Easywave RCJ05 User manual

GB Junction Box Awning Receiver RCJ05
Model
RCJ05E5001-01 868.30 MHz
Scope of Delivery
Control RCJ05, Radio receiver RCJ05,
, , pin
connector attachment set operating instruction
Technical Details
Frequency: 868.30 MHz
Modulation: FSK
Coding: Easywave A/B/C/D
Sensorabfrage: EasywaveSens
Statusmeldung: EasywavePlus „Markise“
Power supply: 230 V AC / 50 Hz
Motor running time of drive: adjustable,
factory setting 2 min
Connected load: 4 VA
Power consumption: 1,3 W
Output: 2 powered relay contacts
(normally open)
Min. switching time of 1 s
Max. contact load:
- ohmic load cosj= 1: 5,0 A / 1.150 VA
- inductive load cosj= 0,8: 4,0 A / 920 VA
Degree of category: IP20
Operating temperature: only for dry rooms,
0°C to +40°C
Dimensions: 80 x 80 x 45 mm
Weight: 127 g
Please read these instructions
carefullybeforeusingthedevice!
Observethe valid lawsand regulations aswell
as the manufacturer's instructions
Have malfunctioning devices checked by the
manufacturers!
Donotextendtheawninginstrongwindsin
emergencyoperationmode.Youcouldinjure
yourselfandpermanentlydamagethe
awning.
Attention! The electrical installation work
must be carried out by a qualified electrici-
an only!
Therelaycontactisdesignedforconnection
toasingle-phasepowersupplyonly!
for the
devicestobeoperated!
Do not make any unauthorized alterations or
modificationstotheunit!
Safety Advice
The junction box awning receiver RCJ05 may
only be used as a Easywave radio control for
controllingmotorsforawnings.
The manufacturer will not be liable for damage
causedbyimproperorinappropriateuse.
Intended Use
The Control 425 unit is a remote control for the
automaticormanualoperationofawnings.
Automatic control is achieved using Easywave
weathersensorsfor:
Wind(SW01),
Wind-Sun(SWS01)or
Wind-Sun-Rain(SWSR01).
Either a wired or a remote weather sensor can be
connectedtothecontrolunit.
Themanualcontrolisachievedonthecontrolunit
usingtheOPEN, STOPor CLOSEbuttonorusing
anEasywavetransmitterwith3-buttoncontrols.
The control controlled following weather situa-
tions:
Wind
The wind function is always active if a weather
sensor has been programmed into the control
unit.If the wind forceexceeds the threshold value
programmed in the weather sensor unit, the
awningisautomaticallyretracted.
Rain
Therainfunctionisactiveifaweathersensorwith
a rain function has been programmed into the
control unit. If the weather sensor reports “rain”,
theawningisautomaticallyretracted.
The rain function could be switched off for
maintenance,tocontroltheawningmanually.
Sun
The sunlight function is active if a weather sensor
with a light sensor has been programmed into the
control unit. If the light intensity exceeds the
threshold value programmed in the weather
sensor unit, the awning is automatically exten-
ded. If the light intensity falls below this value, the
awningisautomaticallyretracted.
Thecontrolunitalsoperformsthefollowing
functions:
Saving the motor running time value
-
-
-
Different motor running times are required
depending on the size of the awning. The running
time can be measured and saved in the awning
controlunit.
Gastro-Funktion
The gastronomy function is a special awning
control function which automatically extends the
awning if it rains, so that guests on the patio are
sheltered.
Functionen
Display
OPEN direction button (LED red)
-Wind function status display
LED light up red: alarm wind
- Rain function status display
LED light up blue: alarm rain
LED flashes blue: rain function off
- Interrupting gastronomy function
LED flashes blue: gastronomy function off
- Rain function ON/OFF
- Sunlight function status display
LED light up: sun function on
- Switching sunlight function on/off
SUN button (LED green)
WIND/RAIN button
Programming button P (LED red)
- Programming/deleting mode display
- Reset
STOP button (LED red)
CLOSE direction button (LED red)
Putting the receiver into service
Table of contents
A Putting the receiver into service .......2
A1 Installing and connecting. . . . . . . . . . . . . . 2
A2 Programming the weather sensor. . . . . . . 2
A3 Programming the remote control. . . . . . . . 2
A4 Saving the motor running time . . . . . . . . . 2
B Operating the awning control ..........2
B1 Windfunction.......................2
B2 Rainfunction.......................2
B3 Sunlightfunction....................3
C Delete function........................3
C1 Deleting the programmed
weather senor
C2 Deleting remote controls . . . . . . . . . . . . . . 3
C3 Deleting the programmed motor . . . . . . . .
C4 Resetting to the factory
settings(Reset).....................4
E Quick User Guide ..................4
F General information ................4
B4 Gastronomy function. . . . . . . . . . . . . . . . . 3
B5 Manual operation of the awning . . . . . . . . 3
B6 Emergency operation . . . . . . . . . . . . . . . . 3
......................3
3
D Faults ............................4
- Retracting the awning
- Saving the motor running time
value
- Stopping the awning
- Programming/deleting remote
control
- Extending the awning
- Saving the motor running
time value
1

If the control unit receives a rain signal from the
weather sensor, the awning will be retracted.
Once the rain alarm is over, a lock-out period of
approximately8to20minutesmustexpirebefore
the awning can be extended again manually bzw.
istdieSonnenfunk-tionwiedernutzbar.
Dependinguponthesizeoftheawning,different
motor running times are required for fully
retracting and extending the awning. This time
canbemeasuredandsavedinthecontrolunit.
1. Hold button P pressed until the WIND/RAIN
and OPEN/STOP/CLOSE buttons start to
flashalternately.ButtonPlightsup.
2. Hold the OPEN or CLOSE direction buttons
pressed for the entire time that the awning is
extendedorretracted.
3. Release the button. The running time is
saved.
If wind or rain thresholds have been
exceeded, it is not possible to measure
the running time for the extension of the
awning.
A1 Installing/connecting the control
A Putting the receiver into service
BOperating the awning control
B Operating the awning control
A3 Programming the transmitter
C2 Deleting remote controls
multi-pin connector
1. Turn the mains supply voltage off. Connect
the cables for the power supply and the
awning motor to the control unit as shown in
the connection diagram. The PE (protective
earth)connectionof themainscablemustbe
connectedexternallytothePEconnectionof
thedrive.UseterminalsS+andS-ifyouwish
toconnectawiredweathersensor.
2. Plug in the 5-pole pin connector supplied to
the connection socket on the rear of the
receiver.
3. SInsert the control unit into the junction box
and screw this firmly to the mounting frame.
Plug in the receiver with the 5-pole pin
connectorstraightintotheconnectionsocket
on the control unit and ensure that the
receiver engages securely in the mounting
frame.
Switchthesupplyvoltage on.All buttons lightup
briefly one after the other. The awning can now
be operated using the OPEN, STOP and
CLOSEbuttons.
The WIND/RAIN and SUN buttons flash as the
weather sensors have not yet been programmed
in.
Now transfer the programming codes of the
weathersensortothecontrolunit.
1. Hold button P pressed until the WIND/RAIN
and OPEN/STOP/CLOSE buttons start to
flashalternately.ButtonPlightsup.
2. Press the STOP button briefly. The button
flashesrapidlyandbuttonPlightsup.
3. Then, within 60 seconds, press and release
the button(s) of your Easywave transmitter.
The transmission code is then transferred.
After approx. 4 seconds, the STOP button
goesoutandtheawningcanbeoperatedvia
the remote control or the status of the
weatherfunctioncanberequested.
Up to 32 transmission codes can be pro-
grammed.
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashalternately.ButtonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press the STOP button briefly. The button
flashesrapidlyandbuttonPlightsup.
4. Then, within 10 seconds, press and release
the button of your transmitter. The STOP
button goes out after 4 seconds. The sensor
transmissioncodehasbeendeleted.
If you wish to delete all transmitters, proceed as
describedinsteps1to3,andinstep4pressand
holdtheSTOPbuttonagain.
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashalternately.ButtonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press the WIND/RAIN button briefly. The
buttonflashesrapidlyandbuttonPlightsup.
4. Press the WIND/RAIN button and hold.
Button P is off and the WIND/RAIN button
goes out after 4 seconds. The sensor
transmissioncodehasbeendeleted.
N
230 V L
M
-
S
-
S
+
S
+
S
230 V ~ 50Hz
MNNL
L 4A
IP40 >5 s
>5 s
>5 s
<2 s
<2 s
<2 s
4 s
4 s
A2 Programming the weather sensor
C1 Deleting weather sensor
C Delete function
1. Hold button P pressed until the WIND/RAIN
and OPEN/STOP/CLOSE buttons start to
flashalternately.ButtonPlightsup.
2. Press the WIND/RAIN button briefly. The
buttonflashesrapidlyandbuttonPlightsup.
3. Then, within 60 seconds, press and release
the “prog” transmitter button of your sensor.
The transmission code is transferred. The
WIND/RAIN button will go out after four
seconds and the SUN button will light up.
The sensor has now been programmed in
and all the weather functions are available
foruse.
>5 s
<2 s
4 s
B5 Manual operation of the awning
To control the awning, briefly press one of the
OPEN/STOP or CLOSE direction buttons on the
receiver. The awning moves in the desired
directionorcanbestopped.
The awning control unit can be operated using
aRT37 status transmitter or using other
Easywave transmitters with three-button
controls. If the awning is operated with a remote
control, the relevant direction button on the
controlunitflashes.
< 3 s
B1 Wind function
B2 Rain function
B6 Emergency operation
Thewindfunctionisactiveonceaweathersensor
has been programmed. This function takes
priority over all other weather functions and
cannotbedisabled.
If the wind speed exceeds the threshold value
programmed in the sensor, the awning will be
retracted. The WIND/RAIN button lights up red
untilthewindcyclehasbeencompleted
If the wind speed falls below the threshold value,
a lock-out periode of approximately 8 to 20
minutes must expire before the awning can be
extended again manually or the controls can
respondtorainorsunsignals.
.
The rain function can be used as soon as a
weather sensor with a rain detection feature has
been programmed in, provided that the
“gastronomy” function has not been switched on
attheweathersensor.
By pressing the WIND/RAIN button, the rain
function can be switched off and the button
flashesblue
If a rain signal is received from the weather
sensor, the awning is retracted and the
WIND/RAIN button lights up blue until the rain
cyclehasbeencompleted.
.
B3 Sunlight function
Thesunlight function is activeifaweather sensor
with a brightness sensor has been programmed
into the control uni. The sunlight function can be
switchedonoroffusingtheSUNbutton.
If the level of brightness exceeds the set
threshold value for a period of 12 to 15 minutes,
the awning will be extended. If a wind or rain
threshold has been exceeded, it will not be
possible to extend the awning until the lock-out
periodhasexpired.
If the level of brightness drops below the set
threshold value for a period of 30 to 33 minutes,
theawningwillberetracted.
These times for delaying the extension and
retraction operations are necessary in order to
prevent the awning from being constantly
extended and retracted in rapidly changing light
conditions.
8-20 min
12 to 15 min
30 to 33 min
A4 Saving motor running time value
>5 s
>5 s
>5 s
mounting frame
radio receiver
control
4 s
C3 Deleting the motor running time
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashalternately.ButtonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press the OPEN or CLOSE button and hold.
The buttons flash rapidly and button P lights
up. Release the button. All buttons go out
andtherunningtimehasbeendeleted.
>5 s
>5 s
Inordertocarryoutmaintenanceandrepairwork,
an emergency manual operating mode on the
controlunitcanbeusedforoperatingtheawning.
The wind function is no longer active when
the manual mode is used. Do not extend
the awning in strong winds. You could
injure yourself and permanently damage
theawning.
2 3
The gastronomy function can only be used in
ombination with a weather sensor that has a rain
detection feature and an activated gastronomy
function.
If a rain signal is received from the weather
sensor, the awning is extended automatically if it
rains and the button lights up blue. If no rain
further rain signals are transmitted and the level
of brightness remains below the threshold level
for 30 to 33 minutes, the awning is automatically
retracted.
The gastronomy function can be disabled by
pressing the WIND/RAIN button or SUN button,
the WIND/RAIN button lights up blue, the SUN
button goes off. Note that if the gastronomy
functionisinterrupted,thenthesunlightfunction
isnolongeravailable.
Only awnings that are specially designed
for use in rain may be operated using the
gastronomyfunction.
B4 Gastronomy function
Gastronomy function
ON
>5 s
8-20 min

If the control unit receives a rain signal from the
weather sensor, the awning will be retracted.
Once the rain alarm is over, a lock-out period of
approximately8to20minutesmustexpirebefore
the awning can be extended again manually bzw.
istdieSonnenfunk-tionwiedernutzbar.
Dependinguponthesizeoftheawning,different
motor running times are required for fully
retracting and extending the awning. This time
canbemeasuredandsavedinthecontrolunit.
1. Hold button P pressed until the WIND/RAIN
and OPEN/STOP/CLOSE buttons start to
flashalternately.ButtonPlightsup.
2. Hold the OPEN or CLOSE direction buttons
pressed for the entire time that the awning is
extendedorretracted.
3. Release the button. The running time is
saved.
If wind or rain thresholds have been
exceeded, it is not possible to measure
the running time for the extension of the
awning.
A1 Installing/connecting the control
A Putting the receiver into service
BOperating the awning control
B Operating the awning control
A3 Programming the transmitter
C2 Deleting remote controls
multi-pin connector
1. Turn the mains supply voltage off. Connect
the cables for the power supply and the
awning motor to the control unit as shown in
the connection diagram. The PE (protective
earth)connectionof themainscablemustbe
connectedexternallytothePEconnectionof
thedrive.UseterminalsS+andS-ifyouwish
toconnectawiredweathersensor.
2. Plug in the 5-pole pin connector supplied to
the connection socket on the rear of the
receiver.
3. SInsert the control unit into the junction box
and screw this firmly to the mounting frame.
Plug in the receiver with the 5-pole pin
connectorstraightintotheconnectionsocket
on the control unit and ensure that the
receiver engages securely in the mounting
frame.
Switchthesupplyvoltage on.All buttons lightup
briefly one after the other. The awning can now
be operated using the OPEN, STOP and
CLOSEbuttons.
The WIND/RAIN and SUN buttons flash as the
weather sensors have not yet been programmed
in.
Now transfer the programming codes of the
weathersensortothecontrolunit.
1. Hold button P pressed until the WIND/RAIN
and OPEN/STOP/CLOSE buttons start to
flashalternately.ButtonPlightsup.
2. Press the STOP button briefly. The button
flashesrapidlyandbuttonPlightsup.
3. Then, within 60 seconds, press and release
the button(s) of your Easywave transmitter.
The transmission code is then transferred.
After approx. 4 seconds, the STOP button
goesoutandtheawningcanbeoperatedvia
the remote control or the status of the
weatherfunctioncanberequested.
Up to 32 transmission codes can be pro-
grammed.
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashalternately.ButtonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press the STOP button briefly. The button
flashesrapidlyandbuttonPlightsup.
4. Then, within 10 seconds, press and release
the button of your transmitter. The STOP
button goes out after 4 seconds. The sensor
transmissioncodehasbeendeleted.
If you wish to delete all transmitters, proceed as
describedinsteps1to3,andinstep4pressand
holdtheSTOPbuttonagain.
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashalternately.ButtonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press the WIND/RAIN button briefly. The
buttonflashesrapidlyandbuttonPlightsup.
4. Press the WIND/RAIN button and hold.
Button P is off and the WIND/RAIN button
goes out after 4 seconds. The sensor
transmissioncodehasbeendeleted.
N
230 V L
M
-
S
-
S
+
S
+
S
230 V ~ 50Hz
MNNL
L 4A
IP40 >5 s
>5 s
>5 s
<2 s
<2 s
<2 s
4 s
4 s
A2 Programming the weather sensor
C1 Deleting weather sensor
C Delete function
1. Hold button P pressed until the WIND/RAIN
and OPEN/STOP/CLOSE buttons start to
flashalternately.ButtonPlightsup.
2. Press the WIND/RAIN button briefly. The
buttonflashesrapidlyandbuttonPlightsup.
3. Then, within 60 seconds, press and release
the “prog” transmitter button of your sensor.
The transmission code is transferred. The
WIND/RAIN button will go out after four
seconds and the SUN button will light up.
The sensor has now been programmed in
and all the weather functions are available
foruse.
>5 s
<2 s
4 s
B5 Manual operation of the awning
To control the awning, briefly press one of the
OPEN/STOP or CLOSE direction buttons on the
receiver. The awning moves in the desired
directionorcanbestopped.
The awning control unit can be operated using
aRT37 status transmitter or using other
Easywave transmitters with three-button
controls. If the awning is operated with a remote
control, the relevant direction button on the
controlunitflashes.
< 3 s
B1 Wind function
B2 Rain function
B6 Emergency operation
Thewindfunctionisactiveonceaweathersensor
has been programmed. This function takes
priority over all other weather functions and
cannotbedisabled.
If the wind speed exceeds the threshold value
programmed in the sensor, the awning will be
retracted. The WIND/RAIN button lights up red
untilthewindcyclehasbeencompleted
If the wind speed falls below the threshold value,
a lock-out periode of approximately 8 to 20
minutes must expire before the awning can be
extended again manually or the controls can
respondtorainorsunsignals.
.
The rain function can be used as soon as a
weather sensor with a rain detection feature has
been programmed in, provided that the
“gastronomy” function has not been switched on
attheweathersensor.
By pressing the WIND/RAIN button, the rain
function can be switched off and the button
flashesblue
If a rain signal is received from the weather
sensor, the awning is retracted and the
WIND/RAIN button lights up blue until the rain
cyclehasbeencompleted.
.
B3 Sunlight function
Thesunlight function is activeifaweather sensor
with a brightness sensor has been programmed
into the control uni. The sunlight function can be
switchedonoroffusingtheSUNbutton.
If the level of brightness exceeds the set
threshold value for a period of 12 to 15 minutes,
the awning will be extended. If a wind or rain
threshold has been exceeded, it will not be
possible to extend the awning until the lock-out
periodhasexpired.
If the level of brightness drops below the set
threshold value for a period of 30 to 33 minutes,
theawningwillberetracted.
These times for delaying the extension and
retraction operations are necessary in order to
prevent the awning from being constantly
extended and retracted in rapidly changing light
conditions.
8-20 min
12 to 15 min
30 to 33 min
A4 Saving motor running time value
>5 s
>5 s
>5 s
mounting frame
radio receiver
control
4 s
C3 Deleting the motor running time
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashalternately.ButtonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press the OPEN or CLOSE button and hold.
The buttons flash rapidly and button P lights
up. Release the button. All buttons go out
andtherunningtimehasbeendeleted.
>5 s
>5 s
Inordertocarryoutmaintenanceandrepairwork,
an emergency manual operating mode on the
controlunitcanbeusedforoperatingtheawning.
The wind function is no longer active when
the manual mode is used. Do not extend
the awning in strong winds. You could
injure yourself and permanently damage
theawning.
2 3
The gastronomy function can only be used in
ombination with a weather sensor that has a rain
detection feature and an activated gastronomy
function.
If a rain signal is received from the weather
sensor, the awning is extended automatically if it
rains and the button lights up blue. If no rain
further rain signals are transmitted and the level
of brightness remains below the threshold level
for 30 to 33 minutes, the awning is automatically
retracted.
The gastronomy function can be disabled by
pressing the WIND/RAIN button or SUN button,
the WIND/RAIN button lights up blue, the SUN
button goes off. Note that if the gastronomy
functionisinterrupted,thenthesunlightfunction
isnolongeravailable.
Only awnings that are specially designed
for use in rain may be operated using the
gastronomyfunction.
B4 Gastronomy function
Gastronomy function
ON
>5 s
8-20 min

C4 Resetting to the factory settings
(Reset)
If a reset is carried out, the codes of all
remote controls and weather sensors
as well as the saved motor running time
are deleted. The weather functions are
thennolongeractive.
1. Hold button P pressed until the OPEN/
STOP/CLOSEandWIND/RAINbuttonsstart
toflashandbuttonPlightsup.
2. Press button P again and hold. The OPEN/
STOP/CLOSE and WIND/RAIN buttons
flashrapidly.ButtonPlightsup.
3. Press button P again and hold.All buttonsgo
out after approximately 4 seconds. The
factorysettingshavenowbeenreinstated.
Programmed weather sensor is not working
(radiointerferenceor faulty sensor cable,power
failure to sensor): The awning is automatically
retracted. Depending upon the type of sensor,
the buttons corresponding to the protective
functionsflashuntilthefaulthasbeenrectified.
Control unit is not working (no supply
voltage): If the OPEN button does not light up
red if it is pressed, then there is no voltage
supply to the control unit. Check the electrical
connections.
Direction button does not flash when
manually operated with remote control:
Check the radio link. Read in the remote control
codeagainifnecessary,orchangethebatteryin
theremotecontrol.
Customer Service
If the device does not work properly despite
proper handing or in case of damage, please
contact your retailer.
ELDAT GmbH
Im Gewerbepark 14
15711 Königs Wusterhausen
Germany
Phone: + 49 (0) 33 75 / 90 37-310
Fax: + 49 (0) 33 75 / 90 37-90
Internet: www.eldat.de
E-Mail: [email protected]
Disposal
Conformity
Put the packaging material into the
recycling bins for cardboard, paper and
plastics.
Disposeofthe waste product viaacollec-
tion point for electronic scrap or via your
specialistdealer.
Waste electrical products should not be
disposed of with household waste!
The product fulfils the essential require-
ments of the R&TTE directive
1999/5/EG.
For application in: EU/CH/FL/IS/N
Warrenty
We will remedy defects on the device based on
material or production errors within the statutory
warranty period or exchange the device.
The Declaration of Conformity can be found on
the internet at: www.eldat.de.
F General Information
>5 s
>5 s
>5 s
4 s
D Faults
E Quick User Guide
Function /
Chapter
Operation
*
[press button ] RCJ05 LED display Action
Programming weather
sensors (wireless or
wired)
A2
Deleting weather
sensors (wireless or
wired)
C1
1. Press P button and hold
(>5 seconds)
2. Press WIND button briefly
3. Press "prog" sensor button
1. Press P button and hold
(>5 seconds)
2. Press STOP button briefly
3. Press transmitter button
1.
2. Press OPEN or CLOSE button until
awning has reached end position
3. Release OPEN or CLOSE button
Press P button and hold
(>5 seconds)
OPEN, STOP, CLOSE, WIND buttons
flash, P button lights up
WIND button flashes rapidly
WIND button lights up for 4 seconds
Ready for programming or after
60 seconds ready for operation
Program mode
Sensor code programmed
Ready for operation after 10
seconds
Running time saved
Program mode
Programming
radio transmitters
A3
OPEN, STOP, CLOSE, WIND buttons
flash, P button lights up
STOP button flashes rapidly
STOP button lights up for 4 seconds
OPEN, STOP, CLOSE, WIND buttons
flash, P button lights up
OPEN or CLOSE button lights up
OPEN or CLOSE button off
Ready for programming or after
10 seconds ready for operation
Program mode
transmitter code programmed
Reinstating the
factory settings
(RESET)
C4
Saving
motor running time
A4
Deleting
motor running time
C3
Deleting
radio tranmitters
C2
Lock-out period for wind
signals 8-20 minutes
WIND/RAIN buttons light up red
Wind function
B1 Lock-out period for rain
signals 8-20 minutes
Rain function switched off, awning
can be extended or retracted
WIND/RAIN buttons light up blue
WIND/RAIN button flashes blue
Rain function
B2
Press SUN button briefly (<2 s)
Press WIND/RAIN button briefly
(<2 seconds) Press "prog" sensor
button briefly
Sensor programmed, sunlight
function switched on
Switch sun protection on/off
SUN button light up green
WIND/RAIN button flashes blue Rain function switched off,
awning extended automatically
if rain signal received
Sun function
B3
Gastronomy
function
B4
Press WIND/RAIN button
briefly (for 1 second)
1. Press P button and hold
(>5 seconds)
2.
4.
Press P button and hold
(>5 seconds)
3. Press WIND/RAIN button
briefly (<2 seconds)
Press WIND/RAIN button and
hold (>3 seconds)
OPEN, STOP, CLOSE, WIND buttons
flash, P button lights up
OPEN, STOP, CLOSE, WIND button
flashes, P button lights up
WIND button flashes rapidly, P button
lights up
WIND button lights up for 4 seconds, P
button off
Ready for deleting or after
60 seconds ready for operation
Delete mode
Sensor code deleted
Delete mode
1. Press P button and hold
(>5 seconds)
2. Press P button and hold
(>5 seconds)
3. Press STOP button briefly (<2 s)
4. Press sensor button
or
Press STOP button and hold
(>5 seconds)
OPEN, STOP, CLOSE, WIND buttons
flash, P button lights up
OPEN, STOP, CLOSE, WIND button
flashes, P button lights up
STOP and P button lights up
STOP button lights up for 4 seconds
Ready for deleting or after
10 seconds ready for operation
Delete mode
Delete mode
Transmitter code deleted
All transmitter codes deleted
1. Press P button and hold
(>5 seconds)
2. Press P button and hold
(>5 seconds)
3. Press OPEN or CLOSE button
4. Release OPEN or CLOSE button
OPEN, STOP, CLOSE, WIND buttons
flash, P button lights up
OPEN, STOP, CLOSE, WIND buttons
flash rapidly , P button lights up
OPEN and CLOSE button flash
rapidly, P button lights up
Ready for deleting or after
10 seconds ready for operation
Running time deleted
Delete mode
Delete mode
1. Press P button and hold
(>5 seconds)
2. Press P button and hold
(>5 seconds)
3. Press P button and hold
(>5 seconds)
OPEN, STOP, CLOSE, WIND
buttonsflash, P button lights up
OPEN, STOP, CLOSE, WIND buttons
flash rapidly , P button lights up
All buttons light up for 4 seconds All codes deleted,
motor running time deleted
Ready for deleting or after
10 seconds ready for operation
Delete mode
* If no button is pressed, the control unit reverts to standby mode after 60 seconds (programming/deleting
weather sensors) or 10 seconds (all other procedures). Press button P to cancel programming/deleting
procedures.
UM97003B 0214 GB
4
Any unauthorized tampering with, or modifica-
tionsto,theproductshallrenderthis warranty null
andvoid.
Table of contents
