E-TOP P/I-P3BVL User manual

P
P/ /I I- -P P3 3B BV VL L
Full-Size PGA370 Pentium II/III AIO CPU Card
User's Manual
Version 2.0

ii P/I-P3BVL User's Manual
Copyright Notice
This publication is protected by copyright and all rights are reserved.
No part of it may be reproduced or transmitted by any means or in any
form, without prior consent of the original manufacturer.
The information in this document has been carefully checked and is
believed to be accurate. However, the original manufacturer assumes
no responsibility for any inaccuracies that may appear in this manual.
In no event will the original manufacturer be liable for direct, indirect,
special, exemplary, incidental, incidental or consequential damages
resulting from any defect or omission in this manual, even if advised of
possibility of such damages. The material contained herein is for
informational purposes only.
Acknowledgments
Award is a registered trademark of Award Software International, Inc.
ATI RAGEXL is a trademark of ATI Technologies Inc.
IBM, PS/2 are trademarks of International Business Machines
Corporation.
Intel and Pentium are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
All other product names or trademarks are properties of their respective
owners.

Contents
P/I-P3BVL User's Manual iii
Contents
Chapter 1 Introduction.............................................1
Checklist..............................................................................2
Description ..........................................................................2
Features...............................................................................4
Specifications.......................................................................5
Intelligence ..........................................................................9
Chapter 2 Installations...........................................11
CPU Installation................................................................12
Memory Installation..........................................................13
Jumpers on the P/I-P3BVL............................................... 14
Jumper Locations on the P/I-P3BVL ........................................15
JP1: On-Board VGA Enable/Disable selection.......................16
JP2 ~ 6: CPU Frequency Selector..............................................16
JP8: ATX POWER........................................................................17
JP10: CMOS RAM Data..............................................................18
JP12: WatchDog Timer Mode Selection..................................18
JP13~14: WatchDog Timer Period Selection..........................19
JP15~JP17: DiskOnChip Expansion Address Select.............19
JP18: On-Board LAN Enable/Disable selection.....................20
Connectors on the P/I-P3BVL ..........................................21
Connector Locations on the P/I-P3BVL...................................22
Front Panel Connector..................................................................23
EIDE Connectors...........................................................................25
Floppy Drive Connector...............................................................27
Parallel Port Connector.................................................................28
COM1 Serial Port..........................................................................29
COM2 Serial Port..........................................................................29
External Keyboard Connector.....................................................30
PS/2 Keyboard Connector ...........................................................30
PS/2 Mouse Connector.................................................................31
VGA Connector..........................................................................31
CPU Fan Power Connector..........................................................31
USB Connectors.............................................................................32

Contents
iv P/I-P3BVL User's Manual
IrDA Connector..............................................................................32
ATX Power on Button ..............................................................32
ATX Power Connector.................................................................33
Chassis Fan Power Connector ....................................................33
LAN-RJ45 Connector..................................................................33
LAN LEDs...................................................................................34
Watchdog Timer Configuration........................................34
Chapter 3 BIOS Configuration...........................36
BIOS Introduction.............................................................37
BIOS Setup ........................................................................37
Standard CMOS Setup......................................................39
Date.............................................................................................................39
Time.............................................................................................................40
Primary HDDs / Secondary HDDs......................................................40
Drive A / Drive B......................................................................................41
Video ...........................................................................................................41
Halt On.......................................................................................................41
BIOS Features Setup.........................................................42
Virus Warning...........................................................................................42
CPU Internal Cache / External Cache ...............................................42
CPU L2 Cache ECC Checking.............................................................43
Processor Number Feature....................................................................43
Quick Power On Self Test......................................................................43
Boot Sequence...........................................................................................43
Swap Floppy Drive..................................................................................43
Boot Up Floppy Seek...............................................................................43
Boot Up NumLock Status .......................................................................43
Gate A20 Option.......................................................................................43
Typematic Rate Setting ...........................................................................44
Typematic Rate (Chars/Sec)..................................................................44
Typematic Delay (Msec).........................................................................44
Security Option.........................................................................................44
PCI/VGA Palette Snoop .........................................................................44
OS Select for DRAM > 64MB...............................................................44
Report No FDD For WIN 95.................................................................44
Video BIOS Shadow ................................................................................44
C8000 -CBFFF Shadow/DC000 -DFFFF Shadow.......................45
Chipset Features Setup......................................................45
Auto Configuration..................................................................................45
SDRAM RAS-to-CAS Delay...................................................................45
SDRAM RAS Precharge Time...............................................................45
SDRAM CAS Latency Time ...................................................................46
DRAM Data Integrity Mode..................................................................46

Contents
P/I-P3BVL User's Manual v
System BIOS Cacheable..........................................................................46
Video BIOS Cacheable............................................................................46
Video RAM Cacheable............................................................................46
8 Bit I/O Recovery Time..........................................................................46
16 Bit I/O Recovery Time.......................................................................46
Memory Hole at 15MB -16MB.............................................................46
Passive Release.........................................................................................47
Delayed Transaction................................................................................47
AGP Aperture Size (MB) ........................................................................47
Auto Detect DIMM/PCI Clk ..................................................................47
Spread Spectrum.......................................................................................47
CPU Host Clock (CPU/CLK)................................................................47
CPU Warning Temperature...................................................................47
Current System Temp. .............................................................................48
Current CPU1 Temperature..................................................................48
Current CPU FAN1 Speed.....................................................................48
VCCP / VTT / VCC3................................................................................48
Shutdown Temperature...........................................................................48
Power Management Setup................................................49
ACPI function ........................................................................................49
Power Management.................................................................................49
PM Control by APM................................................................................50
Video Off Method .....................................................................................50
Video Off After..........................................................................................50
Modem Use IRQ .......................................................................................50
Doze Mode .................................................................................................50
Standby Mode............................................................................................50
Suspend Mode ...........................................................................................50
HDD Power Down...................................................................................50
Throttle Duty Cycle..................................................................................50
VGA Active Monitor.................................................................................51
IRQ 8 Break Suspend...............................................................................51
PNP/PCI Configuration.................................................... 51
PNP OS Installed......................................................................................51
Resources Controlled by.........................................................................52
Reset Configuration Data.......................................................................52
IRQ3/4/5/7/9/10/11/12/14/15, DMA0/1/3/5/6/7 assigned to..........52
Load BIOS Defaults..........................................................52
Load Setup Defaults..........................................................53
Integrated Peripherals ......................................................54
IDE HDD Block Mode............................................................................54
IDE Primary/Secondary Master/Slave PIO.......................................54
IDE Primary/Secondary Master/Slave UDMA.......................................54
On-Chip Primary/Secondary PCI IDE ...............................................55

Contents
vi P/I-P3BVL User's Manual
USB Keyboard Support...........................................................................55
Init Display First......................................................................................55
Onboard FDC Controller ......................................................................55
Onboard Serial/Parallel Port ...............................................................55
UART Mode Select...................................................................................55
Parallel Port Mode..................................................................................55
Supervisor / User Password...............................................56
IDE HDD Auto Detection..................................................57
Save & Exit Setup..............................................................58
Exit Without Saving ..........................................................59
Appendix ...............................................................................60
A. I/O Port Address Map...................................................60
A. I/O Port Address Map...................................................61
B. Interrupt Request Lines (IRQ) ..................................62

Chapter 1 Introduction
P/I-P3BVL User's Manual 1
1
Introduction
This manual is designed to give you information on the P/I-P3BVL
SBC card. The topics covered in this chapter are as follows:
♦Checklist
♦Description
♦Features
♦Specifications
♦Intelligence

Chapter 1 Introduction
2P/I-P3BVL User's Manual
Checklist
Please check that your package is complete and contains the items
below. If you discover damaged or missing items, please contact your
dealer.
üThe P/I-P3BVL Industrial SBC Card
ü1 IDE Ribbon Cable
ü1 Floppy Ribbon Cable
ü1 Serial Port Ribbon Cable and 1 Parallel Port Attached to a
Mounting Bracket
ü1 Serial Port Ribbon Cable Attached to a Mounting Bracket
ü1 CD-ROM Containing ATI VGA Driver, Intel 82559 LAN
Driver, BIOS Udate Utility and User's Manual.
üPS/2 to AT Keyboard Cable
Description
The P/I-P3BVL is a Pentium III Industrial single board computer (SBC)
card based on Intel's 440BX chipset and is fully designed for harsh
industrial environment. It features a PPGA Socket370 that is
compatible with low-profile Intel PPGA package Celeron processors as
well as Intel FC-PGA package Pentium III processor. This card
accommodates up to 384MB of un-registered SDRAMs or 768MB of
registered SDRAM configurations.
The P/I-P3BVL is a high integration design. Intel newest 82559
Fast Ethernet Controller and ATI 3D RageXL 2X AGP VGA controller
are integrated into the system. The high-integration design prevents the
system compatibility issues and increases the PCI add-on cards
scalability. This makes P/I-P3BVL an ideal SBC card for CTI, ISP
servers, workstations, automation as well as other industrial
applications.
The P/I-P3BVL comes with Winbond's W83782 hardware
monitoring device that monitors system and CPU temperature, system
voltages, and CPU fan speeds to prevent system crashes by warning the
user of adverted conditions. The power management feature provides
power savings by slowing down the CPU clock, turning off the monitor
screen and stopping the HDD spindle motor.

Chapter 1 Introduction
P/I-P3BVL User's Manual 3
This page is intentionally left blank.

Chapter 1 Introduction
4P/I-P3BVL User's Manual
Features
•Muilti-Speed: Supports Intel PPGA Celeron Processor from
300M to 1.1GMHz with 66/100MHz FSB and Intel FC-PGA
Pentium III Processor from 500M to 1.1GHz with 100MHz
FSB Speed.
•Low-profile CPU package: Low-profile CPU package makes
the board more compact and reliable and enhances the
add-on-cards scalability.
•Intel 440BX AGPset: Features Intel's 440BX AGPset with
I/O subsystems and front-side bus (FSB) platform, which
boosts the traditional 66-MHz internal bus speed to 100MHz.
•PC/100 Memory Support: Equipped with three DIMM
sockets to support Intel PC/100-compliant SDRAMs(8, 16, 32,
64, 128MB or 256MB). Up to 384MB of un-registered
SDRAMs or 768MB of registered SDRAM system memory.
•ECC function support: Processor front-side bus (FSB) and
Memory subsystem support ECC function for Fault-tolerant
application.
•10/100Base-T Fast Ethernet: Features Intel 82559 Fast
Ethernet controllers that boost network performance, enhances
the system manageability and offers the proven compatibility.
•ATI AGP VGA Chipset: Features ATI RageXL 2X AGP
chipset that support high-performance 2D and 3D graphic as
well as DVD / MPEG-2 decode assist. Integrated 8MB
SGRAM Display buffer runs on 120MHz Speed.
•PCI Bus Master IDE Controller: Two enhanced IDE
channels for up to four devices, support PIO Mode 3/4 or
Ultra DMA/33 IDE Hard Disk, ATAPI CD-ROM and LS-120
drive.
•Watch-Dog Timer: 4 level programmable watchdog timer,
from 10-80 seconds.
•Super Multi-I/O: Provides two high-speed UART compatible
serial ports and one parallel port with SPP, EPP and ECP
capabilities.
•IrDA: Support an optional infrared port module for wireless
interface.
•Concurrent PCI: Allows multiple PCI transfers from PCI
master buses and AGP bus to memory to CPU.

Chapter 1 Introduction
P/I-P3BVL User's Manual 5
•Hardware Monitoring: Features Winbond W83782D to
monitor all the power rails as well as CPU and board
temperature. It can alert user through the speaker or buzzer
when CPU temperature exceeds the safe heat level.
•Enhanced ACPI: Features a programmable BIOS (Flash
EEPROM), Offering enhanced ACPI for Windows98
compatibility and autodetection of most devices for virtually
automatic setup.
Specifications
•Processor Socket: Socket370 for PPGA (Plastic Pin Grid Array)
and FC-PGA package CPU.
•Processor:
§Intel Celeron Processor
500/550/600/650/700/750/800/850MHz/1/1.1GHz (100MHz
and 66MHz FSB)
§Intel FC-PGA Pentium III
500/550/600/650/700/750/800/850MHz/1/1.1GHz (100MHz
and 66MHz FSB)
•Chipset: Intel 440BX AGPset with PCI EIDE and RTC built-in
•Secondary Cache: 128KB(Celeron) or 256K(Pentium III) L2
cache integrated in CPU and runs on CPU core frequency.
•Memory Sockets:
Three 168-pin DIMM sockets
Memory types: 3.3V SDRAM (Synchronous DRAM) support
8MB to 768MB memory capacity
NOTE: Only SDRAM modules that support SPD (Serial
Presence Detect) should be use. Use PC100 modules when
running 100MHz CPU bus speed and use PC66/PC100
modules when running 66MHz CPU bus speed.
•BIOS: Award BIOS, PnP support
§FLASH EEPROM (256KB) for BIOS update
§Enhanced ACPI BIOS and DMI 2.0
§ISA Plug and Play (PnP) extension
§Power management
§Anti-Boot Virus
§Intel 82559 Boot-ROM
•DMI BIOS Support: Desktop Management Interface (DMI)
allows users to download system hardware-level information such

Chapter 1 Introduction
6P/I-P3BVL User's Manual
as CPU type, CPU speed, internal/external frequencies and
memory size.
•Multi I/O: Winbond W83977EF
§Parallel Port: One high-speed parallel port, SPP/EPP/ECP
mode
§Serial Port: Two 16550 UART compatible ports with COM1
and COM2 as RS232
§IrDA Interface: Pin-header connector for the optional IrDA
external connector
•Enhanced IDE: Two Bus Mastering EIDE mode, up to 4 devices,
Two EIDE interfaces for up to four devices, support PIO Mode 3/4
or Ultra DMA/33 IDE Hard Disk, ATAPI CD-ROM and LS-120
drive
•FDD Interface: Two floppy drives (360KB, 720KB, 1.2MB,
1.44MB, 2.88MB)
•AGP bus VGA: ATI RAGEXL chipset
§Support 8MB SGRAM frame buffer, which runs on 120MHz
speed and provides bandwidth up to 960MB/Sec.
§AGP 2X mode (133MHz) offers a peak bandwidth in excess of
500MB/s
§Support DVD and video with enhanced motion compensation
accelerator
§Incorporated 2D and 3D acceleration engine
§230MHz DAC supports 85Hz refresh at 1600x1200x256
resolution
§2D display mode / refresh rates
Colors 256 65K 16.7M
Buffer Size 2MB 2MB 4MB 2MB 4MB 8MB
640x480 200 200 200 200 200 200
800x600 200 200 200 200 200 200
1024x768 150 150 150 150 150
1152x864 120 120 120 120 120
1280x1024 100 100 100 100
1600x1200 85 85 75

Chapter 1 Introduction
P/I-P3BVL User's Manual 7
§Software supported
SOFTWARE SUPPORT DOS Win 3.x Win 95 Win 98 NT 3.51 NT 4.0 Win2K OS/2
2D Software Support (Note 1)
•Accelerated driver support VESA2
üüüüüü6ü
•AutoCAD / MicroStation ü
Video Software Support
•Microsoft DirectDraw üüüü
•Microsoft ActiveMovie/DirectShow üüü
•MPEG-1 software playback üüüü
•DVD/MPEG-2 software playback üüü
•QuickTime acceleration
3D Software Support
•Microsoft Direct3D üüü
•QuickDraw 3D RAVE
•OpenGL (Note 3) üüüü
•ATI 3D CIF (Note 4) üü
•AGP üü5ü
1Additional drivers available from 3rd parties (including SCO and UNIXWARE);2Direct BIOS support;
3 OpenGL LCD; 4 ATI's 3D API for the 3D RAGE family; 5 NT 4.0 Service Pack 3 supports AGP devices, but
does not provide support for AGP Texturing;. 6 Includes QuickDraw support.
•USB Interface: Two USB pin-header connectors, compliant with
USB Specification Rev. 1.0 and support USB Hot-Plug function.
•DiskOnChip: The M-Systems flask disk supports system boot and
storage capacity from 2MB to 288MB.
•ATX Power Supply support:
§On-borad 4-pin ATX power supply header (requires the
passive backplane supports ATX power supply)
§On-board power button header for Soft power off, i.e. front
panel turn off system power.
§Support Win95 and Win98 shutdown automatically turn off
the system power.
§Instant-off or delay-4-seconds selectable via BIOS setup.
•Hardware Monitor System:
§PC Health Monitoring ASIC supports system power voltages,
FAN speed and system temperatures monitoring.
§One FAN connector and one thermal couple header reserved
for chassis FAN and temperature monitoring.

Chapter 1 Introduction
8P/I-P3BVL User's Manual
§CPU over-temperature beep-tone alarm or auto-shutdown. The
trigger temperature is selectable via BIOS setup.
§Hardware monitoring application software supported for
Windows95/98 and NT 4.0. (optional)
§Intel LDCM (DMI driver 2.0) support. (optional)
•Watchdog Timer:
§Read I/O port 0443H to enable watchdog.
§Read I/O port 043H to disable watchdog.
§10s, 20s, 30s and 80s timeout period selectable.
•Green Function: Power management via BIOS, activated through
mouse/keyboard movement or SMI button
•Keyboard and Mouse Connectors: Two 6-pin mini-DIN
connectors are located on the mounting bracket for easy
connection to a keyboard and PS/2 mouse. A 5-pin on-board
keyboard pin header connector is also available to support PC/AT
style external keyboard connector on backplane.
•PICMG Compliance: Fully compliant to PICMG 2.0 standards.
•Environmental and Mechanical:
§Power Supply: 8A@ +5v typical; 300mA@
+12v typical
100mA@ -12V typical; 200mA@ +5VSTB (Option)
§Temperature: 0°C to 60°C operating
-40°C to 70°C storage
§Humidity: 5% to 95%
§Dimensions: 13.3"(L) x 4.8"(W) or
338mm (L) x 124mm (W)

Chapter 1 Introduction
P/I-P3BVL User's Manual 9
Intelligence
•Temperature Monitoring and Alert: A sensor for the CPU
temperature on the P/I-P3BVL monitors the CPU temperature and
alerts the user through the speaker or buzzer when temperature
exceeds the safe heat level.
•Year 2000 Compliant BIOS: The onboard Award BIOS is Year
2000 Compliant and will pass software applications that have the
tendency to invoke INT 1Ah function 04H such as year2000.exe
utility released by NSTL.
•Workstation class On-Board VGA: The built-in ATI Rage XL
VGA chip support AGP 2X (133MHz) mode with Sideband
Addressing and AGP Texturing(Execute mode) to realize all the
benefits of AGP. Superior 3D performance achieved through a
floating point setup engine rated at 1.2 million triangles/sec.
•Newest Intel Fast Ethernet built-in: The newest Intel 82559 Fast
Ethernet controller is integrated into the SBC card. The drivers for
most popular Operation systems and NOS have been validated and
proved the compatibility. It also supports latest network standards
and protocols like speed auto-negotiation between 10Base-T and
100Base-T, half/full duplex (IEEE8023.3u), flow-control
(IEEE8023X), VLAN(IEEE802.3Q), Priority packet(IEEE802.3P)
and etc. The multi-protocols support ensures the best
interoperability.

Chapter 1 Introduction
10 P/I-P3BVL User's Manual
This page is intentionally left blank.

Chapter 2 Installations
P/I-P3BVL User's Manual 11
2
Installations
This chapter provides information on how to use the jumpers and
connectors on the P/I-P3BVL in order to set up a workable system.
The topics covered are:
CPU Installation ................................................................................12
Memory Installation..........................................................................13
Jumpers on the P/I-P3BVL .............................................................14
Connectors on the P/I-P3BVL........................................................21
Watchdog Timer Configuration.....................................................34

Chapter 2 Installations
12 P/I-P3BVL User's Manual
CPU Installation
The P/I-P3BVL Industrial SBC Card provides a 370-pins ZIF socket
for Celeron and Pentium II/III-processors with PPGA (Plastic Pin
Grid Array) package.
Before installing the processor into the Socket, ensure that the CPU
fan is installed first. Without a fan circulating air on the CPU, the
CPU can overheat and cause damage to both CPU and SBC card.
To Install a CPU, first turn off your system and remove its cover.
Locate the ZIP socket and open it by first pulling the lever sideways
away from the socket then upwards to a 90-degree right angle.
Insert the CPU with the correct orientation. Use the notched corner of
the CPU with the white dot as your guide. The white dot should point
towards the end of the lever. Notice that there is a blank area where
one hole is missing from that corner of the square array of pin holds.
Because the CPU has a corner pin for three of the four corners, the
CPU will only fit in one orientation. With the added weight of the
CPU fan, no force is required to insert the CPU. Once completely
inserted, hold down on the fan and close the socket lever.
To disassembly the processor, simply pull the lever sideways away
from the socket then upward to a 90-degree right angle. You can take
the CPU out from the socket without help of any tool.
WARNING!: If no FAN circulating Air on the CPU, the processor
might been overheated and damage both CPU and SBC components.
IMPORTANT: You must set jumpers for "CPU to BUS Frequency
Ratio" and jumper for "CPU FSB speed" depending on the CPU that
you install.

Chapter 2 Installations
P/I-P3BVL User's Manual 13
Memory Installation
The P/I-P3BVL Industrial CPU Card supports three 168-pin DIMM
sockets for a maximum total memory of 384MB unregistered
SDRAMs or 768MB registered SDRAMs. The memory modules can
come in sizes of 16MB, 32MB, 64MB, 128MB and 256MB (for
registered type) SDRAMs.
The P/I-P3BVL Industrial CPU Card supports three 168-pin DIMM
(Dual In-line Memory Module) sockets. In populating the DIMM
sockets, DIMM1 and/or DIMM3 bank should be populated first for
less signal reflection. However, we do not see any issue while
populate DIMM2 only. Refer to the following table on how to
configure the memory.
NOTE: Use SDRAM modules with PC100 specification when
running 100MHz CPU bus speed. With 66MHz CPU bus speed,
SDRAM modules with PC66 or PC100 specification can be used.
168-pin DIMM (3.3V) Unregistered SDRAM
Bank0
(DIMM1)
Bank1
(DIMM2)
Bank2
(DIMM3)
Total Memory
8MB ----- ----- 8MB
16MB ----- ----- 16MB
32MB ----- ----- 32MB
64MB ----- ----- 64MB
128MB ----- ----- 128MB
8MB ----- 8MB 16MB
16MB ----- 8MB 24MB
32MB ----- 8MB 40MB
64MB ----- 8MB 72MB
128MB ----- 8MB 136MB
16MB 16MB 8MB 40MB
32MB 16MB 16MB 64MB
64MB 16MB 32MB 112MB
128MB 16MB 64MB 208MB
32MB 32MB 128MB 192MB
64MB 32MB 16MB 112MB
128MB 32MB 32MB 192MB
64MB 64MB 64MB 192MB
128MB 64MB 64MB 256MB
128MB 128MB 128MB 384MB

Chapter 2 Installations
14 P/I-P3BVL User's Manual
Jumpers on the P/I-P3BVL
The jumpers on the P/I-P3BVL allows you to configure your SBC
card according to the needs of your applications. If you have doubts
about the best jumper configuration for your needs, contact your
dealer or sales representative. The following table lists the jumpers
on P/I-P3BVL and their respective functions.
Jumper Locations on the P/I-P3BVL ...................................... 15
JP1: On-Board AGP VGA Enable/Disable Selection ...........16
JP2 ~ 6: CPU Frequency Selector..............................................16
JP8: ATX Power............................................................................17
JP10: Clear CMOS RAM Data...................................................18
JP12: WatchDog Timer Mode Selection..................................18
JP13~14: WatchDog Timer Period Selection........................ 19
JP15~17: DiskOnChip BIOS Expansion Address Select .....19
JP18: On-Board LAN Enable/Disable selection.....................20
