900
CAIR Center in Canada ........................................... 1-800-688-2002
Recognize Safety Symbols, Words, and Labels
DANGER!
DANGER—Immediate hazards which WILL result in severe personal injury or death.
WARNING!
WARNING—Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION!
CAUTION—Hazards or unsafe practices which COULD result in minor personal injury, product or property
damage.
Important Information

© 2005 Maytag Services 16025981 3
Important Information .................................................... 2
Safety Information
Safety Practices for Servicer .................................... 4
Servicing .................................................................. 4
ALL APPLIANCES ................................................... 5
Precautions .............................................................. 5
Gas Supply Pressure ............................................... 5
Pressure Regulator Connection ................................ 5
Gas Supply Location ................................................ 5
Gas Connection ....................................................... 6
Testing for Gas Leaks .............................................. 6
Product Safety Devices ............................................ 7
General Information
General Information .................................................. 8
Ordering Replacement Parts .................................... 8
Model Nomenclature ................................................ 8
Model Identification .................................................. 9
Service ..................................................................... 9
Parts and Accessories ............................................. 9
Receiving Grill .......................................................... 9
Unpacking Grill ........................................................ 9
Functional Operation
Burners ................................................................... 9
Spark System ........................................................ 9
Troubleshooting Procedures ........................................10
Component Testing Procedures ................................... 11
Table of Contents
Disassembly Procedures
Removing and Replacing Built-In Unit ...................... 12
Hood Thermometer .................................................. 12
Hood Handle ...........................................................12
Front Hood / Spit Saddle Brackets .........................12
Rear Hood ............................................................... 12
Knob Bezel(s) ......................................................... 12
Control Panel .......................................................... 12
Burner Valve(s) ....................................................... 12
Gas Line(s) .............................................................13
Ignitor(s) ..................................................................13
Infra-red Sear Burner ............................................... 13
Burner Support Bracket...........................................13
Spark Ignitor ........................................................... 13
Infra-red Broiler Ignitor ............................................. 14
Infra-red Broiler ........................................................14
Infra-red Broiler Bracket .......................................... 14
Gas Regulator ......................................................... 14
Manifold Pipe .......................................................... 14
Typical Grill Component Layout ..............................15
Typical Base Unit .................................................... 16
Typical Side Burner ................................................. 16
Appendix A
Instruction Sheet for L.P. Conversion .................... A-2
Appendix B
Installation Instructions ......................................... B-2
Use and Care ...................................................... B-18
Appendix C
Bar Tender Installation and Use and Care ............. C-2

4 16025981 © 2005 Maytag Services
As with all appliances, there are certain rules to follow for
safe operation. Verify everyone who operates the grill is
familiar with the operations and with these precautions.
Use appliance only for its intended purpose as described.
Pay close attention to the safety sections of this manual.
Recognize the safety section by looking for the symbol
or the word safety.
Recognize this symbol as a safety precaution.
!
If the information in this manual is not followed exactly,
a fire or explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other flammable vapors
or liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by an
authorized installer, service agency or gas supplier.
To avoid risk of electrical shock, property damage,
personal injury or death; verify wiring is correct, if
components were replaced. Verify proper and
complete operation of unit after servicing.
This gas appliance contains or produces a chemical or
chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
To reduce the risk from substances in the fuel or from
fuel combustion make sure this appliance is installed,
operated, and maintained according to the instructions
in this manual.
Due to the nature of cooking, fires can occur as a
result of overcooking or excessive grease. Although a
fire is unlikely, if one occurs proceed as follows:
Surface Fires
1. Turn all controls to the OFF position.
2. As an added precaution turn off the gas at the
main supply valve.
3. Cover the food or grease to burn itself out.
If smoke or fire persist call the local fire department.
NOTE: The maximum gas supply pressure for these
models must not exceed 14 inches W.C.P.
Safety Practices for Servicer
Safe and satisfactory operation of gas grills, depend upon
its design and proper installation. However, there is one
more area of safety to be considered:
Servicing
Listed below are some general precautions and safety
practices which should be followed in order to protect the
service technician and consumer during service and after
service has been completed.
1. Gas smell—Extinguish any and all open flames.
2. Turn gas off—Service grill with gas turned off unless
testing requires it.
3. Checking for gas leaks—Never check for leaks
with any kind of open flame. Soap and water solution
should be used for this purpose. Apply solution to
suspected area and watch for air bubbles which
indicates a leak. Correct leaks by tightening fittings,
screws, connections, applying approved compound or
installing new parts.
4. Using lights—Use a hand flashlight when servicing
grills or checking for gas leaks. Electric switches
should not be operated where leaks are suspected.
This will avoid creating arcing or sparks which could
ignite the gas. If electric lights are already turned on,
they should not be turned off.
5. Do not smoke—Never smoke while servicing gas
grills, especially when working on piping that contains
or has contained gas.
Safety Information

© 2005 Maytag Services 16025981 5
6. Check grill when service is completed—After
servicing, make visual checks on electrical
connection, and check for gas leaks. Inform
consumer of the condition of grill before leaving.
7. Adhere to all local regulations and codes when
performing service.
ALL APPLIANCES
1. Proper Installation—Be sure your appliance is
properly installed and grounded by a qualified
technician.
2. Never Use Appliance for Warming or Heating the
Room.
3. Do Not Leave Children Alone—Children should not be
alone or unattended in the area where the appliance
is in use. They should never be allowed to sit or stand
on any part of the appliance.
4. Wear Proper Apparel—Loose fitting or hanging
garments should never be worn while using appliance.
5. User Servicing—Do not repair or replace any part of
the appliance unless specifically recommended in the
manual. All other servicing should be referred to a
qualified technician.
6. Storage in or onAppliance—Flammable materials
should not be stored on or around grill.
7. Do Not Use Water on Grease Fires—Smother fire or
flame, or use dry chemical or foam-type extinguisher.
8. Use Only Dry Pot-holders—Moist or damp Pot-
holders on hot surfaces may result in burns from
steam. Do not let pot-holder touch burners. Do not
use a towel or other bulky cloth.
Precautions
• Do not cook food directly on cooktop surface, always
use cookware on side burner(s).
• Do not mix household cleaning products. Chemical
mixtures may interact with objectionable or even
hazardous results.
• Do not put plastic items on warm cooking areas.
They may melt and stick.
• Do not leave fat heating unless you remain nearby. Fat
can ignite if overheated by spilling onto hot surfaces.
• Do not allow pots to boil dry as this can cause damage
to cooking surface and pan.
• Do not use grill for storage or as a display counter.
Gas Supply Pressure
CAUTION
!
To avoid property damage, maximum gas supply
pressure must not exceed 14" WCP.
• Appliance and individual shut-off valve must be
disconnected from the gas supply piping system during
any pressure testing of that system at test pressures
in excess of ½ psig (3.5kPa)(14" WCP).
• Appliance must be isolated from gas supply piping
system by closing manual shut-off valve during any
pressure testing of the gas supply piping system at
test pressures equal to or less than ½ psig (3.5kPa)
(14" WCP).
• Gas supply pressure for checking regulator setting
must be at least 1" WCP above manifold pressure
shown on rating label.
• Must use pressure regulator supplied with grill.
Pressure Regulator Connection
Regulator may have 2 inlets. Remove plug from bottom
inlet of pressure regulator to create 90° connection.
Remove plug from side inlet of pressure regulator to
create a straight connection. Locate pressure regulator
according to gas supply location.
• Support regulator when installing gas supply.
• Do not overtighten fitting or hard pipe when attaching to
gas regulator. Overtightening may crack regulator.
Regulator
Gas Supply Location
Locate gas supply so manual shut-off valve is accessible
after installation. Gas supply can be installed in adjacent
cabinet or behind access panel. Avoid interference with
electrical connection.
Safety Information

6 16025981 © 2005 Maytag Services
Gas Connection
Connect gas supply to regulator using hard pipe or a
flexible connector. Pressure regulator supplied with this
appliance has a ½-inch NPT female connection.
• A manual shut-off, not supplied with grill, must be
installed in an accessible location outside of grill.
• Use joint compound that is resistant to action of
propane gas on all male pipe threads.
• Use supplied pressure regulator only.
• Do not overtighten gas fitting when attaching to
pressure regulator. Overtightening may crack regulator.
• Support pressure regulator with wrench when installing
gas fitting.
Hard Piping
A— To regulator
B—Union
C—Nipple
D—Manual shut-off valve
E—¾-inch to ½-inch reducing elbow
F—¾-inch service pipe stub
Flexible Connector
A—To regulator
B—Adaptor
C—Flexible connector
D—Manual shut-off
E—¾-inch service pipe stub
Testing for Gas Leaks
WARNING
!
To avoid property damage or serious personal injury,
never use a lighted match to test for gas leaks.
After final gas connection is made, test all connections in
gas supply piping and grill for gas leaks.
1. Place soap suds on connection.
• Bubbles appear if leak is present.
2. Tighten joint if leak is at factory fitting.
• If leak is not at factory fitting, unscrew, apply more
joint compound, and tighten to correct leak.
3. Retest connection for leak after tightening.
• Retest any connections that were disturbed.
Safety Information

© 2005 Maytag Services 16025981 7
Product Safety Devices
Safety devices and features have been engineered into the product to protect consumer and servicer. Safety devices
must never be removed, bypassed, or altered in such a manner as to defeat the purpose for which they were intended.
Listed below are various safety devices together with the reason each device is incorporated in the gas ranges.
Pressure Regulator Maintains proper and steady gas pressure for operation of oven controls. Regulator
must be set for the type of gas being used Natural or LP. After servicing regulator,
make certain it is set properly before completing service.
Gas Burner Orifices Universal orifices are used on most valves. They must be adjusted or set for the type
of gas being used Natural
or LP.
After servicing a valve or orifice verify it is adjusted properly before completing service.
Safety Information

General Information
8 16025981 ©2005 Maytag Services
General Information
This manual provides basic instructions and suggestions for handling, installing and servicing gas grills.
The directions, information, and warnings in this manual are developed from experience with, and careful testing of
the product. If the unit is installed according to the Installation Instructions, it will operate properly and will require
minimal servicing. A unit in proper operating order ensures the consumer all the benefits provided by clean, modern
gas cooking.
This manual contains information needed by authorized service technicians to install and service gas grills. There
may be however, some parts which need further explanation. Refer to individual technical sheets or the toll-free
technical support line to answer questions from authorized service technicians.
Ordering Replacement Parts
Model numbers are recorded on the rating label. Rating label is located on the rear of the hood area. Before
ordering parts, write down the correct model and serial number from the rating label. This avoids incorrect
shipments and delays. Please refer to parts reference material when ordering replacement parts.
_ __________________ ____________________ ___________________
Model Number Type of Gas Serial Number
___________________ ____________________ ___________________
Purchase Date Purchased From Telephone Number
___________________ ____________________ ___________________
InstallationDate InstalledBy Telephone Number
NAMEPLATE LOCATION
ATTACHED TO THE
OUTSIDE ON THE FIXED
HOOD OF THE UNIT
NAMEPLATE LOCATION
LOOK UP FROM UNDERNEATH
INTO THE INSIDE OF THE
BURNER UNIT

General Information
©2005 Maytag Services 16025981 9
Model Identification
Complete registration card and promptly return. If
registration card is missing:
• For product information call 1-866-820-9401 or visit
the Web Site at www.jadeappliances.com
When contacting provide product information located on
rating plate. Record the following:
Model Number: ___________________
Manufacturing Number: ___________________
Serial or S/N Number: ___________________
Date of purchase: ___________________
Dealer’s name and address: ___________________
Service
Keep a copy of sales receipt for future reference or in
case warranty service is required. To locate an
authorized servicer:
• For Jade product call 1-866-820-9401 or visit the Web
Site at www.jadeappliances.com
Warranty service must be performed by an authorized
servicer. We also recommend contacting an authorized
servicer, if service is required after warranty expires.
Parts and Accessories
Purchase replacement parts and accessories over the
phone. To order accessories for your product call:
• For Jade product call 1-866-820-9401 or visit the Web
Site at www.jadeappliances.com
Receiving Grill
Inspect grill thoroughly at the time of delivery.
Immediately report any visible damage to carrier.
Damage not discovered until after accepting delivery
can still be claimed by using a concealed damage report
form, available from the carrier’s agent.
All shipments, i.e., complete grill or parts, are shipped at
the buyer’s risk. Jade’s responsibility ends when the
consignment is accepted by the carrier in “good order”.
Jade supports damage claims by supplying invoices,
bills, and other documentation as needed. Providing this
assistance however, does not imply any responsibility for
settling claims. Do not deduct claims for loss or damage
from the invoice and do not withhold payment pending
adjustment of claims. Do not return any units or parts for
credit written consent.
Unpacking Grill
• Uncrate grill from packaging material.
• Remove all packing and printed material packed with
grill.
• Remove burner grates, burner caps, grill, vent cover,
and pressure regulator from packing material.
Functional Operation
Burners
Spark ignitors are used on each burner. The ignitor is
located at each gas inlet to provide a grounding surface
for ignition.
Spark System
The spark ignition system consists of a solid state
module and spark ignitors.
Turning a ignitor knob or pressing the spark ignition
button sends approximately 2 sparks per second to the
spark ignitors. This causes a demand for spark from the
spark module containing an electronic circuit which
produces 12 VDC voltage pulses.

Troubleshooting Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires it.
10 16025981 © 2005 Maytag Services
Problem Possible Cause Correction
Burners will not ignite;
no spark at burner.
Poor ground at ignitor ...............................
Weak or failed spark module ....................
Low gas pressure......................................
•Verify spark.
•Replace spark module
battery 9 VDC.
•Verify pressure 4” WCP for natural, 10”
WCP for LP.
No spark or only random
spark at one ignitor.
Check for cracked ignitor or pinched
ignitor wire ................................................
Poor continuity to ignitor ...........................
Bad ground connection or lack of
continuity to ground or ignitor ...................
Cracked or broken ignitor extension
lead ...........................................................
•Replace ignitor lead or electrode.
•Verify spark adjustment.
•Tighten ground connection and correct
any breaks in ground path from ignitor
path to unit ground path.
•Replace ignitor lead.
Flame blows away from
burner.
Too much air .............................................
Gas pressure too high...............................
Draft around grill area ...............................
•Slightly close air shutter to burner.
•Verify correct gas pressure
•Eliminate source of draft.
Sooting from burner
flame.
Too little primary air ..................................
If using LP gas, grill may not be
properly converted. ...................................
•Open air shutter on burner.
•Verify correct conversion procedures.
Some yellow tipping is normal on LP.
Floating flame. Blocked burner..........................................
Not enough air ..........................................
•Check for possible blockage to burner.
•Open air shutter.
Gas smell. Leak in pipe joints. •Verify gas connections and tighten if
necessary.

Component Testing Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power and shut off gas to unit before
servicing, unless testing requires power.
© 2005 Maytag Services 16025981 11
Illustration Component Test Procedure Results
Pressure regulator Verify gas pressure Water Column
Pressure (WCP).
If on LP service, verify proper gas
supply conversion.
4"(WCP) Natural
10"(WCP) LP/Propane
Spark module Test for voltage at terminals
L and N...........................................
Polarity and ground ........................
12 VDC
Not subject to polarity
Valve Verify gas is supplied.
Orifice adjusted for
Natural or LP.
Adjust set screw for simmer control.
See conversion section.
Ignitor Test for resistance of spark lead ..........
Test ignitor to chassis ..........................
Continuity
No continuity from ignitor to chassis.
H – Burner Verify gas is supplied ...........................
Check for obstructions in burner ports.
Top surface burner Verify gas is supplied ...........................
Verify burner cap is positioned
correctly.
Check for obstructions in burner ports.
Holder orifice Verify gas pressure (WCP).
Check orifice for debris.
4"(WCP) Natural
10"(WCP) LP/Propane
Clean as needed.
Spark ignition
electrode
Test for resistance of spark lead..........
Test ignitor to chassis ..........................
Continuity
No continuity from ignitor to chassis.
Rotisserie Motor Test for voltage at terminals 120 VAC

Disassembly Procedures
To avoid the risk of electrical shock, personal injury or
death; shut off gas supply before following any
disassembly procedure.
WARNING
!
12 16025981 ©2005 Maytag Services
Removing and Replacing Built-In Unit
1. Turn off gas supply to the grill.
NOTE: To avoid property or unit damage, place a
protective covering down to set unit on.
2. Disconnect or unplug any power supply unit by
junction box or outlet depending on connection.
3. Disconnect off gas supply from main gas supply line.
4. Reinstall grill, using Installation Instructions.
Hood Thermometer
Remove thermometer from the hood, by pushing the
stem of the thermometer from the inside of the hood.
Hood Handle
1. Remove screws securing handle bracket to front
hood.
NOTE: Once handle bracket is removed hood handle is
no longer secured.
2. Remove hood handle from handle bracket still
secured to front hood.
3. Replace failed component and reverse procedures to
reassemble.
Front Hood / Spit Saddle Brackets
1. Turn off gas supply to the grill.
2. Open hood to gain access to hinge points.
3. Remove nuts from bolts securing hinge points on spit
saddle brackets.
4. Remove spit saddle brackets from bolts each side.
5. Lower hood to closed position.
6. Remove bolts and spacers (each side) securing front
hood to rear hood.
7. Slowly raise front hood upward to remove from rear
hood.
8. Replace failed component and reverse procedures to
reassemble.
Rear Hood
NOTE: Units prior to 2003, rear hood was welded to
heating chamber.
1. Turn off gas supply to the grill.
2. Remove front hood, see Front Hood procedures.
3. Remove cooking grates from unit, by raising grates
out of burner box area.
4. Remove infra-red broiler bracket, see Infarred Broiler
Bracket procedures.
5. Remove screws securing front portion of rear hood.
6. Remove rear hood from unit.
7. Replace failed component and reverse procedures to
reassemble.
Knob Bezel(s)
1. Turn off gas supply to the grill.
2. Remove burner knobs from control panel, by pulling
knobs straight off.
• Wrap screwdriver with tape or rag to prevent
scratching knobs, if using to assist in removal.
3. Remove screws securing knob bezel to control
panel.
4. Replace failed component and reverse procedures to
reassemble.
Front Panel
1. Turn off gas and power supply to the cooktop.
2. Remove burner knobs from control panel, by pulling
knobs straight off.
3. Remove smoker tray, if equipped.
4. Remove screws securing control panel to unit
chassis (one on each end).
5. Pull bottom portion of control panel outward and slide
downward to remove completely from unit.
6. Replace failed component and reverse procedures to
reassemble.
Burner Valve(s)
1. Turn off gas supply to the grill.
2. Remove front panel, see "Front Panel" procedure.
3. Disconnect all gas lines from burner valves.
4. Remove top bolts and nuts securing manifold pipe.
5. Loosen bottom bolts and nuts securing manifold
pipe.
6. Rotate top portion of the manifold pipe forward to
allow access for valve removal.
7. Remove burner valve from manifold pipe, by
unscrewing burner valve from manifold pipe.
8. Replace failed component and reverse procedures to
reassemble.
NOTE: When installing, use pipe dope compound.
Perform gas leak test to ensure unit will not leak
and grill operates properly.
Gas Line(s)
1. Turn off gas supply to the grill.
2. Remove front panel, see "Front Panel" procedure.
3. Disconnect gas line from burner valve outlet and
burner inlet.
NOTE: If replacing infra-red burner gas line, see
"Infra-red Burner' procedure, for gas line
disconnection.
4. Replace failed component and reverse procedure to
reassemble.
NOTE: When installing, perform gas leak test to ensure
unit will not leak and grill operates properly.

Disassembly Procedures
WARNING
!
©2005 Maytag Services 16025981 13
To avoid the risk of electrical shock, personal injury or
death; shut off gas supply before following any
disassembly procedure.
Ignitor(s)
1. Turn off gas supply to the grill.
2. Remove cooking grates and briquet grates from
heating chamber.
3. Remove front panel, see "Front Panel" procedure.
4. Disconnect wire terminal from ignitor.
5. Remove bolts and nuts securing ignitor bracket to
heating chamber.
6. Remove ignitor bracket and ignitor from unit.
7. Remove bolt and nut securing ignitor to ignitor
bracket.
8. Replace failed component and reverse procedure to
reassemble.
H - Burner
1. Turn off gas supply to the grill.
2. Remove cooking grates and briquet grates from
heating chamber.
3. Raise rear of h - burner to release from bracket and
slide burner to the rear of the heating chamber to
remove.
4. Replace failed component and reverse procedure to
reassemble.
Infra-red Sear Burner
1. Turn off gas supply to the grill.
2. Remove searing grate from heating chamber.
3. Remove front panel, see "Front Panel" procedure.
4. Remove bolt and nut securing ignitor to heating
chamber.
5. Raise rear of infra-red sear burner to release from
bracket and slide burner to the rear of the heating
chamber to remove.
6. Replace failed component and reverse procedure to
reassemble.
Burner Support Bracket
1. Turn off gas supply to the grill.
2. Remove cooking grates and briquet grates from
heating chamber.
3. Raise rear of burner to release from bracket and
slide burner to the rear of the heating chamber to
remove. (Remove all burners from heating
chamber).
4. Remove screws securing support bracket to heating
chamber.
5. Remove support bracket from heating chamber.
6. Replace failed component and reverse procedure to
reassemble.
Spark Ignitor
NOTE: First determine the spark ignitor that needs
replaced.
1. Turn off gas supply to the grill.
2. Remove grease tray, by pulling tray out of unit (if
equipped).
3. Remove nut securing spark ignitor to bull nose.
4. Gently pry spark ignitor secured by stud and lower
spark ignitor from bull nose.
5. Label and disconnect wire terminals from spark
ignitor.
6. Replace failed component and reverse procedure to
reassemble.
Infra-red Broiler Ignitor
1. Turn off gas supply to the grill.
2. Remove screw securing ignitor bracket to infra-red
broiler bracket.
3. If screws contain nuts, remove access panel located
on the back of the rear hood to gain access to nuts.
4. Remove ignitor and bracket to gain access to wiring.
5. Disconnect wire terminal from ignitor to allow
complete removal from unit.
6. Remove screw and nut securing ignitor to bracket.
7. Replace failed component and reverse procedures to
reassemble.
Infra-red Broiler
NOTE: It may be necessary to remove infra-red broiler
ignitor to avoid damaging, before removing
infra-red broiler.
1. Turn off gas supply to the grill.
2. Remove screw securing access panel to the back of
the rear hood.
3. Remove access panel from rear hood.
4. Disconnect gas line from brass flange.
5. Remove screws securing infra-red broiler, one
located on each end.
6. Lift infra-red broiler out of infra-red broiler bracket.
7. Replace failed component and reverse procedures to
reassemble.

Disassembly Procedures
To avoid the risk of electrical shock, personal injury or
death; shut off gas supply before following any
disassembly procedure.
WARNING
!
14 16025981 ©2005 Maytag Services
Infra-red Broiler Bracket
1. Turn off gas supply to the grill.
2. Remove infarred broiler ignitor, see "Infra-red Broiler
Ignitor" procedure.
3. Remove infarred broiler, see "Infra-red Broiler"
procedure.
4. Remove cooking grates from unit, by raising grates
out of burner box area.
5. Remove screws securing bottom portion of broiler
bracket and support bar to the inside of rear hood.
6. Remove screws securing top portion of broiler
bracket on the back of the rear hood.
7. Slide one end of the broiler bracket forward to
remove from burner box area.
8. Replace failed component and reverse procedures to
reassemble.
Gas Regulator
1. Turn off gas supply to the grill.
2. Gas supply line to gas regulator.
• Hard piping - disconnect gas supply line at the
union.
• LP Tank - disconnect gas supply line from tank.
3. Disconnect appropriate piping from gas regulator.
4. Unscrew gas regulator from remaining piping.
5. Replace failed component and reverse procedure to
reassemble.
NOTE: When installing, use pipe dope compound.
Perform gas leak test to ensure unit will not leak
and grill operates properly.
Manifold Pipe
1. Turn off gas supply to the grill.
2. Remove front panel, see "Front Panel" procedure.
3. Disconnect all gas lines from burner valves.
4. Remove top and bottom bolts and nuts securing
manifold pipe to unit chassis.
5. Remove surface valves from manifold pipe.
6. Replace failed component and reverse procedure to
reassemble.
NOTE: When installing, use pipe dope compound.
Perform gas leak test to ensure unit will not leak
and grill operates properly.
Side Burner
1. Turn off gas supply to the grill.
2. Remove grate, burner cap, and burner ring from side
burner.
3. Disconnect gas line from the side burner.
4. Disconnect wire terminal from ignitor.
5. Remove screws securing side burner hub to chassis.
6. Replace failed component and reverse procedure to
reassemble.
Base Unit
Door / Door Hinge
1. Open door to gain access to hinges.
2. Push on metal tab to release door from hinge insert.
3. Remove screws securing hinge insert from cabinet
and door.
4. Reverse procedure to reassemble.
Drawer
1. Pull drawer out to the stop position.
2. Release locking tabs on each side of the drawer
slider.
3. Pull drawer out to completely release drawer from
slider.
4. Reverse procedure to reassemble.
Drawer Slider
1. Remove drawer, see "Drawer" procedure.
2. Remove screws securing slider to the cabinet.
3. Reverse procedure to reassemble.
Casters
1. Place a block underneath the unit to allow access to
the caster bolts.
2. Remove bolts securing caster to the bottom of the
base unit.
3. Reverse procedure to reassemble.

Disassembly Procedures
WARNING
!
©2005 Maytag Services 16025981 15
To avoid the risk of electrical shock, personal injury or
death; shut off gas supply before following any
disassembly procedure.
Typical Grill Component Layout
Spit
Saddle
Brackets
Infra-red
Broiler
Rear Hood
Assembly
Front Hood
Briquetts
H- Burner
Manifold
Heating
Chamber
Front Panel
Bezel
Knob
Cooking Grates
Thermometer Rotisserie
Assembly
Smoker
Box
Hood
Handle
Bezel
Ignitors
Valves
DripPan
Bullnose
Assembly

Disassembly Procedures
To avoid the risk of electrical shock, personal injury or
death; shut off gas supply before following any
disassembly procedure.
WARNING
!
16 16025981 ©2005 Maytag Services
Door
Drawers
Casters
Base
Drawer
Slide
Hinge
Side
Shelf
Side
Burners
Typical Base Unit
Typical Side Burners

A-1 16025981 © 2005 Maytag Services
Appendix A

© 2005 Maytag Services 16025981 A-2
Instruction Sheet
Description: L.P. Conversion for Outdoor Grill Series
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. Open lid
4. If odor continues, immediately call
your gas supplier or your fire department
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance
This conversion kit shall be installed by a qualified service agency in accordance with the
manufacturer’s instructions and all applicable codes and requirements of the authority having
jurisdiction. The information in these instructions must be followed to minimize the risk of fire or
explosion or to prevent property damage, personal injury or death. The qualified service agency is
responsible for the proper installation of this kit. The installation is not proper and complete until
the operation of the converted appliance is checked as specified in these instructions.
If the information in these instructions is not followed exactly, a fire or explosion, may result
causing property damage, personal injury or death
Procedure on other side

A-3 16025981 © 2005 Maytag Services
Procedure:
When converting outdoor grill gas valve to L.P. gas, be sure the incoming gas supply line is equipped with a
pressure regulator (located ahead of the unit) that will maintain the gas supply to the grill.
Surface Orifice Conversion:
NOTE: All orifices with no exception must be converted.
NOTE: Care must be taken to avoid damaging the threads on the orifice and/or valve
NOTE: Follow proper orifice quantities and sizes indicated on orifice chart below.
1. Turn equipment shut-off valve handle to the closed position (if so equipped).
2. Remove control knobs from unit, by pulling knobs off the valve stems.
3. Remove four screws securing front panel to chassis, two on each side.
4. Roll top portion of control panel downward to gain access to gas valves.
5. Remove stainless steel grates, briquette trays and main burners from firebox surface.
6. Replace Natural orifice(s) with Propane orifice(s) from main front gas valve by carefully screwing onto the gas
valve.
7. The infrared orifice is located at the rear of the grill.
8. Remove rear vent cover to access infrared orifice.
9. Disconnect flex line from elbow.
10. Replace infrared Natural orifice with Propane orifice by carefully screwing onto elbow.
11. The smoker orifice can be removed by pulling elbow assembly off the burner tube, then removing the orifice at
the elbow. Install new orifice into elbow assembly.
NOTE: The Natural gas regulator is convertible to Natural or Propane gas by flipping gas cap, when unit is being
hard piped to permanent gas supply.
12. Remove Natural gas regulator from gas manifold (if required)
13. Install propane regulator with hose to gas manifold (if required)
20. Verify that all the internal surfaces and components of the gas valve and new orifice are clean
21. Before turning on gas supply, check for leaks with a soap and water solution -
DO NOT USE AN OPEN FLAME - and verify that all gas valves are turned to the “OFF” position.
22. Adjust air shutters for optimum burner performance.
23. Complete conversion label and attach to BBQ next to rating plate
Orifice Chart
DBQ30MA DBQ30IA DBQ30PA
JBQ30BA
DBQ42PA
JBQ42BA
DBQ42SA DBQ55TA JBQ55HA
Item Btuh Natural
Orifice
Propane
Orifice
Main
Burner
25,000 #42 #53 2 n/a 2 3 2 2 3
Smoker
Burner
2,700 #65 #74 n/a 1 1 1 1 1 1
Small IR
Burner
14,000 #50 #57 n/a 1 1 n/a n/a n/a n/a
Large IR
Burner
16,000 #48 #56 n/a n/a n/a 1 1 1 1
Sear
Burner
20,000 #45 #55 n/a 2 n/a n/a 1 1 n/a
Side
Burner
Inner
17,500
total
#67 #76 n/a n/a n/a n/a n/a 2 2
Side
Burner
Outer
17,500
total
#50 #61 n/a n/a n/a n/a n/a 2 2

©2005 Maytag Services 16025981 B–1
Appendix B
