User Guide
Univox Digi RS-R
Body pack receiver
Art nr 550010
2
Transmitter and receiver channel syncronization
When synchronizing the units should not be more than one meter apart.
• Press mute/sync button on transmitterr before it is turned on.
• Turn the transmitter on and purple LED flashes to indicate the activation of channel-
sync mode.
• Turn receiver(s) on to be channel synchronized (one or multiple receivers can be
turned on at the same time).
• When channel is successfully synchronized, receiver’s LCD shows same channel as that
of the transmitter and its LED turns steady blue.
• Press the transmitter’s mute/sync button to exit sync setup. When the transmitter has
le sync set up, the sound is turned off when the mute/sync button is pressed.
Note! If synchronization fails
1. Turn the transmitter off and repete above procedure to redo the synchronization.
2. If it still doesn’t work, turn off the transmitter and receiver(s) and redo the
synchronzation procedure again as described above.
Receiver
1. Antenna
2. Power/Signal indikator
3. LCD battery status
4. LCD channel lock
5. LCD selected channel
6. Volume
7. Up/Down button
8. Power button
9. Earphone socket
Power on/off
• Press and hold power button for 1 second to turn the receiver on.
LCD screen shows and then last used channel.
• Press and hold power button for 2 seconds to turn the receiver off.
LCD screen shows and then shuts down and the LCD turns black.
Power saving (receiver only)
Power of receivers will be off if no signal is received for 20 minutes.
3
Indicator behavior Transmitter Receiver
Flash
Red Mute activated
Low battery -
Blue Mute activated
Sufficient battery -
Purple Sync activated -
Steady
Red Signal transmitted
Low battery
Signal received
Low battery
Blue Signal transmitted
Sufficient battery
Signal mottagen
Sufficient battery
No LED Device is not turned on Device is not turned on/
Signal is not received
Power / Signal indicator
Technical Data
Frequency range 821-832 and 863-865MHz
(full spectrum 510~937MHz, country dependent)
Channels 32 selectable
Modulation 4 GFSK
Latency < 5ms
Audio process Compander
Dynamic range > 70dB
SNR (Signal to Noise Ratio) > 65dB
T.H.D. (Total Harmonic Distortion) < 3%
Channel positioning Yes
Operation range up to 50m (line-of-sight) with pocket transmitter;
up to 100m (line-of-sight) with stationary transmitter
Temperature -10°C - + 60°C
Sensitivity -110dBm
Output 3.5mm jack
Batteries 1 x 1.2V 2100mA Ni-MH AA rechargeable battery or
1 X 1.5V alkaline AA battery
Battery life > 15 hours
Charging Approx. 8 hours
Size (DxWxH) 24x40x100mm (with antenna)
Weight 70g (incl. battery)
Hearing excellence – in day-to-day-life all over the world
(Univox) Bo Edin AB
Stockby Hantverksby 3,
SE-181 75 Lidingö, Sweden
+46 (0)8 767 18 18
www.univox.eu
digi-rs-r-du-gb 190204 Copyright © Bo Edin AB
Service and warranty
Product is covered by 2 years warranty. The product warranty doesn’t cover failure caused
by tampering, carelessness, improper handling or maintenance.
Under normal circumstances no special maintenance is required. In case of failure, if the
product should not work properly aer the troubleshooting has been performed, please
contact your local distributor for further instructions.
Refer all servicing to qualified service personnel only. If the product is sent to Bo Edin AB,
Safety
Do not attempt to replace, recharge or repair damaged or defective battery as
there may be a risk for heat, fire or short circuit development, if incorrectly
replaced or connected.
Environment
To prevent possible harm to the environment and human health, please dispose the
product responsibly by following statutory disposal regulations.
Univox is a developer and producer of high quality assistive listening products including hearing
loops, IR and FM systems. We have been in business since 1965 and have distributors in over 35
countries all over the world. A Swedish based company known for a strong emphasis on research
and development, continuing to innovate to deliver more firsts in the industry, constantly
improving the performance of our products and service for hard of hearing communities.
