EarthLinked SCWD-024-1C Programming manual

SCWD-QS (12/16) ©2016 EarthLinked Technologies, Inc.
Classic Series
SCWD Geothermal Heating and Cooling System
Quick-Start Instructions

SCWD-QS (12/16) Page 2
Table of Contents
List of Figures.....................................................................................................................................3
List of Revisions.................................................................................................................................4
Model Nomenclature..........................................................................................................................5
Safety.................................................................................................................................................6
Equipment Manuals............................................................................................................................6
Installation..........................................................................................................................................7
1) Component Matching...........................................................................................................7
2) Compressor Unit Placement................................................................................................8
3) Refrigeration........................................................................................................................9
4) System Applications and Electrical....................................................................................13
5) SureStart...........................................................................................................................19
6) Plumbing ...........................................................................................................................23
7) Antifreeze Protection .........................................................................................................25
8) Internal Heat Recovery System .........................................................................................27
Earth Loop Protection System..........................................................................................................30
1) Anode Wire Installation......................................................................................................30
2) EPS Operation and Service...............................................................................................35
3) Voltage Verification............................................................................................................36
Start-Up Process..............................................................................................................................37
1) System Leak Check...........................................................................................................37
2) Evacuation.........................................................................................................................40
3) Initial Charge .....................................................................................................................42
4) Final Charge......................................................................................................................44
Troubleshooting ...............................................................................................................................49
1) Compressor.......................................................................................................................49
2) System ..............................................................................................................................53
Commissioning Document................................................................................................................56
Tools and Equipment .......................................................................................................................57
Triple Evacuation .............................................................................................................................58
Appendix A: Electrical Diagrams –No SureStart.............................................................................59
Appendix B: Functions of the Nano-PLC..........................................................................................62

SCWD-QS (12/16) Page 3
List of Figures
Figure 1. Matching Component Model Numbers..................................................................................7
Figure 2. General Layout of System Components ..............................................................................8
Figure 3. Compressor Unit Clearance..................................................................................................9
Figure 4. SCWD Connections............................................................................................................10
Figure 5. Line Set Sizes.....................................................................................................................12
Figure 6. SCWD Electric Box Components & Electrical Data.............................................................14
Figure 7. SCWD Compressor Unit Electrical Schematic Diagram, 230-1-60......................................15
Figure 8. SCWD Compressor Unit Electrical Schematic Diagram, 230-3-60......................................16
Figure 9. SCWD Hydronic Heating/Cooling/Water Heating Sytem Application...................................17
Figure 10. SCWD Hydronic Heating/Cooling/Water Heating System Field Wiring Diagram ...............18
Figure 11. SureStart Mode of Operation............................................................................................20
Figure 12a. Typical SCWD Primary Hydronic Circuit Plumbing..........................................................23
Figure 12b. Standard Storage Water Heater—Service Connections..................................................27
Figure 12c. GSTE Storage Water Heater—Service Connections.......................................................28
Figure 12d. GSTE Storage Water Heater—Tank Top View ...............................................................28
Figure 13. Compressor Cabinet Socket/Cap.....................................................................................30
Figure 14. Disassembled Plug Connector.........................................................................................31
Figure 15. Anode Wire Insertion .......................................................................................................32
Figure 16. Install the Plug Insert .......................................................................................................33
Figure 17. Engage the Gland Nut .....................................................................................................33
Figure 18. Secure the Anode Wire....................................................................................................34
Figure 19. The Plug and Socket Joint...............................................................................................34
Figure 20. Electric Box with EPS Components .................................................................................35
Figure 21. EPS Voltage Ratings .......................................................................................................36
Figure 22. Typical Test for DC Voltage.............................................................................................36
Figure 23. SCWD Internal Flow Schematic........................................................................................38
Figure 24. SCWD Piping....................................................................................................................39
Figure 25. Evacuation of SCWD System ...........................................................................................41
Figure 26. Initial Charge of SCWD System........................................................................................43
Figure 27. Final Charge of SCWD System........................................................................................45
Figure 28. Charging to the Middle Sight Glass (Heat only units).......................................................46
Figure 29. Final charging to the Top Sight Glass (Heat/Cool units)...................................................46
Figure 30. Pressure-Temperature for R-410A....................................................................................47
Figure 31. Start-Up Process ..............................................................................................................48
Figure 32. Compressor Unit Voltage Information..............................................................................50

SCWD-QS (12/16) Page 4
Figure 33. Compressor Motor Circuit Testing....................................................................................51
Figure 34. Compressor Motor Grounded Winding Test.....................................................................52
Figure 35. System Troubleshooting Chart.........................................................................................53
Figure A1. SCWD Compressor Unit Electrical Schematic Diagram (No SureStart), 230-1-60……..60
Figure A2. SCWD Compressor Unit Electrical Schematic Diagram (No SureStart), 230-3-60……..61
List of Revisions
New EPS system –Revised Electric Box
Carried over:
SureStart does not come standard on Classic Series compressor units
anymore. It remains an option, similarly to the EDM system
Revised charging method due to elimination of TXV
Removed the requirement to add 1,000 BTUH to the Heating Load for each
occupant if domestic water heating by Heat Recovery Module (HRM) is part
of the system. See Technical Bulletin TEC-021616.

SCWD-QS (12/16) Page 5
Model Nomenclature
Disclaimer
Proper installation and servicing of the EarthLinked®Heat Pump is essential to its reliable
performance. All EarthLinked®systems must be installed and serviced by a technician trained and
authorized by Earthlinked Technologies. Installation and service must be made in accordance with the
instructions set forth in this manual. Failure to provide installation and service by an ETI trained and
authorized installer consistent with this manual will void and nullify the limited warranty coverage for
the system.
EarthlinkedTechnologies shall not be liable for any defect, unsatisfactory performance, damage or
loss, whether direct or consequential, relative to the design, manufacture, construction, application or
installation of the field specified components.
Earthlinked Technologies, Inc.
4151 S. Pipkin Road
Lakeland, Florida 33811 USA
phone: 863-701-0096 | toll-free: 866-211-6102
General Info: info-question@earthlinked.com
www.earthlinked.com
CSI # 23 80 00

SCWD-QS (12/16) Page 6
Safety
Warning, Caution and Important notices appear throughout the manual. Read these items carefully
before attempting installation, servicing or troubleshooting the equipment.
Equipment Manuals
The following is a listing of the equipment installation manuals that are provided with each component
specified for this EarthLinked®system.
Series SV Service Valve and AKS Adapter Kit
Series HCM Hybrid Cooling Module
Series GSTE Storage Water Heater
Series GSTE Hydronic Buffer Tank
Model HHK/CWK-1872 Temperature Control Kit
Earth Loop Specification and Installation Manual
Earth Loop Protection Kit Installation Manual
IMPORTANT!
Notification of installation, operation or maintenance information which
is important, but which is not hazardous.
WARNING!
Indicates a hazardous situation, which if not avoided will result in
serious injury or death, or equipment or property damage.
CAUTION!
Indicates a potentially hazardous situation or an unsafe practice, which
if not avoided, may result in injury, or equipment or property damage.
IMPORTANT!
Read and follow all installation instructions in these manuals,
appropriate for the EarthLinked®system being installed, BEFORE
initiating the Start-Up procedure.

SCWD-QS (12/16) Page 7
Installation
1) Component Matching
Upon receipt of the equipment, carefully check the component model numbers by referencing
Figure 1, to ensure that all components of the system match.
Classic Systems
Compressor Unit1
Hybrid Cooling Module
Earth Loop2
-024
HCM-1860C
-024-C
-030
-030-C
-036
-036-C
-042
-042-C
-048
-048-C
-060
-060-C
1. Contained in each compressor package: compressor unit; four L-shaped hold
down brackets; service valves-liquid and vapor; adapters for service valves and
earth loop line set; product literature
2. All series Earth Loops
Figure 1. Matching Component Model Numbers
Guidelines for the general layout of the system components are shown in Figure 2. Before placing the
compressor unit (outside or indoors), review the guidelines in Figure 2.
INSTALLATION GUIDELINES
All refrigerant and water lines between these above ground components must be insulated
with at least 1/2” wall thickness Armaflex, Insul-Tube or equivalent insulation. Thicker
insulation is recommended for the Compressor Unit-to-Air Handler refrigeration lines for sound
isolation
If you plan to exceed the 40 ft. max elevation of the Air Handler, please contact our Tech
Support Department. Increased height will reduce performance and shall be factored into
system sizing.
The Hydronic Water Module (HWM) shall always be mounted above the Compressor Unit,
never below
Warning!
WEAR ADEQUATE PROTECTIVE CLOTHING AND PRACTICE ALL
APPLICABLE SAFETEY PRECAUTIONS WHILE INSTALLING THIS
EQUIPMENT. FAILURE TO DO SO MAY RESULT IN EQUIPMENT
AND/OR PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

SCWD-QS (12/16) Page 8
Figure 2. General Layout of System Components
2) Compressor Unit Placement
EarthLinked®SCWD compressor units may be located inside only. When placing it inside,
place it on a level, hard surface.
Avoid placing the compressor unit in or near sound sensitive areas of the residence.
Attic installations must include an auxiliary condensate pan with drain, and suspension
from rafters with suspension isolators.
Clearance around the unit for service is illustrated in Figure 3. However, local codes and
applicable regulations take precedence.
Compressor unit or other refrigerant-containing system components located indoors shall
be in a location which (1) is an unoccupied space, or (2) is served by the circulating air
system, or (3) provides 280 cu. ft. of open space per nominal ton of rated system capacity.
The 2012 International Mechanical Code defines residential occupancy as including
permanent provisions for living, sleeping, eating cooking, and sanitation. Consult local
code authorities to define unoccupied space for the specific installation.

SCWD-QS (12/16) Page 9
Figure 3. Compressor Unit Clearance
Placement instructions for other pieces of equipment that make up the EarthLinked®System are
included with those pieces of equipment and are listed in this manual under Equipment Manuals.
3) Refrigeration
After the EarthLinked®compressor unit and other system components are placed, the refrigeration
system tubing is run from the compressor unit to the other components, as appropriate. Figure 4
illustrates the refrigeration and electrical connection points for the compressor unit.
IMPORTANT!
EarthLinked®compressor units that provide space cooling shall be
equipped with an EarthLinked® Hybrid Cooling Module (HCM) when:
(1) Required by the performance tables; OR
(2) System is in a Cooling dominant application where soil thermal
conductivity is unknown or known to be poor (less than 1
BTU/hr.ft.°F). Examples of such soils are light dry soil, dry sand, peat
and organic soils, dry clay and hardpan; OR
(3) In any system where soil thermal conductivity is unknown or known
to be poor (see (2) for definition) and ambient outdoor temperatures
have exceeded the outdoor summer design temperature conditions
for a continuous system run time of at least 7 hours.
IMPORTANT!
EarthLinked®compressor units that provide space heating shall be
equipped with a Heating Performance Enhancement kit (HPE) when
required by the performance tables.

SCWD-QS (12/16) Page 10
PORT
FUNCTION
TYPE OF
CONNECTION
SIZE, INCHES
-024
-030
-036
-042
-048
-060
A1
Electrical, Power
1-1/4” Hole
---
---
---
---
---
---
B1,2
Electrical, Control
7/8” Hole
---
---
---
---
---
---
1
Plugged
----
----
----
----
----
----
----
2
Plugged
----
----
----
----
----
----
----
3
EL Liquid*
Braze
3/8
3/8
1/2
1/2
1/2
1/2
4
Anode Socket
----
----
---
----
----
----
----
5
EL Vapor*
Braze
5/8
3/4
3/4
3/4
7/8
7/8
6
Plugged
----
----
----
----
----
----
----
7
DWT Supply
Braze
1/2
1/2
1/2
1/2
1/2
1/2
8
DWT Return
Braze
1/2
1/2
1/2
1/2
1/2
1/2
9
HWT Return
Braze
7/8
7/8
7/8
1-1/8
1-1/8
1-1/8
10
HWT Supply
Braze
7/8
7/8
7/8
1-1/8
1-1/8
1-1/8
N = Nameplate and other information
1: Nominal electrical connector sizes
2: Two additional electrical control ports on opposite side, same size
*Line set sizes with provided compressor unit adapters
LEGEND
EL –Earth Loop
HWT –Hydronic Water Tank
DWT –Domestic Water Tank
Figure 4. SCWD Connections

SCWD-QS (12/16) Page 11
Compressor units are shipped from the factory with a low pressure nitrogen holding charge. Carefully
relieve the holding charge when the compressor unit is being prepared to connect refrigerant system
piping.
Caution!
REFRIGERANT PIPING CONNECTIONS
Refrigerant joints are to be brazed with 15% silver content brazing
alloy, utilizing the NITROGEN BRAZING PROCESS.
NITROGEN BRAZING PROCESS
PURPOSE:
Utilize the NITROGEN BRAZING PROCESS on all brazed refrigerant
piping connections. This process eliminates oxidation products from
inside joint surfaces.
TECHNIQUE:
“Trickle” nitrogen gas at 1-2 psi pressure through the joint area being
brazed, to displace the oxygen. When oxygen has been displaced,
turn off the nitrogen, and relieve the pressure at the joint to
atmospheric prior to brazing.
CONSEQUENCES:
Failure to displace oxygen with nitrogen at the brazed joint will result
in particulate matter being released into the system. The result is
discoloration of refrigerant oil, contamination of the system and
possible system failure.
Caution!
This compressor unit is equipped with Copeland Ultra 32-3MAF Polyol
Ester Oil (POE). This is the only brand and type of oil that is
recommended for use with ETI compressor units.
POE oil absorbs significant amounts of moisture from the air very
rapidly. Exposure of the POE oil to air must be minimized. Even a few
minutes of exposure to air can be harmful to the system.
After the initial nitrogen holding charge has been released from the
compressor unit, it is critical that air not be allowed to enter the
compressor unit during the process of preparing compressor unit
refrigerant connections (tube cutting, deburring, cleaning, brazing, etc).
To ensure air does not enter the compressor unit while preparing
refrigerant connections, “trickle” dry nitrogen through the compressor
unit, entering at the access port nearest the Active Charge Control
(ACC), to keep airborne moisture out of the compressor unit and the
POE oil.
Complete preparing and brazing all compressor unit refrigerant
connections at one setting to minimize exposure of open connections
to air. Failure to implement the above precautions will result in an
extended period of time to effectively evacuate the system, and may
adversely affect system performance and cause system failure.

SCWD-QS (12/16) Page 12
The compressor unit package contains a service valve kit and an adapter kit. The two service
valves are to be installed on the earth loop vapor and liquid connections of the compressor
unit, using the adapters to right-size to the proper earth loop line set.
Installation of the service valves will provide isolation of the earth loop system from the compressor
unit and provide easy access to the refrigerant system.
For the installation of system components requiring refrigeration connections, refer to Figure 5 for line
set sizes and the appropriate installation manual(s) following Figure 5.
EARTH LOOP LINE SETS
COMPRESSOR UNIT SIZE
LINE SET O.D., INCHES
LIQUID*
VAPOR*
2.0 Tons (-024)
3/8
5/8
2.5 Tons (-030)
3/8
3/4
3.0 Tons (-036)
1/2
3/4
3.5 Tons (-042)
1/2
3/4
4.0 Tons (-048)
1/2
7/8
5.0 Tons (-060)
1/2
7/8
*Liquid and Vapor lines must BOTH be insulated with Armaflex® or
equivalent with at least 1/2” wall thickness for the vertical portions of the
line set.
Figure 5. Line Set Sizes
Series SV Service Valve and AKS Adapter Kit
Series HCM Hybrid Cooling Module
Earth Loop Specification and Installation Manual
After installing and nitrogen brazing the HVAC system components and compressor unit service
valves, turn the Service Valves to Full Open and pressurize the refrigeration system to 150 psig with
dry nitrogen and a trace of refrigerant. Valve off the nitrogen Tank from the HVAC system
components and check joints with a sensitive Electronic Leak Detector and bubble solution to ensure
they are sealed. Repair any leaks and re-test as appropriate.

SCWD-QS (12/16) Page 13
4) System Applications and Electrical
The SCWD compressor unit electrical box major components and electric data for all compressor
sizes are shown in Figure 6.
The SureStart Module is an optional factory installed component that (1) reduces compressor
starting current, (2) reduces compressor starting torque, thus reducing stress on the compressor at
start-up, and (3) monitors the run capacitor. The electrical diagrams that follow include the
SureStart.
For compressor unit electrical diagrams that do not include SureStart, see the Appendix A.
The SCWD compressor units are equipped with a Nano-PLC (Programmable Logic Controller) to
provide a range of functions that enhance the comfort and efficiency of system operation. See
Appendix B detailing the Nano-PLC functions for the hydronic heating and cooling systems.
The Earth Loop Protection Control System, comprised of the EPS Power Supply, EPS Module and
EPS Fuse is contained within the electric box. This system is factory wired and ready to be
connected to the anode wire through an external electrical connection on the backside of the
compressor cabinet. The anode wire connection is detailed in a later section of this manual.
SCWD Heating and Cooling System electrical and application illustrations are as follows.
Figure 7. SCWD Compressor Unit Electrical Schematic Diagram, 230-1-60
Figure 8. SCWD Compressor Unit Electrical Schematic Diagram, 230-3-60
Figure 9. SCWD Hydronic Heating/Cooling/Water Heating System Application
Figure 10. SCWD Hydronic Heating/Cooling/Water Heating System Field Wiring Diagram

SCWD-QS (12/16) Page 14
Compressor
Unit Model
Compressor
Model
Voltage/Phase/
Hz
Voltage
LRA
RLA
MCA
MFS
Min.
Max.
-024-1C
ZP25K6E-PFV
230-1-60
207
253
72.5
15.0
18.0
30
-024-2C
ZP25K6E-TF5
230-3-60
207
253
61.4
9.8
12.0
20
-030-1C
ZP31K5E-PFV
230-1-60
207
253
78.0
18.6
23.0
35
-030-2C
ZP31K5E-TF5
230-3-60
207
253
73.0
11.6
14.0
20
-036-1C
ZP38K5E-PFV
230-1-60
207
253
109.0
22.1
27.0
40
-036-2C
ZP38K5E-TP5
230-3-60
207
253
83.1
15.1
19.0
30
-042-1C
ZP44K5E-PFV
230-1-60
207
253
135.0
23.9
29.0
50
-042-2C
ZP44K5E-TF5
230-3-60
207
253
98.0
16.1
20.0
30
-048-1C
ZP51K5E-PFV
230-1-60
207
253
134.0
29.4
36.0
60
-048-2C
ZP51K5E-TF5
230-3-60
207
253
110.0
17.8
22.0
35
-060-1C
ZP61K5E-PFV
230-1-60
207
253
178.0
34.3
42.0
60
-060-2C
ZP61K5E-TF5
230-3-60
207
253
136.0
21.9
27.0
40
LRA = Locked Rotor Amps
RLA = Rated Load Amps
MCA = Minimum Circuit Ampacity
MFS = Maximum Fuse or HACR Circuit Breaker Size
(External)
Average Wire Size = Consult NEC and Local Codes
Figure 6. SCWD Electric Box Components & Electrical Data

SCWD-QS (12/16) Page 15
Figure 7. SCWD Compressor Unit Electrical Schematic Diagram, 230-1-60

SCWD-QS (12/16) Page 16
Figure 8. SCWD Compressor Unit Electrical Schematic Diagram, 230-3-60

SCWD-QS (12/16) Page 17
Figure 9. SCWD Hydronic Heating/Cooling/Water Heating Sytem Application

SCWD-QS (12/16) Page 18
Figure 10. SCWD Hydronic Heating/Cooling/Water Heating System Field Wiring Diagram

SCWD-QS (12/16) Page 19
5) SureStart
Features
SureStart is an optional factory installed soft starter that reduces light flicker caused at start-up by
scroll compressor motors. This control has the following features:
60 to 70% reduction in direct in-rush current
Under voltage protection
Motor reversal protection
Self-adjusts for optimal start performance
50/60 Hz compatible
ETL, CE, EMC and RoHs compliant
Tolerant to “dirty power” conditions
Fault LED
Internal current limiting
Run capacitor monitoring
SureStart is factory wired for the appropriate power supply.
Operation
When the system control calls for compression operation, the compressor contactor will energize. If
the supply voltage is less than “minimum start-up voltage”, a 50 second delay is initiated. At the end
of the delay, another attempt will be made to start the compressor unless the supply voltage remains
unchanged. See Figure 11 for the SureStart Mode of Operation.
SureStart uses an optimated starting process that learns the starting characteristics of the
compressor to further refine the starting cycle on each recurring start.
If the compressor fails to start, the module will terminate the start attempt after 1 second and initiate a
3 minute lockout before attempting a restart.
While the compressor is running, if supply voltage falls below the “shutdown on low voltage” limit for 2
seconds, SureStart will stop the compressor and initiate a 3 minute lockout. A restart will be initiated
after 3 minutes if the supply voltage is equal to or greater than the “minimum startup voltage”. This is
done to protect the compressor against a sudden drop in supply voltage.
SureStart is able to detect an interruption in power, when the interruption is 0.1 seconds or longer.
When a power interruption is detected, it will shut down the compressor for 3 minutes. A power
interruption that is shorter than 0.1 seconds may result in the compressor running backwards.
SureStart is able to determine if the compressor is running backwards. If this condition is detected,
the control will stop the compressor for 3 minutes before restart is initiated.
If the run capacitor is faulty or has failed, SureStart will shut down the compressor for 3 minutes
before initiating a restart.

SCWD-QS (12/16) Page 20
Figure 11. SureStart Mode of Operation
This manual suits for next models
11
Table of contents
Popular Heat Pump manuals by other brands

Carrier
Carrier 51QC owner's manual

Thermia
Thermia Athena installation guide

DeDietrich
DeDietrich AWHP-2 MIT-IN-2 iSystem Installation and service manual

Daikin
Daikin Altherma 3 M Series Operation manual

HTW
HTW RSJ Series Owners and installation manual

Accorroni
Accorroni S Series Operation and installation manual

Fairland
Fairland Inverter-Plus Series Installation and user manual

Panasonic
Panasonic Aquarea WH-ADC1216H6E5 Service manual

Kensa Heat Pumps
Kensa Heat Pumps Shoebox Heat Pump user manual

Zodiac
Zodiac Jandy Pro Series JE1500T Installation and operation manual

Toshiba
Toshiba ESTIA HWS-802XWHM3-E engineering data

Ice-O-Matic
Ice-O-Matic RGA0501-HM installation manual
