EcoTrust EcoPower4 ECP240R User manual

MODEL ECP240R
• Installation
• Operation
• Specifications
• Warranty
NEMA 3R OUTDOOR ENCLOSURE and FLUSHMOUNT
OWNER’S MANUAL
read these instructions before use • save this manual
300 East Valley Drive
Bristol, VA 24201
1.800.989.2299
© 2009. DBG Group Investments, LLC
300 East Valley Drive, Bristol, VA 24201, dba Ecotrust Energy. All Rights Reserved

ECP240R
warninG:
1. Opening the unit without prior permission from EcoTrust Energy will void its
warranty coverage. Contact EcoTrust Energy at 1.800.989.2299 if you have any
questions.
2. Apply this unit to 240V AC, 50/60Hz, single phase residential load only.
3. The unit must be mounted vertically, in a dry location, using the four mounting
holes.
4. The unit must be installed by a licensed electrician in compliance with local electrical
code.
5. IMPORTANT! This unit must be connected directly to a dedicated circuit breaker. Do
not, under any circumstances, hard-wire install without a dedicated breaker!
YoU wiLL need:
1. A dedicated, 2-pole, 20 Amp, circuit breaker.
2. Appropriate tools including conduit.
3. A licensed electrician for installation.
moUntinG the ecoPower4™ fLUshmoUnt (ecP240r)
1. Inspect the exterior of the unit to ensure that it has not been damaged in transit.
Ensure that the front label/overlay is still intact, that the warranty seals are intact,
and that the cables protruding from the unit have not been damaged.
2. Place the back of the Flushmount Box against wall where the unit is to be installed
and trace around its outside edge. Cut drywall along traced line (dimension of
traced area should be approximately 4.866” wide by 8.250” high).
3. Run conduit (according to code) between the conduit connector on the box and the
power panel, and feed the connection cables through the conduit into the power
panel.
4. Secure the four (4) clips to the mounting box and tighten screws to tightly fit.
5. Screw Cover Plate onto unit.
moUntinG the ecoPower4™ nema 3r (ecP240r)
1. Inspect the exterior of the unit to ensure that it has not been damaged in transit.
Ensure that the front label/overlay is still intact, that the warranty seals are intact,
and that the cables protruding from the unit have not been damaged.
2. Mount the unit to a clean, dry wall near the power panel. Lengthening of the wires
to accommodate mounting the unit further away from the panel than the current
wiring allows may be necessary. As a general rule, the length of the wires should
be kept as short as possible and electricians should follow standard electrical code
regarding adding wire to the unit. When mounted, the phase indication lights
should be visible.

ECP240R
RATINGS:
Voltage:
US/CA: 120/240V~, 2W + N + PE,
60Hz, 2.7A
International: 240V~, 50Hz, 2.7A
Configuration:
3-wire plus ground (US)
2-wire plus ground (International)
Capacitance: 30µf (US)
Line Current: 2.7 A
KVA Rating: .65 at 240V AC
TEST PROCEDURES:
1. Energize the power panel.
2. Close the circuit breaker leading to the
EcoPower4™ unit.
3. Check if Line 1 and Line 2 indicator lights
are on:
IF NO - De-energize the unit and check if
cables are connected correctly.
NOTE: For international appliances, only
1 indicator light may be on.
Check the ground cable connections.
If problem persists, call EcoTrust Energy
at 1.800.989.2299.
4. Keep these instructions near the unit for
future use.
EcoPower4
ECP240R
LINE
RED
BLACK
GREEN
WHITE
L1
L1
L2
L2
NEU
BUS
GND
BUS
20A
BREAKER
POWER PANEL
LINE
BROWN
GREEN WITH YELLOW STRIPE
BLUE
L
L
NEU
BUS
GND
BUS
20A
BREAKER
POWER PANEL
EcoPower4
ECP240R
US/CANADIAN INSTALLATION INTERNATIONAL INSTALLATION
3. Run conduit (according to code) between the conduit connector on the box and the
power panel, and feed the connection cables through the conduit into the power
panel.
instaLLation ProcedUres:
1. If possible, de-energize the power panel prior to connection of the EcoPower4™
unit.
2. Install the circuit breaker onto the power panel.
3. US/Canadian Installation - Connect the (red) L1 and (black) L2 wires to the circuit
breaker, the ground cable (green) to the ground bus, and the neutral cable (white) to
the neutral bus, as shown in the diagram below.
4. International Installation (240V, 50Hz) - Connect the brown wire (hot) to the circuit
breaker, the ground wire (green with yellow stripe) to the ground bus, and the blue
wire to the neutral bus as shown in the diagram below.

ECP240R
dimensions for the ecoPower4™ fLUshmoUnt (ecP240r)
8.2509.750
4.866
4.746
2.875
MOUNTING CLIPS 4X
FOR FLUSHMOUNT

ECP240R
dimensions for the ecoPower4™ nema3 (ecP240r)
3.80
1.08
10.45 11.10 9.52
3.02
3.97
4.35
4.45
0.26
0.28
5.10
5.10 5.00

© 2009. DBG Group Investments, LLC
300 East Valley Drive, Bristol, VA 24201, dba Ecotrust Energy. All Rights Reserved
EPW_OM_DOM_65-00309-0809 *P65-00309-0809*
300 East Valley Drive
Bristol, VA 24201
1.800.989.2299
CE DECLARATION OF CONFORMITY
We, on behalf of the manufacturer: DBG Group Investments, LLC
300 East Valley Drive
Bristol, VA 24201
U.S.A.
Declare under our sole responsibility, that the Energy Management Device
Model: EcoTrust Energy ECP240R (NEMA 3R and Flushmount)
to which this declaration relates, conforms with the following standards:
EN60950-1:2006 Safety of Information Technology Equipment - General
Requirements
By conformance with the standards referenced, the product meets the
provisions of the EU Directives listed below:
Low Voltage Directive 73/23/EEC as amended by
98/68/EEC
RoHS Directive 2002/95/EC
WEEE Directive 2002/96/EC
Authorized by:
Representative: Robert S. Vincent
Title: General Manager
Company: Quest United UK Ltd.
The Atrium
Curtis Road
Dorking, Surrey RH4 1XA
United Kingdom
Date: April 24, 2009
