Easee E02-EQP User manual

UK Single Phase
Equalizer Guide
Quick guide

2
This kit consists of main components required to
install an Easee Equalizer on a charging site with
one or multiple circuits. All of the components
are tested and guaranteed to work with the
Easee Equalizer (E02-EQP). Not for use with the
Easee Equalizer HAN version.
Energy Meter:
Eastron SDM120CT-RJ12
Current Transformer:
ESCT-TU16-RJ12-100A (3m length)
Cable:
RJ12 6P6C 1.5m Cable
Product overviewTable of contents
Product overview
Technical specifications
Before you start
Installation instructions
Troubleshooting






3
Eastron SDM120CT-RJ12
Measurements (mm): H:118 x W:18 x D:64
Voltage: 230V ac
Network frequency: 50/60Hz (± 2%)
IP-classification: IP51
Running temperature: -25°C - 55°C
Primary connection: 2,5mm2
Current Input: RJ12 CT Clamp
Output connection: RJ12 6P6C
Mounting: DIN-rail
Material: Self-extinguishing UI94 V-0
ESCT-TU16-RJ12-100A
Max Primary Current- 100A
Secondary Current - 100mA - RJ12
Cable Length - 3m
Measurements - 31.50mm x 29.00mm x 45.50mm
Diameter - 16mm
Running Temperature - -15C - +60C
RJ12 cable
Length: 1.5m
Connector plug: RJ12
Lead cable: 6 pin
Technical specifications
WARNING! This product shall only be installed,
repaired or serviced by an suitable competent
and qualified electrician. All applicable local,
regional and national regulations for electrical
installations must be adhered to.
— Please check the safety instructions on
the manufacturer’s user guides for all the
components of the kit.
— Make sure you have enough space on the DIN
rail for all the components. Minimum required
space is 36mm or 2 Modules
— The cable from the meter to the Equalizer
can be extended up to 200m. Please use
appropriate specification of cable for
installation method.
— Ensure the Equalizer and the master
charger(s) will be connected to the same WiFi
network. The Equalizer requires connection to
a suitable and secure wifi network to ensure
correct operation.
— CT Clamps and Rogowski Coils must be fitted
in the correct orientation to read incoming
power line.
— 6A Single Pole Fuse
— Install the Easee Installer App on your phone
by using the QR code below.
Before you start

4
1Installing
Equalizer Kit
WARNING! Turn off the power before you begin
the installation. Use extreme caution and follow
instructions carefully.
— Install the components in the distribution box
according to the wiring diagram below:
Wiring
Connection
CT clamps

5
Download the Easee Installer App via App
store or Google play. To use the Easee Installer
App, you must have an Easee Cloud account.
If you already have an account, you can log in
immediately.
If you have created a site already, then please
skip directly to step 2.
1. Create new Site:
— Fill in site information.
— Select Easee as the operator.
— Input Main fuse size
— Input Circuit fuse size and name.
— Input Wifi information, if available.
— Scan the backplate and complete the site.
2. Equalizer.
Under Site Structure:
— Add Equalizer.
— Input Wifi information.
— Scan Equalizer with your phone’s NFC reader.
— Connect Equalizer to the meter reader.
— Update Equalizer to at least V114 (~ 10 min).
— Set meter type → Eastron SDM
— Set main fuse limit → 100%.
— Set circuits for load balancing → Circuit (on).
— Restart the device.
3. Transfer ownership.
At Site Overview:
— Upload to cloud.
— Invite new owner by phone number (you
remain the administrator).
— Ask the customer to download the Easee
app and create an Easee cloud account. If an
account already exists, the customer needs
to accept the ownership request which is
sent via email.
2Setting up
Equalizer

6
— Ensure that the charger is connected to the
same Wi-Fi that you want the Equalizer to
be connected to. This is due to the name and
password being copied over when you scan
the devices.
— If the Wi-Fi is not already available, connect
the Charging Robot via the Easee Cloud, the
Easee app or via the Charging Robot’s Wi-Fi
interface.
I am receiving negative values on my meter
reader. Check the following:
— The arrows on the Rogowski coils or CT
clamps are connected in the right direction.
— That the connection is correct from the fuse
to the meter reader.
— If the site has solar cells, it can show negative
values during production.
Equalizer is offline. Do the following steps:
— Check that the Charging Robot is connected
to Wi-Fi.
— Disconnect the Equalizer from the meter
reader until it stops flashing.
— Hold the Equalizer against the Charging
Robot until it lights up green.
— Reconnect the Equalizer to the meter reader.
— If the Equalizer does not appear in the
Easee Installer App, the signal is too weak.
Reposition Wi-Fi or Equalizer to get a
stronger signal. If necessary, install a Wi-Fi
extender (Mesh) for portable connection.
How to make sure the Equalizer is displaying
the correct values? Do the following steps:
Via the Easee Installer App, go to Site Overview
→ Site Structure → Equalizer, you can click on the
product card and get the same visual image of
the Equalizer that the customer gets via their
Easee app.
Here you can confirm that the same ampere values
are displayed as on the Eastron meter. Ampere
values can be found on the Eastron meter by
clicking on [U / I] and scrolling to ampere values (A).
Is the charger already installed? If the charger
is already installed you will need to be invited
as an administrator to access it in the Easee
Installer App.
— Do this by asking the site owner to invite you
as an administrator via the Easee Cloud, or
— Add the charger (master) to the users Easee
app with the serial number and pin code.
Then you will automatically become an
administrator and will find the site under
“update existing site” in the Easee Installer App.
Note that you must be logged in with the same
account in the Easee app as for your Easee
Installer App for this step to work.
I can’t connect the Equalizer to the Wi-Fi via the
Easee Installer App. If you are unable to connect
the device to the Wi-Fi, check the following:
— The name and the password of the Wi-Fi.
Be sure to check lowercase and uppercase
letters as well as special characters. If you
have the option to rename the Wi-Fi, only use
letters and numbers, avoid special characters
and spaces.
— The Wi-Fi must have a password, it can’t be
an open Wi-Fi.
— Connected on 2.4 GHz Wi-Fi (5 GHz is not
supported).
— Firewalls or login portals blocking internet
access.
— Make sure that the Equalizer has good
coverage for Wi-Fi. Change location of the
Wi-Fi router and Equalizer. Open any garage
doors and the facade meter cabinet to get
as good coverage during the connection
process as possible. Alternatively, install a
Wi-Fi extender (Mesh).
How to connect the Equalizer via the charger.
If you do not succeed in connecting the Equalizer
to Wi-Fi via the Easee Installer App, you can
try moving the Equalizer towards the Charging
Robot until the box displays a green light.
Troubleshooting

7
LED colours meaning
3 Use the Easee App to set up the WiFi.
4 Contact your utility company to activate the HAN port.
5 Go to http://easee.support.
6 Check your internet connection.
7After booting, it can take a few minutes before Easee Link
RFTM status flashes green.
White, fast flashing – Booting
White, breathing every 10s – Normal
operation
Red / white, switching – No WiFi added3
Red, flashing – No data from power meter4
Red, breathing every 10s – Error5
Purple, breathing every 10s – Offline
operation6
Touch the Easee logo in the middle to
check power consumption:
Blue, fast flashing – High power
consumption
Blue, slow flashing – Low power
consumption
Count the flashes for percentage –
1 flash (10%), 2 flashes (20%),
up to 10 flashes (100%)
Hold the Easee logo for 3 seconds to check
connectivity. You will see 2 flashes:
1st flash – Easee Link RF status7
2nd flash – WiFi status
Green – Connected
Red – Not connected
3''
Ampere values screen

Easee AS
Grenseveien 19
4313 Sandnes, Norway
.easee.com
THIS DOCUMENT CONTAINS INFORMATION THAT IS
SUBJECT TO CHANGE WITHOUT NOTICE.
The latest version of this publication can be downloaded at
http://easee.support
No part of this publication may be reproduced or
transmitted in any form or by any means, electronic or
mechanical, including, but not limited to, copying, recording,
retrieving data, or computer networks without the written
permission of Easee AS.
Easee and all other Easee product names and slogans are
trademarks or registered trademarks of Easee AS. Easee
products can be protected by one or more patents.
All other products and services mentioned may be
trademarks or service marks of their respective owners.
Illustrations of the product and user interface are exemplary
and may differ from the actual appearance.
November 2022 – Version 1.00
© 2022 by Easee AS. All rights reserved.
Assistance
Make sure to have the serial number available
for the Easee Home and Equalizer to receive
more rapid assistance.
