About This Manual
This manual has been prepared to assist you in the operation and maintenance of your Eddyfi
Technologies’Inuktun equipment. Correct and prudent operation rests with the operator who must
thoroughly understand the operation, maintenance, service and job requirements. The specifications and
information in this manual are current at the time of printing.
This product is continually being updated and improved. Therefore, this manual is meant to explain and
define the functionality of the product. Furthermore, schematics or pictorials and detailed functionality may
differ slightly from what is described in this manual.
Eddyfi Technologies reserves the right to change and/or amend these specifications at any time without
notice. Customers will be notified of any changes to their equipment.
Information in this manual does not necessarily replace specific regulations, codes, standards, or
requirements of others such as government regulations.
This manual copyright © 2019 by Eddyfi Robotics Inc. All rights reserved.
Description
The Inuktun Spectrum 120™ (SP120) is an industrial video camera system for use in pipe inspection
systems, harsh industrial environments and underwater. Standard features include 360 ° continuous pan,
280 ° tilt, zoom and a 60 m (200 ft) or 300 m (1,000 ft) depth rating. It is designed to fit into a 120 mm
(4.75 in) ID space and still be able to tilt and pan throughout its full range. The camera is made from either
anodized marine-grade aluminum or 316 stainless steel. Optional video formats are HD 1080p /1080i and
SD NTSC or PAL. Installation options include integration with a larger inspection system (such as the
Versatrax 150™ pipe inspection system) or independent use as a drop camera or static system. Typical
applications include:
•Toxic environment, confined space or underwater inspections
•Small diameter pipe inspection
•Dam and lock inspection
•Reactor vessel inspection
•Foreign object search and retrieval
•Robotics and remote tooling
•ROV integration
•Corrosion evaluation
•Remote and/or continuous monitoring
•Drop camera use.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 5 of 23
User Manual
Specifications
Operating Voltage
36 –70 VDC
Operating Power
75 W Peak
Operating Current
2.1 A Peak
Depth Rating
Standard
60 m (200 ft)
Deep Water
300 m (1,000 ft)
Speed
Pan
0 –26 °/s
Tilt
0 –9 °/s
Range
Pan
360 ° Continuous
Tilt
280 ° (+/- 140 °)
Dimensions
Standard
Ø121 x 333 mm (Ø4.75 x 13.1 in)
Deep Water
Ø121 x 356 mm (Ø4.75 x 14.0 in)
Weight
Standard
Aluminum
3.4 kg (7.5 lb)
Stainless Steel
9.0 kg (20 lb)
Deep Water
Aluminum
4.8 kg (10.5 lb)
Stainless Steel
12.7 kg (28 lb)
Imager
Sensor
1/2.8in Exmor R CMOS
Lens
Standard
f = 3.8 to 38 mm
120x Zoom (10x Optical, 12x Digital)
67 ° HFOV (air)
Option
f = 4.3 to 129 mm
360x Zoom (30x Optical, 12x Digital)
64 ° HFOV (air)
Focus
Manual or Auto
Resolution
1920 x 1080
Format
1080p (30 fps) / 1080i (60 fps)
Minimum Illumination
1.4 lux
Depth of Field
10 mm (0.4 in) to infinity
Lights
4 x High intensity LEDs

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 6 of 23
User Manual
Lasers (optional)
2 x Laser Lines, 635 nm, 77 mm (3.03 in) Spacing
Controls
Pan, tilt, zoom, focus, lights, lasers, exposure
Maximum Tether Length
300 m (1,000 ft)
Operating Temperature
0 –50 ºC (32 –122 ºF)
Storage Temperature
-20° –60 ºC (-4 –140 ºF)
Certification
The Spectrum 120™ Camera system is built in accordance with the Machinery Directive 2006/42/EC and
Electromagnetic Compatibility Directive 2004/108/EC and Directive 2014/30/EU.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 7 of 23
User Manual
Connector Pin-Out
NTSC / PAL
The Spectrum 120™ Standard Definition (SD) camera connects to power and communications through a
Subconn MCBH8M connector.
Note: The pin-out is shown for the Bulkhead Connector on the camera.
Pin
Function
1
70 VDC GND (-)
2
70 VDC (+)
3
RS485 (+)
4
RS485 (-)
5
SpareA
6
SpareB
7
Video1 (+)
8
Video1 (-)
High-Definition (HD)
The Spectrum 120HD High Definition (HD) camera connects to power and communications through a
Subconn MCBH10M connector.
Note: The pin-out is shown for the Bulkhead Connector on the camera
Note: The HD Receiver PCB is tuned to specific length of tether. Do
not change length of tether. Contact factory for assistance.
Pin
Function
1
70 VDC GND (-)
2
70 VDC (+)
3
RS485A (+)
4
RS485B (-)
5
Pb Out (+)
6
Pb Out (–)
7
Y Out (+)
8
Y Out (–)
9
Pr Out (+)
10
Pr Out (–)

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 8 of 23
User Manual
Laser Lines
The Spectrum 120™ camera may be optionally equipped with horizontal laser lines (red Class 2 lasers at
635 nm, 1.5 mW). Laser line separation is 77 mm (3.03 in).
•CAUTION: Class II Laser: Do not intentionally stare
into the beam. Typically, Class II relies on the blink
reflex to limit exposure to no more than ¼-second.
Intentionally staring into the beam can cause eye
injury.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 9 of 23
User Manual
Safety
In order to be able to use this product properly and safely, every user must first read these operating
instructions and observe the safety instructions contained therein. Take care of these operating
instructions and keep them in a place where they can be accessed by everyone.
CAUTION: Failure to follow these safety instructions may result in injury or
equipment damage.
WARNING: High Voltage 36-70 VDC. If the equipment is powered from a
source other than an Eddyfi Technologies provided controller, the power supplied
to the product must have reinforced isolation from the mains with no reference to
earth ground.
WARNING: Spark Hazard - Under no circumstances should this equipment be
used in a potentially explosive atmosphere.
WARNING: Intense Optical Radiation –The Spectrum 120™ camera lights are
extremely bright. Never look directly at the lights. Use a welding filter (shade #8
or higher) if inspecting the LEDs.
•CAUTION: Class II Laser: Do not intentionally stare into
the beam. Typically, Class II relies on the blink reflex to limit
exposure to no more than ¼-second. Intentionally staring
into the beam will cause eye injury.
•When performing maintenance or functional checks of the
lasers and camera lights, take precautions to protect nearby
personnel from unintended exposure which could be
temporarily blinding.
•The Spectrum 120™ is an industrial product. All personnel operating or maintaining this
equipment must be competently trained.
•There are no user serviceable parts inside. This product may be serviced only by qualified
technicians or trained personnel.
•Our equipment is used in many varied environments from hot/dry to confined spaces to deep
underwater. Such diverse environment risks must be addressed by the operators who are trained
to work in such surroundings. As such, the operator is responsible to determine safe site setup
and appropriate personal protective equipment (PPE) for operation and maintenance of the
equipment.
•Do not use the product or any component exposed to pressures higher than the rated working
pressure.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 10 of 23
User Manual
In addition, observe the following precautions when cleaning or servicing the Spectrum 120™ :
•Do not operate the camera with a damaged connector or cable. Inspect connectors and cables
regularly for damage.
•Call the Eddyfi Technologies Service department for assistance or service if needed.
CAUTION: Disconnecting the camera while the power is on can cause damage to
the camera. Disconnect the power source before servicing the product.
CAUTION: Do not over-pressure the camera through the Schrader valve.
Applying pressure beyond 15 psi through the Schrader valve may cause the
camera to burst resulting in injury and equipment damage. When re-purging, use
a regulated, gauged supply and apply no more than 10 psi pressure.
System Setup
Unpacking Components
The Spectrum 120™ camera is shipped in a rugged case or is installed on an integrated system.
Packaging is selected to protect the camera from damage during shipping or storage. Upon receiving
your system, check the case and contents for any damage that may have occurred during transport.
Should any of these components be missing or damaged, please notify your vendor. We suggest that
when the system is re-shipped or stored for any length of time, it should be re-packaged in its original
case or be put in a cardboard box encased in high-density foam. It is also strongly advised that the case
be placed in a cardboard box again for shipping purposes. This measure greatly reduces rough handling
and subsequent shipping damage.
CAUTION: The Schrader cap installed on your camera is a proprietary cap
rated to 300 m (1,000 ft) depth. Do not install any other Schrader cap. Doing
so may result in flooding and destruction of the camera or in personal injuries
from electrical shorts. Standard automotive style Schrader valve components
will be forced open below 40 m (130 ft) depth by the water pressure.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 11 of 23
User Manual
Mounting the Camera
There are two distinct versions of the Spectrum 120™ camera with different mounting requirements.
These are:
•Standard definition camera with M6 mounting holes (8-pin connector)
•High Definition camera with M6 mounting holes (10-pin connector).
Both of these are illustrated below. In addition to the mounting pattern, the standard (60 m / 200 ft) and
deep water (300 m / 1,000 ft) cameras are different lengths as illustrated.
Alternatively, the cameras may be mounted by a clamp around the 90 mm (3.5 in) diameter stationary
portion of the barrel. The camera may be mounted in any orientation.
CAUTION: Avoid forcing the PAN mechanisms by hand. It will wear the clutch
discs and could cause premature failure.
Standard Camera Mounting

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 12 of 23
User Manual
Deep Water Camera Mounting

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 13 of 23
User Manual
Galvanic Corrosion Control
We strongly recommend stainless steel cameras for salt water environments or other corrosive
environments. The camera warranty is conditional when aluminum body cameras are chosen these kinds
of applications.
Cathodic protection is required whenever the camera is being deployed in a salt water environment, either
submerged or in salt spray, regardless of camera material.
Our cameras use aluminum marine anodes for both stainless and aluminum cameras. Aluminum anodes
are common in the marine industry and are replacing zinc anodes in many areas. For cameras systems
that are often pulled in and out of the water, aluminum anodes are especially important, as zinc anodes
tend to scale over when exposed to air and may not reactivate when submerged again. An aluminum
anode will always reactivate.
It is required that the structure to which the camera is mounted also be protected by aluminum anodes. If
the structure is of a dissimilar metal, the camera mount must be isolated from the structure. Do not mix
anode types (zinc and aluminum) on the assembly. There must be only one anode type throughout the
structure. Magnesium anodes must never be used with Spectrum™ camera installations.
Anodes are installed onto the camera as illustrated below. The small anode is installed onto the mounting
bracket using an M5 x 10 mm 316 SS SHCS. A large disk anode is attached to a mounting bracket for the
base using an M6 x 12 mm 316 SS SHCS. Contact your sales representative for replacements.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 14 of 23
User Manual
Connector Handling
Connectors are an essential part of system reliability. They should be properly maintained and cared for to
ensure long life and reliability. It is recommended to follow these steps to help prevent damage and
increase the life of connectors.
•Always put the cap back on the tether bulkhead when the tether is disconnected
•Always inspect the end of the connector prior to engaging
•Never plug in a dirty or damaged connector
•Visually align key-ways or locating pins prior to engaging the connector
•Always fully engage or tighten the connector
•Secure locking collars finger tight
•Install dummy plugs on unused connectors
•Disconnect by pulling straight, not on an angle
•Do not pull on the cable to disengage the connector
IMPORTANT: Never “Hot Plug” any connector, this will result in internal damage to the
electronics. Power down the system prior to connecting the inspection system tether.
Note:
Never use WD-40 or similar solvent-based fluids on connectors or crawlers. These will cause
the rubber parts of the connector or crawler to soften and swell rendering them inoperable.
SubConn Connector: Lubrication and Cleaning
•Periodically apply Molykote 111 silicone grease or equivalent before mating connectors
•For dry mate connections, a layer of grease corresponding to 1/10 the socket depth should be
applied to the female connector
•After greasing, fully mate the male and female connector and remove excess grease from the
connector joint
•General cleaning and removal of sand or mud on a connector should be performed using a
spray-based contact cleaner like isopropyl alcohol

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 15 of 23
User Manual
Drop Cone Assembly
A drop cone assembly should be attached to the rear of the camera for drop camera configurations.
Always use the drop cone as the connector is not strong enough by itself for lifting applications.
To install the drop cone do the following:
1. Insert the tether cable through the cone and connect to the camera.
2. Align the recess with the purge valve as shown above.
3. Secure the drop cone with 3x M6 x 16 mm SHCS.
4. Attach the Kellem’s grip to the tow cable on the drop cone.
Flow Thru Cooling (Continuous Purge)
The Spectrum 120™camera may be continuously purged for cooling purposes. Contact Eddyfi
Technologies for more details.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 16 of 23
User Manual
Schrader Valve
All versions of the Spectrum 120™ camera use a proprietary Schrader valve rated up to 300m (1000ft)
depth. The factory Schrader cap and O-ring must always be installed.
CAUTION: The Schrader cap installed on your camera is a proprietary cap
rated to 300 m (1,000 ft) depth. Do not install any other Schrader cap. Doing
so may result in flooding and destruction of the camera or in personal injuries
from electrical shorts. Standard automotive style Schrader valve components
will be forced open below 40 m (130 ft) depth by the water pressure.
DEPTH RATED SCHRADER VALVE ASSEMBLY
Nitrogen Purge and Pressurization
The Spectrum 120™ camera has been nitrogen purged and pressurized at the factory as part of the
production process. This will ensure that no moisture is present inside the camera housing and camera
body.
The Spectrum 120 camera has the capability to be re-purged and pressurized by the user. All necessary
hardware for purging is installed on the camera, all that is needed is a supply of bottled nitrogen with a
pressure regulator and gauge suited for 5 –10 psi control, and a locking rubber air chuck.
1. Remove the seal screw from the camera’s left side plate as illustrated below.
2. After removing the depth rated protective cap, hook up the nitrogen supply to the Schrader valve
at the bottom end of the camera using an air chuck at the end of the hose.
3. Turn on the nitrogen. Pressure must be no more than 10 psi. Internal passages are routed to
ensure nitrogen flows throughout the entire camera.
4. Let the nitrogen flow for minimum one minute, and then re-install the seal screw again while the
nitrogen is still flowing to create a small internal pressure.
5. When the nitrogen source is removed, the Schrader valve will keep the pressure inside. Cap the
valve again when done. Fasten the depth rated cap securely.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 17 of 23
User Manual
CAUTION: Do not over-pressure the camera through the Schrader valve.
Applying pressure beyond 15 psi through the Schrader valve may cause the
camera to burst resulting in injury and equipment damage. When re-purging, use
a regulated, gauged supply and apply no more than 10 psi pressure.
SEAL SCREW LOCATION ON LEFT SIDE PLATE
NITROGEN PURGE SCHRADER VALVE

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 18 of 23
User Manual
Operation
Pre-Operations Check
A Pre-Operations check should to be carried out prior to every camera mission.
1. Visually inspect the camera to ensure that there is nothing jamming the movement.
2. Check the camera cable for cuts, tears, etc.
3. Check that the camera connector is fully engaged and that the locking collar is finger tight.
4. Ensure that all other cables are properly connected including the monitor.
5. Clean the camera port (window).
6. Power up and test all camera functions. This includes adjustability of the lights and full pan and
tilt movements.
7. Verify the functionality of your monitor and video recording equipment. At this time verify the
functionality of the video overlay, zoom and manual focus settings.
Post-Operations Check
A Post-Ops inspection should be carried out after every camera mission.
1. The system should be visually inspected for mechanical damage.
2. If the system has been used in salt water, thoroughly rinse the camera and pole with fresh water
right away. Accelerated corrosion will result if the camera is not rinsed properly. Pay close
attention to rinsing and cleaning the spaces between moving parts.
CAUTION: Do not use a pressure washer to clean the camera. Very high-
pressure water can push past seals and flood the camera resulting in electrical
damage or personal injuries.
3. Clean off the camera and remove objects or debris from between its moving parts.
4. Visually check through the camera port to ensure that no water has entered the camera.
5. Inspect the camera cable for cuts, nicks or kinks. Store the camera in its rugged case with the
connector sufficiently protected.
ICON™ & ICON™ RPT
Camera control and video recording are accomplished using ICON graphical interface controller software.
Video playback and reporting are conducted through ICON RPT. Manuals for these two software
packages are included separately. Controls for recording and snapshot functions are kept on-screen
with the camera controls.
•ICON Manual –(Control Interface and Recording)
•ICON RPT Manual - (Reporting, Playback and Video Export)

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 19 of 23
User Manual
Troubleshooting
Camera Control Problems
1. Not all the auxiliary lights are on.
•The ICON™ software allows the lights to be controlled independently. Ensure all lights are
enabled. Refer to the ICON interface manual.
•Inspect for blown LEDs.
CAUTION: High Intensity. Do not look directly into the lights or lasers. Use a
welding filter (shade #8) to observe the light elements.
2. Camera tilt does not function in one or both directions.
•Check that the camera is not jammed.
•If you can hear a motor running but see no movement, there is a mechanical or clutch problem
inside the camera. Contact us.
3. Camera is moving very slowly.
•Check the tilt speed in the camera control window. Refer to the ICON™ user interface manual.
Video Problems
1. No video (black or blue background).
•Interface box is not turned on.
•Video cables are not hooked up between interface box and computer.
•Camera connector on vehicle is loose (turn power off first before plugging in camera).
•Check monitor input settings.
•Vehicle power is not on.
•Check for problems with other video components between the computer and monitor.
•Try a different monitor. Whole days have been spent on field maintenance trips only to discover a
faulty monitor.
2. Picture is very dark or very bright.
•Check the light levels of both the camera and main lights.
3. Intermittent picture.
•Check and replace the video cables.
•Check the monitor is working properly.
•Check that the camera harness whip is fully plugged in.
•Check for intermittent breaks in the camera harness cable.
•Check the tether connectors at both controller and vehicle.
•Check for tether or slip ring damage by testing tether continuity.
4. Picture is blurry, will not focus, or has poor color.
•This may be a dirty camera view port, or a narrow object lying in front of the view port.
•Object may be too close to the camera.

Spectrum 120™
Document: UMBM000112.docm
Revision: A14
Created by: PJ
Date: 08 Dec 2019
IPN: 3041026-A14
Source Location: C:\ePDM\ISLEng\products\bm-spectrum120\manuals\UMBM000112.docm
Page 20 of 23
User Manual
Maintenance
Tether Re-termination
Tether termination is a specialized service beyond the scope of this manual. Contact Eddyfi Technologies
if the tether is damaged or requires re-termination.
Rinsing and Cleaning
After every mission check to see if the camera needs cleaning.
1. If the system has been used in salt water, thoroughly rinse the camera with fresh water prior to
being stored away. Accelerated corrosion will result if the inspection system is not rinsed properly.
Pay close attention to rinsing and cleaning the camera window, LED lights dome and the spaces
between moving parts.
2. Use an open hose or tap at regular water line pressure for rinsing. Do not pressure wash the
equipment –water will be forced into the camera at these high pressures.
3. Avoid scratching the camera port. Use glass cleaner and a soft cloth to clean the port.
CAUTION: Do not use a pressure washer to clean the camera. Very high-
pressure water can push past seals and flood the components resulting in
electrical damage or personal injuries.
Periodically:
1. Use a damp cloth or spray cleaner for the power supply / controller box. The box must never be
sprayed down or immersed in water. Unplug the controller before cleaning.
2. For general cleaning of the camera, use a mild detergent.
Inclinometer Calibration
Contact your local representative for calibration instructions.
Factory Maintenance
The Spectrum 120™ camera is equipped with a number of rotary surface seals that have to operate with
close tolerances to achieve the 60 m (200 ft) or 300 m (1,000 ft) depth rating. It is of the utmost
importance that the sealing surfaces are protected from scratches during maintenance work. When seals
are removed or replaced the sealing surfaces and seals must be clean and sufficiently lubricated before
installation.
To re-certify a camera’s depth rating we recommend the camera be serviced at Eddyfi Technologies in-
house service centre.
This manual suits for next models
1
Table of contents
Other Eddyfi Technologies Digital Camera manuals
