ECOCOLD APPLE Series User manual

APPLE SERIE
GROUP OF CHESTFREEZER
USER GUIDE
NEGATIVE CHESTFREEZER
APPLE 150 APPLE 188
APPLE 188 FG APPLE 212
APPLE 212 FG APPLE 250
APPLE HEAD APPLE HEAD FG
POSITIVE CHESTFREEZER
AAPPLE 150 APPLE 188
APPLE 188 FG APPLE 212
APPLE 212 FG APPLE 250
APPLE HEAD APPLE HEAD FG

2
CONTENTS
COVER 1
CONTENTS 2
GENERAL INFORMATION 3
ABOUT THE COOLER 4
GENERAL APPEARANCE OF COOLER 5-6
ATTENTION 7
INSTRUCTION FOR CARRYING 8
INSTRUCTION FOR INSTALLATION 9-10
ASSEMBLY OF THE COOLER 11
USAGE OF THE COOLER 12
BEFORE CALLING THE SERVICE 13
CLEANING AND MAINTENANCE 13
CONTACT NUMBER 14

3
GENERAL INFORMATION
Dear customer;
This chestfreezer which has successfully passed from quality control
tests, has been produced in the plant of Ecocold A.S. with a big
passion.
To increase efficiency of your cooler, before using it we strongly
recommend you;
to read the whole guide
keep the guide as a source
to use the cooler according to guide instructions.
We want to remind that, we will be not responsible for the damages
that depends on the incorrect usage or instruction disobedience.
For damage and information issues, please contact to nearest
customer service center.
The product will also be out of warranty, if someone other than
authorized service interferes the product directly.
The aim of this cooler is keeping the beverages and foods cold.
We will also be not responsible if you run the product out of this
purpose.
Thank you for preferring us and for your trust

4
For commercial types, energy consumption tests are done according to the standarts Technical features are specified on the labels.Ecocold
Cooling A.S. reserves all the rights for changing technical features of the products , without any kind of declaration.
TECHNICAL FEATURES OF COOLER
TECHNICAL FEATURES APPLE 212 APPLE 212 FG APPLE 250
Gross volume
Net volume
Internal dimensions (WxDxH)
External dimensions (WxDxH)
Packaged external dimensions (WxDxH)
Area of projection view
Grose weight
Net weight
Operating temperature
Product display area
1005 LT
745 LT
1976x780x730
2124x952x900
2220x1010x950
2 m²
160 Kg
150 Kg
NT-18/-23;PT -1/+4
1,51 m²
1216 LT
905 LT
2360x780x730
2508x952x900
2605x1010x950
2,38 m²
178 Kg
166 Kg
NT-18/-23;PT -1/+4
1,80 m²
TECHNICAL FEATURES OF COOLER
TECHNICAL FEATURES APPLE 150 APPLE 188 APPLE 188 FG
Gross volume
Net volume
Internal dimensions (WxDxH)
External dimensions (WxDxH)
Packaged external dimensions (WxDxH)
Area of projection view
Grose weight
Net weight
Operating temperature
Product display area
688 LT
488 LT
1360x780x730
1508x952x900
1605x1010x950
1,425 m²
125 Kg
115 Kg
NT-18/-23;PT -1/+4
1,03 m²
870 LT
643 LT
1730x780x730
1879x952x900
1975x1010x950
1,78 m²
140 Kg
130 Kg
NT-18/-23;PT -1/+4
1,31 m²
ABOUT THE COOLER
THIS PRODUCT
Is respectful to environment
and has been produced in modern plants.
The operating temperature range of the chestfreezer is between -1 and +4
degrees.
The operating temperature range of the cooler is between -18/-23 degrees.
The product does not contain Asbestos, formaldehyde, cadmium and CFC
materials
Compressor oil is based on none PCB and PCT.
The refrigerant gas is R404a, or R290a, which is is proper for KYOTO protocol.
This device is also proper for WEEE (Waste Electric and Electronic Equipment)
regulations
APPLE HEAD
APPLE HEAD FG
870 LT
485 LT
1730x780x730
1879x952x900
1975x1010x950
1,78 m²
150 Kg
140 Kg
NT-18/-23;PT -1/+4
1,31 m²
865 LT
620 LT
1860x780x677
2008x952x900
2105x1010x950
1,9 m²
145 Kg
135 Kg
NT-18/-23;PT -1/+4
1,41 m²
1005 LT
548 LT
1976x780x730
2124x952x900
2220x1010x950
2 m²
170 Kg
160 Kg
NT-18/-23;PT -1/+4
1,51 m²
865 LT
511 LT
1860x780x677
2008x952x900
2105x1010x950
1,9 m²
155 Kg
145 Kg
NT-18/-23;PT -1/+4
1,41 m²

5
APPLE HEAD
APPLE 188
APPLE 212 FG
GENERAL APPEARANCE

6
GENERAL APPEARANCE
SLIDING LID
SLIDING LID
HANDLE
PROTECTIVE
BUMBERS
DIGITAL
THERMOSTAT
COMPRESSOR
AIR GLIDE

7
ATTENTION
The products that shown in this guide, are designed and produced
according to National and International security norms. For safe and
secure usage, following issues must be considered.
Check the socket, whether it is suitable or not. A grounded socket
is must.
Make sure your structure wiring. Do not use sockets that are not
fixed. Extension cable and multiple sockets are not advised. If it is
an obligation, beware of voltage and cable diameter.
If the cable is damaged, the replacement must be done by
authorized Ecocold service. While running, if you have a hesitation
concerning electrical connection, call the nearest service.
When unplugging, hold the knob of the socket, never hang from
cable.
External covers must not be removed. Otherwise, dangerous parts
and sections will be accessible.
Never use pressured water. It may cause damages in electrical
parts.
A defection may come from cooler electrical system or building
electrical installation. For both, do not intervene to cooler directly.
Unplug the cord, call the nearest service.
Never plug and run a damaged product (like a transport damage)
Please contact to service.
Consider the maximum loading capacity. Do not pass the loading
line.
Replacement of electrical parts must be done by nearest service.
Keep package materials somewhere, that none-adults can reach.
Package items (nylon, Styrofoam etc.) may be dangerous for
nonadults or children.
For children and non-adult person usage, viewer discretion is
advice.
For interior or exterior cabinet, always use materials that producer
advise to use.
If an intervention is need, please contact to nearest service.
Never carry or move your cooler while it is plugged. Mending or
maintenance must be prevented.
Obey the locate rules. To not to obey shutters and grids locations,
may cause fires.

8
INSTRUCTION FOR CARRYING
If possible, carry the cooler with a forklift or a hand lift
If you have a no lift, carry
the cooler with enough
person in a stable position.
While carrying the cooler,
just handle from wooden
pallet. Never use front or
back protection wires.
While carrying the cooler
always use gloves.
11
22
44
33

9
INSTRUCTION FOR INSTALLATION
Remove the plastic clamps
to release the cabinet from
the transport pallet.
Cut off the protection
nylon on the cabinet by
using a cutting tool.
Unfix the fixed screws and
move the cabinet on to the
floor from the pallet with
the help of 4 people.
Remove the cardboard
package and the
styrofoam conserves on
the cabinet.
Remove the cabinet that is
fixed to the pallet from the
fixing areas with screwing
tools.
11
2255
33
44

10
INSTRUCTION FOR INSTALLATION
Make a stable pushing.Between cooler and wall, there must be min 15 cm
gap.
After allocated the cooler, you should wait for 6 hours. Than you can plug
it, the first run must be when the cooler is empty for 2 hours.
77
66

11
ASSEMBLY OF COOLER
The protective film should be removed (if it exists)
By using adjustable feet, make the cooler stable. Avoid gaps,
prevent vibration.
Compressor group air inlet must not be prevented. This is the most
important issue. Allocate your product that it will be parallel to
the ground, no aim is required. Adjustable feet and rollers must
touch the base. The distance between compressor group and wall
is important. More distance, provides increasing performance. For
that reason, at least 15 cm gap is required.
After transport of the cooler, before operating it, you should wait
for three hours.
The first running must be done when the cooler is empty. Loading
can be done after this period.
Connection of the cooler must be checked by experienced
electrician. The fuse height must be 170 cm
For fault current, electric connection must be supported with 30
mA fuse.
The cooler must be also provided with the nearest ground.

12
USAGE FOR THE COOLER
Temperature of the cooler is calibrated for the most proper conditions.
The operating temperature can be adjusted from the digital
thermostat. We advice you to keep them with default factory value.
Internal temperature of the cooler is -18/ -23 degrees, can be adjusted
01 – 04 degrees. Digital thermostats have default factory values, and
no need adjustment. Thermostats may have many programs within
(eco mode) If you have a problem with your cooler, please contact
to service. Failure codes are listed in failure section. If you get any of
these, stop the alarm of the thermostat and inform the service.
There is no a private defrost process in your cooler. Although your
products prevents snowing, high humudity and temperature may
cause snowing rate. Operating time depends on snowing, which also
means energy consumption will rise. At this position, stop the working
and clean the snow.
DON NOT FORGET! UNFROZEN EVAPORATOR WILL GIVE THE
HIGH EFFICIENCY.
Evaporator waters, stream to drip pan in compressor department.
Although hot gas pipe evaporates this water, checking and cleaning
the pan is advised, at least for one time in a month.
IMPORTANT!
Please do the loading by taking care of the loading line
For the coolers; The loading should be up to 45 cm from
the height of 5-6 cm from the base. The front of the fan must
not be closed.
For the Freezers; The maximum loading distance is 48 cm.
Do not load above this height.
For the Apple FG Freezer model; loading should be from
5-6 cm height from the base up to 40 cm.

13
BEFORE CALLING SERVICE & CLEANING
BEFORE CALLING SERVICE...
FAILURE POSSIBLE SOLUTION
THE COOLER
IS NOT
WORKING
THERE IS
SNOWING OR
SWEATING IN THE
CABINET
SWEATING AT THE
GLAS
TEMPRATURE IS
HIGH BUT IT IS
NOT COOLING
CHECK THE PLUG AND FUSE.
THE PROBLE CAN BE AT ELECTRICAL CABLE OR PLUG..
MAKE SURE THE SLIDING LIDS ARE FULL CLOSED.
MAKE SURE THAT THERE IS NO AIR IN THE FREEZER.
EXTERNAL HUMIDITY MAY BE INCREASED OR THERE IS AIR IN THE
FREEZER. PLEASE CONTROL THE SLIDING LIDS.

CONTROL THE ADJUSTMENT OF THE THERMOSTAT.
MAKE SURE THAT AIR PANELS ARE NOT BE CLOSED.
INTERNAL CLEANING
Remove beverages. Wait for the internal temperature that it will be
same with environment temperature. For cleaning and maintenance
use a protection glove, this will protect you from injuries. Remove the
accessories. Use a soft cotton linen with warm soap water .For drying,
use cotton based linen. For first operating, wait for two hours. Than
you can reload your beverages.
EXTERNAL CLEANING
Use a cotton base linen with warm water. Avoid water from front
control panel or lighting departments. For door gasket, just use clean
water with soap.
