Dynavision DVN 6901 Pro V User manual

www.dynavin.de
Perfecting Your Perspective
DVN 6901 Pro VDVN 6901 Pro V
Camera + Display SystemCamera + Display System
for Fiat Ducato fully integrated vansfor Fiat Ducato fully integrated vans
Operating instructionsOperating instructions

www.dynavin.de 2
DVN 6901 Pro V Operating instructions

www.dynavin.de 3
DVN 6901 Pro V Operating instructions
Table of contents
Key assignment ..............................................................................................4
System components...................................................................................... 5
Menu settings..................................................................................................6
Extra Display For Reverse Camera .............................................................................6
Front Camera Active Automatically.......................................................................... 6
Reverse camera connected ............................................................................................6
Brightness...................................................................................................................................6
Language ....................................................................................................................................6
Wiring diagram...............................................................................................7
Views...................................................................................................................8
Flank protection......................................................................................................................8
Mirror view ..................................................................................................................................8
Front view....................................................................................................................................8
Blind Spot view........................................................................................................................9
Reversing view .........................................................................................................................9
Firmware update .......................................................................................... 10
Technical data ................................................................................................ 11
Display ...........................................................................................................................................11
Cameras........................................................................................................................................11

www.dynavin.de 4
DVN 6901 Pro V Operating instructions
Key assignment Press lightly to open
1 Calling up the menu / Exiting the menu
2 In the menu: navigate to the left
Outside the menu: Forward front camera view to external display
3 In the menu: navigate upwards
4 Navigate down in the menu
5 In the menu: Check / uncheck / open submenu / navigate to the right
Outside the menu: Switches between top view and front view
6 Micro SD slot for firmware updates
23
4
5
1
6

www.dynavin.de 5
DVN 6901 Pro V Operating instructions
System components
Front camera Rear view camera
available separately
Blind spot camera
Flip-up display
Blind spot camera

www.dynavin.de 6
DVN 6901 Pro V Operating instructions
Menu settings
Extra Display For Reverse Camera
If this function is activated, the rear view camera view is forwarded to another display, e.g. to the navigation device.
If no check mark is set, the rear view camera view is displayed on the monitor.
Note: For 1-DIN radio, please deactivate this option!
Front Camera Active Automatically
When this function is activated, the monitor displays the front camera view when driving slowly.
The threshold is 30 km / hour.
If the function „Extra Display For Reverse Camera“ is also activated, the navigation system displays the front camera view
while the monitor displays the mirror view.
Reverse camera connected
If the vehicle is equipped with a reverse camera, please activate this function.
Brightness
Here you can adjust the brightness of the display, values from 0 to 10.
Auto: Display switches to preset brightness when driving lights are switched on.
Manual: Display remains at set brightness
Language
Here you can set the menu language to German or English.

www.dynavin.de 7
DVN 6901 Pro V Operating instructions
Wiring diagram
1 2 3 4
5 6 7 8
1 2 3 4
5 6 7 8
PART PART B
A
GND
Connect To The OBD Of The Car
DVN 6901 Pro – V
Dynavision Lead A
Power & Data Adaptor Cable
3.5 m Extension Cable
Side-view Camera (L)
Left Camera Input
Reverse Trigger To Head Unit
Dynavision Lead B
Front Camera Input
To Head UnitVideo Output
Radio Connector
1 2 3 4
5 6 7 8
1 2 3 4
5 6 7 8
PART PART B
A
DVN 6901 Pro – V Wiring Diagram
Dynavision Front Camera
Dynavision Reverse Camera
(Option)
Video Input To Reverse Camera
12V To Reverse Camera
GND
Car Lead
Right Camera Input
Side-view Camera (R)

www.dynavin.de 8
DVN 6901 Pro V Operating instructions
Views
Front view
The front camera view can be shown either on the monitor or
on the external display.
Flank protection
The side cameras calculate a bird‘s eye view of the vehicle‘s
surroundings to the side.
This way, if the rear view camera is installed, you can see the
rear view on the navi display while the monitor shows the
view on the side.
Mirror view
In normal driving mode from 30 km/h, the monitor shows
the mirror view.
i
Note
The mirror view depends on the rear view
camera installed.
Here you see an example with Dynavision
Pro or Comfort camera.
i
Note
The front camera is not active here!
You cannot see what is in front of the
vehicle.
With this button you can switch
the front camera view

www.dynavin.de 9
DVN 6901 Pro V Operating instructions
Blind Spot view
When the indicator is set, the side camera is activated.
The display shows what is in the blind spot.
Reversing view
If you have connected a reversing camera to the monitor, the
reversing view is shown on the monitor or on the navigation
display when reverse gear is engaged.
You can set this in the menu (menu item 1).
You can set the parking lines
with these buttons
i
Note
The mirror view depends on the rear view
camera installed.
Here you see an example with Dynavision
Pro or Comfort camera.
i
Note
If you have connected a Dynavision Pro
or Comfort camera to the display, you can
adjust the parking lines.

www.dynavin.de 10
DVN 6901 Pro V Operating instructions
Firmware update
The DVN 6901 Pro system is updateable.
This means that new functions can be added in the future.
To update the system, you need an empty micro SD card.
This is how you proceed:
• Go online to our website www.dynavin.de
• Navigate to the menu Downloads / Firmware Updates
• Download the new firmware to your PC
• Unzip the firmware
• Copy the unzipped files to your empty micro SD card.
• Switch on the system via the ignition.
• There is a Micro-SD slot on the right side of the monitor, insert the SD card.
• The update starts automatically

www.dynavin.de 11
DVN 6901 Pro V Operating instructions
Declaration of compliance
Dynavin GmbH hereby confirms that this product complies with the essential requirements of
all relevant directives and regulations in force in the European Community.
The declaration of compliance is available for download on our website:
https://www.dynavin.de/wp-content/uploads/Dynavision-CE-Konform.pdf
CE compliance
Disposal of old appliances
Only for the European Union and countries with recycling systems.
This symbol, on the products, packaging and/or accompanying documents means,
that used electrical and electronic products must not be disposed of with general household waste. Please take
old products to the appropriate collection points for treatment, refurbishment or recycling in accordance with the
law.
By disposing of these products properly, you will help to protect valuable resources and avoid any negative impact
on human health and the environment.
For more information on collection and recycling, please contact your local waste management service provider. In
accordance with national regulations, penalties may be imposed for improper disposal of this waste. fines may be
imposed for failure to dispose of this waste properly.
Technical data
Display
Display size: ................................................ 7‘‘
Resolution: .................................................. 800 x 480 pixel
Video input channels: ......................... 4
Video output channels:...................... 1
Linbus and 1 CANBUS connection
Firmware update via micro SD card
Cameras
Resolution: ................................................. 720 x 480 pixel
Image mode:............................................. NTSC
CMOS sensor:............................................ 1/4 CMOS AR0140
............................................................................. from ON-Semi
ISP:.................................................................... GW4 from GEO-Semi
Lens FOV: ..................................................... Horizontal 210°,
............................................................................. Vertical 140°
IP67 waterproof

DVN 6901 Pro V Operating instructions
Rev. 1.0
Dynavin GmbH
Siemensstr. 7
76316 Malsch
Germany
E-Mail: inf[email protected]
© 2021 Dynavin GmbH
All rights reserved.
Reprinting and reproduction, in whole or in parts, is prohibited.
The characteristics of the products are correct at the time of printing.
We assume no liability for possible typesetting errors.
The color of the products may vary.
Check with your dealer to see if the actual specifications meet your requirements.
We reserve the right to make changes.
Perfecting Your Perspective
